Elefine EF-DZJ10S User manual

EF-DZJ10 AC Boom Barrier
User's Manual
Issue Date: 2021.08
Shenzhen Elefine Technology Co., Ltd.
www.elefinetech.com

1
Model
Description
Max boom
length
( L ≦ meter )
Action time
( second )
Boom height
(meter)
EF-DZJ10S
Medium speed , straight L ≦4 m30.83
EF-DZJ10F90°Folding boom L ≦4m 30.83
1) Production Outline
2)Production Series
3)Functions and Features
4)Working Environment
Table 1) Products outline
We adopt the most reliable barrier motor from an
OEM barrier manufacturer in China, and with our own
cabinet design and built to match our parking system
devices. All production including assembly and testing are
all locally conducted by technical team in our factory to
ensure a premium quality level that can line up with our
parking system products.
5) M
achine Core Design 3
6) Di
rection Rules 4
7) Installation,A
djustment and Use 5
Installation for Mechanism Part 5
Adjustment and Use of the Mechanism Part 6
Springs Selection, Installation and Adjustment 10
7.4)Installation and Connections of the Electric Part 13
7.5)Electricity Adjustment and Attentions 15
8) Com
mon Malfunctions and Solutions 16
9)Packing List 17
10)Service Items 18
2)
Production series
Appendix
1)Remote Control Code Instruction and Figure 18
2)Installation of the Infrared Photocell 19
3)Adjustment of the Limit Switch 20
Attention: please read this instruction before installation!

2
Notice: The "Boom Height" means height from
the boom holding point to the ground

23
3) Functions and Features
The humanized clutch device: In case of power off,
unlock the clutch device and raise the boom manually. By the
time the power is supplied, lock the clutch device to make it
working normally again.
Special spring device: Both the compression spring and
tension spring can be used in the machine. Using the
5)Machine core
Boom tray
Boom tray cover Boom
compression spring can avoid accidents caused by the
tension spring.
Three control buttons: for boom raising, falling and pausing.
3.4) Boom backtrack function: the boom will rise if it hits
something when falling.
Infrared photocell design: for avoiding the crash when
the boom falling, so as to prevent the vehicles from being
pressed.
Both external and internal loop detectors are supported.
3.7) 'Open', 'Close' and 'Stop' controlling interfaces.
RS-485 communication serial interface (optional).
Traffic light signal connection device: red light for stop;
green light for pass.
Remote control and wire control for selection.
4) Working environment
Balance crank
Link hole1
Link hole2
Shock absorption
screw1
Screw mandrel
Spring bracket
Spring sleeve
Shock absorption screw2
Shock absorption crank
Librate cushion
Electric stroke limit
Sway crank
Limited triangle
Fan
Initiative crank
Connecting rod
Motor
Machine core working temperature
Electric cabinet working temperature
Rating voltage
Rating power
Relative humidity
Remote control distance
Net weight
-25 °C ~ +85°C
-20°C ~ +75°C
220 / 110V±10 %, 50 / 60Hz
100W
≦90%
≧30m
65kg
Balance spring
Buffer spring
Sensor
Adjust screw

45
6) Direction rule
The right-side fixed barrier gate installation rule:
The bar inside the gate
7) Installation, debugging and usage
Installation of mechanism part
7.1.1) Please select the right type of the barrier gates according
to the specifications of the place. Fix the barrier gate case
L board with expansion bolts(refer to the fig.3)
H Reference size Expansion bolts
Outside the gate
Barriers fix at right side of the gate
Fig.1
Fixation of R-type case
Reference size
The barrier gate fix at the right hand side of the access
The left-side fixed barrier gate installation rule:
The bar inside the gate
Bar is inside the gate L
H
Barriers case board
Fig.3
Fix the boom to the boom tray with the boom press board,
then cover the boom capuche with the screws. After that, fix
the cover of the boom to the splint and fasten them with
four screws of 4×16, and slip the cover tap to the
correspondent hole in the boom cover. Finally, fasten the
cover tap with the cover by two 3×10 screws.
Unlock the clutch device with the clutch key clockwise. Move
the boom to the horizontal and vertical position manually to
make sure there is no obstruction. Then turn on the power
(refer to the Fig.4)
Barrier fix at left side of the gate
Fig.2
The barrier gate fix at the left hand side of the access
Fig . 4
Lock Unlock

67
Debugging and use of the mechanism(cautions:turn
off the power before setting)
Fig.5(Cautions: turn off the power before setting)
Nut 1 of shock absorption screw 1
Clutch axis
Unsteady
Barrier case cover Remove the coping
Boom tray
Fix screw
Lock screw Shock absorption
rubber
Link pole
Adjust screw for balance spring
Fig.5
(A) The barrier gate has been well set in our factory, but it can be
further debugged if there is any problem in usage.
(B) Dismantle the machine coping:(1)Remove the fixed screws which
were fixed under the boom tray.(2)Open the machine door and
loose the lock screws.(3)Take away the coping.(Refer to fig.5)
(C) Methods to make the boom in the vertical position:
Fig.7(Attention:The clutch device should be locked in these methods.)
(a) If the boom is not in the vertical position:(refer to fig.6)
(a-1) raise up the boom to the vertical position, then loosen the
Nut 1 of shock absorption screw 1 to diminish the press to
the shock absorption rubber A.
If there is a gap between the screw A and rubber as the
boom is in vertical position, please adjust it again until the
press is just right.
(a-2) Adjust locknuts in both sides of link pole until the boom is
vertical. Then tighten up the locknuts again.
(b) If the boom is unsteady in the horizontal position:(refer to
fig.7)screw the adjusting screw of the balance spring clockwise
to enhance the spring tension.
(Attention: the spring tension could not be too hard.)
Fig.6 Fig.7
(D) The best methods to adjust the boom(Attention:the clutch device
should be unlocked in these methods), please try as follow:
(a) Unlock the clutch device and erect the boom manually.
If the boom cannot keep standing or fall down easily, that
means the balance spring is not tensional enough. In this
case, move the boom to the vertical position and adjust the
screw which is used to balance the spring.
(b) Move the boom to 45 degrees manually.
If th e boom is still easy to fall down, repeat the step the
above step, until the boom does not fall down anymore and
has the trend of moving upwards.
(c) Change a new balance spring then readjust the boom again.
(E) If the boom is vibrant too much when it backtracks in case of
coming across any obstacle, please try as follow:(refer to fig.8)
(E-a) Turn off the power, unlock the clutch device with the clutch
key clockwise, and erect the boom to the vertical position
manually. Adjust the adjusting screws of the balance spring
anticlockwise to diminish the tension of the spring.

89
(E-b) Repeat Step( E-a).
(E-c) If the balance spring has been adjusted to the tension, the
problem still could not be solved. Please hang the balance
spring to link pole 2 instead of link pole 1.
If the problem still exists, please change a smaller line diameter
spring and repeat the above steps.
(F) Methods to make the boom in the horizontal position:
(Attention: The clutch device should be locked in these
methods.) a(Fs-afo) llIofwb:oom is not at the exact horizontal position,
please try
Adjust screw 2 to diminish
the tension
Fig . 9 . 1
Shock absorption
rubber
Link pole
Balance crank
Link hole 1
(F-a-1) Refer to Fig.9-1, fall down the arm, and then adjust the
shock absorption screw 2 to make the boom in the horizontal
position. If it doesn't work, try the next step.
(F-a-2) Loosen the locknuts on both sides of the link pole, rotate
the link pole right or left to adjust the arm, then screw down
the locknuts again when the boom is in the horizontal position.
(F-b) If the boom is vibrant as it falls down to the horizontal
position.
(F-b-1) Refer to Fig.9-1, adjust the shock absorption screw B to
diminish the press to the shock absorption rubber B(shock
absorption cushion); if the adjusting is not satisfied, please
try as follow.
(F-b-2) Unlock the clutch device, and rise up the boom to the
vertical position manually. Rotate the adjusting screw for
balance spring to enhance or diminish the tension.
(F-b-3) Lock up the clutch device and run the machine. If the
problem still exists, retry the above steps.
(G) The method to lock up unlock the clutch device. The clutch can
not be unlocked. Insert the clutch key and rotate it clockwise to
unlock it, and the anticlockwise to lock it. If the clutch device
could not been locked up or unlocked easily, please pull up or
pull down the boom by hand lightly.(Refer to Fig.4)
Sway up
and down
Link hole 2
Fig.9.2
Fig.8

10 11
Num The length of the arm
(L=meter)
Line diameter/diameter of
the spring
(D=mm)Link hole selection
12.5<L<3.5D=4.5Link hole 1
23.5≦L≦4.0 D=5.5Link hole 2
34.0<L<5.5D=6.5Link hole 2
45.5≦L≦6.0D=6.5Link hole 1
5
6 . 0 ≤ L
For special order
Spring selection,installation,and adjustment
(A)Spring selection
A. Selection: Balance spring
The parameter for selecting the balance spring
(B) Spring installation
(B-a)Selcect a suitable spring together with the screw mandrel
and insert them into the spring sleeve.
(B-b)Put the whole assembled sleeve into the spring bracket.
(B-c)Make the screw mandrel connected to the balance crank
by link hole 1 or link hole 2.
(B-d)Install the gasket and the screw at the bottom of the
screw thread pole.
(B-e)Spin the screw clockwise to adjust the press of the balance
spring,so that it can balance the weight of the arm.
(C) Spring replacement
(C-a)Rise up the boom to the vertical position.If the power is
off,unlock the clutch device,put the boom to the vertical
position manually,and make sure the boom would not fall
down.
(C-b)Spin the bottom adjusting nut anticlockwise to disassemble
it and the baffle ring.
(C-c)Fall down the boom to the horizontal position manually,
loosen
from the
the
spring
fixedsleeve screw.and take out the screw mandrel
(C-d)Loosen 4 setscrews to take off the spring sleeve for
changing the new spring.(Refer to Fig.10)
4 setscrews for
spring bracket
Inbuilt spring:
Inbuilt spring:line diameter is 3.0mm;
Length is 145 mm;
External diameter is 26 mm.
The length of the boom from 5.5to 6 meters has additional
instruction for inbuilt spring.
In order to make a safe and steady performance and to decrease
the metal fatigue of the balance spring,3 inbuilt springs covered
with PVC pipe are inserted into the 6.5mm compressed balance
spring and separated with rubber cushion.
Mandrel
Spring bracket
Fig . 10
Adjusted nut

12 13
Electrical Connections
Capacitor Limit Signal Input
Sensor Interface
Up indicator light Communication
Down indicator light Module Interface
Radio Receiver
Interface
1-2:delay-down
Capacitor 2 3:Set Leave
Interface Permitted
Motor Power Speed adjust switch
Output Interface
Output Interface Indicator Light
Socket
IC System&Wire Up Limit
Control Interface Down Limit
Fan Connector Vehicles Detector
Photocell Signal Input Photocell
Line Fuse(5AF) Stop
Vehicles Detector Down
Loop Up
Up Limit Signal Output Power
Power input interface board
R&G light output interface board
Vehicles Detector
Shortcut Interface
Fan Testing
Change the Radio controller
into line control form
If the electrical connections in the user manual differ from
this diagram, please reference this diagram.
RS-485 Communication Exterior Vehicles Detector Signal Interface Special for Motorcade Down Limit Signal Output Photocell Power Output
(C-e) Insert the screw mandrel again and fix it to the selected
link hole.
(C-f) Rise up the boom to the vertical position again and make
sure the boom will not fall down.
(C-g) Install the adjusting nuts and the baffle ring in the lower
part of the screw mandrel and adjust the press to the
balance spring , so that it can balance the weight of the arm.
(D) Spring adjustment
The bottom screw can be screwed clockwise or anticlockwise to
adjust the press to the balance spring.(Refer to Fig.11)
Installation and connections of the electric part(refer
to Fig.12)
Uptrend area
2
25 5° °
Balance area
15° Downtrend
area
Fig.11
(D-a) In the uptrend area, the boom will move upright because
of the balance spring.
(D-b) The boom can keep balance and motionless in any position
of the balance area.
(D-c) In the downtrend area, the boom will be fallen down to
horizontal position because of the gravity.
Fig.12

14 15
(A) 220V(110V) power connection:
Remove wiring terminal cover and connect power wire to [Power input
interface board].
(B) Traffic light (R&G light) connection:
The traffic light connector provides 220v power. Connect the Red
Light Wire, Green Light Wire and COM wires to the [R&G light output
interface board] according to text indication printed on the board.
(C) Photocell emitter and receiver connection:
To use photocell device, first connect photocell (emitter and receiver)
to wiring terminal power output [Photocell power output], and then
connect receiver signal wire to signal input [Photocell signal input] on
wiring terminal board.
(D) Loop detector terminal:
This controller can support both the internal and the external loop
detector connections.
However, just one way can be chosen.
If external loop detector is selected, just connect the loop detector
to 220V power, and connect the signal wire to the signal input
terminal.
If the internal loop detector is selected, connect the internal loop
detector to the socket on the circuit board directly and the signal
wire to vehicles detector signal input terminal.
(E) "COM","UP","DOWN","STOP" signal input terminal:
The input terminal can work as a switch. If choose the "UP",
"DOWN","STOP" input terminal to connect to the "COM" by a
wire, the main board will give the correlative reaction signal to the
barrier gate arm.
The user can use this method for the IC system controlling or the
circuitry controlling.(Note: the wire control is advised to be used
in the guards' room)
(F) "UP" and "DOWN" position limit switch:
This switch transmits the "UP" and "DOWN" command to boom by
optical signal.(Notice: More details please refer to Fig.12)
(G) RS485 serial communication terminal:
The main board supports the Rs485 serial communication to control
the boom UP and DOWN. Please link the computer with Rs485
interface by the communication module.
The software please refer to the instruction in the disk.(Optional
device)
(H) Terminal special for motorcade:
If the users have installed the loop detector, and do not want the
barrier boom fall down automatically when there are still some cars
in line behind the passing car. Then please add an exterior circuit
to this device. If the circuit is on, the loop detector will work; if
the circuit is off, the loop detector will not work.
Electric part adjustment and attentions
(A) Barrier gate controlling:
There are three buttons to control the barrier gate conveniently
when the barrier gate sets well.
If the boom can not fall down or rise up to the right position, or
rises up automatically after reaching the horizontal position, please
check whether the abnormal situation is caused by loop detector
or not.
If the abnormal situation mentioned above is not caused by loop
detector, please check the "Gate Type Selection "setting.
(Note: the barrier gate speed has been fixed. And this "Gate Type
Selection" is just for controller adjustment to keep its' working
speed accord with the barrier gate speed.) The "Gate Type
Selection has been well set before leaving our factory, but user
can adjust
it if needed.
(B) Boom backtrack function:
The boom will rise up if it comes across obstacles when falling.
And it will stop if it hits something when rising.
(C) Infrared photocell function:
If the infrared signal is cut off when the boom is falling, the boom
will rise up automatically.
(D) R&G light terminal:
The light will turn green only when the boom is at the vertical
position. Red light is for other positions.
(E) Loop detector terminal:
If the vehicles detector is installed correctly, the boom will
automatically rise up when there is some press of the vehicle on the
loop, and it will automatically fall after the vehicles leaves the loop.

16 17
Title Specification
Qty Note
Barrier Gate Core 1Main part
Barrier Gate Boom Straight boom/Fence boom/
Folding boom 1According to your choice
Hexagonal Head
Tap Bolt M8×55mm 6For fixing the boom
Boom Press Board 1For fixing the boom
Self-tapping screw ST4×16 1For fixing the boom
Self-tapping screw ST3×10 4For fixing the boom
Supporting pole 1For supporting the boom
Expansion Bolt M16×150 4For fixing the case
Hexagonal Inner
Screw M8×35 4For fixing the case
Clutch Key 1For clutch device
Case Key 2For barrier gate case
and cove locking
Balance Spring According to length
of the arm 1For spare usage
Remote Emitter Less than 30M is available 1For remote controlling
Remote Controller Less than 30M is available 2For remote controlling
Instruction 1For reference
Rs485 transition
Interface 1Optional part
Disc 1Optional part
Communication
Module 1Optional part
Cover head 1
Expansion nut M8 4For fixing the supporting
pole
8) Common malfunctions and solutions
(1) Motor works but there is no reaction on the arm
a. Please check whether the clutch device is locked or
not.
(2) There is too much vibrant when the boom is rising or
falling.
a. Please check whether the shock absorption rubber is
broken or not, if yes, change a new one.
b. Please check whether the balance spring is overused
and distorted. If yes, change a new one; or spin
bottom adjust nut.
(3) The boom could not rise up or fall down to the end.
a. When change a long boom to a short one, please
readjust it.
b.The sensor dose not plug well, please check it.
c. The "Speed adjust switch" is wrong adjust, please
readjust it.
(4) The distance of the remote control decreases.
a. Check whether the charge capacity of the remote
controller is enough or not.
(5) There is no reaction when pressing the remote controller
buttons.
a. Please check whether the power is supplied to the
barrier gate or not.
b. Please check whether the fuse is burnt out or not.
c. Please check whether the code both in the remote
controller and the control board are accordant or not.
(6) There is no reaction on the motor when the user
changes a control board.
a. Please check the capacitance is correctly fixed or not.
b. Please check the sensor is right inserted or not.
(7) If the user changes a new control board and the boom is abnormal
when rising and falling.
a. Please adjust the "Gate Type Selection"(Refer to the control board).
9) Packing list

18 19
10) Service items
(1) One year's free servicing is supplied(not including the arm);
(2) Lifetime charged servicing is offered.
(3) Technology servicing is supplied.
The following situations are charged for servicing(or changing):
(1) Broken by wrong installation.
(2) Broken by improper voltage.
(3) The surfaces of the system destroyed by wrong installation or use.
(4) Broken by natural disaster.
(5) Overdue.
(6) Servicing items out of our promises.
The upgrade and improvement of the product won't be
Left side
2) Installation of the infrared photocell
Photo test(Fig.13)
Emitter
Top
Right side
Bottom
notified if there is any.
The explaining authority of this product instruction and
service article belongs to the production factory.
Appendix
Receiver
1) Remote control code instruction and figure
If the remote control code does not match the one on the remote
controller and the infrared photo cell, please adjust it as below:
There is a control code table pasted on the back of the remote
controller and the transformer of the radio controller for coding.
Open the controller cover, take out the battery. There is a code
pad on the PCB, the direction is from right to left, and the first code
is on the right.
"0" stands for linking the middle and the top, "1" stands for linking
the middle and the bottom, "X" stands for empty. The following
Receiver
3) Adjustment of the limit switch
Emitter
code is: 01XX1X0X
(1) The blue laser obstacle on the spindle near the clutch is the laser
obstacle to stop the boom after it stands straight:
When the boom is at the falling limit position, adjust this laser to
make it point downwards and form an angle (≦90°) with the arm.
When the laser obstacle moves into the slot and the green light is
on, the rising limit will work and the boom will stand straight. Check
the vertical angle between the boom and the horizontal position and
adjust.

the laser obstacle, so as to make the boom be perfectly vertical.
(2) The blue laser obstacle on the spindle near the boom is the laser
obstacle to stop the boom after it lies horizontally:
When the boom is at the rising limit position, adjust this laser
obstacle to make it point upwards and form an angle (90°) with the
arm. When the laser obstacle moves into the slot and the red light is
on, the falling limit will work and the boom will lie horizontally. Check
the horizontal angle between the boom and the horizontal position and
adjust the laser obstacle, to make the boom be perfectly horizontal.
20
