Electrolux 588050 User guide

Modular Cooking Range Line
thermaline 80 - 4-Burner Gas
Top with Ecolam, 1 Side
ITEM #
MODEL #
NAME #
SIS #
AIA #
Short Form Speciication
Item No.
APPROVAL:
Electrolux Proessional
www.electrolux.com/professional
[e-mail]
Modular Cooking Range Line
thermaline 80 - 4-Burner Gas Top with Ecolam, 1 Side
Modular Cooking Range Line
thermaline 80 - 4-Burner Gas Top with
Ecolam, 1 Side
588050 (MAGGAAHOPI4-burner gas top, ecoflam,
one-side operated
Unit constructed according to DIN 18860_2 with 20 mm drop nose top. Internal
frame for heav dut sturdiness in 2 mm and 3 mm in 1.4301 (AISI 304). 2 mm
top in 1.4301 (AISI 304). Flat surface construction, easil cleanable.
THERMODUL connection sstem enables seamless worktop when units are
connected and avoids soil penetrating. 4 gas burners with optimized
combustion, flame failure device, thermocouple safet hand valve and protected
pilot flame. Triple ring "flower" flame burners with anti-clogging design. Manual
gas valves allow precise flame intensit control. Large pan support in cast iron
with long center fins for various pan sizes. ECOFLAM pan detection sstem to
save energ and to reduce unnecessar heat radiation in the kitchen. Deep flat
spillage tra with rounded corners and drain hole. Metal knobs with embedded
hgienic silicon "soft" grip enable easier handling and cleaning.
IPX4 water resistant certification.
Configuration: One-side operated top. The base is supplied b the factor
Main Features
•Flame failure device on each burner protects against gas
leakage when accidental extinguishing of the flame
occurs.
•Large sized pan support in cast iron with long center fins
to allow the use of the largest down to the smallest pans.
•Manual gas valves allow precise control of the flame
intensit between high and low positions.
•Pans can easil be moved from one area to another
without lifting.
•IPX4 water resistance certification.
•All major components ma be easil accessed from the
front.
•THERMODUL connection sstem creates a seamless work
top when units are connected to each other thus avoiding
soil penetrating vital components and facilitating the
removal of units in case of replacement or service.
•Metal knobs with embedded hgienic silicon "soft" grip for
easier handling and cleaning. The special design of the
controls prevent infiltration of liquids or soil into vital
components.
•Burners with optimized combustion. Triple ring flower
flame burners with anti-clogging design.
•Deep flat spillage tra with rounded corners and drain hole
to facilitate cleaning.
•Model is supplied with Ecoflam pan detection sstem,
which reduces energ consumption and unnecessar heat
dispersion in the kitchen.
Construction
•Each burner equipped with thermocouple safet hand
valve and protected pilot flame.
•2 mm top in 1.4301 (AISI 304).
•Flat surface construction with minimal hidden areas to
easil clean all surfaces
•Internal frame for heav dut sturdiness in 2 mm and 3
mm in 1.4301 (AISI 304).
•Unit constructed according to DIN 18860_2 with 20 mm
drop nose top.
•Unit constructed according to DIN 18860_2 with 20 mm
drop nose top and 70 mm recessed plinth.

Modular Cooking Range Line
thermaline 80 - 4-Burner Gas
Top with Ecolam, 1 Side
Modular Cooking Range Line
thermaline 80 - 4-Burner Gas Top with Ecoflam, 1 Side
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
204.02.4
Optional Accessories
•Connecting rail kit, 800mmPNC 912500 ❑
•Portioning shelf, 800mm widthPNC 912526 ❑
•Portioning shelf, 800mm widthPNC 912556 ❑
•Folding shelf, 300x800mmPNC 912577 ❑
•Folding shelf, 400x800mmPNC 912578 ❑
•Fixed side shelf, 200x800mmPNC 912583 ❑
•Fixed side shelf, 300x800mmPNC 912584 ❑
•Fixed side shelf, 400x800mmPNC 912585 ❑
•Stainless steel side panel (12mm),
800x350mm, wall installationPNC 912670 ❑
•Connecting rail kit, right PNC 912971 ❑
•Connecting rail kit, left PNC 912972 ❑
•Stainless steel side panel, 800x350mm, flush-
fitting, wall installationPNC 913083 ❑
•Endrail kit, flush-fitting, left PNC 913109 ❑
•Endrail kit, flush-fitting, right PNC 913110 ❑
•Endrail kit (12mm) for thermaline 80 units, leftPNC 913200 ❑
•Endrail kit (12mm) for thermaline 80 units,
rightPNC 913201 ❑
•T-connection rail for back-to-back installations
without backsplashPNC 913227 ❑

Modular Cooking Range Line
thermaline 80 - 4-Burner Gas
Top with Ecolam, 1 Side
Modular Cooking Range Line
thermaline 80 - 4-Burner Gas Top with Ecoflam, 1 Side
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
204.02.4
Front
Top
G=Gas connection
Side
Gas
Gas Power:
588050 (MAGGAAHOPI95452 Btu/hr (28 kW)
Gas Type Option:
Gas Inlet:1/2"
Key Inormation:
Configuration:One-Side Operated;Top
Front Burners Power:7 - 7 kW
Back Burners Power:7 - 7 kW
Back Burners Dimension - mmØ 70 Ø 70
Front Burners Dimension - mmØ 70 Ø 70
External dimensions, Height:250 mm
External dimensions, Width:800 mm
External dimensions, Depth:800 mm
Net weight:63 kg
