CAB 5314 User manual

MF
Made in Germany
Operator's Manual
5314 / 5316
Vacuum-Belt
Applicator

2 2
Family Type
Vacuum-Belt Applicator 5314
5316
Edition: 10/2017 - Part No. 9009884
Copyright
This documentation as well as translation hereof are property of cab Produkttechnik GmbH & Co. KG.
The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original
intended purpose demand the previous written authorization by cab.
Editor
Regarding questions or comments please contact cab Produkttechnik GmbH & Co. KG.
Topicality
Due to the constant further development of our products discrepancies between documentation and product can occur.
Please check www.cab.de for the latest update.
Terms and conditions
Deliveries and performances are effected under the General conditions of sale of cab.
Operator's Manual
for the following products
Germany
cab Produkttechnik
GmbH & Co KG
Postfach 1904
D-76007 Karlsruhe
Wilhelm-Schickard-Str. 14
D-76131 Karlsruhe
Telefon [phone]
Telefax [phone]
www.cab.de
[email protected]
France
cab technologies s.a.r.l.
F-67350 Niedermodern
Téléphone [phone]
www.cab.de/fr
[email protected]
USA
cab Technology Inc.
Tyngsboro MA, 01879
Phone [phone]
www.cab.de/us
[email protected]
Asia
cab Technology Co., Ltd.
Junghe, Taipei, Taiwan
Phone [phone]
www.cab.de/tw
[email protected]
China
cab (Shanghai)Trading Co., Ltd.
Phone [phone]
www.cab.de/cn
[email protected]
Representatives in other countries on request

2
3
Table of Contents
1 Introduction............................................................................................................................................4
1.1 Instructions...............................................................................................................................................4
1.2 Intended Use............................................................................................................................................4
1.3 Safety Instructions....................................................................................................................................4
1.4 Safety Markings .......................................................................................................................................5
1.5 Environment.............................................................................................................................................5
2 Product Description...............................................................................................................................6
2.1 Important Features...................................................................................................................................6
2.3 Technical Data..........................................................................................................................................6
2.4 Overview..................................................................................................................................................7
2.5 Contents of Delivery.................................................................................................................................8
3 Operation................................................................................................................................................9
3.1 Standard Operation..................................................................................................................................9
3.2 Cleaning...................................................................................................................................................9
3.3 Mounting ................................................................................................................................................10
3.4 Power Supply of the Devices..................................................................................................................11
3.5 Start Signal via External Sensor .............................................................................................................11
3.6 Mounting & dismounting the Applicator..................................................................................................12
4 Adjustments .........................................................................................................................................13
4.1 Setting the Angle to the Printer ..............................................................................................................13
4.2 Adjusting the Setup of the Printer ..........................................................................................................13
4.3 Signals ...................................................................................................................................................14
5 Error Messages....................................................................................................................................15
5.1 Error Messages of the Printer................................................................................................................15
5.2 Error Messages of the Applicator...........................................................................................................15
6 Licences................................................................................................................................................16
6.1 Declaration of Incorporation...................................................................................................................16
6.2 EU Declaration of Conformity.................................................................................................................17

4 4
1 Introduction
1.1 Instructions
Important information and instructions in this documentation are designated as follows:
Danger!
Draws attention to an exceptionally great, imminent danger to your health or life due to hazardous
voltages.
!
Danger!
Draws attention to a danger with high risk which, if not avoided, may result in death or serious injury.
!
Warning!
Draws attention to a danger with medium risk which, if not avoided, may result in death or serious injury.
!
Caution!
Draws attention to a danger with low risk which, if not avoided, may result in minor or moderate injury.
!
Attention!
Draws attention to potential risks of property damage or loss of quality.
i
Note!
Advice to make work routine easier or on important steps to be carried out.



Environment!
Gives you tips on protecting the environment.
Handling instruction
Reference to section, position, illustration number or document.
Option (accessories, peripheral equipment, special ttings).
Time Information in the display.
1.2 Intended Use
• The device is manufactured in accordance with the current technological status and the recognized safety rules.
However, danger to life and limb of the user or third parties and/or damage to the device and other tangible assets
can arise during use.
• The device may only be used for its intended purpose and if it is in perfect working order, and it must be used with
regard to safety and dangers as stated in the operating manual.
• The device applicator mounted on a cab printer of the Hermes+ series is intended exclusively for applying suitable
materials that have been approved by the manufacturer. Any other use or use going beyond this shall be regarded
as improper use. The manufacturer/supplier shall not be liable for damage resulting from unauthorized use; the
user shall bear the risk alone.
• Usage for the intended purpose also includes complying with the operating manual, including the manufacturer‘s
maintenance recommendations and specications.
i
Note!
The complete and current version of the documentation can be found in the Internet.
1.3 Safety Instructions
!
Attention!
Initiation, adjustments and changing of parts are to be performed by qualied service personnel only.
!
Warning!
This is a class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.

4
5
1 Introduction
• Before mounting the delivered components disconnect the printer from the power supply and close the shutoff
valve of the applicator.
• Only connect the device to other devices which have a protective low voltage.
• Switch off all affected devices (computer, printer, accessories) before connecting or disconnecting.
• In operation, moving parts are easily accessible.
This applies especially for the zone, where the pad is moved between the starting and the labelling position.
During operation do not reach into that zone and keep long hair, loose clothes, and jewelry distant. Before any
manipulations in those areas, close the shutoff valve.
• The device may only be used in a dry environment, do not expose it to moisture (sprays of water, mists, etc.).
• Do not use the device in an explosive atmosphere.
• Do not use the device close to high-voltage power lines.
• Perform only those actions described in this operating manual.
Work going beyond this may only be performed by trained personnel or service technicians.
• Unauthorized interference with electronic modules or their software can cause malfunctions.
• Other unauthorized work on or modications to the device can also endanger operational safety.
• Always have service work done in a qualied workshop, where the personnel have the technical knowledge and
tools required to do the necessary work.
• There are various warning stickers on the device. They draw your attention to dangers. Warning stickers must
therefore not be removed, as then you and other people cannot be aware of dangers and may be injured.
1.4 Safety Markings
233
with demounted cover
1
1: Danger of electrocution! 2: Warning of damage by rotating parts!
3: Danger of crushing of hands and/
or ngers by the swing motion of the
applicator!
Fig.1 Safety marking
1.5 Environment



Obsolete devices contain valuable recyclable materials that should be sent for recycling.
Send to suitable collection points, separately from residual waste.
The modular construction of the applicator enables it to be easily disassembled into its component parts.
Send the parts for recycling.
!
Attention!
Never remove or cover safety
markings!
Replace them in case of
damage!

6 6
2 Product Description
2.1 Important Features
• Use the I/O interface of the printer for operation within a system.
2.2 Technical Data
1)
The product speed must be higher than the vacuum belt speed.
2)
Calculated at label height 100 mm / print speed 250 mm/s
Technical data Vacuum belt applicator
5314-3 5316-3
Labeling on the surface on the surface
Label width mm 20-114 46-174
Label height mm 60-356 60-356
Product during labeling in motion  
Labeling on the product from top
from below
from the side
 
 
 
Product distance steady  
Product height steady steady
Product speed max. m/s 0,5 0,5
Distance between one product and the next min. m 1,0 1,0
Vacuum belt speed1) mm/s 100-500 100-500
Length mm 390 390
Cycle time2) max. labels/min 30 30
Label distance to conveyor belt
when labeling from the side Y min. mm 20 20
Table 1 Technical Data

6
7
2.3 Overview 3
6 7 9
4
11 12
15
13108
2
Fig.2 Device overview
1 Power switch applicator
2 3-pin female connector for a start sensor
3 Power cable (Voltage) to the printer
4 SUB-D 15 Interface to the printer
5 Power module
6 Pressure roller
7 Sensor
8 Fans
9 Screws to adjust the angle of the applicator
10 Control unit
11 Locking pin
12 Base plate for mounting on printer
13 Screw roller changing (pressure)
2 Product Description

8 8
2 Product Description
2.4 Contents of Delivery
3
4
1
2
Fig.3 Contents of delivery
- Applicator mounted (1)
- Base Plate to mount to the printer (2)
- Cable-clip self-adhesive 4x (3)
- Screws to mount on the printer (4)
- Documentation
2.5
i
Note!
Please keep the original packaging in case the applicator must be returned.
!
Attention!
The device and printing materials will be damaged by moisture and wetness.
Only set up label printer with applicator in dry locations protected from moisture and splashes.

8
9
3 Operation
3.1 Standard Operation
Check all external connections.
Load the material. Ensure that the locking system is locked "Operator's Manual" of the printer.
Switch on the printer.
Press the feed key on the printer.
A synchronization feed is released. The processed labels have to be removed manually. After a few seconds the
printer carries out a short backfeed to position the front edge of the next label at the printing line.
i
Note!
The synchronization also has to be carried out when the print job has been interrupted with the cancel key.
Synchronizing is not necessary when the print head was not lifted between print jobs. This also applies if
the printer was powered down between print jobs.
Start a print job.
Start the labelling process via PLC interface.
Error messages during labelling process are shown in the display of the printer Error Messages.
3.2 Cleaning
!
Attention!
Never use solvent and abrasive.
1 2 3 4
1: Clean the pressure roller with multi
purpose cleaner.
2: Use glass cleaner to clean the reex
sensor.
3: Clean the fan area with a soft brush
and/or a vacuum cleaner.
4: Clean the outside surfaces and
transport belts with a multi purpose
cleaner.
Fig.4 Cleaning

10 10
3 Operation
3.3 Mounting
5 6 7 8 10
12 1311
9
1 2
3 4
Fig.5 Mounting
To clean the applicator and printer it's sometimes necessary to turn away or even dismount the applicator from the
printer.
Do not adjust the setting screws, throttle valves or other alignment elements. This will enable use of the applicator
directly after cleaning.
1 Pull out the locking bolt (3) and put the base plate (2) into the opening (1).
2 Let the locking bolt (3) snap into the holes (4).
3 It may be necessary to lay the printer on its side or back to gain access to the bottom of it.
4 Put the hole of mounting plate (9) over the pin (3).
5 Connect SUB-D 9 male connector (8) to the female connector (6) of the printer.
6 Swing the applicator to the printer and turn in the screw (10) loosely.
7 The holes in the mounting plate (13) must be aligned to the holes in the printer base plate (11).
8 Place the screws (12) and tightening them.
9 Tighten screw (10).
!
Attention!
Initiation, adjustments and changing of parts is to be performed by qualied service personnel only.
Initiation/Service Manual Applicator
!
Attention!
Disconnect the printer and applicator from the power supply before mounting the applicator!
Ensure the printer is in a stable position!
