Ellies BPHDMICK2 User manual

Product Code:
Barcode: 600284406 4853
BPHDMICK2
www.ellies.co.za
AV SOLUTIONS
The HDMI Extender allows HDMI Audio/Video and IR signals to
be transmitted over a single Cat5e/6 shielded cable. TECHNICAL INFORMATION
Specifications:
Mechanical Specifications:
THE PACKAGE CONTAINS
1 x Transmitter 1 x Power Supply
1 x Receiver 1 x User Manual
1 x Wide band IR TX cable
1 x Wide band IR RX cable
Package
PACKAGE DIMENSIONS
Weight
(kg)
1215 0.4615059
QTY
(mm)(mm)(mm)
Width
Height Depth
D
Diagram
HDMI Extender - Single CAT5e/6
HDMI Extender - Single CAT5e/6
Cable with Dual IR Control
Video Bandwidth:
Video Support:
Audio Support:
Transmission Range:
Input TMDS Signal:
Input DDC Signal:
ESD Protection:
PCB stack-up:
HDMI connector:
RJ-45 connector:
3.5mm connector:
Single-link 165Mhz [ 4.95Gbps]
480i/480p/720p/1080i/1080p @60Hz
Surround Sound (up to 7.1ch) or stereo digital audio
HD [1080p 24-bit color] – up to 50m Cat5e/6 cable
3.3 volts
5.0 volts/P-P
Human Body model: +/- 8 kV (air-gap discharge) +/- 4 kV
(contact discharge)
4 layouts
Type A 19 pin female
WE/SS 8P8C
(TX and RX) IR Receiver/IR Blaster
Housing:
Power Supply:
AC Power Adaptor
Power consumption:
Operation temperature:
Storage temperature:
Relative humidity:
Metal enclosure
5V DC
2 pin Euro plug
2.5 watts (TX); 1.2 watts (RX)
0°C to 40 °C
-20°C to 60 °C
20~90 % RH (no condensation)
Bi-directional IR system allowing for control of source or
display (IR accessories included).
Smart EDID management.
Transmission Range: Extends 1080p resolution up to 50m over
a single Cat5e/6 cable.
Works with HDMI and HDCP compliant devices.
Supports up to 1080p High Definition resolution.
Compact design for an easy and flexible installation.
IR BI directional and loop through.
Panel Descriptions Transmitting Unit
1. Power LED: This LED will illuminate when the device is connected with power supply.
2. HDMI IN: This slot is where you connect the HDMI output port of your source equipment
such as DVD/Blu-ray players or Set-Top-Box with an HDMI cable.
3. DC 5V: Connect from 5V DC power supply into the unit and connect the adaptor to an
AC outlet.
4. CAT5e/6: Connect the CAT5e/6 output of the transmitter with the CAT5e/6 input of the
receiver with Cat5e/6 cable.
5. EDID: The Extender can switch STD EDID mode(1080p60,2CH audio) or copy TV EDID
information to HDMI source.
6. IR IN: Connect to the IR Receiver for IR signal reception.
Ensure that remote being used is within the direct line-of-sight of the IR receiver
7. IR OUT: Connect the IR Transmitter cable included in the package for IR signal transmission.
Pace the IR Transmitter in direct line-of-sight of the equipment to be controlled
1. HDMI LED: This LED will illuminate when the HDMI signal from the transmitter is stable.
2. HDMI OUT: This slot is to connect the HDMI input port of your display such as an HDTV.
3. DC 5V: Connect from 5V DC power supply into the unit and connect the adaptor
to an AC outlet.
4. CAT5e/6: Connect the CAT5e/6 input of the receiver with the CAT5e/6 output of the
transmitter with Cat5e/6 shielded cable.
5. IR IN: Connect to the IR Receiver for IR signal reception. Ensure that remote being used
is within the direct line-of-sight of the IR receiver.
6. IR OUT: Connect the IR Transmitter cable included in the package for IR signal
transmission. Place the IR Transmitter in direct line-of-sight of the equipment
to be controlled.
Panel Descriptions Receiver Unit
Turn over for the connection diagram
POWER
HDMI
HDMI

Product Code:
Barcode: 600284406 4853
BPHDMICK2
AV SOLUTIONS
HDMI Extender - Single CAT5e/6
Cable with Dual IR Control
www.ellies.co.za
Diagram
Controls Source
Controls TV
HDMI Splitter
Upto 50m CAT5e/CAT6
Upto 50m CAT5e/CAT6
