Electrolux EW30ES65G B User manual

Flex-2-Fit™System
Premium smoothtop cooking with triple-ring
expandable, double-ring expandable and
single-ring elements fits all pots and pans.
Sure-2-Fit™Convection Oven
with Hidden Bake Element
Adjustable Luxury-Glide™oven racks are so smooth
and extend effortlessly. Luxury-Design™Lighting
ramp-up designer halogen lighting is as beautiful
as it is functional. Exclusive Luxury-Hold™oven
door stays put at whatever angle you place it.
Baking Options
Features 7 cooking modes and 10 cooking options
including our exclusive Perfect Turkey™button
for large holiday meals. Perfect Convect3™Third
Element European Convection System features
a variable 2-speed fan for more even cooking.
Perfect Pair™Oven
Our ranges feature a large main oven and a second
oven for the utmost cooking capacity. Use both
simultaneously to cook two different items at two
different temperatures.
Electric Built-In Ranges
EW30ES65G S, EW30ES65G W, EW30ES65G B
Featuring Wave-Touch™Electronic Controls
electroluxappliances.com
Wall OvensWarmer DrawersCooktops
Built-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsDishwashersRefrigerators
FreezersUnder Counter
30" ELECTRIC BUILT-IN RANGES
Sabbath Mode (Star-K®Certified)
Control Panel Features
Wave-Touch™Electronic Oven Control
Perfect Set™Element Controls
Keypad Entry of Time & Temperature
Electronic Clock & Timer
Temperature Display
Automatic Oven (Delay, Cook & Off)
Cooktop Features
Flex-2-Fit™Ceramic Glass Smoothtop
6" to 9" to 12" Triple Expandable Element –
1000W/2000W/2700W
6" to 9" Dual Expandable Element – 1600W/3000W
5" to 7" Dual Expandable Element – 750W/1800W
6" Electric Element – 1200W
Hot-Surface Indicator Light
Surface Controls
Oven Features
Capacity
Hidden Bake Element
Eight-Pass Bake Element – 2500 Watts
Eight-Pass Broil Element – 4000 Watts
Convection Element – 2500 Watts
Cobalt Blue Interior
Self-Clean Options with Door Lock
Perfect Convect3™with Variable 2-Speed Fan
Cooking Modes –
Bake, Broil, Convection Bake, Convection Roast,
Convection Broil, Keep Warm, Slow Cook
Cooking Options –
Perfect Turkey™, Defrost, Dehydrate, Bread Proof,
My Favorites, Multi-Stage Cooking, Temperature Probe,
Rapid Preheat, Delay Bake, Convection Convert
Luxury-Design™LightingwithDual 40W Halogen Bulbs
Luxury-Glide™Racks
Conventional Racks
Convection Roasting Rack
Additional Features
Luxury-Hold™Oven Door
Extra-Large Glass Window
Perfect Pair™Lower Oven
Adjustable Leveling Legs
Accessories
Porcelain Broiler Pan and Insert
Cleaning Sponge
Rear Filler Kit, Side Panel Kit, Backguard Kit, Side Trim Kit –
See Back for Part Numbers
Specifications
Oven Cavity Dimensions –
Height
Width
Depth
Overall Exterior Dimensions –
Height (Adjustable)
Width
Depth (to Center of Arc)
(with 90° Door Open)
Power Supply Connection Location
Connected Load (kW Rating) @ 240/208 Volts
Amps@240/208 Volts
Minimum Circuit Required (Amps)
Product Weight
Shipping Weight (Approx.)
NOTE: Always consult local and/or national electric codes. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1
1
1
2
Yes
Yes
4.2 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
3
Yes
7
10
Yes
2
1
Yes
Yes
Yes
Yes
Yes
Included
Included
Optional
16-1/2"
24-1/8"
18-1/32"
36-7/16" – 37-7/16"
31-1/2"
28-5/16"
45-1/4"
Left Bottom Rear
14.5/10.9
60.5/52.4
50
238 Lbs.
258 Lbs.

Electric Built-In Ranges
EW30ES65G S, EW30ES65G W, EW30ES65G B
High standards of quality at Electrolux Major Appliances mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EW30ES65G 01/08 © 2008 Electrolux Major Appliances, NA Printed in the U.S.A.
Overall
depth
including
oven door
in 90°open
position –
451/4"
Power
supply
location
(left
bottom
rear)
285/16"
Side
271/2"
253/4"
Front
30"
311/2"
355/8"
Adjustable
to
365/8"
13/16"
Front Face of Cabinet
227/8"min.
231/4"max.
11/8"
213/4"min.
221/8"max.**
Countertop
13"
min.
30"min.
18"
min.
*Cabinet and countertop
cutout width should match
**24" with optional
backguard installed
24"
min.
1/2"min.
WALL
311/2"
(critical)
30
±
1/16"*
Approx.
17/8"
Hatched area
should be flat
and leveled
11/2"
max.
Shave raised
edge to clear
space for
311/2" wide
cooktop rim
30
±
1/16"*
251/8"
213/4"min.
221/8"max.**
1/2"min.
Locate grounded
junction box or wall
outlet 8" - 17" from
right cabinet and
2"-4" from floor
355/8"
min.
365/8"
max.
Locate cabinet
doors 1" min.
from cutout
opening
3/8"min.
24" min. clearance
with protected cabinet bottom
30" min. for unprotected
30" Electric Built-In Range Specifications
•
Product Weight – 238 Lbs.
•
Single phase 3- or 4-wire cable, 120/240 or 120/208 Volt, 60 Hertz,
fused on both sides of line with ground. (If local code permits, range may
be connected by hard-wiring or by means of power supply cord kit.)
•
Connected Load (kW Rating) @ 240/208 Volts = 14.5/10.9 kW
•
Amps @ 240/208 Volts = 60.5/52.4 Amps
•
Recommended Circuit Breaker – 50 Amps
•
Always consult local and/or national electric codes.
•
Countertop MUST be level in all directions and adjustable range
height at least 1/16" greater than tallest cabinet height, to ensure metal
rangetop flange will fit properly on countertop edge.
•
When installing optional Backguard Kit, cutout depth of 21-3/4"
minimum / 22-1/8" maximum needs increased to 24".
•
Overhead cabinetry should not exceed a 13" maximum depth.
•
Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum width
of appliance.
•
Allow 24" minimum clearance between rangetop and bottom of cabinet
when bottom of wood or metal cabinet is protected by not less than 1/4"
flame-retardant millboard covered with not less than No. 28 MGS sheet
steel, 0.015" stainless steel, 0.024" aluminum or 0.020" copper. Allow
30" minimum clearance when cabinet is unprotected.
•
To reduce risk of fire when using overhead cabinetry, install range hood
that projects horizontally a recommended minimum of 5" beyond bottom
of cabinets.
Countertop Preparation
For detailed preparation instructions, refer to installation guide on the web.
•
Flat square-finish (flat) countertop requires no preparation since rangetop
flange lays directly on countertop edge.
•
Formed front-edged countertops require front molded edge to be shaved
flat 3/4" from each front corner of opening.
•
Tile countertops may need cut back 3/4" from each front corner of
opening and/or rounded edge flattened.
•
For existing cutout width greater than 30-1/16" reduce the 3/4" overlap
dimension or for cutout width of 29", replace actual side trim panels with
smaller side trim panels, available with optional Side Filler Kit (refer to
detailed kit installation instructions).
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
Rear Filler Kit: S – (903113-901S), W – (903113-9011),
B – (903113-9010).
•
Side Panel Kit: S – (903102-901S), W – (903102-9011),
B – (903102-9010).
•
Backguard Kit: S – (903111-901S), W – (903111-9011),
B – (903111-9010).
•
Side Trim Kit: S – (903110-901S), W – (903110-9011),
B – (903110-9010).
