Elo TouchSystems EM10 User manual

1
Dash Cam Manual
Model EM10

2
Table of Contents
Dash Cam Diagram 3
Installation Guide 4
Features 6
Basic Functions of the Dash Cam 8
Power On/Off | Turn On/Off screen | Reset
UI of the Dash Cam 9
Camera DVR 11
FM Transmitter 12
App List 13
Camera Playback 14
Settings 15
Product Specifications 18

3
Dash Cam Diagram
1: Sim card port
2: SD card port
3: Reset
4: Angle Tighten Knob
5: Power button
6: Touch screen
7: Second camera port
8: USB connection
9: GPS antenna
1
2
3
5
6
7
8
9
4

4
Installation Guide
1. Turn off the engine of the vehicle
2. Unit comes with a 64GB SD Card which will be already in
the SD card slot
[Note] If the user needs to replace this SD card, please take
out the current SD card and insert new card into the SD card
port. Please use a high-speed SD card (Class 10 or higher). The
storage should be 2GB or more, and up to 128 GB
3. Clean the windshield glass from inside the truck with an
alcohol wipe or the cleaning rag provided in the package
4. Remove the Plastic Film over the 3M sticker, and place the
Dash Cam near the rear-view mirror of the truck. Hold for 5
seconds to keep in place
5. Connect the ACC cable with the Automotive Fuse Box
[Note] When wiring, the charging extension line can be laid
along the edge of the car windshield
[Optional] Dash Cam can also be connected with the cigarette
lighter charger to the USB port of the dash cam with a

5
charging extension cable. This is Not Recommended. Using it
this way could lead to permanent damage to the unit.
6. Adjust the lens position to ensure that the lens is level with
the ground
7. Tighten the dash cam position by using the Angle tighten
Knob (4 in diagram above) to get the desired angle of the dash
cam
8. Install the second camera on the rear of the vehicle, side of
the vehicle, or facing the driver. The wiring can be laid along
the roof of the vehicle if needed. After installation, connect the
plug to the second camera port of the Dash Cam

6
Features
Automatic Locked Files
A file is automatically locked and sent to the portal if the
collision sensitivity is met. The upload will happen on the
background as long as the camera is powered on. Even if
powered off- the moment it gets power the locked file will start
uploading again. Each minute of locked file video is
approximately 100MB and can take the appropriate time to
upload.
All locked files will be automatically uploaded on secure servers
which can be accessed from anywhere in the world for over a
period of 2 years.
Fleet Management Functionality
The GPS antenna of the dash cam can be used to do near live
tracking of the truck. Ensure that the GPS Antenna is facing
upwards. Full Telematics on near real time basis will be
available to fleet manager or back office team. This includes
geofencing, custom alerts, reports, full breadcrumb, and
location sharing. Additionally, the dash cam can provide video
of hard breaking, hard acceleration, or any collision.
Both features above require a monthly subscription

7
Loop Recording
Once the memory of the dash cam has been reached new video
is automatically saved over the oldest video files.
1080P Front Camera & AHD for Second Camera
High quality video footage saved.
Standalone 4G LTE Dash Cam
This dash cam does not require any use of smart phone in
order to view video files. All files can be viewed and locked
directly on the dash cam.
Google Maps
Dash Cam has inbuilt google maps which can be used for
navigation purposes. Our sim card is required for this
feature.
Other features are detailed in this manual.

8
Basic Functions of the dash cam
Power on/off function
A: In the powered-on state, long press the power button and
hold for 3 seconds, the unit will automatically save the current
video file and shut down;
B: In the power-off state, long press the power button and hold
for 3 seconds for turning on the unit.
Turn on/off the screen
Short press the power button, and the unit will enter HUD
mode with the screen off. Short press the power button again
to light on the screen. If short pressed the dash cam will
continue to take video files even if the screen is off.
Reset button
Short press the reset button to restore the dash cam to factory
default settings.

9
The UI of the dash cam
The dash cam is touchscreen. Use a finger for navigation and
clicking. The above UI is the home screen. The items on the
home screen are described further below:
Enters the recording interface which shows what
is currently being recorded by the dash cam
Lists out the current videos that are available on
the dash cam
Enters Radio FM
Opens Google maps.
Opens Music.
Enters into the full list of apps that are
downloaded on the dash cam.

10
means the video is being recorded with a voice
recording, while clicking on it again toggles it to which
means the video is not doing a voice recording.
Takes the user to the settings below:
to go back to the home page
to go back to the previous page

11
Camera DVR:
The UI above is what is seen when clicking on the Camera
DVR app. Red Dot on the top left indicates that the video is
being recorded. The Preview icon is to switch between
viewing the front camera and the second camera.
Clicking on the Camera Icon will take a picture.
Clicking on the Voice Recorder will either toggle sound
recording on or off.
Press the Setting button to be taken to the setting screen.
Note- setting screen is not supported if it is on video recording
mode.
The Back Icon will take the user back one screen.

12
FM transmitter
After clicking on the FM function, the frequency can be
adjusted manually. (note - turn on the radio first and adjust to
an empty frequency band without sound)
Turn on the radio on the truck and adjust to the corresponding
frequency, then the FM function can be used normally.

13
App List
The app list stores all the apps that are downloaded by the
user on the dash cam, along with a pre-installed set of apps. To
add apps please go into the play store (labeled “Play”) and
input your google account to download a new app. Apps
cannot be deleted once downloaded. Only apps that are
downloaded through the playstore are automatically updated.

14
Camera Playback
Long press the video for choosing “Lock/delete/Cancel”. If
moved to the lock tab this video will stay on the dash cam at all
times. However, it will not be uploaded to the back-end portal.
Only locked files as described in the Features section get
automatically uploaded to the back-end portal.

15
Settings
Clicking on the setting icon, will enter the view as shown in
section V. The view below is for more settings:
Network & Internet: When clicking on the open/off button
in the Network & Internet, a user can open the WiFi
function. The system automatically scans nearby WiFi
signals and lists the searched wireless routers. Once
clicking on the searched wireless router name, a setting
window will pop up. Please follow the prompts to complete
the WiFi network link. Some encrypted networks need to
enter a valid password. Please enter the correct password
and click "Connect" to the network.
Parking monitor: The parking monitor function is
triggered by the G sensor in the unit. When park mode is

16
Off, the G sensor and CPU will not work. When it is On,
the unit will be switched to Park mode after shutting off.
The device will enter sleep mode after parking, and if there
is a shake during the parking period, the device will
automatically wake up and record for one minute (the
screen will not light up) and then continue to be in sleep
mode after that. Note-Parking Monitor functionality may
not work for certain truck models depending on how the
dash cam is powered to the engine. Parking monitor will
not work if the dash cam is powered using the cigarette
lighter.
Connected device: User can turn on/off a Bluetooth
connection if needed.
Sound and Display: For adjusting the Volume of Music of
the dash cam and the brightness level of the screen.
Storage: The information about the storage of the dash cam
and the SD card.
Google: Information about the users android services and
preferences.
System ->
Language & input: Select for choosing a different language
Date & time: It is for adjusting day and time. There are 3

17
ways for the user to choosing the way to adjust the correct
time, use network-provided time, use GPS-provided time
and automatic time zone
Change Automatic Sensitivity
Go to DVR Camera. Then click on the settings icon. From
here user can select the sensitivity of the collision
detection.

18
Product Specifications
Processor & Memory characteristics
Processor type
Quad-core
DDR
2 GB
eMMC Flash
16 GB
Functional characteristics
Display
MIPI 4.39 inch screen
Display resolution
640 * 360 pixels
External I / O port
1 USB 2.0 (power supply: DC5V / 3A)
1 SIM card slot, support MICRO SIM card
Expansion memory card: TF card/SD card capacity
supports up to 128 GB
1 GPS feeder interface
1 analog rear camera (2.5MM 4-segment headphone
holder) interface, compatible with auto reversing function
Speaker
Built-in (8ohm / 1.5W)
MIC
Built-in -40db ± 2db
Pull back camera
Support AHD (high-definition camera) cable length: 5.5
meters or shorter cable length available if needed
Full screen touch
Full capacitive screen
WIFI
2.4G 802.11b/g/n
Band
Band：
2G：B2/B5
3G：B1/B2/B4/B5
4G：B2/B4/B5/B7/B12/B17
BT
BLE 4.0 supports master and slave devices
GPS navigation
Dual Mode Google Maps + GPS
FM transmission
Support 88-108MHz
Photograph
Support
Front camera
1080P
Camera angle
140° wide angle
Video format
MP4
Image Format
JPEG
Storage
compression
method
Front Cam H.264
Software Support
Operating system
Android 8.1

19
© Eld Mandate Biz. All rights reserved
Language support
Multi-language
G-SENSOR
X/Y/Z Axis - Triaxial
Loop recording
Support, seamless recording
recording function
Support
Time watermark
Support
Front camera video
quality
Supports up to 1920 x 1080 (1080P 25 f/s) or 1280 x 720
(720p 25 f/s)
Second camera
video quality
AHD Camera
