Electrolux E30WD75EPS Instruction Manual

E30WD75EPS.eps BE30WD75DSS1.eps DE30WD75EPS1.EPS 318049901.eps
Product No. E30WD75EPS1
31266300950S1
Series 30" warm drawer
Color stainless
Market North America
Wiring Diagram 318049901
Owner's Guide 318201005
Installation Instructions 318201805
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995439022
05/06/09
(EN/SERVICE/ECL)
377
WARMER DRAWER
Model No.
E30WD75E
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995439022 E30WD75EPS1
06/05 2
BODY
201
86
86
81
84A
84
202
209
39
86
196
203
13A
14
198
69
205
36A
BE30WD75DSS1
46
19
10
11
203A
205A
207
32

E30WD75EPS1 Publication No: 5995439022
# Functional Parts 3 06/05
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
10 5304437021 Screw, mounting, 8-18 x 0.25, chrome, (2)
11 5303300265 Screw, 8-18 x 0.500, chrome, (3)
13A# 316095500 Switch, infinite, warmer
14 # 318250400 Light, indicator, blue
19 318246902 Panel, control, stainless
32 318228100 Strain relief
36A 318017600 Knob, warmer
39 318144001 Cord, service
46 318250500 Lens, indicator light
69 5303323134 Screw, 8-32 x 0.188
81 318251000 Element, warmer drawer
84 # 318005106 Thermostat, safety
84A# 318005103 Thermostat, safety
86 316095800 Clip, hold down, warmer element
196 318100101 Cover, access
198 08008009 Bushing, side panel, nylon, RH, snap
201 318145104 Wrapper, outer
202 318121602 Wrapper, lower
203 318025711 Bracket, side panel, RH
203A 318025701 Bracket, side panel, LH
205 318123711 Panel, side, RH
205A 318123701 Panel, side, LH
207 318143601 Panel, wire cover
209 318247401 Bracket, wall
209* 5303302745 Screw, 10-16x1-1/8, square drive
* 318199730 Wiring Harness
* 08067961 Fastener, clip cable
* 5303211311 Screw, 8 x 0.500
* 5303311333 Screw, 8-32 x 3/8, (4)
* 5303323140 Screw, ground, 10-32 x 0.375

Publication No: 5995439022 E30WD75EPS1
06/05 4
DRAWER

E30WD75EPS1 Publication No: 5995439022
# Functional Parts 5 06/05
* Non-Illustrated Parts
DRAWER
POS. NO PART NO. DESCRIPTION
1 318246400 Drawer, warmer, w/track
4 318284001 Panel, drawer front, stainless, w/nameplate
10 5304447921 Screw, #6-32 x 3/4, (4)
10* 5304447922 Washer, flat, (4)
13 318248400 Channel, drawer slide, outer
39 241637906 Handle Assembly, stainless, w/endcaps
39* 318303700 Screw, set, #10-32 x 3/4, (4)
80 318254400 Gasket, warmer drawer
85 318257600 Rack, warmer drawer
122 318281605 Panel, drawer, interior
123 318247100 Panel, control, humidity
124 08002868 Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
125 5304436030 Rivet
126 318251100 Handle, control, humidity
209* 5303302745 Screw, 10-16x1-1/8, square drive
* 318163602 Cleaner, stainless steel
* 5303323175 Adhesive tape, 1" lg.
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303311333 Screw, 8-32 x 3/8, (4)

Publication No: 5995439022 E30WD75EPS1
06/05 6
WIRING DIAGRAM
