Elkay LK4461YHLHB Series User manual

PAGE 1
4461_FTN_A
1000004339 (Rev. A - 10/17)
To assure you install these models easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR
INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL, AND OTHER
APPLICABLE CODES. After installation, leave these instructions with the Fountain for
future reference.
Owners Manual
Models LK4461YHLHB* and 4461YHLHB*
Yard Hydrant With Locking Hose Bib
INSTALLER
MODELS
LK4461YHLHB* & 4461YHLHB*

PAGE 21000004339 (Rev. A - 10/17)
4461_FTN_A
1. This yard hydrant is to be mounted on a smooth, at, nished surface with adequate support structure.
2. Refer to rough-in for plumbing.
3. Install shut-off valve on water supply, (valve not furnished).
4. Locate and install hydrant using 3/8" minimum fasteners, (Fasteners not furnished).
5. Connect water supply. Water connection must comply with local codes.
6. Turn on water supply and check all connections for leaks.
CAUTION: This hydrant is rated for inlet water pressure of 20-105 PSI. A pressure reducing regulator should be used if the
inlet water supply exceeds 105 PSI. Any damage caused by reason of connecting this product to supply line
pressures lower than 20 PSI or higher than 105 PSI is not covered by warranty.
7. Water supply 1/2" O.D. unplated copper tube. Contractor to supply service stop valve in accordance with local code.
8. Connecting lines to be made of unplated copper and should be thoroughly ushed to remove all foreign matter before being
connected to hydrant. This yard hydrant is manufactured in such a manner that it does not in any way cause taste, odor,
color, or sediment problems.
9. Connect hydrant to supply line with a shut-off valve and install a 1/2" unplated copper water line between the valve and the
faucet compression elbow tting. Remove any burrs from outside of water line. Push the tubes straight into the ttings until
they reach a positive stop, approximately 3/4".
INSTALLATION INSTRUCTIONS
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM THE
BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREATING AN
ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE
WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN
FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE
FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.

PAGE 3
4461_FTN_A
1000004339 (Rev. A - 10/17)
LEGEND A = 1/2" O.D. UNPLATED COPPER TUBE CONNECT - SHUT OFF VALVE BY OTHERS.
"A"
14" 356mm
O
12" 305mm
OB.C.
8 5/8"
220mm
1/2" 13mm
O(6 PL) EQUALLY SPACED
6" 152mm
18 13/16"
478mm
27 1/4"
692mm
16 1/2" 420mm 8" 203mm
10" 254mm
O

PAGE 41000004339 (Rev. A - 10/17)
4461_FTN_A
ITEM
NO. PART NO.
75624C
75619C
1000004235*
70977C
70972C
1000004233*
1000003814*
75535C
75724C
66555C
75521C
ITEMIZED PARTS LIST
1
2
3
4
5
6
7
8
9
NS
NS
Fitting - Hose Vacuum Breaker
Faucet - 1/2" NPT
Door - Hose Bib Housing
Nut - Lock 1/2" Conduit
Elbow - 90° x 1/2" NPT
Panel - Locking Hose Bib
Plate - 7" Round Cover
Pinned Torx Screw 1/4-20 x .75"
Pinned Torx Screw 1/4-20 x .75" Flat Head
Tube - 1/2" O.D. X 36.00" Lg.
Bit - Torx
DESCRIPTION
PRINTED IN U.S.A.
Halsey Taylor – halseytaylor.com
Elkay – elkay.com
FOR PARTS CONTACT YOUR LOCAL DISTRIBUTOR OR CALL TECHNICAL SERVICES AT 1.800.834.4816
2222 CAMDEN COURT, OAK BROOK, ILLINOIS 60523
*select color option to complete part number
NS = Not Shown
*FINISH COLOR OPTIONS – Choose color option to
complete your model number, add as sufx example:
4461YHLHBEVG
Matte nish: Evergreen = EVG
Gloss nish:
Beige = BGE Gray = GRY Terracotta = TER
Black = BLK Orange = ORN White = WHT
Blue = BLU Purple = PUR Yellow = YLW
Brown = BRN Red = RED
3
6
9
1
2
45 4
7
8 (5) PLCS
