Elements LUME-29R User manual

DO NOT DISCARD. THIS INSTALLATION INSTRUCTIONS HAS
IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS. LEAVE WITH THE
HOMEOWNER.
MODEL:
SERIAL #:
LUME-29R
LUME-34R
LUME-36R
LUME is a 100% Stainless Steel drop-in smokeless wood-burning fire pit, specially
designed to burn more efficiently and emit less smoke. The LUME comes in three sizes
and can easily be installed in a paver system by simply fastening the two bases of the
pit and the heavy-duty single rim together, and then dropping the unit in over the
retaining wall. Stack wood at the open base of the pit using the log cabin technique,
light it, and then allow a few minutes for the fuels to ignite properly. Within minutes
enjoy the warmth, ambiance, and comfort of the Smokeless Fire Pit.
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS,
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE.
WARNING: Fuels used in wood-burning appliances, and the products of combustion of
such fuels, can expose you to chemicals including carbon black, which is known to the
state of California to cause birth defects or other reproductive harm. For more
information go to www.p65Warnings.ca.gov
WARNING: FOR OUTDOOR USE ONLY
WARNING: Do not leave unattended during use.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage, personal injury, or loss of life. Read the installation
instructions provided with this appliance.
1

Smokeless Fire
Pit
PATENT PENDING
LUME-29R
LUME-34R
LUME-36R
Dimensions 29R 34R 36R
Rim Outer
Diameter (A)
34” 39” 41”
Rim Inner
Diameter (B)
26” 31” 34”
Height (C) 12” 12” 12”
Base Outer
Diameter (D)
29” 34” 36”
Weight 21 lbs 25 lbs 26 lbs
Fits Openings 29 ½” - 32” 34 ½” - 37” 36 ½” - 39”
Material: 100% Commercial Grade Stainless Steel
2

ITEM NO. PART # DESCRIPTION QTY.
1 80521 WELDMENT, TOP PLATE, SINGLE WALL 1
2 80597 WELDMENT, HALF DRUM, SINGLE WALL 2
3 10865 BOLT, ¼-20 X ½”, 18-8 SS, HEX HEAD 8
4 10864 LOCKNUT, FLANGED, ¼”-20, SERRATED 8
5 10794 BOLT, ¼”-20 X 2” 18-8 SS HEX HEAD 2
3

Clearance to Combustibles (Not to be used in an enclosed space)
This fire pit is designed for outdoor use only. Not approved for any indoor use. The
NES should NEVER be used in a building, garage, or any other enclosed area. Avoid
using near or under overhanging trees and shrubs.
CAUTION: Due to the Stainless Steel construction of the Lume, there is potential for
sharp edges. It is recommended to use gloves for installation.
Install the fire features on any level, flat, stable, non-combustible surface. NOTE: Do not
place Fire Pit directly on grass, dirt, or rocks as this may prevent proper ventilation.
Paver height 14”.
Fill the bottom of fire pit 1” with gravel or sand from the bottom of the fire pit to the
bottom of the stainless steel insert.
Vents are required for any solid concrete fire pit.
SRW (Segmented Retaining Wall) does not require vents and are optional as long as
they are not cemented together, but are recommended for best performance. Ventilation
can be accomplished by cutting an inch off of the width of 3 wall stones and space
symmetrically around the perimeter at the elevation of the bottom of the LUME insert. A
no-cut option is the use of a PAVER-VENT4LNTS or PAVER-VENT6LNTS depending
on the height of the wall stone used.
Stone or sand must be installed to be even with the bottom of stainless steel insert.
SUGGESTED FUEL
Selecting the right wood will depend on preference for comfort, aroma, and visual
image. If you want constant heat output and a short flame with glowing coals,
hardwood such as hickory, oak, or beech are recommended.
If short hot fire for damp weather, select a softer wood such as redwood, fir, or white pine.
4

TYPE OF WOOD DESCRIPTION OF WOOD
OAK Very desne, Hot burning, Should season at
least once a year.
MAPLE Difficult to split, efficient, hot burning, Should
season at least once a year.
CHERRY Burns at medium heat, sweet burning aroma,
sparks a lot - doesn't produce lots of smoke.
BIRCH Burns very quickly, bright - hot burning, good
firestarter.
PINE High sap content, burns messy, don’t use as
exclusive firewood.
ELM Very dense - hard wood, difficult to split,
doesnt smell great as it burns.
CHESTNUT Burns and splits easily, burns at a low heat,
sparks alot, heavy smoke.
*For best results, do not overfill the fire pit with logs that cover or extend above the top
air holes.
MAINTENANCE
Clean out ashes every 2-3 Burns or when ash covers lower holes to maintain airflow for a
smokeless fire.
When you are finished enjoying your fire, do not extinguish the fire with water. Let the fire
extinguish on its own.
During winter months in cold climates and various seasons of operation, the fire feature
may be affected by weather conditions. It is recommended to use a cover/lid over top of
your fire pit opening to protect it from humid/rainy weather conditions when not in use.
Heavy rains/downpours can affect the operation of the fire pit if not covered.
5

Stainless steel materials used in the construction of your LUME are highly rust-
resistant, however, chlorine in the air from swimming pools or the salt from sea air may
cause rust to appear and even create some pitting if left on the product.
Cleaning the Stainless Steel
In extreme environments apply a rust inhibitor which leaves a microscopic protective
layer on the unit.
REQUIREMENTS
1. These fire features are designed for outdoor use only. Not approved for any
indoor use. The fire pit should NEVER be used in a building, garage, or any other
enclosed area. Avoid using near or under overhanging trees and shrubs.
2. Never leave any other combustible material on the fire feature. This could
cause unsafe operation and damage the component that will not be covered
under our warranty.
3. To Maintain appropriate airflow, clean out ashes every 2-3 burns or when ash
covers lower holes.
SAFETY WARNINGS
1. Never leave the Fire Pit unattended during operation.
2. Clothing or other flammable materials should be placed on or near the
appliance.
3. Due to the Stainless Steel construction of the fire pit, there is potential for
sharp edges. It is recommended to use gloves for installation.
4. The fire pit is designed for outdoor use only. Not approved for any indoor use
or enclosed areas.
5. Improper installation, adjustment, alteration, service, or maintenance may
result in property damage, injury, or death.
6. The fire pit was designed for wood fuel – using other fuels is not
recommended and may produce more smoke as the design will not function
properly.
7. After a period of non-use, check the unit for signs of damage or buildup.
8. The use of a spark screen is required by most states to reduce the number of
embers leaving the fire pit while in use.
6

WARNING: This appliance is HOT when operated and can cause severe burns if
contacted. Use Protective gear such as oven gloves or pot holders when in contact.
SEQUENCE OF OPERATION
Choosing Fuel - Dry, seasoned, split hardwoods cut to less than 24” in length. 16-18”
being the optimal length.
Recommended wood placement - For best performance firewood should be
concentrated to the outer edges of the fire pit and over a bed of coals.
Lighting - Kindling stacked around crumpled newspaper is an easy method for a 1
match fire. Once the kindling is burning slowly add increasingly larger diameter pieces
of wood.
Feeding flames - When adding logs to the fire as it burns down there will be additional
smoke.
Burn out - Allow fire to burn out on its own. Avoid snuffing with the lid or extinguishing
with water.
DISCLAIMER: NES is a Smokeless wood burning fire pit. The term Smokeless means
reduced smoke as compared with a typical fire pit. The design allows it to be catalytic.
By introducing heated air to the top of the fire where it mixes with the unburned fuel
(smoke) and allows it to burn a second time. This process does take time to begin. It
relies on the outer walls being very hot to create convection to move the air. From the
ignition of your fire it will take between 15-30 minutes. You may see fire projecting from
the series of holes around the top.
7

FOR TECHNICAL SERVICE, CALL: [phone]
Belgard
400 Perimeter Center Terrace
Suite 1000
Atlanta, GA 30346
belgard.com/elements
Manual changes often occur, ensure to check the Belgard website for any recent
updates and warranty information.
STOP
Having problems installing the fire pit? Don’t leave the job site! We want to help. Call
[phone] for Technical Support & Limited Lifetime Warranty information between
the hours of 8:00 am to 5:00 pm.
BEFORE YOU CALL WE WILL NEED THIS INFORMATION
1. Model Number:
2. Serial Number:
3. Be prepared to send photos to us when on the phone.
4. Found missing or damaged parts? Let us know ASAP or send photos.
