Elo TouchSystems E688656 User manual

www.elotouch.com
© 2014 Elo Touch Solutions, Inc. All rights reserved.
Elo Touch Solutions Technical Support
Online self-help: www.elotouch.com/go/websupport
Technical Support contacts in your region:
www.elotouch.com/go/contactsupport
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Afliates (collectively “Elo”) makes no
representations or warranties with respect to the contents herein, and specically disclaims any implied warranties of merchantability or tness
for a particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof without
obligation of Elo to notify any person of such revisions or changes.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior
written permission of Elo Touch Solutions, Inc.
Elo (logo) and Elo Touch Solutions are trademarks of Elo and its Afliates.
North America
Elo Touch Solutions
1033 McCarthy Boulevard
Milpitas, CA 95035
800-ELO-TOUCH
Tel [phone]
Fax [phone]
[email protected]
Europe
Tel [phone]
Fax [phone]
[email protected]
Asia-Pacic
Tel [phone]
Fax [phone]
www.elotouch.com.cn
Latin America
Tel [phone]
Fax [phone]
www.elotouch.com
Revision B
P/N E164990
Quick Installation Guide
Webcam
For all Elo Touch Solutions IDS Touchmonitors
E164990 Rev B

Please go to www.elotouch.com/support to verify you have the latest drivers before installing this device.
Installation
1
3
2
DIsconnect AC power from the monitor and then remove the accessory
port covers on the top of the monitor using a paperclip or tweezers.
Connect the webcam cable to the connector under the accessory port
and fasten the webcam to the monitor using the included screws.
Adjust the camera viewing angle if desired using a 3mm hex wrench and
then install the mylar covers for the mounting and adjustment screws.
Webcam P/N E688656
