Elo TouchSystems i Series User manual

www.elotouch.com
© 2015 Elo Touch Solutions, Inc. All rights reserved.
Elo Touch Solutions Technical Support
Online self-help: www.elotouch.com/go/websupport
Technical Support contacts in your region:
www.elotouch.com/go/contactsupport
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Afliates (collectively “Elo”) makes
no representations or warranties with respect to the contents herein, and specically disclaims any implied warranties of merchantability or
tness for a particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof
without obligation of Elo to notify any person of such revisions or changes.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise
without prior written permission of Elo Touch Solutions, Inc.
Elo (logo) and Elo Touch Solutions are trademarks of Elo and its Afliates.
North America
Elo Touch Solutions
1033 McCarthy Boulevard
Milpitas, CA 95035
800-ELO-TOUCH
Tel [phone]
Fax [phone]
[email protected]
Europe
Tel [phone]
Fax [phone]
[email protected]
Asia-Pacic
Tel [phone]
Fax [phone]
www.elotouch.com.cn
Latin America
Tel [phone]
Fax [phone]
www.elotouch.com
Revision B
P/N E174817
Quick Installation Guide
i-Series Interactive Signage
Audio Out/
Microphone In
Android Home
Button
Peripheral Bay
USB Type A
Micro SD
Slot
Micro-HDMI Out
Peripheral connections
NOTE:
This device requires non-booted ethernet cables.
The boots interfere with the power connector and
do not t under the cable cover.
Contents
1x i-Series All-in-One Touchcomputer
1x US power cable
1x EU power cable
2x Cable clamps with mounting screws
Power
Button
Peripheral Bay
Ethernet
3G/4G Expansion Bay
and
GPIO Connections
Boot Style
Non-Boot Style
OK

Remove the left side cable cover by sliding downward
Go to www.elotouch.com/support to download user manual.
Connect the power cable. The system will power on
automatically when plugged in.
Secure the power cable using the included cable clamp
and screw and replace the cable cover. The system must
be connected to a network for software setup. Connect an
ethernet cable now or setup wi in step 5.
The device is now ready to mount in your environment.
A selection of wall, desk, shelf, and oor mount options is
available at www.elotouch.com
After connecting to the network, click “Register Device” on the HOME screen
and enter account username and password. If you do not have one, go to
manage.eloview.com to create an account.
The Network screen on the control panel will appear if no wired connection is
found. Set up your wireless network. Note: The control panel can be opened
any time by pressing the HOME and POWER keys simultaneously, and typing
in a password. The default password is 1elo.
1 3 5
2 4 6
