I-View EPOC-131VA User manual

1
Product Overview:
1.) Data: BNC Female Connector (No analog video) converter allows 10/100 Base-T Ethernet and PoE power to
be transmitted using coaxial cable or 2-Wire cable such as UTP, STP, 18/2, or similar cable.
2.) Link: The LED indicates the cable link status. The LED will be on after 10 seconds when first connection is
success; Off: No connection.
3.) Pwr: The LED indicates the power status. On: Power on; Off: No power.
4.) Ethernet/PoE: RJ45 connector, attaches to POE IP Camera or Hub via Cat5, 5e, 6 or 7 patch cables.
5.) Eth: The LED indicates the communication status. Flash: Communicate with Traffic; Off: No connection.
6.) Power jack: Plug DC power adapter to for PoE source when PoE Hub cannot provide enough power source.
7.) PoE: The LED indicates the PoE power status. On: PoE power is provided; Off: No PoE power.
Packing Checklist:
Check the package box the following items are included: EPOC-131VA and EOPC-131PS x 1 set; Menu x 1 Pc.
Installation Steps:
IPcamera end
1. Connect the IP camera RJ45 connector to the 10/100BaseT Ethernet port of EPOC-131PS using a standard
Cat5/6 cable of maximum 100 m (328 feet) in length.
2. Connect one end of the long coax cable or 2-Wire cable such as UTP, STP, 18/2 or similar cable to the BNC
connector of EPOC-131PS. (*)(**)
3. When the IP camera and EPOC-131PS cannot receive power through the coax or 2-Wire cable, even through
using the POE+ Hub or plug DC56V power adapter for EPOC-131VA. Plug the DC48V power adapter into the
EPOC-131PS will be needed at this end. Please refer to “Power Distance VS. Cable Impedance”table.
Switch Hub end
1. Connect the PoE switch Hub RJ45 connector to the 10/100BaseT Ethernet port of EPOC-131VA using a standard
Cat5/6 cable of maximum 100 m (328 feet) in length.
2. Connect one end of the long coax cable or 2-Wire cable such as UTP, STP, 18/2 or similar cable to the BNC
connector of EPOC-131VA. (*)(**)
3. When the IP camera and EPOC-131PS cannot receive power through the coax or 2-Wire cable, please change the
POE+ Hub or plug DC56V power adapter to EPOC-131VA.
* Using 2-Wire cable should plug BTB-100 BNC to Terminal block converter. Connect the converter
to the BNC jack on the EPOC-131PS and connect one wire conductor to a terminal marked “+”.
Connect the other wire conductor to a terminal marked “-”. Observe polarity so that it will match that
Ethernet/PoE Extender over 2-Wire Installation Guide V1.2
6
5
4
3
2
1
1
6
4
2
3
1
5
7

2
of the Hub end.
** A Cat.5, 5e, 6, 7 UTP installation cable is converted to a two-wire cable as follows: Open the four twisted wire
pairs and remove approx. 7 mm of insulation from the ends. Then connect the four white wires and the four
colored wires to one cable respectively and attach wire-end sleeves.
ProductApplication Diagram
The Ethernet over 2-Wire system allows the Star topology or Daisy-chained communication. It supports virtually
any type of wire, including coax, UTP, STP, even un-twisted wire. And different wire types can be concatenated
together, as needed.
Star Topology
Daisy Chain
Open the four twisted
wire pairs
Remove insulation from
the ends of all eight wires
Combine 4x white
and 4x colored
Plug DC56V power adapter to EPOC-131VA or DC48V to EPOC-131PS when the IP Camera cannot receive power.

3
The IP camera and EPOC-131PS cannot receive power through the coax or 2-Wire cable. Please do as below:
1. POE+ Hub or plug DC56V power adapter for EPOC-131VA.
2. Plug the DC48V power adapter into the EPOC-131PS will be needed at this end. Please refer to “Power
Wattage VS. Cable Distance”table or visit www.i-view.com.tw
Power Wattage VS. Cable Distance
Data Rate VS. Cable distance
LED Function table
Name
Color
Status
Function
Pwr
Yellow
On
Power is on
Off
Power is off
Eth
Green
Flashing
Communication is OK with Traffic
Off
No communication
Link
Green
On
Connection is OK; (It take 10 sec. for LED on)
Off
No connection
PoE
Green
On
PoE is offering
Off
No PoE offer

4
Specification:
1.Distance and number of devices supported may be lower due to power supply capacity and wire voltage-drop. The bandwidth is
dynamically allocated (shared based on traffic), and decreases with wire distance.
Phone: [phone] Fax: [phone]
Mail: [e-mail]
ITEM \ MODEL
EPOC-131VA
EPOC-131PS
EPOC-131PS-O
Ethernet
Connector
RJ-45
RJ-45
RJ-45
Connectivity
10/100/1000 Base-T auto-negotiation, auto MDI / MDX crossover
Wire type
Cat5 or better
Distance
Up to 328 feet (100m)
Cable Link
Connector
BNC or Terminal block (by converter)
Type
Receiver (Hub Site)
Transmitter (Camera Site)
Wire type
Coax, single- or multi-pair UTP, 18/2, or STP wire
Distance
Up to 1.5Km (4950 feet)
Topology
Supports Star, Daisy-Chain, or any combination
Encryption
128-bit AES
Latency
3 ms
Bandwidth
Total network bandwidth 150 Mbps; with dynamic bandwidth allocation
Power
Power Source
PoE Hub; DC44～56V
PoE or DC48V
PoE or DC48V
Power Output
PoE (2-Wire / Coax)
25W PoE (RJ45); (50W Option)
Physical
Waterproof
None
None
IP 66
Dimensions (mm)
100 x 55 x 34
100 x 55 x 34
128 x 102 x 36
Weight
140g
140g
310g
LEDs
Status indicators
Cable link
Ethernet Power
Ethernet link/activity
Cable link
Ethernet Power
PoE Connection
Ethernet link/activity
Cable link
Ethernet Power
PoE Connection
Ethernet link/activity
Environment
Temperature
Operation: 0℃to 50℃/ 14℉to 122℉
Humidity
20% ~ 85% non-condensing
Power consumption
≤ 2W
Transient immunity
20µS x5 3,000A, 6,000V; ESD 20KV, 200pF
