Electrolux Roll-in/Pass-through
1600 liter Refrigerators
The Electrolux range of Roll-in and Roll-in/Pass-Through cabinets has been produced for high productivity
kitchens, as big caterers, hospitals, in-flight, institutions etc., demanding the highest efficiency in the flow of
the kitchen. The appliances host most of the trolley in the market, which are a basic necessity in every well
organized food flow. The Electrolux Roll-in are also used to implement a Cook & Chill and Banqueting concept.
The whole range includes different sizes, refrigerated roll-in and roll-in/pass-through and hot roll-in.
726496
EASY TO INSTALL
• Plug-in installation: 1 phase,
220/240V supply.
• Universal shock-protectors on all
sides.

EASY TO CLEAN
• The interior cell and external
panel are constructed in 304 AISI
stainless steel.
• No 90° corners are present in
the bottom panel to avoid dirt
traps.
• In compliance with NSF
regulations.
EASY TO USE
• Designed to operate at ambient
temperatures of up to 43ºC.
• Automatic defrost and
evaporation of the defrost water.
• Simple control panel: on/off
switch, high/low humidity switch,
digital temperature display.
• Ventilated cooling for the best
temperature distribution.

EASY TO MAINTAIN
• All models finished in top quality
materials to guarantee durability.
• Simple refrigeration system
easily accessible from the rear of
the units.
EASY ON THE ENVIRONMENT
• 100% CFC and HCFC free
insulation. Refrigeration circuit:
R134a gas. Gas in foam:
cyclopentane.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
• All models comply with the
standards required by the main
international approval bodies and
are H marked.

Electrolux Roll-in/Pass-through
1600 liter Refrigerators
Internet: http://www.electrolux.com/foodservice
HAI0102011-07-13Subject to change without notice
TROLLEY FOR 20X2/1 ROLL-IN RACK 922134 922134 922134 922134
TROLLEY FOR 2/1-GN ROLL-IN RACK 880017 880017 880017 880017 880017
ROLL-IN RACK FOR 2/1 GASTRONORM GRIDS 881449 881449 881449 881449 881449
KIT WITH 2 HINGES FOR DOOR REVERSIBILITY 881432 881432 881432
KIT HACCP EKIS 922166 922166 922166
BASE FOR ROLL-IN-RACK 880018 880018 880018 880018 880018
BASE FOR 20X2/1 ROLL-IN RACK 922142 922142 922142 922142 922142
BANQ.TROLLEY-92PLATES-85MM PITCH-20GN2/1 922055 922055 922055 922055 922055
80MM PITCH ROLL-IN RACK 14X2/1GN 922206 922206 922206 922206 922206
60 MM PITCH ROLL-IN RACK FOR 20X2/1 922204 922204 922204 922204 922204
ACCESSORIES
height - mm 1840 1840 1840 1840 1840
depth - mm 1015 1015 1015 1015 1015
width - mm 620/820 620/820 620/820 620/820 620/820
Maximum trolley size
Net weight - kg. 200 220 180 200 220
installed-electric 0.6 0.58 0.2 0.6 0.58
Power - kW
at evaporation temperature - °C -10 -10 -10 -10
Refrigerant power
Refrigeration power - W 546 546 546 546
Refrigerant quantity - g. 340 340 340 340
Refrigerant type R134a R134a R134a R134a R134a
N° defrost in 24 hrs. 3/30' 3/30' 3/30' 3/30' 3/30'
Compressor power - HP 3/8 3/8 3/8 3/8
N° and type of grids (included) GN 2/1 GN 2/1 GN 2/1 GN 2/1 GN 2/1
Door hinges Right Side Right Side Right Side 1 Left+1 Right Right Side
N° and type of door 1 1 1 2 2
Min/Max internal humidity - % 75/90 75/90 75/90
height 2272 2271 2270 2272 2271
depth/with open doors 1163, 2112 1163, 2112 1163, 2112 1237, 3136 1237, 3136
width 1021 1021 1021 1021 1021
External dimensions - mm
Control type Digital Digital Digital Digital Digital
Cooling unit Built-In Built-In Remote Built-In Built-In
Gross capacity (D.I.N. 8952) - l. 1630 1630 1630 1630 1630
panels 304 AISI 304 AISI 304 AISI 304 AISI 304 AISI
Internal material
panels 304 AISI 304 AISI 304 AISI 304 AISI 304 AISI
External material
Operating mode Ventilated Ventilated Ventilated Ventilated Ventilated
Operating temperature - min/max °C 2/10 2/10 0/10 2/10 2/10
TECHNICAL DATA
RI16R1F
726496
RI16R1G
726869
RI16R1FR
726065
RI16R2FT
726497
RI16R2FGT
726498

Electrolux Roll-in/Pass-through
1600 liter Refrigerators
Internet: http://www.electrolux.com/foodservice
HAI0102011-07-13Subject to change without notice
EI - Electrical connection 230 V, 1N, 50
LEGEND
RI16R1F
726496
726496

Electrolux Roll-in/Pass-through
1600 liter Refrigerators
Internet: http://www.electrolux.com/foodservice
HAI0102011-07-13Subject to change without notice
EI - Electrical connection 230 V, 1, 50
LEGEND
RI16R1G
726869
726869

Electrolux Roll-in/Pass-through
1600 liter Refrigerators
Internet: http://www.electrolux.com/foodservice
HAI0102011-07-13Subject to change without notice
EI - Electrical connection 230 V, 1, 50
LEGEND
RI16R2FT
726497
726497

Electrolux Roll-in/Pass-through
1600 liter Refrigerators
Internet: http://www.electrolux.com/foodservice
HAI0102011-07-13Subject to change without notice
EI - Electrical connection 230 V, 1, 50
LEGEND
RI16R2FGT
726498
726498
