Eliminator Lighting Furious Three RG User manual

Furious Three RGFurious Three RG
User Manual
SKU#: FUR128
UPC#: 818651029314

©2021 Eliminator Lighting all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. Eliminator logo and identifying product
names and numbers herein are trademarks of Eliminator Lighting. Copyright protection claimed in-
cludes all forms and matters of copyrightable materials and information now allowed by statutory or
judicial law or hereinafter granted. Product names used in this document may be trademarks or reg-
istered trademarks of their respective companies and are hereby acknowledged. All non-Eliminator
brands and product names are trademarks or registered trademarks of their respective companies.
Eliminator Lighting and all aliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/
or as a result of the improper, unsafe, insucient and negligent assembly, installation, rigging, and
operation of this product.
Eliminator Lighting USA
6122 S. Eastern Ave. | Los Angeles, CA 90040 USA
Tel: [phone] | Fax: [phone] | www.eliminatorlighting.com | [email protected]
DOCUMENT VERSION
An updated version of this document may be available online.
Please check www.eliminatorlighting.com for the latest revision/update of this docu-
ment before beginning installation and use.
2
Date Document
Version
Software
Version DMX Channels Notes
04/20/2021 1.0 1.0 9 Channels Initial Release

CONTENTS
General Information 4
Limited Warranty (USA Only) 5
Safety Guidelines 6
Laser Warnings and Safety 8
Maintenance Guidelines 10
DMX Setup 11
Overview 14
Installation Instructions 15
System Menu 17
DMX Traits 19
Dimensional Drawing 23
Specications 24
3

GENERAL INFORMATION
INTRODUCTION
Please read and understand all instructions in this manual carefully and thoroughly before attempting
to operate this product. These instructions contain important safety and use information.
UNPACKING: This product has been thoroughly tested and has been shipped in perfect condition.
Carefully check the shipping carton for damage that may have occurred during shipping. If the car-
ton appears to be damaged, carefully inspect your product for damage and be sure all accessories
necessary to assemble the product have arrived intact. In the event that damage has been found
or parts are missing, please contact our customer support team for further instructions. Please do
not return this product to your dealer without rst contacting customer support at the number listed
below. Please do not discard the shipping carton in the trash. Please recycle whenever possible.
INCLUDED ITEMS
• Mounting Bracket (x1)
• Bracket Adjustment Knobs (x2)
• Power Cable (x1)
• Laser Safety Key (x1)
CUSTOMER SUPPORT
Tel: [phone] | Fax: [phone]
www.eliminatorlighting.com | [email protected]
WARRANTY RETURNS
All returned service items, whether under warranty or not, must be freight pre-paid and accompa-
nied by a return authorization (R.A.) number. The R.A. number must be clearly written on the outside
of the return package. A brief description of the problem as well as the R.A. number must also be
written down on a piece of paper and included in the shipping container. If the unit is under warranty,
you must provide a copy of your proof of purchase invoice. Items returned without an R.A. number
clearly marked on the outside of the package will be refused and returned at customer’s expense.
You may obtain an R.A. number by contacting customer support.
Warning! To prevent or reduce the risk of electrical shock or re, do not expose this unit to rain or
moisture.
Warning! This unit is capable of causing severe eye damage. Avoid looking directly into the laser
source and/or light source at all times!
Caution! There are no user serviceable parts inside this unit. Do not attempt to perform any repairs
yourself, as doing so will void your manufacturer’s warranty. In the unlikely event that your unit may
require service, please contact Eliminator Lighting. Eliminator Lighting will not accept any liability for
any resulting damages caused by the non-observance of information in this manual or any unauthor-
ized modications to this unit.
During operation, the housing may become extremely hot. Avoid touching the unit with bare hands
while in use.
4

LIMITED WARRANTY (USA ONLY)
A. Eliminator Lighting, an ADJ Products, LLC brand, hereby warrants, to the original purchaser, ADJ Products, LLC
products to be free of manufacturing defects in material and workmanship for a prescribed period from the date of
purchase (see specic warranty period listed below). This warranty shall be valid only if the product is purchased
within the United States of America, including possessions and territories. It is the owner’s responsibility to estab-
lish the date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the product,
please contact ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the ADJ Prod-
ucts, LLC factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts re-
placement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a des-
ignated point within the United States. If the entire instrument is sent, it must be shipped in its original package. No
accessories should be shipped with the product. If any accessories are shipped with the product, ADJ Products,
LLC shall have no liability whatsoever for loss of or damage to any such accessories, or for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modied in any manner
which ADJ Products, LLC concludes, after inspection, aects the reliability of the product; if the product has been
repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior written authorization was
issued to purchaser by ADJ Products, LLC; if the product is damaged because not properly maintained as set forth
in the instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning or periodic check-up.
During the period specied above, ADJ Products, LLC will replace defective parts at its expense with new or refur-
bished parts, and will absorb all expenses for warranty service and repair labor by reason of defects in material or
workmanship. The sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the
product, or replacement thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered
by this warranty were manufactured after August 15, 2012, and bear identifying marks to that eect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products with-
out any obligation to include these changes in any products theretofore manufactured. No warranty, whether
expressed or implied, is given or made with respect to any accessory supplied with products described above.
Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC in connection
with this product, including warranties of merchantability or tness, are limited in duration to the warranty period
set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or t-
ness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be
such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC
be liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to Eliminator Lighting, an ADJ Products, LLC brand, and su-
persedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
All Eliminator Lighting products (except laser diodes) = 1-year (365 days) Limited Warranty (Such as: Special
Eect Lighting, Intelligent Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans,
Trussing, Lighting Stands etc., excluding lamps)
Laser Products = 1 Year (365 Days) Limited Warranty (excluding laser diodes which have a 6 month limited war-
ranty)
Batteries = 180 Day Limited Warranty
To register your Eliminator Lighting product online, please click here to the ADJ Warranty Registration Page:
https://www.adj.com/portal/user/register/
5

SAFETY GUIDELINES
THERE ARE NO USER SERVICEABLE PARTS INSIDE THESE DEVICES. DO NOT
ATTEMPT ANY REPAIRS YOURSELF; DOING SO WILL VOID YOUR MANUFAC-
TURER’S WARRANTY. DAMAGES RESULTING FROM MODIFICATIONS TO THESE
DEVICES AND/OR THE DISREGARD OF SAFETY INSTRUCTIONS AND GUIDE-
LINES IN THIS MANUAL VOID THE MANUFACTURER’S WARRANTY AND ARE
NOT SUBJECT TO ANY WARRANTY CLAIMS AND/OR REPAIRS.
NEVER TOUCH FIXTURE DURING OPERATION, AS IT MAY BE HOT!
ALWAYS REPLACE FUSES WITH REPLACEMENTS OF THE SAME TYPE!
KEEP FLAMMABLE MATERIALS AWAY FROM THESE DEVICES!
INDOOR / DRY LOCATIONS USE ONLY!
DO NOT EXPOSE DEVICES TO RAIN AND/OR MOISTURE!
NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE OR LASER!
RETINA INJURY RISK - MAY INDUCE BLINDNESS!
SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!
6

SAFETY GUIDELINES
This unit may “pop” the fuse if the maximum allotted load of 3 amps is reached.
• To reduce the risk of electrical shock or re, do not expose this unit rain or moisture.
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to remove or break o the ground prong from the electrical cord. This prong is
used to reduce the risk of electrical shock and re in case of an internal short.
• Do not attempt to operate this unit if the power cord has been frayed or broken.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user serviceable parts inside.
• Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6”
(15cm) between this device and a wall.
• Do not attempt to operate this unit if it has been damaged in any way.
• This unit is intended for indoor use only. Use of this product outdoors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power cords should be routed so they are not likely to be walked on, pinched by items placed
upon or against them.
• Cleaning - The xture should be cleaned only as recommended by the manufacturer. See the
Maintenance Guidelines section of this manual for cleaning details.
• Heat - The appliance should be situated away from heat sources such as radiators, heat regis-
ters, stoves, or other appliances (including ampliers) that produce heat.
• The xture should be serviced by qualied service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into, the unit.
C. The unit has been exposed to rain or water.
D. The unit does not appear to operate normally or exhibits a marked change in performance.
7

8
LASER WARNINGS AND SAFETY
After completing setup, and before public use, test the laser to ensure proper function. Do not use
if any defects are detected. Do not use if the laser emits only a few laser beams rather than dozens/
hundreds, as this could indicate damage to the diraction grating optic, and could allow emission of
laser intensity levels that exceed Class 3R.
• Do not point lasers at people or animals. Never look into the laser aperture or directly at laser
beams.
• Do not point lasers into areas which could create instances of unintentional or harmful exposure,
such as uncontrolled balconies, etc.
• Do not point lasers at highly reective surfaces, such as windows, mirrors, and shiny metal. Even
laser reections can be hazardous.
• Never point a laser at aircraft. This is a federal oense.
• Never point un-terminated laser beams into the sky.
• Do not expose the output optic (aperture) to cleaning chemicals.
• Do not use laser if the laser appears to be emitting only a few beams.
• Do not use the laser if the housing is damaged, the housing is open, or if the optics appear dam-
aged in any way.
• Never open the laser housing. The high laser power levels inside of the protective housing can
start res, burn skin, and will cause instantaneous eye injury.
• Never leave this device running unattended.
• The operation of a class 3R laser show is only allowed if the show is controlled by a skilled and
well-trained operator who is familiar with the information enclosed in this manual.
• The legal requirements for using laser entertainment products vary from country to country. The
user is responsible for determining the legal requirements at the location/country of use.
• Always use proper lighting safety cables when hanging lights and eects overhead.

9
LASER WARNINGS AND SAFETY

MAINTENANCE GUIDELINES
DISCONNECT POWER BEFORE PERFORMING ANY CLEANING OR
MAINTENANCE!
CLEANING
Frequent cleaning is recommended to ensure proper function, optimized light output, and an extend-
ed life. The frequency of cleaning depends on the environment in which the device operates: damp,
smoky, or particularly dirty environments can cause greater accumulation of dirt on the xture hous-
ing and/or light xture optics. Clean the external surface and the front lens of the device periodically
with a soft cloth to avoid dirt/debris accumulation
NEVER use alcohol, solvents, or ammonia-based cleaners.
MAINTENANCE
Regular inspections are recommended to ensure proper function and extended life. There are no
user serviceable parts inside these devices; please refer all other service issues to Eliminator Light-
ing. Should you need any spare parts, please order genuine parts from Eliminator Lighting.
Please refer to the following points during routine inspections:
• A detailed review should be performed by an approved electrical engineer every three months, to
make sure the circuit contacts are in good condition in order to prevent overheating.
• Be sure all screws and fasteners are securely tightened at all times. Loose screws may fall out
during normal operation, resulting in damage or injury as larger parts could fall.
• Check for any deformations on the unit. Deformations could allow for dust to enter into the
device, or cause the device to fall and seriously injure a person(s).
• Electric power supply cables must not show any damage, material fatigue, or sediments.
FUSE REPLACEMENT
This device features a replaceable fuse located alongside the Power Input on the back side of the
device. To access the fuse, use a at head screwdriver to catch the groove in the wall of the Power
Input. BE CAREFUL NOT TO DAMAGE THE FUSE CLIP, THE POWER INPUT, OR THE PRONGS.
When replacing the fuse, be sure to replace the correct one, as the fuse clip contains both an opera-
tional fuse and a spare fuse. Replace the fuse only with an identical F2A 250V fuse.
10

DMX SETUP
DMX-512: DMX is short for Digital Multiplex. This is a universal protocol used as a form of commu-
nication between intelligent xtures and controllers. A DMX controller sends DMX data instructions
from the controller to the xture. DMX data is sent as serial data that travels from xture to xture
via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX xtures (most controllers only
have a DATA “OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of dierent manufacturers to be
linked together and operate from a single controller, as long as all xtures and the controller are DMX
compliant. To ensure proper DMX data transmission, when using several DMX xtures try to use
the shortest cable path possible. The order in which xtures are connected in a DMX line does not
inuence the DMX addressing. For example, a xture assigned a DMX address of 1 may be placed
anywhere in a DMX line: at the beginning, at the end, or anywhere in the middle. When a xture is
assigned a DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that
unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation): This device can be controlled via
DMX-512 protocol. The DMX address is set using the display screen on the back of the device. Your
unit and your DMX controller require a standard 3-pin XLR connector for data input and data output
(Figure 1). We recommend Accu-Cable DMX cables. If you are making your own cables, be sure to
use standard 110-120 Ohm shielded cable (This cable may be purchased at almost all pro lighting
stores). Your cables should be made with a male XLR connector on one end and a female XLR con-
nector on the other. Also remember that DMX cable must be daisy chained and cannot be split.
11

12
DMX SETUP
Notice: Be sure to follow gures two and three when making your own cables. Do not use the
ground lug on the XLR connector. Do not connect the cable’s shield conductor to the ground lug or
allow the shield conductor to come into contact with the XLR cable’s outer casing. Grounding the
shield could cause a short circuit and erratic behavior.
Special Note: Line Termination. When longer runs of cable are used, you may need to use a termi-
nator on the last unit to avoid erratic behavior. A terminator is a 110-120 ohm 1/4 watt resistor which
is connected between pins 2 and 3 of a male XLR connector (DATA+ and DATA-). This unit is inserted
in the female XLR connector of the last unit in your daisy chain to terminate the line. Using a cable
terminator will decrease the chances of erratic behavior.
5-Pin XLR DMX Connectors. Some manufacturers use 5-pin DMX-512 data cables for DATA trans-
mission instead of 3-pin connectors. 5-pin DMX xtures may be implemented in a 3-pin DMX line.
When inserting standard 5-pin data cables in to a 3-pin line, a cable adaptor must be used. These
adaptors are readily available at most electronics stores. The chart below details a proper cable con-
version.

DMX SETUP
DMX ADDRESSING
All fixtures should be given a DMX starting address when operating with a DMX controller, in order to
ensure that the correct fixture responds to the correct control signal. This digital starting address is
the channel number from which the fixture starts to “listen” to the digital control signal sent out from
the DMX controller. This starting DMX address is assigned by setting the correct DMX address on
the digital control display on the fixture.
You can set the same starting address for all fixtures or a group of fixtures, or set different addresses
for each individual fixture. Setting all fixtures to the same DMX address will cause all fixtures to react
in the same way. In this case, please note that changing the settings of one channel will affect all the
fixtures simultaneously.
If you set each fixture to a different DMX address, each unit will start to “listen” to the channel num-
ber you have set, based on the quantity of DMX channels of each fixture. That means changing the
settings of one channel will only affect the selected fixture.
As an example, since this device has 9 DMX channels, you should set the starting DMX address of
the first unit to 1, the second unit to 10 (1 + 9), the third unit to 19 (1+ 9 + 9), and so on. (See the
chart below for more details.)
Channel Mode Unit 1 Address Unit 2 Address Unit 3 Address Unit 4 Address
9-Ch 1 10 19 28
13

OVERVIEW
1. Laser Aperture
2. Mounting Bracket
3. Bracket Adjustment Knobs (x2)
4. Sound Indicator
5. DMX Indicator
6. Display Screen
7. Auto Mode Indicator
8. Secondary Mode Indicator
9. Sound Sensitivity Adjustment
10.DMX Out
11.DMX In
12.Enter Button
13.Down Button
14.Up Button
15.Function Button
16.Laser Safety Switch
17.Fuse
18.Power In
19.Power Out
20.Safety Cable Loop
14

INSTALLATION INSTRUCTIONS
FLAMMABLE MATERIAL WARNING
Keep devices at least 5.0 feet (1.5m) away from ammable materials and/or pyrotech-
nics.
ELECTRICAL CONNECTIONS
A qualied electrician should be used for all electrical connections and/or installations.
DO NOT INSTALL THE DEVICE IF YOU ARE NOT QUALIFIED TO DO SO!
OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, INCLUDING CALCULATING
WORKING LOAD LIMITS, KNOWLEDGE OF INSTALLATION MATERIAL BEING USED, AND
PERIODIC SAFETY INSPECTION OF ALL INSTALLATION MATERIALS. IF YOU LACK THESE
QUALIFICATIONS, DO NOT ATTEMPT THE INSTALLATION YOURSELF. IMPROPER INSTALLA-
TION CAN RESULT IN BODILY INJURY.
BEFORE RIGGING/MOUNTING DEVICES TO ANY METAL TRUSS/STRUCTURE OR CEILING, A
PROFESSIONAL EQUIPMENT INSTALLER MUST BE CONSULTED TO DETERMINE WHETHER
THE METAL TRUSS/STRUCTURE OR CEILING IS PROPERLY CERTIFIED TO SAFELY HOLD
THE COMBINED WEIGHT OF THE LIGHT FIXTURE, CLAMPS, CABLES, AND ACCESSORIES.
BEFORE MOUNTING DEVICES TO ANY SURFACE OR STRUCTURE, MAKE SURE THE SUR-
FACE OR STRUCTURE CAN HOLD A MINIMUM POINT LOAD OF 10 TIMES THE WEIGHT OF
THE DEVICES.
MAKE SURE SCREWS AND/OR ANCHOR BOLTS (NOT INCLUDED) FIT INTO MOUNTING
HOLES!
FOR ADDED PROTECTION, MOUNT DEVICES OUTSIDE WALKING PATHS, SEATING AREAS,
OR AREAS WHERE UNAUTHORIZED PERSONNEL CAN REACH THE DEVICES.
SECURE FIXTURE WITH A SECONDARY SAFETY ATTACHMENT, SUCH AS AN APPROPRIATE
SAFETY CABLE. (NOT INCLUDED)
NEVER STAND DIRECTLY BELOW THE DEVICES WHEN MOUNTING, REMOVING OR SERVIC-
ING.
DEVICES MUST ALL BE INSTALLED FOLLOWING ALL LOCAL, NATIONAL, AND COUNTRY
COMMERICAL ELECTRICAL AND CONSTRUCTION CODES AND REGULATIONS.
15

INSTALLATION INSTRUCTIONS
CLAMP INSTALLATION
This xture features a mounting clamp attachment point, which is located on the mounting yoke, as
well as a safety cable rigging point, located on the rear face of the unit near the power connection
(see the illustration below). When mounting the xture to a truss or any other suspended or overhead
installation, be sure to secure an appropriately rated clamp (not included) to the clamp attachment
point and attach a separate SAFETY CABLE of the appropriate safety rating to the safety cable rig-
ging point.
SAFETY CABLE: ALWAYS ATTACH A SAFETY CABLE WHENEVER INSTALLING
THIS FIXTURE IN A SUSPENDED ENVIRONMENT TO ENSURE THAT THE FIX-
TURE WILL NOT FALL IF THE CLAMP FAILS.
RIGGING
Overhead rigging requires extensive experience, including but not limited to: calculating working
load limits, understanding the installation material being used, and periodic safety inspection of all
installation material and the xture itself. If you lack these qualications, do not attempt to perform
the installation yourself. Improper installation can result in bodily injury.
16

CONTROL PANEL
The device includes an easy to navigate system menu that can be accessed via a set of control but-
tons located on the back face of the device below the digital display.
FUNC: Press to cycle through main menu options (Auto, Sound, Secd, DMX).
ENTER: Press to conrm selection and open up the option sub-menu, if applicable.
UP/DOWN: Press to scroll through menu or sub-menu options.
SYSTEM MENU
17

SYSTEM MENU
18
Auto
Aut0: Laser + RGBWY +
8x1WLED
ENTER to conrm, then UP/DOWN to select display
speed.
S0 (fastest) to S100 (slowest).
Aut1: Laser + RGBWY
Aut2: Laser + 8x1WLED
Aut3: RGBWY + 8x1WLED
Aut4: RGBWY
Aut5: Laser
Aut6: 8x1WLED
Sound
Sou0: Laser + RGBWY +
8x1WLED
ENTER to conrm, then adjust sensitivity with Sound
Sensitivity Adjustment knob.
Sou1: Laser + RGBWY
Sou2: Laser + 8x1WLED
Sou3: RGBWY + 8x1WLED
Sou4: RGBWY
Sou5: Laser
Sou6: 8x1WLED
Secd
When selected, the unit will fol-
low the movements of a desig-
nated primary unit.
NOTE: A ashing display screen indicates a poor con-
nection to the primary unit. Please check the cable
connections.
DMX D001 - D506
NOTE: A ashing display screen indicates a poor
DMX connection. Please check the cable connec-
tions.

DMX TRAITS
19
Eliminator Furious Three RG - DMX Traits
Software Version 1.0
CHANNEL DMX VALUE DESCRIPTION
1
Mode
0 - 9 No Function
10 - 24 Aut0
25 - 39 Aut1
40 - 54 Aut2
55 - 69 Aut3
70 - 84 Aut4
85 - 99 Aut5
100 - 114 Aut6
115 - 129 Sou0
130 - 144 Sou1
145 - 159 Sou2
160 - 174 Sou3
175 - 189 Sou4
190 - 204 Sou5
205 - 220 Sou6
221 - 255 DMX Mode
2
LED Operation
0 - 9 No Function
10 - 14 Red
15 - 19 Green
20 - 24 Blue
25 - 29 Yellow
30 - 34 White
35 - 39 Red + White
40 - 44 Red + Green
45 - 49 Green + Blue
50 - 54 Blue + Yellow
55 - 59 Yellow + White
60 - 64 Green + White
65 - 69 Green + Yellow
CONTINUED ON NEXT PAGE

DMX TRAITS
20
Eliminator Furious Three RG - DMX Traits
Software Version 1.0
CHANNEL DMX VALUE DESCRIPTION
2
LED Operation (continued)
70 - 74 Red + Yellow
75 - 79 Red + Blue
80 - 84 Blue + White
85 - 89 Red + Green + Blue
90 - 94 Red + Green + Yellow
95 - 99 Red + Green + White
100 - 104 Red + Blue + Yellow
105 - 109 Red + Blue + White
110 - 114 Red + Yellow + White
115 - 119 Green + Blue + Yellow
120 - 124 Green + Blue + White
125 - 129 Green + Yellow + White
130 - 134 Blue + Yellow + White
135 - 139 Red + Green + Blue + Yellow
140 - 144 Red + Green + Blue + White
145 - 149 Green + Blue + White + Yellow
150 - 154 Red + Green + White + Yellow
155 - 159 Red + Blue + White + Yellow
160 - 164 Red + Green + Blue + Yellow + White
165 - 209 Automatic (single colors only)
210 - 255 Automatic (two colors at a time)
3 0 - 255 Automatic Speed, slow to fast (when CH2 is set to a DMX value
between 165 - 209)
4
LED Strobe
0 - 4 No Function
5 - 254 Strobe Speed, slow to fast
255 Sound-Activated Strobe Mode
CONTINUED ON NEXT PAGE
