Emit Bulk Tape Light Install Instructions
(Part #’s: TLB24KK-LLLLWL-8-XXX)
Safety/Installation Considerations
• Disconnect power before installing, adding or changing any component.
• To avoid a hazard to children, account for all parts and destroy all packing materials.
• Lights are not rated for damp or wet location installation.
• Note, this light is susceptible to damage by electrostatic discharge, use care when handling.
• For safety purposes, tape light installations must be used with a Class 2 power device.
• The tape light will come in a 108’ roll, but can only be installed to a maximum of 54’. Installing
lengths longer than 54’ could cause a re or electrical hazard, will affect the tape lights
performance and will void the warranty.
• Electrical Specs at 54’:
Input voltage: 24V DC| Max Wattage: 72W | Max Current: 3.0A
Operating Temp: -5ºC - 50ºC |Storage Temp: -40ºC - 70ºC
• Recommended for surface mount, cabinet or undercabinet applications.
• Caution: The mounting means provided with this tape light has not been tested in every install application. Specialty applications
where mounting failure could cause damage to people or property should use supplemental mounting methods.
For warranty information please visit www.itc-us.com
1. Determine the installation location and measure out the necessary length on your tape light. Cut between
the solder joint and LED. The tape light can be cut with scissors as shown below1. Failure to cut on these
intervals will damage the light.
PARTS / TOOLS NEEDED:
Bulk Tape Light Connectors (x2)
Mounting Channel
& #4 Flat Head Screws
(optional)
UL Class 2 Power Supply
(purchased separately)
Butt Splices
(not provided)
Alcohol Wipes
(not provided)
2. To make a proper connection, the paper backing and tape on the light should be removed before sliding
the light into the connector. Slide the light into the connector and screw the two screws down.
1. CUT HERE
TIGHTEN SCREWS

3030 Corporate Grove Dr • Hudsonville • MI • 49426
Phone: [phone] • www.itc-us.com • [email protected] • DOC#: 710-00179 Rev A • 02/24/21
*http://www.3m.com/3M/en_US/bonding-and-assembly-us/resources/full-story/?storyid=b3996cbd-9954-455f-8e72-88e452ca38c0
3. Before installing, clean the mounting surface (wood, plastic or metal) using alcohol wipes (not provided). For
more information on surface prep please review the 3M website*.
Adhesive Installation: Peel back the paper backing and press into place.
Channel Installation: Starting 3” from the end, screw the channel in place using #4 self-threading at head
screws (not provided) every 3”. Peel the paper backing off the tape light and press into channel.
*Ensure the positive and negative on one tape
light piece aligns to the positive and negative
on another tape light piece. Follow the wiring
diagram below.
4. Follow the wiring diagram below to wire the light to your system.
Tape Light
Red (+)
Black (-)
Green (G)
Class 2
Power Supply
Neutral (N)
Load (L)
Buildings Incoming
120V - 277V
Power
Positive (+)
Negative (-)
Connector
