Modular Cooking Range Line
thermaline 90 - Gas French Top on
Static Gas Oven 1 Side H=700
ITEM #
MODEL #
NAME #
SIS #
AIA #
Short Form Specification
Item No.
APPROVAL:
Electrolux Professional
www.electrolux.com/professional
[e-mail]
Modular Cooking Range Line
thermaline 90 - Gas French Top on Static Gas Oven 1 Side
H=700
Modular Cooking Range Line
thermaline 90 - Gas French Top on
Static Gas Oven 1 Side H=700
589637 (MCVGAJCPO)Gas French top on gas static
oven, one-side operated
Unit constructed according to DIN 18860_2 with 20 mm drop nose top and 70 mm
recessed plinth. Internal frame for heay duty sturdiness in 2 mm and 3 mm in 1.4301
(AISI 304). 2 mm top in 1.4301 (AISI 304). Flat surface construction, easily cleanable.
THERMODUL connection system enables seamless worktop when units are connected
and aoids soil penetrating. Large surface cooking plate made with durable cast iron,
allows the use of arious sizes of pans. Central gas burner with optimized combustion,
flame failure deice and protected pilot light. Center of the plate can reach max. 550°C
while decreasing outwards, thus allowing temperature gradients to satisfy different
cooking needs. Electrical ignition powered by battery with thermocouple for added
safety. Safety thermostat and thermostatic control. Metal knobs and oen handles with
embedded hygienic silicon "soft" grip enable easier handling and cleaning.
Gas static oen chamber with 40 mm thick oen door and ribbed enamelled steel base
plate. Oen chamber with 2 leels of runners for 2/1 GN sheles to enable simultaneous
and faster cooking. Heay duty thermostat with temperature range up to 300°C,
electronic sensor for precise temperature control and manual humidity control in the
cooking chamber. Upper heating element can also be used for grilling, with or without
entilating mode.
IPX4 water resistant certification.
Configuration: Freestanding, One-side operated.
Main Features
•Durable cast iron cooking plate, easy to clean.
•Central burner with optimized combustion, flame
failure deice and protected pilot light.
•Oen temperature up to 300 °C
•Pans can easily be moed from one area to another
without lifting.
•Safety thermostat and thermostatic control.
•Various sizes of pans can be used at the same time
due to large surface area with no intermediate
sectors.
•IPX4 water resistance certification.
•40 mm thick oen door for heat insulation.
•THERMODUL connection system creates a seamless
work top when units are connected to each other
thus aoiding soil penetrating ital components and
facilitating the remoal of units in case of
replacement or serice.
•Metal knobs with embedded hygienic silicon "soft"
grip for easier handling and cleaning. The special
design of the controls preent infiltration of liquids
or soil into ital components.
•Oen chamber to hae 2 leels of runners to
accommodate 2/1 GN trays and ribbed enamelled
steel base plate.
•The upper heating element of the oen can also be
used for grilling.
•Manual control of humidity in cooking chamber.
•Electronic sensor for precise temperature control.
•Electrical ignition powered by battery with
thermocouple for added safety.
•100% safety pilot and thermocouple.
•Manual oen shut-off ale.
•All major components may be easily accessed from
the front.
•Large isible digital display manufactured in
tempered glass to resist heat and chemicals,
showing temperatures or power settings. The display
also shows on/off status of the appliance and on/off
status of the heating elements.
•The center of the plate can reach a maximum
temperature of 550 °C while decreasing outwards.
Construction
•2 mm top in 1.4301 (AISI 304).
•Unit constructed according to DIN 18860_2 with 20
mm drop nose top and 70 mm recessed plinth.
•Flat surface construction with minimal hidden areas
to easily clean all surfaces
•Internal frame for heay duty sturdiness in 2 mm
and 3 mm in 1.4301 (AISI 304).

Modular Cooking Range Line
thermaline 90 - Gas French Top on
Static Gas Oven 1 Side H=700
Modular Cooking Range Line
thermaline 90 - Gas French Top on Static Gas Oven, 1 Side, H=700
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
204.02.0
Optional Accessories
•Baking sheet 2/1 GN for oensPNC 910651 ❑
•Grid, chromium plated, for oens 2/1 GNPNC 910652 ❑
•Bottom steel plate 2/1 GN for fire clay plate
800&900 with baking oenPNC 910655 ❑
•Fire clay plate 2/1 GN for oensPNC 910656 ❑
•Connecting rail kit, 900mmPNC 912502 ❑
•Stainless steel side panel (12mm),
900x700mm, freestandingPNC 912512 ❑
•Portioning shelf, 1000mm widthPNC 912528 ❑
•Portioning shelf, 1000mm widthPNC 912558 ❑
•Folding shelf, 300x900mmPNC 912581 ❑
•Folding shelf, 400x900mmPNC 912582 ❑
•Fixed side shelf, 200x900mmPNC 912589 ❑
•Fixed side shelf, 300x900mmPNC 912590 ❑
•Fixed side shelf, 400x900mmPNC 912591 ❑
•Stainless steel front kicking strip, 1000mm
widthPNC 912636 ❑
•Stainless steel side kicking strip left and right,
freestanding, 900mm widthPNC 912657 ❑
•Stainless steel side kicking strip left and right,
wall mounted, 900mm widthPNC 912660 ❑
•Stainless steel side kicking strip left and right,
back-to-back, 1800mm widthPNC 912663 ❑
•Stainless steel plinth, against wall, 1000mm
widthPNC 912941 ❑
•Stainless steel plinth, freestanding, 1000mm
widthPNC 912960 ❑
•Connecting rail kit, right PNC 912975 ❑
•Connecting rail kit, left PNC 912976 ❑
•Stainless steel side panel, 900x700mm, flush-
fitting, freestandingPNC 913087 ❑
•Stainless steel panel (12mm) 900x700mm,
against wall, left sidePNC 913101 ❑
•Stainless steel panel 900x700mm, flush-fitting,
against wall, left sidePNC 913103 ❑
•Stainless steel panel (12mm) 900x700mm,
against wall, right sidePNC 913105 ❑
•Stainless steel panel 900x700mm, flush-fitting,
against wall, right sidePNC 913107 ❑
•Endrail kit, flush-fitting, left PNC 913111 ❑
•Endrail kit, flush-fitting, right PNC 913112 ❑
•Back panel, 1000x450mm, for bases and units,
one-side operatedPNC 913169 ❑
•Endrail kit (12mm) for thermaline 90 units with
backsplash, rightPNC 913209 ❑
•Stainless steel side panel, left, H=700, flushPNC 913218 ❑
•Stainless steel side panel, right, H=700, flushPNC 913219 ❑
•Stainless steel side panel, left, H=700PNC 913222 ❑
•Stainless steel side panel, right, H=700PNC 913223 ❑
•T-connection rail for back-to-back installations
without backsplashPNC 913227 ❑

Modular Cooking Range Line
thermaline 90 - Gas French Top on
Static Gas Oven 1 Side H=700
Modular Cooking Range Line
thermaline 90 - Gas French Top on Static Gas Oven, 1 Side, H=700
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
204.02.0
Front
Top
G=Gas connection
Side
Gas
Gas Power:
58963 (MCVGEAJCPO)66475.5 Btu/hr (19.5 kW)
Gas Type Option:
Gas Inlet:1/2"
Key Information:
Configuration:On Oen;One-Side Operated
Solid top usable surface (width):790 mm
Solid top usable surface (depth):700 mm
Oven working Temperature:80 °C MIN; 300 °C MAX
Oven Cavity Dimensions (width):683 mm
Oven Cavity Dimensions (height):255 mm
Oven Cavity Dimensions (depth):671 mm
External dimensions, Height:700 mm
External dimensions, Width:1000 mm
External dimensions, Depth:900 mm
Net weight:185 kg
Oven GN:GN 2/1
