ELPRO EL-EX-H02N User manual

1
HDMI (HDBaseT) CAT5 Extender Series
Elpro Video Labs Ed. 1 April 2014
ITEM NO.:
EL-EX-H0 N
HDMI (HDBaseT) CAT5 Extender with Ethernet/ARC/IR/RS 3
The transceiver EL-EX-H02N uses H BaseT technology to extend uncompressed high-definition
video/audio with a data transfer rate of 10.2Gbps. This product also meets all H MI v1.4 standards
including full 3 support, H MI Ethernet Channel, audio return channel and 4Kx2K Resolution.
Additional Ethernet ports on both the Sender and Receiver are provided to connect network devices
such as 100Base-T routers, hubs, computers and your TV. IR channel is bi-directional, therefore in the
same time you can control the destination device from the location of the source and A/V sources from
the location of the destination. H MI, RS232, IR and Ethernet signal can be transmitted simultaneously
without affecting each other. This product offers the ideal solution for extending high-definition video
and audio over long distances.
EL-EX-H0 N
HDMI (HDBaseT) CAT5 Extender with Ethernet/ARC/RS 3 /IR
Extends H MI, Ethernet, ARC, RS232 and IR signal over one CAT5e/6 cable.
Uncompressed high definition video up to 1080p 60Hz 16 bits.
H MI 1.4 with 3 , 4k x 2k support, H CP and VI Compliant.
Max. ata Rate- 10.2Gbps.
Audio supports up to LPCM 7.1 192KHz, olby TrueH , TS-H MA
Transmission range up to 100 meters at 1080p resolution.
ARC or optical digital audio mode auto selection, send TV digital audio back to the amplifier.
Bi-directional IR, IR carrier support 30÷60khz.
Bi- irectional RS232 interface – commands and data can flow in both directions via RS232, allowing
status requests and control of the destination unit.
Support one port 10/100Mbps network, allowing to connect the network TV or devices.
Installation view:

2
Connection Diagram:
PLAYER / AV CENTER Transmitter Receiver TV / PROJECTOR
┌ ─ ─ ─ ─ ─ ─ ─ ┐ HDMI CABLE ┌ ─ ─ ─ ─ ─ ─ ┐ ┌ ─ ─ ─ ─ ─ ─ ┐ HDMI CABLE ┌ ─ ─ ─ ─ ─ ─ ─ ─ ─ ┐
│ OPTICAL HDMI │ ─ ─ ─ ─ ─ ─ ─ ─ ─ →│ HDMI │ │ HDMI│ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ →│
HDMI
│
└ ─ ─ ─ ─ ─ ─ ─ ┘ ← ARC │ │ │ │ ← ARC │ OPTICAL ETHERNET│
↑ │ │ ├ ─ ─ MAX 100M ─ ─ ┤ │ │ └ ─ ─ ─ ─ ─ ─ ─ ─ ─ ┘
└ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ │ OPTICAL │ Link Cable │ OPTICAL│ ←─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ┘ ↑
┌ ─ ─ ─ ─ ─ ─ ┐ │ HDBaseT│ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ │ HDBaseT │ │
│ ETHERNET │ ←─ ─ ─ ─ ─ ─ ─ ─ →│ ETHERNET │ Cat.5e / Cat.6 │ ETHERNET│ ←─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ┘
└──────┘ │ │ │ │
┌────┐ │ │ │ │ ┌────┐
│ IR CABLE│ ←─ ─ ─ ─ ─ ─ ─ ─ →│ IR │ │ IR│ ←─ ─ ─ ─ ─ ─ ─ ─ ─ →│ IR CABLE│
└────┘ │ │ │ │ └────┘
┌────┐ │ │ │ │ ┌────┐
│ RS-232 │ ←─ ─ ─ ─ ─ ─ ─ ─ →│ RS-232 DC│ ←┐ ┌ →│ DC RS-232│ ←─ ─ ─ ─ ─ ─ ─ ─ ─ →│ RS-232 │
└ ─ ─ ─ ─ ┘ RS-232 CABLE └ ─ ─ ─ ─ ─ ─ ┘ │ │ └ ─ ─ ─ ─ ─ ─ ┘ RS-232 CABLE └ ─ ─ ─ ─ ┘
┌ ─ ─ ─ ─ ┐ ┌ ─ ─ ─ ─ ┐
│ DC 5V/2A│ │ DC 5V/2A│
└ ─ ─ ─ ─ ┘ └ ─ ─ ─ ─ ┘
Cable:
Link cable recommend use high quality Cat.5e、Cat.6、Cat.6a、Cat.7 UTP / STP or FTP cable.
Poor quality cable or network connection or improper construction will cause unstable
connection, video or sound disruptions, picture noise appears.
HDBaseT Distance chart by different cable:
Cable Type Range Pixel Clock Rate Video Data Rate Supported Video
100m <=225Mhz <=5.3Gbps
(HD Video) Up to 1080p 60Hz 12 bpp
CAT5e / CAT6 70m
CAT6a / CAT7 100m >225Mhz >5.3Gbps
(Ultra HD Video)
1080p 60Hz 16 bpp,
1080p 60Hz 3D,
4K x 2K 30Hz
If connection through the wall socket, the cable length must less 5 meters between H MI
extender and wall jack, as below drawing:
10/100Mbps network connection using general CAT5e cable and working distance up to 100M.
Transmitter
Wall Jack
Wall Jack
Receiver
MAX 100M
< 5M
< 5M

3
RJ45 Define:
LED Indication:
DC JACK Port:
Color LED Function EL-EX-H02NT EL-EX-H02NR
GREEN Power On: power on
BLUE IR Receive On: IR received signal
RED IR Emitter On: IR emitting
HDBaseT Port:
Color LED Function EL-EX-H02NT EL-EX-H02NR
GREEN HDBaseT Linking On: HDBaseT linking, Flash: Low power mode
BLUE Digital Audio
transmission On: Receiving ARC or digital audio signal
RED HDMI On: with HDCP, Dark: HDMI Unlink, Flash: Without
HDCP
10/100 Ethernet Port:
Color LED Function EL-EX-H02NT EL-EX-H02NR
GREEN Ethernet linking On: Linking, Flash: data transmission
YELLOW
No function
Low-power Mode:
If there is no any H MI video input, the product will enter a low-power mode to save power.
Under low power mode, Ethernet, RS-232, IR and ARC works properly.
Digital Audio Return:
This product supports the TV audio sent from H MI ARC (Audio Return Channel) or igital optical
audio mode, from the receiver back to the transmitter end.
EL-EX-H02NR: When ARC and optical digital inputs signals are present simultaneously, it will use
optical digital as priority transmission.

4
EL-EX-H02NT: When EL-EX-H02NT receives digital audio signal, it will be provided simultaneously
both ARC and optical digital.
Caution:
1. The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone,
microwave, radio equipment, fluorescent lamp, high voltage power lines.
2. This H BaseT port is not general Ethernet signal which also carry power, therefore do not
connect to Network to avoid damage.
3. IR transmitter and IR receiver must be placed in order to avoid mutual interference.
Panel view:
EL-EX-H0 NT
EL-EX-H0 NR
Package Includes:
Transmitter x 1 piece
Receiver x 1 piece
Power adapter x 1 piece
IR Emitter cable x 2 pieces
IR Receiver cable x 2 pieces
Specification:
ITEM NO. EL-EX-H02NT EL-EX-H02NR
HDMI Connector HDMI Type A x 1
HDMI Video Support Up to 1080p 60Hz 16 bits, 3D, 4K x 2K
HDMI Audio Support Up to LPCM 7.1, 192 KHz, Dolby TrueHD, DTS-HD, MA
HDBaseT Connector RJ45 x 1
HDBaseT Distance 100M (Max)
Ethernet Connector RJ45 x 1 (with 2 LED)
Ethernet Data Rate 10 / 100Mbps
Ethernet Distance 100M (Max)
RS-232 Connector DB9 Female DB9 Male
RS-232 Baud Rate Up to 115200 bps / Full Duplex
IR Connector 3.5mm Phone Jack x 2
IR Carrier 30-60KHz / T：± 15° / R：± 55° / 5M / 2 Way
Digital Audio Connector Optical (TOSLINK) TX Optical (TOSLINK) RX
Power Supply Regulated 5V 2A
Power Consumption 800mA (Max) 1200mA (Max)
Dimensions mm 88 x 120 x 30
Weight g 260 280
Rev. A
