Electrolux Icon E36WC75GSS User manual

36" WALL-MOUNT VENT HOOD
Installation Type
FEATURES
Intelligent Heat Sensor
Air Discharge
Air Delivery (CFM)
Blower Type
Controls
Fan Speeds
Halogen Lights
Washable Stainless Steel Filters
Exhaust Duct
Duct Required
OPTIONAL ACCESSORIES
Charcoal Filter – CF40EC
Duct-Free Kit – DFKTWC75GS
Flue Extension – 35-7/16" EXWC75GS
SPECIFICATIONS
Overall Exterior Dimensions –
Width
Height (With One Cover)
(With Flue Extension)
Depth
Voltage Rating
Connected Load (kW Rating) @120 Volts‡
Power Supply Location (Within Flue
Adjacent to Bottom of Air Outlet)
Product Weight
Shipping Weight
Sones Rating
* Ventilation is convertible to be either ducted outside, or recirculated inside
requiring no ducting. (Recirculated option requires use of optional Duct-Free Kit.)
‡For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
NOTE: Always consult local and/or national electric codes. Check local building codes
for installation requirements, as they may vary per locale. Refer to Product Installation Guide
for detailed installation instructions |on the web at electroluxicon.com.
Specifications subject to change.
Wall Mounted
Yes
Vertical
600
Dual Centrifugal
Wave-Touch™
4
Yes
Yes
Convertible*
6" Round
Optional
Optional
Optional
35-7/16"
16-1/2" min.
27-3/16" min.
36" max.
19-11/16
120V/60Hz/15A
0.46
Enters Flue
Top at Right
49 Lbs.
61 Lbs.
9.5
electroluxicon.com
Wave-Touch™
Control Panel Technology
A simple touch, anywhere on the panel, lights
controls and provides access to all functions.
This allows easy programming while keeping
activated functions lighted for easy monitoring.
Four-Speed, Dual-Centrifugal Blower
Quietly and effectively removes the most
persistent food and cooking odors at 600 CFM.
Dual Halogen Lighting
Two overhead halogen bulbs evenly illuminate
the cooking surface and provide abundant light
to enhance the cooking experience.
Washable Stainless Steel Filters
Saturated filters can be rinsed and cycled
through the dishwasher. The stainless steel filter
provides strength and durability not found in
foam filters.
Designed for the well-lived home.
Wall-Mount Vent Hood
E36WC75GSS
Wall-Mount Vent Hood
E36WC75GSS
High standards of quality at Electrolux Home Products, Inc. mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxicon.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxicon.ca
E36WC75GSS 05/08 © 2008 Electrolux Home Products, Inc. Printed in the U.S.A.
36" Wall-Mount Vent Hood Specifications
•
Product Weight – 49 Lbs.
•
Wall-Mount Installation
•
Ventilation is convertible to be either ducted outside, or recirculated
inside requiring no ducting.
•
Sones Rating – 9.5
•
Voltage Rating –120V/60 Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 0.46kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @120 Volts = 3.93 Amps
•
Always consult local and/or national electric codes. Check local building
codes for installation requirements, as they may vary per locale.
•
For most efficient operation, position hood low to cooktop.
Recommended installation is 30"-36" above countertop.
Ducted Option Specifications
•
For outside ventilation only.
•
Exhaust Duct Required – 6" round
•
For most efficient airflow exhaust, use a straight run or as few elbows
as possible.
•
Use metallic flex ducting only to connect rigid duct directly to transitions
(if allowed by code).
•
Thermal breaks such as short section of nonmetallic duct, should be
used in areas of extreme cold.
•
Cold weather installations should have additional backdraft damper
installed.
•
Refer to web for detailed duct preparation installation instructions.
Ductless (Recirculated) Option Specifications
•
If ducting to outside is not an option, vent hood can be converted to
ductless with use of optional Duct-Free Kit (DFKTWC75GS).
•
Refer to web for detailed convertible ventilation installation instructions.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxicon.com for detailed instructions.
Optional Accessories
•
Charcoal Filter – (CF40EC).
•
Duct-Free Kit – (DFKTWC75GS).
•
35-7/16" Flue Extension – (EXWC75GS).
Dimensions
from base of
hood to ceiling,
and include
clearance
required for
installation. 161/2"
(min.
height
with one
cover)
1015/16"
25/8"
1911/16"
1013/16"
357/16"243/8"
1415/16"
273/16"
min.**
36"
max.
(Ducted
dimensions
shown)
Ductless
dimensions:
*77/8"min.
**2615/16"min.
81/16"
min.*
16 15/16"
max.
Top
Wiring box Air outlet - 57/8" diam.
Controls
