Elkay Pacemaker BPSH15C User manual

GENERAL
Fine quality sink bowl seamlessly formed of #20 gauge, type 304
(18-8) nickel bearing stainless steel. Self-rimming.
DESIGN FEATURES
Bowl Depth: 6-1/8".
Coved Corners: 1-3/4" vertical and horizontal radius.
Bowl and Faucet Deck Recess: 3/16" below outside edge of
sink.
Finish: Exposed surfaces are polished to a lustrous highlighted
satin finish.
Underside: Fully undercoated to dampen sound and prevent
condensation.
These sinks comply with ANSI Standard A112.19.3M.
SINK PACKAGES
BPSRA150C Package includes:
(1) BPSR15 Sink.
(1) LK20888 Deluxe two-handle faucet with 4-1/2" rigid goose-
neck spout.
(1) LK36 Strainer.
BPSH15C Package includes:
(1) BPSR15 Sink.
(1) LKA2437 Hi-Arc®two-handle bar faucet with 9" high (deck
to aerator height) traditional swing spout.
(1) LK36 Strainer.
OTHER
Drain Opening: 2".
NOTE: Unless otherwise specified, sink is furnished with 1 faucet
hole as shown. BPSH15C is furnished with 3 faucet holes.
OPTIONAL ACCESSORY
Cutting Board: CB912.
Model BPSR(Q)151
SINK DIMENSIONS (INCHES)*
* Length is left to right. Width is front to back.
Elkay 2222 Camden Court
Oak Brook, IL 60523 Printed in U.S.A. ©2004 Elkay
(Rev. 3/04) 1-6F
www.elkayusa.com
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice. This specification describes an Elkay product with design, quality and functional benefits to the user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
Pacemaker®Single Bowl Hospitality Sink
and Sink Packages
Models BPSRA150C, BPSH15C, BPSR15 and BPSRQ15
®
SPECIFICATIONS
Model BPSH15C
Model BPSRA150C
Cutout in No. of
Countertop 11/4" or
U-Channel Quick-Clip®(11/2" Radius 11/2" Dia. Minimum Ship.
Model Model Overall Inside Bowl Corners) Faucet Holes Cabinet Wt.
Number Number L W L W D L W 4" Centers Size Lbs.
BPSRA150C – 15 15 12 91/461/8143/8143/81189
1/2
BPSH15C –15 15 12 91/461/8143/8143/83189
1/2
BPSR15 BPSRQ15 15 15 12 91/461/8143/8143/81, 2, MR2 or 3 18 51/4
SEE OTHER SIDE FOR PRODUCT DIMENSIONS.

Model BPSR151 Illustrated
6-1/8"
15
15
12
9-1/4"
1-3/4" R
1-3/4" R
Quick-Clip®Mounting System
U-Channel Type Mounting System
HOLE DRILLING
CONFIGURATIONS
4"
4"
4" 4"
1
(1-1/4" diameter)
2
(1-1/4" diameter)
MR2
(1-1/2" diameter)
3
(1-1/2" diameter)
Pacemaker®Single Bowl Hospitality Sink
and Sink Packages
Models BPSRA150C, BPSH15C, BPSR15 and BPSRQ15
®
SPECIFICATIONS
Elkay 2222 Camden Court
Oak Brook, IL 60523
www.elkayusa.com
Printed in U.S.A.
©2004 Elkay
1-6F (Rev. 3/04)
