Element ELE1X808N User manual

SPLITTER
ELE1X808N
1x8 HDMI Splitter
INSTALLATION MANUAL

INTRODUCTION
Dear customer,
Thank you for purchasing this product. For optimum performance and safety, please read
these instructions carefully before connecting, operating, or adjusting this product. Please
keep this manual for future reference.
Our series of HDMI converters, switches, extenders, matrixes, and splitters are designed to
make using your A/V device more convenient, more comfortable, more productive, and more
cost-efficient.
The ELE1X808N HDMI Splitter uses a single HDMI source output to project to eight HDMI
input devices. The Splitter allows one HDMI device to be converted easily into eight HDMI
monitors or projectors.
It supports Full HD, 3D, and regenerates the HDMI signal for long runs.
It offers solutions for noise, space and security concerns, data center control, information
distribution, conference room presentation, school, and corporate training environments.
Features
 One HDMI 1.4a input signal splits to eight HDMI 1.4a output signals
 Supports Full HD & 3D
 Supports 4K*2K resolution
 Supports CEC
 Supports Deep Color 30-bit, 36-bit, 48-bit
 Supports BlueRay 24/50/60fs/HD-DVD/xvYCC
 Digital Audio Format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD/HD
 Supports Signal Retiming
 Supports input up to 15m and output up to 20m AWG26 HDMI Standard cable length
 No loss of quality
 Installs in minutes
 Need DC5V/2A power supply
2

Package Contents
 ELE1X808N (x1)
 Installation Manual (x1)
 +12V DC Power Adapter (x1)
Specifications
 HDMI Version: HDMI 1.4a
 HDMI Resolution: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
 Supports Video Format: 24-bit/Deep Color 30-bit, 36-bit, 48-bit
 Supports Audio Format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD
 Max Bandwidth: 340 MHz
 Max Baud Rate: 10.2 Gbps
 Input/Output TMDS Signal: 0.5~1.5 Volts p-p (TTL)
 Input/Output DDC Signal: 5 Volts p-p (TTL)
 Input Cable Distance: ≤15m AWG26 HDMI Standard Cable
 Output Cable Distance: ≤20m AWG26 HDMI Standard Cable
 Max Working Current: 2A
 Power Adapter Format (Input): AC (50-60Hz) 100V-240V
 Power Adapter Format (Output): DC 12V/3A
 Operating Temperature Range: (-15° to +55°C)
 Operating Humidity Range: 5 to 90%RH (No Condensation)
 Dimension (LxWxH): 280mm x 138mm x 25mm
 Weight: 871g
3

INPUT/OUTPUT PANELS
Front Side
LED panel
 Output LEDs
 Input LED
 Power Switch LED
 Reset Button
Back Side
Connection panel
 DC 12V Power Supply
 8 HDMI Outputs
 1 HDMI Input
Connections & Operation
Installation
 Connect HDMI cable from HDMI source into ELE1X808N HDMI Splitter input
 Connect one HDMI cable from each display (monitor or projector) into the ELE1X808N
HDMI Splitter outputs
 Connect 12V Power Supply to the ELE1X808N HDMI Splitter
4

NOTICE
Performance Guidelines
 Be sure to use the product as directed to maximize the performance quality and the
operational lifetime of your hardware.
 Be sure to place the device in a suitable environment. Do NOT place in damp, dusty,
erosive, or oxidative areas. Keep out of high-temperature locations as well as any other
extreme conditions.
 Be sure the hardware is safe and secure. Do NOT install in areas exposed to heavy
motion or places that put the hardware at risk of falling.
 Do NOT touch the power adapter with wet hands.
 Do NOT pull on the power supply cord under any circumstance.
 Be sure to turn the power off when not in use.
 Do NOT open hardware, remove cover, or touch any parts within the device.
 For best result, be sure to use the factory supplied power adapter.
 Before powering on, be sure to check the connections carefully for accuracy.
Troubleshooting
 No Power...First, double check the connections at both ends of the power supply. Also,
be sure the power switch is in the on position.
 No Picture...First, make sure the display is powered on and that the devices are properly
connected. Then, confirm the status of the source device is powered on and transmitting
signal. If the problem persists, check the signal quality at each connection by testing
each cable and each connection in the signal path. (NOTE: Cables should be HDMI V1.3
compliant.)
 Obscure Picture...First, try re-connecting the each cable to eliminate any poor connec-
tions. If the problem persists, check the signal quality at each connection by testing
each cable and each connection in the signal path. (NOTE: Cables should be HDMI V1.3
compliant.)
5
