Viking EVEWD530 User manual

Professional/Custom Panel Built-In
Electric Warming Drawers
Viking Installation Guide

Table of Contents
Warnings & Important Safety Instructions _______________________________________________3
Dimensions _________________________________________________________________________4
Specifications _______________________________________________________________________5
Cutout Dimensions __________________________________________________________________6
Electrical Requirements ______________________________________________________________7
General Information__________________________________________________________________8
Installation _________________________________________________________________________9
Final Preparation ___________________________________________________________________10
Service & Registration_______________________________________________________________11
2

IMPORTANT– Read and Follow!
Your safety and the safety of others is
very important.
We have provided many important safety
messages in this manual and on your
appliance. Always read and obey all
safety messages.
This is the safety alert symbol. This
symbol alerts you to hazards that
can kill or hurt you and others.
All safety messages will be preceded by
the safety alert symbol and the word
“DANGER,” “WARNING” or “CAUTION.”
These words mean:
Hazards or unsafe practices
which WILL result in severe personal
injury or death
DANGER
Hazards or unsafe practices
which COULD result in severe personal
injury or death
Hazards or unsafe practices which
COULD result in minor personal injury or
property damage.
All safety messages will identify the
hazard, tell you how to reduce the chance
of injury, and tell you what can happen if
the instructions are not followed.
WARNING
CAUTION
•Before beginning, please read these
instructions completely and carefully.
• DO NOT remove permanently affixed
labels, warnings, or plates from product.
This may void the warranty.
•All local and national codes and ordinances
must be observed. Installation must
conform with local codes.
•The installer must leave these instructions
with the consumer who should retain for
local inspector’s use and for future
reference.
WARNING
FIRE AND ELECTRICAL
SHOCK HAZARD
To reduce the risk of electric
shock and fire, DO NOT use a
flexible power-supply cord with
this appliance.
WARNING
Make sure that incoming voltage is the
same as unit rating. An electric rating plate
specifying voltage, hertz, wattage, amps,
and phase is attached to the product.
Wiring the warming drawer with more
voltage than it is rated for may cause
severe damage to the thermostat,
element, and other components. Wiring
the warming drawer with less voltage than
it is rated for may cause significant
decrease in performance.
WARNING
To reduce the risk of fire, electric shock, or
injury to persons, installation work and
electrical wiring must be done by qualified
people in accordance with all applicable
codes and standards, including fire-rated
conditions.
3

Dimensions
4
59.1 cm
70.5 cm
22.8 cm
26.0 cm
A
70.5 cm
67.9 cm 59.1 cm
4.9 cm
EVEWD527 EVEWD530 EVEWD536
Overall
width A 67.3 cm 74.9 cm 89.9 cm
Professional
EVEWD527/530/536

Specifications
5
Description EVEWD527 EVEWD530 EVEWD536
Overall width 67.3 cm 74.9 cm 89.9 cm
Overall height
(from bottom) 26.0 cm
Overall depth (from rear)
To end of handle
With drawer fully
extended
70.5 cm
130.5 cm
Interior width 43.8 cm 52.1 cm 63.5 cm
Interior height 15.2 cm
Interior depth 27.8 cm
Electrical Requirements Equipped with 3-prong grounding European plug;
240 Vac / 50-60 Hz
Max. Amp Usage 425 watts
1.8 amps
450 watts
1.9 amps
550 watts
2.3 amps
Approx. shipping wt. 36 kg 40.5 kg 49.5 kg
Rear View
EVEWD
C
5.1 cm
22.8 cm
5.1 cm
230V Supply Cord
(When facing cabinet, opening is
located on right side.)
EVEWD527 EVEWD530 EVEWD536
Overall
width C 63.2 cm 70.8 cm 85.4 cm
Dimensions

Cutout Dimensions
6
A
C
B
EVEWD527 EVEWD530 EVEWD536
Cutout width (A) 64.1 cm 71.8 cm 86.4 cm
Cutout depth (B) 59.7 cm 59.7 cm 59.7 cm
Cutout height (C) 23.5 cm 23.5 cm 23.5 cm
Flush Mount Option:
Note: To install the warming drawer in a flush mount application, a flush
mount accessory kit is required and sold separately.
EVEWD527 EVEWD530 EVEWD536
Cutout width (A) 68.4 cm 76.0 cm 90.5 cm
Cutout depth (B) 64.5 cm 64.5 cm 64.5 cm
Cutout height (C) 27.0 cm 27.0 cm 27.0 cm
Professional Models

Electrical Requirements
WARNING
Electrical shock hazard.
To avoid the risk of electrical
shock, personal injury or death;
verify electrical power is turned
off at the breaker box until the product is
installed and ready to operate, installation
by an authorized installer only.
7
Electrical Connection
EVEWD527 EVEWD530 EVEWD536
Max. amp
usage
425 watts
1.8 amps
450 watts
1.9 amps
550 watts
2.3 amps
Electrical Requirements
A 240 volt, 50-60 Hz, AC only 16 amp
fused electrical supply is required. (A time
delay fuse or circuit breaker is
recommended.) It is recommended that a
separate circuit, serving only this appliance,
be provided. DO NOT use an extension
cord.
ELECTRICAL GROUND IS REQUIRED ON
THIS APPLIANCE.

General Information
8
• When installing this unit directly below
other units, only install with Viking built-
in products.
• Remove warming drawer carefully from
carton. Remove all loose packaging and
accessories.
• It is the responsibility of the installer to
comply with local codes.
• Line disconnect switch, circuit breaker, or
plug/receptacle of power cord
connection should be readily accessible
to the operator.
• Ground unit per applicable electrical
codes.
• Any installation not matching the
specifications discussed in these
instructions will void the manufacturer’s
warranty.
READ AND FOLLOW ALL WARNING
AND CAUTION INFORMATION
WHEN INSTALLING THIS
APPLIANCE.
Moving, Handling and Unpacking
Remove and discard all packing materials,
including cardboard and tape on the
outside and inside of the warming drawer.
Some stainless steel parts may have a
plastic protective wrap which must be
peeled off. The interior should be washed
thoroughly with hot, soapy water to remove
film residues and any dust or debris before
being used, then rinsed and wiped dry.
Solutions stronger than soap and water are
rarely needed.

9
1
2
1
2
Pull out warming drawer
pan until fully extended.
Slide finger along right and left side until you reach the
black hand latches (located at the front of the rails). Pull
up on both the right and left latches and pull out
drawer pan support.
3
step
4
Connect electrical power cord.
5
x4
Slide cavity assembly into the cabinet opening.
Secure the warming drawer using four
#8 mounting screws (four screws provided).
6
Replace drawer assembly.
Installation

10
Final Preparation
• All stainless steel body parts should be
wiped with hot, soapy water and with a
liquid cleaner designed for this material.
If buildup occurs, DO NOT use steel wool,
abrasive cloths, cleansers, or powders!
If it is necessary to scrape stainless steel
to remove encrusted materials, soak with
hot, wet cloths to loosen the material, then
use a wool or nylon scraper. DO NOT use
a metal knife, spatula, or any other material
tool to scrape stainless steel! Scratches are
almost impossible to remove.

11
Service & Registration
If service is required, call your dealer or authorized service agency. The name of the authorized
service agency can be obtained from the dealer or distributor in your area.
Have the following information readily available.
• Model number
• Serial number
• Date purchased
• Name of dealer from whom purchased
Clearly describe the problem that you are having. If you are unable to obtain the name of an
authorized service agency, or if you continue to have service problems, contact Viking Range,
LLC at [phone] or write to:
VIKING RANGE, LLC
PREFERRED SERVICE
111 Front Street
Greenwood, Mississippi 38930 USA
Record the information indicated below. You will need it if service is
ever required.
The serial number and model number for your appliance can be found
by pulling drawer out until it stops and lifting inner lining. Rating/Serial
plate is located on the left, rear side.
Model number ____________________________________________________________________________________
Serial number _____________________________________________________________________________________
Date of purchase __________________________________________________________________________________
Date installed ______________________________________________________________________________________
Dealer's name _____________________________________________________________________________________
Address ___________________________________________________________________________________________
If service requires installation of parts, use only authorized parts to insure protection under the
warranty.
These installation instructions should remain with the unit for future
reference.
