Elesa DD52R-E-RF Instruction manual

Wireless spindle
positioning system
PREVIEW SPRING 2017

2
All rights reserved in accordance with the law. Always mention the source when reproducing our drawings and photos.
Efficient Machine Set-Up
The system saves time during the format alignment
process.
• Once the setup profile has been called up by the PLC,
the control unit UC-RF transmits the target position to
each DD52R-E-RF position indicator.
• The current / target position is displayed on the LCD
of the DD52R-E-RF.
• The operator manually sets the position of the
spindles following the arrow displayed on the LCD
(clockwise / counter clockwise rotation).
• Once all the spindles are correctly set, the UC-RF
control unit communicates to the PLC of the machine
that the setup has been completed.
The wireless system, made of the control unit UC-RF and up to 36 electronic position indicators DD52R-E-RF,
is designed for an efficient manual spindle positioning.
The position indicators DD52R-E-RF (Elesa Patent) are networked to the control unit UC-RF by radio frequency (RF)
connection, so that connecting cables are not required for an easy and quick installation.
Current and target positions are transmitted by RF from and to the control unit, facilitating machine set up.
Wireless Connection
Up to 36 position indicators can be networked (by radio
frequency) to the control unit.
No cables required to connect the position indicators to
the control unit.
Checking
Fast and efficient electronic check of manual spindle
positions.
Safety
The system prevents the start of the machine until the
set-up has been completed, so as not to result in a loss
of production.
Wireless spindle
positioning system
Target positions
Current positions
Up to 36
PLC

DD52R-E-RF UC-RF
STAINLESS
STEEL
INOX
RoHS PA PA-T
+50°
0°IP65 IP67 RoHS PC ABS
+50°
0°
3
All rights reserved in accordance with the law. Always mention the source when reproducing our drawings and photos.
Orange or grey colour.
LCD display with values visualization in units of measure
(mm, inches or degrees).
Absolute or incremental mode. Reading orientation.
The visualization parameters can be set by the operator.
Protection class IP67 according to IEC 529.
Boss Ø 20H7 in AISI 304 stainless steel.
Self-extinguish technopolymer case.
Power supply 24V.
Two LED for status display
• Wide LCD 6-digits display showing current / target
positions
• Programmable parameters
• Battery life over 3 years
• Wireless RF network with up to 36 position indicators
• Compatible with DIN rails
• PLC Interfaces: RS232, RS485, Ethernet/IP, Profibus,
Modbus
Electronic position
indicators
Control unit for
DD52R-E-RF
