Electrolux E36GC75GSS1 User manual

E36GC75GSS.eps ME36GC75GSS1.eps BRE36GC75GSS1.eps 318047111.eps
Product No. E36GC75GSS1
37766426870S1
Series 36" gas
Color stainless
Market North America
Wiring Diagram 318047111
Owner's Guide 318200687
Installation Instructions 318201475
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995511135
08/04/04
(EN/SERVICE/ECL)
377
36” GAS COOK-TOP
RANGE
Model No.
E36GC75G
Copyright ©2008 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995511135 E36GC75GSS1
04/08 2
COOK TOP

E36GC75GSS1 Publication No: 5995511135
# Functional Parts 3 04/08
* Non-Illustrated Parts
COOK TOP
POS. NO PART NO. DESCRIPTION
10 7318392500 Bracket, box, (2)
* 75304403558 Screw, 10-16 x 0.250
15 7318024206 Deflector, spark module
16 7318185208 Main Top Assy, frame/glass, stainless/black
19 7318234908 Panel, control, stainless
20 7318361402 Grate, top burner, black, (3), double
21 7316514800 Skirt, 5K burner, black
21A 7316515100 Skirt, 18K burner, black
21B 7316515000 Skirt, 14K burner, black, (2)
21C 7316514900 Skirt, 9.5K burner, black
22 7316510902 Cap, 5K burner, black
22A 7316511502 Cap, 18K burner, black, (2)
22B 7316511302 Cap, 14K burner, black, (2)
22C 7316511102 Cap, 9.5K burner, black
26 7318363800 Bracket, channel mtg, (2)
26A 7318363900 Bracket, channel mtg.
31 7316515200 Seal, 5K burner
31A 7316515203 Seal, 18K burner, (2)
31B 7316515202 Seal, 14K burner, (2)
31C 7316515201 Seal, 9.5K burner
32 73201437 Strain relief
33 7318242225 Knob, control, (4)
33A 7318242226 Knob, control, dual, (2)
34 7318251600 Griddle
35 7318251911 Skirt, (6)
37 7316518100 Screw, ignitor assy mt, 6-32 x .62
39 7318144006 Cord, service
46 7318242805 Panel, base
47 7318241712 Panel, side, (2)
48 7318241806 Panel, rear
49 7318241904 Panel, interior side, RH
49A 7318241905 Panel, interior side, LH
57 7318286400 Panel, service
65 75303304032 Seal, rubber
69 75303300265 Screw, 8-18 X 1/2, (4)
77 7318355511 Bracket, channel mtg.
159 7318242912 Panel, bottom
162 7318399700 Deflector, heat
165 7318254300 Support, WOK
166 7318254200 Simmer Plate
* 7316459400 Pad, cleaning
* 7318163602 Cleaner, stainless steel
* 75303305528 Screw, 8-32 x 1/4
* 708016432 Screw, truss head, 8-18 x 0.375

Publication No: 5995511135 E36GC75GSS1
04/08 4
BURNER

E36GC75GSS1 Publication No: 5995511135
# Functional Parts 5 04/08
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 # 7318234314 Manifold Pipe
2 # 7316520700 Valve, burner, 5K
2A # 7316520701 Valve, burner, 9.5K
2B # 7316520703 Valve, burner, 14.2K
2D # 7316412510 Valve, top burner, 18K, dual port
3 # 7318232635 Wiring Harness, w/igntr switch
8 7318079001 Module, spark
* 75303311174 Screw, 10-24 x 3/8
10 # 7316510800 Burner, sealed, 5K
10A# 7316511000 Burner, sealed, 9.5K
10B# 7316511200 Burner, sealed, 14K
10D# 7316525400 Burner, sealed, dual, 18K
11 # 7316524800 Ignitor/orifice assy., top burner, 5K, w/holder
11A# 7316524900 Ignitor/orifice assy., top burner, 9.5K, (2), w/holder
11B# 7316525000 Ignitor/orifice assy., top burner, 14K, w/holder
11D# 7316525100 Ignitor/orifice assy., top burner, 18K, w/holder
12 # 7318221368 Tubing, 5/9.5/14K, rear, (3)
12A# 7318221367 Tubing, 18K, (2)
12B# 7318221366 Tubing, 18K, (2)
12C# 7318221369 Tubing, 14K, front
13 7318054514 Tube, connection, manifold
14 # 7318122705 Regulator, pressure
24 7318054010 Elbow, fitting
* 708011955 Screw, 10-24 x 0.375, square drive
37 7316518100 Screw, ignitor assy mt, 6-32 x .62
44 7316523504 Orifice, top burner, 5K
44A 7316523500 Orifice, top burner, 9.5K
44B 7316523506 Orifice, top burner, 14K
44D 7316523508 Orifice, top burner, 18K
72 7316215600 Screw, valve mtg., 1/4 - 20
* # 7318127438 LP Conversion Kit
* # 7318243102 Harness, burner wiring

Publication No: 5995511135 E36GC75GSS1
04/08 6
WIRING DIAGRAM
