Electrolux E30WD75ESS2 User manual

Use _ Care
Warm _ Serve
Guide
Drawer
Electrolu×

Finding information
MAKEA RECORDFORFUTUREUSE
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
Brand
Purchase Date
Model Number
Serial Number
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
For toll-free telephone support in the U.S. and Canada:
l=877=4ELECTROLUX (1=877=435=3287)
For online support and internet product information:
www.electrolux.com
©2003 Electrolux Home Products, Inc.
Post Office Box 212378, Augusta, Georgia 30917, USA
All rights reserved. Printed in the USA

Finding information 3
TABLEOFC E...TS,•,,, • •,,, • •,
[] [] [] [] [] [] []
s_fotv...................................................................4
ImportantSafetyInstructions..............................4
Setting Control ...................................................7
BeforeSettingWarmerDrawerControl..............7
SettingWarmerDrawerControl.........................7
GeneralCare& Cleaning....................................9
Care& CleaningTable......................................9
ToRemoveandReplaceWarmerDrawer...... 10
So ut ons to Common Prob eros ...................11
DrawersNotLeve ....................11
CannotMoveApplianceEasily.........................11
WarmerDrawerDoesNotOperate..................11
Warranty information.......................................12
:: ;i;;;;;;;;;;;;;;;;;;;;

Safety
iMPORTANTSAFE iNSTRUCTiONS
m [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
Please read a(I safety instructions before using your new Eiectrolux Warm & Serve Drawer.
=Remove a(I tape and packaging wrap before using the appliance. Destroy the
carton and plastic bags after unpacking the appliance. Never allow children to p(ay
with packaging material.
Proper Instal(ation. Be sure your appliance is properly insta(led and grounded by
a qualified technician in accordance with the Nationa( Electrical Code ANSI/
NFPA No. 70 -latest edition in the United States, or CSA C22.1, Part 1in Canada,
and local code requirements, install only per installation instructionsprovided in the
literature package for this appliance.
Ask your dealer to recommend a qualified technician and an authorized repair service. Know
how to disconnect the electrical power to the drawer at the circuit breaker or fuse box in case
of an emergency.
• User Servicing. Do not repair or replace any part of the appliance unless
specifically recommended in the manuals. All other servicing should be done only by
a qualified technician to reduce the risk of personal injuryand damage to the appliance.
* Never modify or alter the construction of the drawer by removing panels, wire covers,
locking plates, or any other part of the product.

Safety
•Storage in or on Appliance--Flammable materials should not be stored in the
drawer. This includes paper, plastic and cloth items, such as cookbooks, plasticware
and towels, as well as flammable liquids. Do not store explosives, such as aerosol cans,
on or near the warmer drawer. Flammable materials may explode and result in fire or
propertydamage.
• Do not leave children alone. Children should not be left alone or unattended in
the area where an appliance is in use. They should never be allowed to sit or stand on
any part of the appliance.
•DO NOT TOUCH INTERIOR SURFACES OF THE WARMER DRAWER. Surfaces may be
hot even though they are dark in color. During and after use, do not touch, or let clothing
or other flammable materials touch these areas until they have had sufficient time to cool.
Wear Proper Apparel--Loose-fitting or hanging garments should never be worn
while using the appliance. Do not let clothing or other flammable materials contact hot
surfaces.
Use Only Dry Potholders--Moist or damp potholders on hot surfaces may result in
burns from steam. Do not let the potholders touch hot heating elements. Do not use a
towel or other bulky cloth instead of a potholder.
Do Not Heat Unopened Food Containers--Build-up of pressure may cause the
container to burst and result in injury.
IMPORTANT--Do not attempt to operate the warmer drawer during a power
failure. If the power fails, always turn the control off. If the drawer is not turned off
and the power resumes, the drawer may begin to operate again. Food left unattended
could spoil.
• Protective Liners--Do not use aluminum foil to line warmer drawer. Any other use of
protective liners or aluminum foil may result in poor performance or damage to the
appliance. Only use aluminum foil as recommended for baking ifused as a cover placed on
thefood.
•Glazed Cooking Utensils--Only certain types of glass, glass/ceramic, ceramic
earthenware, or other glazed utensils are suitable for use without breaking due to the
sudden change in temperature. Check the manufacturer's recommendations.
• Use Care When Opening Warmer Drawer--Stand to the side of the unit when opening
the door of a hot drawer. Let hot air or steam escape before you remove or replace food in
thewarmerdrawer.

Safety
o Placement of Warmer Drawer Racks--Always place rack in desired location while
drawer iscool. If rack must be moved while hot, use extreme caution. Use potholders and
grasp the rack with both hands to reposition. Do not let potholders contact the hot element
or interior of the warmer drawer. Remove all utensils from the rack before removing rack.
= Do Not Use Water on Grease Fires--Smother the fire or flame or use dry chemical
or foam=type extinguisher.
iMPORTANT iNSTRUCTiONS FOR CLEANING YOUR WARM &SERVE
DRAWER
o Clean the drawer regularly to keep all parts free of grease that could catch fire. Do
not allow grease to accumulate. Greasy deposits could catch fire.
= Kitchen cleaners/aerosols--Always followthe manufacturer's recommended directions
for use. Be aware that excess residue from cleaners and aerosols may ignite causing
damage and/orinjury.

Setting Control
BEFORESE_NG WARMERDRAWERCONTROL
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
Arranging Warmer Drawer Rack Positions
Set the warmer drawer rack in the vertical position as shown below.
The rack can be used in 2 ways:
In the upright position to allow low
profile food items to be placed both
under and on top of the rack (for ex-
ample, rolls or biscuits on top of the
rack and a casserole dish under).
•in the downward position to allow
you to place light weight food items
and empty dishware (for example,
rolls or pastries and dinner plates). Downward Position Upright Position
SE_mNGWARMERDRAWERCONTROL
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []

Setting Control
SE (NG WARMERDRAWERCONTROL
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
OFF HI
MED
The knob shown istypical only.
Warmer Drawer Recommended
Food Settings Chart
Food Item Setting
Bacon HI
Biscuits MED
Casseroles MED
Eggs MED
Empty Dinner Plates LO
Fish, Seafood MED
Fried Foods HI
Gravies, creams, sauces MED
Ham MED
Hamburger Patties HI
Pancakes, Waffles HI
Pastries MED
Pies MED
Pizza HI
Pork Chops HI
Potatoes (baked) HI
Potatoes (mashed) MED
Poultry HI
Roasts(Beef, Pork, Lamb) MED
Rolls, soft LO
Rolls, hard MED
Vegetables MED
To Set the Thermostat Control
The thermostat control knob is used to select the temperature of the
warmer drawer. It is located at the right side of the warmer drawer in the
open position. The temperatures are approximate, and are designated by
HI, MED and LO. The control can be set to the three settings, or
anywhere between.
1. To set the thermostat, push in and turn the knob to the desired setting.
2. For best results, preheat the drawer before adding food. An empty
drawer will reach the LO setting in about 8 minutes, the MED setting
in about 10 minutes, and the HI setting in about 12 minutes.
3. When done, turn the thermostat control to OFF.
Temperature Selection
Refer to the chart in the side column for recommended settings, if a
particular food is not (isted, start with the medium setting. If more
crispness isdesired, remove the lid or aluminum foil.
Most foods can be kept at serving temperatures by using the medium
setting.
When a combination of foods are to be kept warm (for instance, a meat
with 2 vegetables and rolls), use the high setting.
Refrain from opening the warmer drawer while in use to e(iminate loss of
heat from the drawer. Open only for adding or removing food.
To Warm Serving Bowls and Plates
Heat bowls and plates on the LO setting. Place empty dishes on the rack
to raise them off drawer bottom. To further heat dishes or to heat fine
china, check with the manufacturer for maximum heat tolerance.
To Set the Humidity Controller
The humidity controller islocated on the inside of the warmer drawer and
used to control humidity inthe warmer drawer. The humidity control knob can
•O0 •
be set at any position between Moist _ (Figure 1) and Crispy _ (Figure 2)
position. To set the humidity controller, slightly unscrew the knob, slide the
controller to the desired location and screw the knob (closed) inplace.
Figure 1 Figure 2

i ii!iiii_i
General Care & Cleani
c_ea__gVar_o__Part_or¥o_rAppJ_a_oe :)
Before cleaning any part of the drawer be sure control isturned OFF and the drawer is
COOL REMOVE SP LLOVERS AND HEAVY SO L NG AS SOON AS POSSIBLE. REGU-
hAm ChEA NINe S WIhh mEUUCE TH E NUMa EmOF MAJOR ChBANINe S LATEm.
Surfaces How to Clean
Past c To remove control knob turn to the OFF position grasp firmly and pull straight
Contro Knobs off the shaft. Clean with a cloth soaked in soapy water. Rinse with a clean
water and a dishcloth. To replace knob after cleaning line up the flat sides of
both the knob and the shaft then push the knob into place.
Note: Humidity controll er knob can not be removed.
Stan ess Stee Cleaners made especially for stainless steel are recommended. Always follow
Door & Drawer Body the manufacturer s instructions. Be sure to rinse the cleaners. DO NOT clean
the door gasket. The door gasket is essential for a good seal. Care should be
taken not to rub, damage or remove thegasket.
Porcelain Enamel Gentle scouring with a soapy scouring pad will remove most spots. Rinse with
Body Parts and Cavity a 1:1 solution of clear water and ammonia. If necessary, cover difficult spots
with an ammonia-soaked paper towel for 30 to 40 minutes. Rinse with clean
water and a damp cloth, and then scrub with a soap-filled scouring pad. Rinse
and wipe dry with a clean cloth. Remove all cleaners or the porcelain may
become damaged during future heating. DO NOT use spray oven cleaners.
Warmer Drawer Rack The rack may be removed for cleaning. If removed, clean by using a mild,
abrasive cleaner following manufacturer's instructions. Rinse with clean water
and dry.

General Care & C(eani
TOREMOVEANDREPLACEWARMERDRAWER
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
Push here
Warmer Drawer
Push here
To Remove Warmer Drawer:
1. Make sure the drawer is COOL. Open the drawer to the fully
opened position.
2. Locate the (atches on both sides of the warmer drawer. Push
at the same time on both latches while pulling the drawer out.
3. Tocleanwarmerdraweranddrawercavity, seethec(eaning
chart.
To Replace Warmer Drawer:
1. Align the glide latches on both sides of the drawer with the
slots on the drawer.
2. Push the drawer back in until you heard two little clicks which
will indicate that the drawer iswe(( instai(ed.

Solutions to Common Problems
Before calling for service, review this list. it may save you both time and expense. This
list includes common experiences that are not the result of defective workmanship or
material in your Warm & Serve Drawer.
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
,, Poor Installation, Place a level on the cutout bottom, Make sure bottom _s
level,
Be sure cutout bottom _sstrong and stable enough to adequately support
drawer (and wall oven, If applicable),
[]
o
o
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
Appliance must be accessible for service,
Cabinets not square or are built in too tightly, Contact builder or Installer to
make appliance accessible,
__ ,. _i, ;, ,,,,;i _.. _ , , , ,, .... _,_. y-,_ , _....... ; , _,,__ _..... ,_. , _ .... _,_.
_"_ _""-"?,I_,.,.: '_/ "_,_.'_,,I_:'"_,_.
[] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] [] []
• Make sure cord/plug Is plugged tightly Into outlet,
Service wiring is not complete, Contact your dealer, installing agent or
authorized servicer,
,, Power outage, Check house lights to be sure, Call your local electric
company for service,
[] []

Warranty information
WARMERDRAWERWARRANTY
Yourwarmerdraweris protectedby thiswarranty
In the U.S.A.,your applianceis warrantedby ElectroluxHome ProductsNorth America,a divisionof White ConsolidatedIndustries,Inc. We
authorizeno personto changeor add to any of our obligationsunderthis warranty.Our obligationsfor serviceand partsunderthiswarranty
must be performedby us or an authorized ElectroluxHomeProducts North Americaservicer.In Canada, your applianceis warranted by
Electrolux Canada Corp.
FULLONE-YEAR
WARRANTY
LIMITED
WARRANTY
(Applicabletothe
StateofAlaska)
WARRANTYPERIOD
Oneyearfrom
oNginalpurchase
date
Timeperiodslisted
above.
THROUGHOURAUTHORIZEDSERVICERS,
WEWILL:
Payall costsfor repairingor replacingany
partsof thisappliancewhichproveto be
defectivein materialsor workmanship.
All of theprovisionsof thefull andlimited
warrantiesaboveandtheexclusionlisted
belowapply.
THECONSUMERWILLBERESPONSIBLEFOR:
CostsofservicecallsthatarelistedunderNORMAL
RESPONSIBILITIESOFTHECONSUMER.*
Costsofthetechnician'straveltothe homeandany
costsforpick upanddeliveryof theappliancerequired
becauseofservice.
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED
SERVICE
This warranty applies only to products in ordinary household use, and the consumer is responsible
for the items listed below:
1.Proper use of the appliance in accordancewith instructionsprovidedwith the product.
2.Properinstallationby an authorizedservicer in accordancewith instructionsprovidedwith the applianceand
in accordancewith all local plumbing,electrical and/or gas codes.
3.Proper connectionto a grounded power supply of sufficient voltage, replacementof blown fuses, repair of
loose connectionsor defects in housewiring.
4.Expensesfor making the applianceaccessiblefor servicing,such as removalof trim, cupboards,shelves,etc.,
which are not a part of the appliancewhen it was shippedfrom the factory.
5.Damagesto finish after installation.
6.Replacementof light bulbsand/or fluorescenttubes (on models with these features).
This warranty does not cover the following:
1.CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSESRESULTINGFROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
NOTE: Some statesdo not allowthe exclusionor limitationof incidentalor consequentialdamages,so this
limitationor exclusion may not apply to you.
2.Service calls which do not involve malfunctionor defects in workmanshipor material,or for appliances not
in ordinary household use. The consumer shall pay for such service calls.
3.Damages caused by servicesperformed by servicers other than Electrolux Home ProductsNorth America
or its authorizedservicers; use of parts other than genuine Electrolux HomeProductsparts; obtainedfrom
personsother than such servicers;or external causes such as abuse, misuse,inadequatepower supply or
actsof God.
4.Productswith original serial numbersthat have been removedor altered and cannotbe readilydetermined.
Keepyour bill of sale, deliveryslip, or someother appropriatepaymentrecord. The date on the bill establishes
the warranty period shouldservice be required.If service is performed,it is in yourbest interestto obtain and
keep all receipts. This written warrantygives you specific legal rights.Youmay alsohave other rightsthatvary
from state to state. Service underthis warranty must be obtained by contacting ElectroluxHomeProducts:
USA Canada
1,800,944,9044 1,866,294_9911
ElectroluxHome Products Electrolux Home Products
North America North America
P.O.Box 212378 802, bouh L'Ange-Gardien
Augusta,GA 30917 L'Assemptien, Quebec
JSW 1T6
Thiswarrantyonly appliesinthe 50 statesof the U.S.A.,PuertoRico,andCanada.
Productfeaturesor specificationsas describedor illustratedare subjectto change
without notice. All warranties are made by Electrolux Home Products North
America,a divisionofWhiteConsolidatedIndustries,Inc.In Canada,yourappliance
is warranted by Electrolux Canada Corp.
