Welcome...
InduraPower Intelligent Baery Series offers unmatched levels of starng
power, durability and reliability to consumers in the mobility markets, in
addion to a much smaller size and weight versus the compeon. Smart
Technology ulized in our baeries, “Puts the power of your baery in the
palm of your hand” through our interacve mobile app on the iOS and An-
droid plaorms.
Table of Contents Page
Serial Number........................................... 1
Baery Modes.......................................... 2
Baery Instrucons.................................. 3
Baery Module Modes............................. 4
LED Status Indicators................................ 5
Cold Temp Operaons.............................. 5
Smart Phone / Tablet App......................... 6
RMA / Return Info..................................... 8
Compliance and Warranty......................... 9

User Guide Page 1
Lithium iron phosphate
LiFe
PO
4
BATTERY
INTELLIGENT
Power
Intelligent Battery Series
Indura
Autos | Trucks | Motorcycles | ATVs | Boats
www.InduraPower.com
Baery Instrucons:
The system serial number must be entered as authencaon of baery ownership for
the inial connecon using the App. An authencaon pop-up will be displayed when
connecng to the baery.
Enter the system serial number scker listed under the barcode. Alternavely, select
the buon Scan Barcode to scan the barcode on the scker.
Move the camera screen pop-up over the barcode scker. When it detects the
barcode, the app will display a pop-up with the barcode number, press OK.
The barcode will be populated into
the serial number field on the
Authencaon screen. Press OK
to complete authencaon
process.
The system serial number only
needs to be entered the first me
the baery profile is connected to
the baery.
Place InduraPower Serial Number
scker here. Store this User Guide with
your vehicle owner’s manual
IMPORTANT
RETAIN THIS SERIAL #

User Guide
Page 2
Baery Modes:
The baery has a LED light on the top to indicate the current baery status such as
ON and OFF state, charge state, and provide feedback for baery condion. The LED
is located on the topside of baery (See Figures 1 and 2).
Storage Mode (OFF State):
In this mode baery terminals will not deliver power or consume energy. To set
baery in Storage mode or OFF state, place baery with (+) baery terminal down
and (-) terminal up. In this baery state, baery can be stored or shipped safely. It is
recommended to place baery in this mode when storing, shipping or not in use.
Normal Power Mode (ON State):
In this mode baery terminals will produce the required voltage and current to start
a vehicle. To set baery in Acve mode or ON state, place baery with (+) baery
terminal and (-) terminal up. Baery will remain in Acve Mode in any orientaon
other than storage mode orientaon and Bluetooth connecvity mode orientaon.
Bluetooth Connecvity:
To pair to a mobile device such as a mobile phone or a tablet this mode needs to be
enabled. If connecon to a mobile device is not desired, the mode should be
disabled to reduce baery unit power consumpon.
Heater ON:
Through a mobile app, the baery unit’s heater can be enabled to warm baery for
10 minutes or up to 30 degC.
Baery Modes (Connued):
Low Power:
Enabled through mobile app paired to baery unit only or enabled when baery voltage is
low (12V or less). This mode prevents excessive current discharging. When enabled, this
mode will prevent vehicle starng or drawing high currents.
Power Off:
Enabled through mobile unit paired to baery unit only through applicaon. In this mode
no power is available at the baery terminals (similar to disconnecng baery cables from
baery).
One Last Start:
Enabled through mobile unit paired to baery unit through applicaon only. When baery
is discharged below 12V, Low Power mode is automacally enabled to prevent excessive
current draw from the baery. Enabling this mode allows engine starng for 30 seconds
aer enabling.
Figure 2 - LED Indicator Lights
Series 108 Series 120 Series 220

User Guide Page 3
Baery Instrucons:
To Acvate Baery (Normal Power Mode):
1. Remove Baery from package and orient baery in OFF state (Figure 1).
2. When ready to use, rotate baery to posion topside of baery up (terminals
upward). The LED will flash GREEN for a few seconds to indicate ON state.
3. Baery is ready to use. The LED will alternavely flash between GREEN and
BLUE momentarily every 8 seconds while in Acve Mode if Bluetooth
connecvity mode is enabled. If Bluetooth Connecvity is disabled, LED will
flash alternavely between GREEN and YELLOW every 8 seconds.
To set in Storage Mode:
1. When baery is not in use, orient baery with (+) baery terminal down and (-)
terminal upward as shown in Figure 1. When posioned in OFF mode, LED will
flash WHITE 4 to 8 mes before turning off.
2. Baery is now in Storage mode (OFF state) with less than 1V Volt at terminals.
No flashing of LED will occur while in this mode.
To enable Bluetooth Connecvity mode:
Note: if LED flashes GREEN and BLUE alternavely, Bluetooth connecvity is already enabled.
1. Orient baery with (-) baery terminal down and (+) terminal upward. Opposite
as show in Figure 1, (-) terminal down, versus (+) terminal down.
2. Led will flash alternavely between GREEN and BLUE at a fast rate 4 mes then
BLUE LED will flash 4 mes rapidly to enable mode. May take up to 30 seconds.
3. Orient the baery back to normal mode (terminals upward). Unit will flash
alternavely between GREEN and BLUE for approximately 8 seconds.
Baery Instrucons (Connued):
To enable Bluetooth Connecvity mode:
Note: if LED flashes GREEN and BLUE alternavely, Bluetooth connecvity is already enabled.
4. Aer several GREEN flashes, a RED quick Flash, and again several GREEN Flashes,
unit will enabled for Bluetooth connecvity. Normal LED flashing in this mode will
alternang GREEN and BLUE flashes every 8 seconds or every 1 second when
connected to a mobile device.
To disable Bluetooth Connecvity mode:
Note: if LED flashes GREEN and YELLOW alternavely, Bluetooth connecvity is already disabled.
1. Orient baery with (-) baery terminal down and (+) terminal upward. Opposite
as show in Figure 1, (-) terminal down, versus (+) terminal down.
2. Led will alternavely flash between GREEN and YELLOW at a fast rate 4 mes
then YELLOW LED will flash 4 mes rapidly to enable the mode. May take 30 sec.
3. Orient the baery back to normal mode (terminals upward). Unit will
alternavely flash between GREEN and YELLOW for approximately 4 seconds.
4. Aer several GREEN flashes, a quick RED flash, and then again several GREEN
flashes, unit will enabled for Bluetooth connecvity. Normal LED flashing in this
mode will flash alternang between GREEN and YELLOW flashes every 1 second
at first then every 8 seconds aer 1 minute.
To Pair a Mobile Device:
1. Enable Bluetooth connecvity mode.
2. Use the InduraPower mobile applicaon to connect to unit
(See mobile app pairing instrucons below).

User Guide
Page 4
Baery Module Modes
Short Circuit Protecon:
The LED will light solid PURPLE for duraon of short circuing. Short Circuit mode will
terminate when short-circuing is removed at baery terminals. When short-circuit-
ing is removed, baery module LED will be will flash GREEN momentarily to indicate
reset of baery to normal mode.
Module Fault:
The LED will flash RED once every 5 seconds when fault occurs with baery (see
Under-Voltage Protecon and Over-Voltage Protecon secons).
Over-voltage Protecon:
This Mode is automacally set when baery voltage reaches 14.8V. When in this
mode, the contactor opens and rapid RED LED flashing will occur. Also, when in this
mode baery cannot be charged in acve mode orientaon because contactor is
open. The unit will automacally reset when charging is removed.
Under-voltage Protecon:
Mode is set automacally when baery voltage
discharges to below 12.0V. When in this mode,
LED will flash RED once every 5 seconds. To remove
baery from this mode, baery must be charged
(see One Last Start Mode below).
Baery Module Modes (Connued):
Power Off:
Mode seng only by Smartphone/tablet applicaon usage. In this mode, power
capabilies are disabled (similar to disconnecng baery from vehicle). See below in
Smartphone / Tablet Applicaon for Instrucons.
Short Circuit Protecon Disable:
This mode is automacally enabled when 4-16A discharge current (ignion key turn
ON) is sensed at baery and when baery temperature is 10degC (50degF) or less and
when baery voltage is 12.5V or less at temperatures above 10degC. This mode
disables short circuit protecon to enhance starng capabilies at cold temperatures
of 10degC or less or when baery is in a discharged state (12.5V or less). LED will be
solid RED when in this mode.
IMPORTANT: At any me when in this mode (Solid RED LED), avoid any short
circuing of baery- extra care is needed when handling baery when in
this mode. Short circuing without short circuit protecon may damage the
baery.

User Guide Page 5
LED Status Indicators:
Purple On Solid Connuous Short circuit exists
Green Blink Slow 1 rapid flash per second Engine is Off /
or 8 seconds; alternang Baery is idle
between GREEN and
YELLOW or BLUE
Green Blink Fast 8 rapid flashes per second Engine is On
Cyan Blink Fast 4 rapid flashes per second One last start
mode is in effect
Cyan Blink Slow 1 rapid flash per second Power OFF mode
is enabled
White Blink Med 3 rapid flashes per sec. for Baery is entering
3 sec. RED flash at end storage mode
Red Blink Slow 1 solid Flash every 1 sec. Over or under voltage
condion detected
Red On Solid Connuous Short circuit protecon
is disabled
Blue Blink Slow Aer enabled, rapid BLUE Bluetooth enabled
flash alternang with GREEN
flash every 1 sec, or 8 sec.
Yellow Blink Slow Aer disabled, rapid YELLOW Bluetooth enabled
flash alternang with GREEN
flash every 1 sec, or 8 sec.
Cold Temperature Baery Performance
Embedded baery heater:
Lithium-ion phosphate baeries perform at their best at temperatures between
85-140 degrees Fahrenheit. The cranking amps, charging efficiency and capacity are
maximized when baery cells are within this temperature range. InduraPower Baer-
ies ulize an embedded heater that warms the baery at approximately 10 to 15
degrees every ten minutes. The heater will automacally shut down aer 10 minutes
or when temperature reaches 86 degrees Fahrenheit
Starng vehicles in Extreme Cold Temperatures (below 15 degrees Fahrenheit)
Cold weather makes the engine hard to start for two main reasons. First, oil thickens
when it's cold, which increases fricon and makes it harder for the starter motor to
spin the engine. Cold also affects the car's baery starng power capabilies, reduc-
ing its cranking power output greater than 50% at temperatures less than 15 degrees
F. If a vehicle that has an InduraPower baery fails to start, the baery will warm up
automacally to improve the cranking power.
All InduraPower baeries have an internal heater that will be started when a failed
engine start is detected. The electronics in the baery have sensors that measure the
temperature and detect a failed start. If the temperature is below 32 degrees Fahren-
heit and a failed engine start is detected, the heater will be acvated and warm the
baery to improve the baery cranking power. Baery Cranking power is improved
by ~10% for every 20 degrees. At 15 degrees Fahrenheit, a lithium-ion baery has
~55% of its maximum cranking power.

User Guide Page 6
Cold Temperature Baery
Performance (Connued):
Procedure for starng vehicles In Cold Temperatures and vehicle fails to
start:
1. Wait 10 minutes and try again. The baery heater will automacally start
when the engine fails to start and will warm baery for 10 minutes.
2. Try and start the engine again. If engine fails to start wait another 10 minutes.
3. Repeat unl vehicle starts.
Using Baery Heater:
Note: The baery heater can be enabled using the mobile app without aempng
to start engine.
1. Use Mobile unit applicaon to acvate heater.
2. Heater will remain ON for a maximum of 10 minutes duraon.
Ulizing One Last Start Mode:
Note: One Last Start mode is used when baery is discharged and is in Under-Volt-
age Protecon mode.
1. Acvate One Last Start mode by enabling through paired mobile device.
2. Aempt to start vehicle within 30 seconds of One Last Start mode acvaon. If
vehicle fails to start in One Last Start mode, baery needs to be recharged.
Smartphone / Tablet Applicaon:
The mobile applicaon telemetry page allows for monitoring of baery and some
remote control of power output of the baery.
Monitoring of baery:
1. Baery Internal Voltage - baery cell total voltage
2. Baery Terminal Voltage - voltage that is available at (+) terminal of baery
3. Baery Capacity - displays baery capacity level (displayed in % and actual
levels).
4. Power OFF mode status - indicates whether baery is ON or OFF.
5. Baery/Smartphone device connecon status - Green LED displayed for
connecon.
6. Baery Temperature - shows temperature of baery in metric or imperial mode.
7. Module Voltage - display of internal voltage of baery module.
8. Module Current - display of module charging or discharging.
9. Module temperature - display of module temperature.
10. Module Capacity - display of current capacity of the module.
Remote Control of baery (controls all modules):
1. Low Power Mode - enable or disable mode.
2. One Last Start Mode - enable or disable mode.
3. Power OFF Mode - enable or disable mode.
4. Heater On Mode - enable or disable mode.

www.InduraPower.com
User Guide
Page 7
Smartphone/Tablet Remote Control:
Low Power Mode
1. On Applicaon telemetry display page, tap the Low Power Mode switch.
Switch will toggle from le to right and the baery LED will change color from
white to light blue which indicates mode is ON.
2. To turn mode OFF, tap the Low Power Mode switch. Switch will toggle from
right to le and the baery LED will change color from light blue to white
which indicates mode is OFF.
Power OFF Mode
1. On Applicaon telemetry display page, tap the Power OFF Mode switch.
2. A message will appear with addional instrucons.
3. To connue press OK. Selecng CANCEL will not enable mode.
4. Switch will toggle from le to right and the baery LED color will change from
white to light blue which indicates mode is ON. Below the switch, a display is
shown that shows status of the Power OFF mode (ON or OFF).
5. To turn mode OFF, tap the Power OFF Mode switch. Switch will toggle from
right to le and the baery LED will change color from light blue to white,
that indicates mode is OFF.
One Last Start Mode
1. When baery is discharged to a point where vehicle will not start, selecon
of ‘One Last Start’ will disable baery from Under-Voltage Protecon mode.
2. To acvate ‘One Last Start’ mode, slide switch from le to right.
3. Start vehicle within 30 seconds of acvang mode (switch will show acve
mode by remaining switch to the right side).
Heater On Mode
1. The heater will turn on for a maximum of 10 minutes.
Smartphone/Tablet Remote Control (Connued):
Heater On Mode
1. To warm baery using baery heater, select Heater ON switch by sliding switch to
the right. Note: Not available if internal temperature of baery is above 86
degrees Fahrenheit
2. Heater will remain ON unl baery temperature reaches 30degC or 10 minutes.
3. While ON, switch will be displayed ON (to the right side).

InduraPower.com
Power
Intelligent Battery Series
Indura
User Guide Page 8
RMA / Returns
All warranty claims are handled by Elise / InduraPower directly. All warranty claims must be accompanied by a copy of the
original receipt from your retailer or your Elise / InduraPower Invoice along with a Warranty Claim form. Do not contact your
reseller for warranty claims. You may request a Return Merchandise Authorizaon (RMA#) by sending an email noficaon
with warranty claim form to info@indurapower.com and stang your Invoice number or aaching a copy original receipt. Or
you put the above informaon in the Shipment to:
Elise / InduraPower 1668 S. Research Loop, #332, Tucson, AZ 85710.
Returns will only be accepted from the original owner and with valid receipt. A return authorizaon number must be acquired
from Elise / InduraPower before the baery is shipped. If a baery is received without a Return Authorizaon Number, or
without the original invoice then the baery will be returned to the original shipper COD. Elise / InduraPower LLC reserves
the right to deny any and all claims if all condions and terms are not met.
Returns MUST be accompanied by:
1. A copy of Original Receipt or Purchase Invoice
2. Warranty Claim form
3. Elise / InduraPower -Issued RMA#
Products found defecve aer in-house tesng at Elise / InduraPower can only be returned to customers, at their expense
for shipping or disposed of.
DO NOT SHIP DAMAGED BATTERIES THROUGH THE MAIL. IT IS AGAINST THE LAW!
Please note: that the DOT requires all persons shipping baeries to be Hazmat cerfied. It is recommended that customers
find a nearby baery dealer or specialist to ship, or addional charges will be incurred for a freight pick up, which can exceed
$100. If your Elise / InduraPower products was shipped aer December 1, 2013, it must be shipped in the original box with
original packaging material
REPLACEMENTS
Elise / InduraPower are only eligible for one warranty replacement. Once a baery has been repaired or replaced under
warranty, the replacement item only holds the remainder of the warranty period from the date of the original purchase of the
baery.
SHIPPING
All shipping charges, insurance and any damage incurred during shipping for any and all warranty claims is the customer’s
responsibility. If the baery is determined to be defecve, Elise / InduraPower will pay for return shipping of the replacement
baery back to the customer (within the connental US only) by ground shipping only. If the baery is NOT defecve, or the
baery sale originated outside the connental US, shipping back to the customer will be at the customer’s expense. Any
shipping service other than ground shipping as requested by the customer would be at the customer’s expense.
Any item damaged in transit must be reported to the SHIPPER IMMEDIATELY upon opening of the package, and Elise /
InduraPower nofied of damage at which me Angravity will inform customer of next acon.
ELITISE LLC / INDURAPOWER LIABILITY IS LIMITED TO REPLACEMENT OF THE BATTERY ACCORDING TO THE
TERMS STATED ABOVE.

FCC / IC Compliance:
This device complies with part 15 of the FCC and Industry Canada license-exempt RSS standard(s). Operaon is
subject to the following two condions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operaon. FCC NOTE: The manu-
facturer is not responsible for any radio or TV interference caused by unauthorized modificaons to this equipment.
Such modificaons could void the user’s authority to operate the equipment. Important note: To comply with the
FCC RF exposure compliance requirements, no change to the antenna or the device is permied. Any change to the
antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority
to operate the device.
Limited Warranty:
This InduraPower product is warranted to be free from defects in materials or workmanship for 5 years from the
date of purchase. Within this period, Elise will, at its sole opon, repair or replace any components that fail in
normal use. Such repairs or replacement will be made at no charge to the customer for parts or labor, provided that
the customer shall be responsible for any transportaon cost. This warranty does not apply to: (i) cosmec damage,
such as scratches, nicks and dents; (ii) damage caused by accident, abuse, misuse, water, flood, fire or other acts of
nature or external causes; (iii) damage caused by service performed by anyone who is not an authorized service
provider of InduraPower; or (iv) damage to the product that has been modified or altered, serial number altered or
removed, or warranty seal is removed, opened, modified, or stripped without the wrien permission of InduraPow-
er. In addion, InduraPower reserves the right to refuse warranty claims against products or services that are
obtained and/or used in contravenon of laws of any country. InduraPower retains the exclusive right to repair or
replace the unit or offer a full refund of the purchase price at its sole discreon. To obtain warranty service, contact
InduraPower product support or an InduraPower authorized dealer for shipping instrucons and an RMA tracking
number.
InduraPower / Elise LLC
1668 S. Research Loop, #332
Tucson, AZ 85710
Phone: (520) 499-3799
Email: info@elise.com
PN: 020-01000-00_0B
InduraPower.com
Power
Intelligent Battery Series
Indura
User Guide Page 9
This manual suits for next models
3
Table of contents
Popular Camera Accessories manuals by other brands

Vinten
Vinten V4045-4980 Operator's guide

EAC Video Marketing
EAC Video Marketing Handheld 3-Axis Stabiliser for Smartphones user manual

Ikelite
Ikelite 6212.07 Supplemental instructions

Visceral Psyche Films
Visceral Psyche Films Leeming LUT ONE manual

Sanyo
Sanyo Cadnica KR-1200SCL Specifications

Empower
Empower ElektroBank14 Installer manual
