Electrolux RH30WC40G Instruction Manual

UNIVERSAL/MULTIFLEX
Product No. RH30WC40GSA RH36WC40GSA
Market North America North America
Color stainless steel stainless steel
Exhaust-CFM 400 CFM 400 CFM
Volts 120 120
Owner's Guide 316488521 316488521
Installation Instructions 316488521 316488521
Wiring Diagram 5995510962 5995510962
RH30-36WC40G Cover.eps RH30-36WC40G Parts.eps SE1RAA.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995535217
09/03/13
(EN/SERVICE/KC)
099
RANGE HOOD
Model No.
RH30WC40G /
RH36WC40G
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995535217 RH30WC40G / RH36WC40G
03/09 2
REPLACEMENT PARTS
1
2
3
20
RH30-36WC40G Parts
4
5
5
6
7

RH30WC40G / RH36WC40G Publication No: 5995535217
# Functional Parts 3 03/09
* Non-Illustrated Parts
REPLACEMENT PARTS
Model Index: ARH30WC40G (RH30WC40GSA)
BRH36WC40G (RH36WC40GSA)
POS. NO PART NO. DESCRIPTION
1 # 5304466678 A B Blower Assembly, w/motor, fan
2 # 5304464200 A - Filter, grease, 30 inch hood
2 # 5304466252 - B Filter, grease, 36 inch hood
3 # 5304466253 A B Lampholder, socket, w/harness, lamp
4 # 5304464201 A B Control Panel, display, LCD
5 # 5304464202 A B Capacitor
6 # 5304464263 A B Power Board, pcb, w/spacers
7 5304466254 A B Screw Kit, assembly
20 # 5304472119 A B Switch, on/off
* 5304464285 A B Hardware Kit, installation
* 5304466742 A - Filter Kit, charcoal, 30" hood
* 5304466743 - B Filter Kit, charcoal, 36" hood

Publication No: 5995535217 RH30WC40G / RH36WC40G
03/09 4
WIRING DIAGRAM
