APPLICATION:
Allows the M1 or M1EZ8 to monitor remote tem-
peratures. Rules are used to activate outputs,
dial phone numbers, deliver voice alerts, etc. A
sensorcanbeinterfacedtozones1-16oftheM1
or zones 1-8 of the M1EZ8. Unit available with
short or long (7 ft.) Probe.
FEATURES:
•Measures Temperature From: -50 to +140 F
•Communicates to Control Over 3 Wires
•Operates On Any Main Board Zone, M1 zones
1-16, M1EZ8 zones 1-8
•Up to 16 Interfaces May Be Connected To An
M1, Up to 8 Interfaces To An M1EZ8
•Interface May be Placed Up To 1000 ft Away
•Suitable for Indoor/Outdoor Use in a Covered
Environment
•Available with Short Probe (M1ZTS)
or with 7 ft. Probe (ELK-M1ZTSR)
SPECIFICATIONS:
•Operating Voltage: 12 Volts D.C.
•Current Draw: 10mA
•Housing Dimensions: 2.375" x 1.25" x 1"
* * IMPORTANT NOTE * *
For full compatibility with the ELK-M1ZTS or ELK-
M1ZTSR the M1 or M1EZ8 Control must have
firmware version 4.2.5 or higher and the Elk-RP
Software must be version 1.4.1 or higher. Earlier
version firmware/software may appear to work
but will not produce accurate readings.
10/04
Auxiliary
+12VDC Power
Outputs
Master Power Switch (SW1),
disconnects AC and Battery
power from control
This example shows the
Temperature Interface
connected to Zone 15.
However, any of the 16 main
zones will accept a
Temperature Interface.
Zone Def=033 Temperature
ELK-M1
(Left Side Terminals)
Temperature
Sensor/Interface
with cover
removed
Four conductor cable from
Temperature Inteface to the Control
(Maximum distance: 1000 ft.)
+SAUX
NEG
+VAUX
NEG
+VAUX
NEG
+VAUX
NEG
AC
ZONE 16
NORMAL JP1
SW1
16.5 V
JUMPER TO
START WITH NO
AC
POWER
TELCO SEIZED
AC
Z9
NEG
Z10
Z11
NEG
Z13
NEG
Z15
Z14
Z12
NEG
Z16
DIALER ACTIVE
2WIRE
SMOKE
STATUS
REVERSE
BAT LEADS
+-
BATTERY
Red
Green
Black
ELK-M1ZTS "Short"
Temperature Probe
ELK-M1ZTSR "7 ft."
Temperature Probe plugs in here.
+12V ZN NEG
Red
Green
Black
CAL + T-
Calibration pads - DO NOT USE without
help from ELK Technical Support
INSTALLATIONOFM1ZTSorZTSR
1. Remove the cover from the base of the Interface.
2. Mount the base using a #6 x 3/4" sheet metal
screw though hole in center of circuit board.
NOTE: The Interface is not weatherproof. If
mounted outdoors, place under a roof or deck
overhang or in a weather resistant box. For
freezer monitoring or extreme conditions the
model with 7 ft. Probe model (M1ZTSR) is best as it
allows the interface to be mounted away from the
sensor (indoors) in a more suitable environment.
3. Turn the Control Panel power OFF.
4. Run a four conductor cable (max. of 1000 ft.) from
the Interface to the Control. Connect the wires
per and diagram steps below:
- Connect a Green wire from terminal ZN on the
interface to any unused Zone input terminal on the
main M1 board (Z1-Z16) or M1EZ8 (Z1-Z8). No
EOL resistor is needed.
- Connect a Red wire from terminal +12V on the
Interface to Aux. +12 Volt DC terminal on control.
- Connect a Black wire from terminal NEG on the
interface to NEG terminal on control.
5. After all connections are complete, place the
cover on the interface and turn the Control Panel
power ON. ZoneTemperatureSensor/Interface
ELK-M1ZTSR(7ftProbe)
ELK-M1ZTS(ShortProbe)
ZoneTemperature
Sensor/Interface
ELK-M1ZTS(ShortProbe)
ELK-M1ZTSR(7 ft. Probe)

TemperatureZoneDefinition:
1. Select the zone that is to be connected to the Interface. ONLY ZONES 1 THRU 16 ON THE M1 OR
ZONES 1 THRU 8 ON THE M1EZ8 MAY BE USED WITH THE ZONE TEMPERATURE SENSORS.
2. Program the definition of this zone to: 33 -Temperature Zone.
3. Under the Zone Definitions menu enable the "Fast Loop Response" option ONLY. Disable all other
options. VERY IMPORTANT: A zone defined as Temperature MUST also be enabled for Fast Loop
Response with the response time set to 200ms or less.
4. Under the Global Definitions menu and go to the "Zones" tab and verify the "Fast Loop Response"
option to be 200ms or less. The factory default is 040 ms., requiring no change.
View Temperature: It takes ~30 seconds after power up for the Temperature Interface to stabilize and
transmit a reading to the Control. Updates are transmitted every 17 seconds. The Control stores each
temperature reading but discards rapidly changing readings as follows: If a reading is more than 20
degrees higher or 9 degrees lower than the last reading, it will be regarded as a possible error and
discarded. If the control is turned off or reset it takes ~30 seconds to display the temperature.
1. To view temperature from the keypad, press the ELK key (enter code if prompted), then press the
RIGHT arrow key to select the View/Control Automation menu.
2. Press the 4 key (or scroll up) to display: 4-Temperature Sensor, then press the RIGHT arrow key.
3. The first temperature zone will be displayed with its Name, Zone Number, and reading.
4. Additional Temperature zones (if any) may be displayed by entering their 3 digit number OR by
scrolling with the UP or DOWN arrow keys. To exit from this menu press the * key.
Using a Temperature Sensor in a Rule: This ELK-RP Whenever/And/Then Rule example turns on
Output 3 for 10 minutes whenever the temperature exceeds 90 degrees.
1. Open the account in ELK-RP. Click on the Automation tab, the Rules tab, and then on New.
2. Click Whenever, then point to Time Occurrence, then Every X Seconds, and then click done. **
3. In the block beside the words Fixed Value, type in 30 and click OK.
4. Click And, followed by Temperature which is located near the bottom of the drop down list.
5. Highlight the temperature sensor zone (by name), click the Greater than button, and change the
temperature selection number to 90. Make sure the button beside F is selected, and click OK.
6. Click Then, followed by Turn Output On/Off. Highlight Output 3 (use the scroll down arrow), make sure
the button beside Turn on is selected, then select the box labeled For. Highlight the hrs:mins:secs
window and enter 00:10:00 (10 minutes). Click OK. Double check everything and click Done. The
Rule should resemble the example below.
Temperature Text String Displayed on a Keypad
1. From the Automation tab click Texts, then click New. In the text string box type the word Outside.
2. Click the down arrow on the Insert box. Select Temperature Sensor Reading from the list, then click
the down arrow on the next box. Select the temperature sensor zone by name. Click OK. The text
block should resemble: Outside|% TEMP ZN15 %| This causes the current temperature to display.
3. Click the Rules tab followed by New to write a rule for sending this text string to a keypad.
4. Click Trigger, followed by Time Occurrence, and Every X Seconds. Enter a value of 30 In the block
beside the words Fixed Value, then click OK. **
5. Click Then, followed by Send Text to Keypad. Make sure the button Display the following message is
selected, then choose the text Outside|% TEMP ZN15 %| using the drop down box and arrow.
6. Select Area must match where the keypad is located. Three (3) other options determine whether the
text message: may be Cleared with the * key, will Display for a time period, or will Beep Keypad when
the message displays. Select any options and click OK. Double check everything and click Done.
** Numeroustriggersmaybeusedforatemperaturetyperule,i.e.,timeoccurence,armingofthesecuritysystem,
openingofazone,etc. However,theControldoes not allow a temperature reading tobeusedasatrigger. This
helpspreventa falseactivation"runaway"thatcould occursimplebecausethe temperaturehasfluctuatedbya
degreeorfractionofadegree. Instead,theANDcommandisusedtocompareor"test"atemperaturesensor
readingagainstatargetvalue,eachtimethetriggeroccurs. Thetargetvalueisprogrammableandthecompare
optionsare"Equalto,Notequalto,Lessthan,andGreaterthan". The"Equalto"isnotrecommendedasacompare
optonbecauseitmaybeimpossibleforatemperaturereadingtobeexactlyatthetargetvaluewhenthetrigger
occurs.
