Electrolux E36EC75ESS User manual

E36EC75ESS.eps CE36EC75DSS1.eps ME36EC75ESS1.eps 318046804.eps
Product No. E36EC75ESS1 E36EC75ESS2
38066423850S1 38066423850S2
Series 36" elec 36" elec
Color stainless stainless
Market North America North America
Wiring Diagram 318046804 318046804
Owner's Guide 318200616 318200616
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995425997
05/01/07
(EN/SERVICE/ECL)
377
ELECTRIC COOK-TOP
RANGE
Model No.
E36EC75E
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995425997 E36EC75E
01/05 2
CONTROL PANEL
69
CE36EC75DSS1
54B
54A
54A
54A
54
14
14
54
33
32
32
O
F
8
6
4
2
HI
LO
HI
LO
8
6
4
2
F
O
F
8
6
4
2
HI
LO
HI
LO
8
6
4
2
F
O
F
10
8
6
4
2
HI
LO
F
333231
31
31
31
35
35
35
35
35
19
14

E36EC75E Publication No: 5995425997
# Functional Parts 3 01/05
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AE36EC75E (E36EC75ESS1)
BE36EC75E (E36EC75ESS2)
POS. NO PART NO. DESCRIPTION
14 # 318250400 A B Light, indicator, blue
19 318234903 A B Panel, control, stainless
31 318242203 A B Knob, control
32 318242202 A B Knob, control, dual
33 318242201 A B Knob, control, dual
35 318251900 A B Skirt, (6)
54 # 318220074 A B Switch, surface unit, small
54A# 318191024 A B Switch, infinite, dual
54B# 318220076 A B Switch, surface unit
69 5303305528 A B Screw, 8-32 x 1/4
* 318163602 A B Cleaner, stainless steel

Publication No: 5995425997 E36EC75E
01/05 4
MAIN TOP/SURFACE UNITS
16
51
53
52
52A
52A
52
52B
15
15A
15B
15A 15
46
159
62
34
47
48
49
162
164
164
47A
49A
ME36EC75ESS1

E36EC75E Publication No: 5995425997
# Functional Parts 5 01/05
* Non-Illustrated Parts
MAIN TOP/SURFACE UNITS
Model Index: AE36EC75E (E36EC75ESS1)
BE36EC75E (E36EC75ESS2)
POS. NO PART NO. DESCRIPTION
15 # 318198817 A B Element, surface, small/6", 1200 W
15A# 316418400 A - Element, dual, 6"/9", surface, 1200W/1300W, radiant
15A# 318198925 - B Element, surface, 6/9, 1200/2500W, dual radiant
15B# 318258201 A B Element, bridge
16 318185200 A B Main Top Assy, glass, black
34 318246100 A B Griddle
46 318242801 A B Panel, base
47 318241702 A B Panel, side, RH
47A 318241703 A B Panel, side, LH
48 318241801 A B Panel, rear
49 318241900 A B Panel, interior side, RH
49A 318241901 A B Panel, interior side, LH
51 # 318044822 A B Light, indicator, clear
52 318122006 A B Spring, element mtg, small
52A 318122010 A B Spring, element mtg, 1000W/2500W
52B 318122008 A B Spring, element mtg
53 318125960 A B Bracket, pilot light
53* 318235710 A B Insulation, pilot light, aluminum foil
62 316056000 A B Terminal Block
62* 5303323144 A B Nut, 10-32
62* 5303323139 A B Screw, 10-24 x 0.906
159 318242901 A B Panel, bottom
162 318245500 A B Shield, heat
164 318252901 A B Support, box, (6)
* # 318078541 A B Box & wires assy
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303323140 A B Screw, ground, 10-32 x 0.375

Publication No: 5995425997 E36EC75E
01/05 6
WIRING DIAGRAM
