ELRO Pro PV40-P2M2 User manual

PV40-P2M2 Manual version: A
HD VIDEO INTERCOM
2 APARTMENTS
PV40-P2M2

- 2 -
Table of contents
English..................................................................................................................................... - 3 -
Deutsch ..................................................................................................................................- 25 -
Nederlands .............................................................................................................................- 48 -
Français ..................................................................................................................................- 70 -

- 3 -
English – Instruction manual
Introduction ............................................................................................................................ - 5 -
Contents of the package .......................................................................................................... - 5 -
Product description ................................................................................................................. - 6 -
Outdoor unit ...............................................................................................................................- 6 -
Monitor.......................................................................................................................................- 7 -
Getting started ........................................................................................................................ - 8 -
Necessary materials ....................................................................................................................- 8 -
Step 1: outdoor unit....................................................................................................................- 8 -
Step 2: Monitor ...........................................................................................................................- 9 -
Using the video door intercom ...............................................................................................- 12 -
Main menu................................................................................................................................- 12 -
File management ......................................................................................................................- 13 -
Incoming calls............................................................................................................................- 14 -
Answering calls .....................................................................................................................- 15 -
Voicemail function ....................................................................................................................- 16 -
Activate voicemail function...................................................................................................- 16 -
Record outgoing messages ...................................................................................................- 16 -
Motion detection recording......................................................................................................- 17 -
Activate motion detection recording ....................................................................................- 17 -
Change settings.........................................................................................................................- 17 -
General settings ....................................................................................................................- 17 -
Time settings.........................................................................................................................- 20 -
Sound settings.......................................................................................................................- 20 -
Frequently asked questions (FAQ) ..........................................................................................- 21 -
Safety and conformity ............................................................................................................- 22 -
Technical specifications ..........................................................................................................- 22 -

- 4 -
Service and contact ................................................................................................................- 23 -
Would you rather watch a video in which the installation and use of this product are explained?
Then please visit www.elro.eu! There you will find the latest version of this manual, answers to
frequently asked questions, and more useful information.
Read this manual carefully and keep it in a safe place for future reference.

- 5 -
Introduction
Congratulations on the purchase of your new ELRO PRO PV40 HD Video Door Intercom. This set
consists of an outdoor unit with camera and 2 doorbells and 2 monitors, which makes it suitable to
use in two apartments or in two homes sharing a front door. The set can be upgraded with
additional monitors. (not included)
Contents of the package
1. Monitor (2x)
2. Outdoor unit with camera and 2
bellpushes
3. Adapter with 1.5 metre cable (2x)
4. Connection cable 15 metres (2x)
5. Connecting cable 50 cm (2x)
6. Mounting brackets Monitor (2x)
7. Mounting materials for monitor (2x)
a. Screws (2x)
b. Wall Plugs (2x)
c. Mini cables. Caution: these
small cables are not needed
to connect this set
and will remain unused.
8. Mounting materials for outdoor unit
a. Screws (2x)
b. Wall plugs (2x)
c. Double-pole cable clamp
d. Pricking tool
e. House number card (2x)
f. Hex screws (3x)
g. Hex key
h. Mini cable. Caution: these
small cables
are not needed to connect
this set
and will remain unused.
9. User manual

- 6 -
Product description
Outdoor unit
1. Microphone
2. Camera
3. IR LEDs for night vision
4. Doorbells
5. Speaker
6. Connection cable
7. Mounting plate
8. Hex screw

- 7 -
Monitor
Frontside
1. LED power indicator
2. Home button
3. Microphone
Side view
4. On/off switch
5. Speaker
6. Micro SD card slot
Backside
7. Connection panel

- 8 -
Getting started
Follow the steps below to connect this system quickly and easily. Tip: If you encounter any
problems during installation please visit www.elro.eu. There you will find installation videos,
answers to frequently asked questions, and the latest version of this manual among other things.
Necessary materials
For the installation you need:
•A small Philips screwdriver
•A drill and drill bits
•Marking-out materials
•A 5/8" PVC pipe
•Measuring tape
•A level
Step 1:outdoor unit
Start the installation by mounting the outdoor unit. Place the outdoor unit on a wall or on a frame,
preferably at 1.35 - 1.7 meters high (2). Caution: make sure the sun does not shine directly into the
lens.
1. Remove the mounting plate from the bell push
2. Take the mounting plate and mark the drill holes where the screws will be inserted. Then drill
two holes.
3. Mark the location of the hole where the wires will be inserted and drill a hole with a diameter
of 16 mm from the outside in. Drill approximately 10 degrees upwards diagonally.
4. We recommend to insert a 5/8" PVC pipe in the drill hole. This tube is available in most home
depots. Caution: If you need to drill through wood, use a speed drill with a diameter
comparable to that of the bell push wires.
5. Mount the mounting plate using the screws to the wall/frame.
6. Push the cables of the camera into the PVC pipe from the outside in.
oThe plugs with red, yellow, and blue wires are used for connecting an electric door
release.
oThe plugs with red, yellow, blue and white wires are used for connecting to the
monitors.

- 9 -
7. Place the camera on the mounting plate and attach the hex screw to the bottom of the bell
push. Now, the camera has been mounted to the mounting plate.
Step 2:Monitor
Connecting and mounting the monitors is the next step of the installation. The perfect mounting
height of a monitor is between 1.35 and 1.7 meters depending on the height of the users (1).
1. Take the mounting bracket for the monitor and mark the drill holes where the screws should
be inserted.
2. Drill two holes and mount the mounting bracket with the included materials.
3. Connect the bell push to the monitors:
a) Take the 50-cm connecting cable and link it to the outdoor unit's connection cable.
b) Take the 15-metre connection cable and link it to the 50-cm connecting cable.
c) Connect the other end of the connection cable to the monitor.
d) Link the cables with red, yellow, blue, and white wires to the included extension
cables.
e) Plug the connectors of the extension cables into the monitor (top right, AD1)
4. Plug the adapter into the monitor (bottom left, GND) and into a power socket.
5. Carefully slide the monitor over the hooks of the mounting bracket. Now, the video door
intercom is ready to use!
Repeat these steps to mount the second monitor.

- 10 -
Connection diagram and electric lock
Below you will find the comprehensive connection diagrams for extra monitors or door locks.
Based on safety guidelines, we recommend to connect an electric door release via the monitor.
This diagram also indicates how to link a second monitor (1). The electric door release can also be
released using the second monitor. The 2 connecting cables (2) are not used if no electric door
release is linked during the installation. In this case, use the cable clamps (2) to seal the separate
brown KEY1 wires.

- 11 -
An externally powered electric door release (AC/DC 5V ~ 24V) can be connected via the bell
push/camera optionally. Check the NO red and blue or NC blue and yellow connection. Consult the
lock's user manual for the right connection.

- 12 -
Using the video door intercom
Now that the outdoor unit and the monitors have been connected and powered it is time to setup
the system. Slide the on/off switch (see chapter Monitor Product Overview) on the monitor
upwards to power the system.
Main menu
The main menu provides access to the submenus below. Press the home button (see chapter
Monitor Product Overview) to go from standby mode to the main menu, to go back from a sub
menu to the main menu, or to go from the main menu to standby mode.
1.
Time and date
Display current time and date

- 13 -
2.
Monitor
Listen along with other monitors. Caution: this functionality
only works if several monitors are connected.
3.
Broadcasting
Communicate via the other monitor. The sound is recorded
and played live on the other monitor. Caution: This
function is only available if multiple monitors are
connected.
4.
Recording
Press the Record icon to start a sound recording and press
it again to end the sound recording. You can listen to sound
recordings via the Message menu. Caution: this function is
only available if a micro SD card is inserted.
5.
Settings
Change settings.
6.
View
View live images from the outdoor unit. Via the View menu
you can also change display settings such as volume,
contrast, brightness, and opacity (colour). Aside from that,
in this menu you can also open the gate and door, talk to
someone outside, take pictures, and record videos.
7.
Calling
Call a monitor in another room.
8.
Recording
Watch video recordings which were earlier recorded by the
outdoor unit. Caution: this function is only available if a
micro SD card is inserted.
9.
Music
Play music from the micro SD card. Caution: this function
only works if a micro SD card is inserted.
10.
Clock
Display calendar and time in standby mode.
11.
Message
Listen to voice messages from visitors and yourself.
12.
Camera
Look at images made by the outdoor unit and saved in the
monitor's internal memory.
13.
This allows you to look at photo's saved on the micro SD
card. Moreover, you will see a slideshow of all the pictures
saved on the SD card. This enables you to transform your
monitor into a digital picture frame!
File management
When files are saved they are stored in different locations. Here you can read how to manage and
remove them.
1. Displaying files:
a. Swipe left / right on the screen to display the last / next file;

- 14 -
b. Swipe up to return;
c. Tap the screen to adjust the volume.
2. In the Files menu, swipe the slides up /down to see more pictures. This can also be done by
pressing the arrow buttons.
3. Files can be removed by pressing and then by selecting the images you want to remove.
Subsequently, you press again and you are asked if you are sure you would like to
remove the files.
Incoming calls
When the bell is rung both the monitor and the outdoor unit play a ringtone (selection of 13
melodies included) until the call is answered. The duration of the ringtone can be set between 10
and 60 seconds in the sound settings menu. The outdoor unit automatically takes a picture when
the bell is rung. This picture is saved in the monitor's internal memory, which has the capacity to
store 100 pictures. You can view the pictures stored in the internal memory via the Camera menu.
If a micro SD card is inserted in the monitor, pictures are automatically saved there. Pictures saved
in the internal (flash) memory can be transferred to the micro SD card. When the outdoor unit has
taken a new photo, after receiving an incoming call, a red ball indicator becomes visible at Camera
in the main menu to indicate that a new, unseen picture has been saved.

- 15 -
Answering calls
Both the monitor and the outdoor unit play a melody when a visitor rings the bell, and the
message INCOMING CALL is displayed on the monitor.
1. Press to answer the call and talk with the visitor. The green telephone receiver icon now
changes into a By pressing on the microphone you can activate or deactivate the
microphone.
2. Press to end or reject the call.
3. Press to take a picture. Pictures are saved in the monitor's internal memory or on an
inserted SD card.
4. Press to record a video. This function only works if a micro SD card is inserted. A red ball
indicator is now visible in the main menu to indicate that a new, unseen video has been
saved.
5. Press to release the door. This function is only available if an electric door release is
connected.
6. Press to release the gate. This function is only available if a gate lock release is connected.

- 16 -
7. By pressing you change the point of view. (only available if more than one camera/bell
push is connected).
8. Press to forward a conversation to a second monitor (only available if more than one
monitor is connected).
9. Press to return to the main menu
10. Press to enter the video settings
If the call is not answered the monitor switches back to standby mode. The time you have to
answer incoming calls can be set at "Melody Duration" in the Settings menu.
Voicemail function
This video door intercom is equipped with a voicemail function. If an incoming call is rejected or
unanswered a standard message or message selected by the user, is played after the ringtone has
finished. Subsequently, the visitor is given the option to leave a message of approximately 20
seconds. This is followed by a closing message, selected by the user. If a visitor has left a message,
a red ball indicator becomes visible in the main menu at Message to indicate that a new message
has been saved.
Activate voicemail function
-Go to the Settings menu.
-Select .
-Swipe to the second page and activate the voicemail function by selecting "Leave automatic
message".
Record outgoing messages
The standard outgoing messages are saved in the monitor's internal memory and cannot be
changed. If you would like to record your own outgoing message, it is necessary to insert an SD
card in the monitor
1. In the main menu select Record and record your welcome message (e.g. "unfortunately,
your call cannot be answered right now but please leave a message after this message ends").
Select Record again to end the recording.
2. Repeat this step to record a concluding message (e.g. "Thank you for your message, we will
get in touch with you soon").
3. In the main menu at Message, a red ball indicator becomes visible to indicate that new
messages have been recorded.

- 17 -
4. Click Message in the main menu and select the recorded welcome message. As soon as
the welcome message starts playing tap on in this screen to configure the voicemail
function.
5. Subsequently, change the TONE TYPE from SYSTEM TONE to USER TONE.
6. Subsequently, for the welcome message select (WELCOME MESSAGE).
7. Return to the recorded messages, select your concluding message. As soon as the concluding
message starts playing tap on in this screen to configure the voicemail function.
8. Where you selected welcome message (STARTING TONE) before, you now select concluding
message (CONCLUDING TONE).
9. Here you can also set the volume of the voicemail function.
Motion detection recording
The motion detection recording function enables you to know at all times if someone is at your
front door. Once this function is enabled, the outdoor unit starts recording at set times if motion is
detected. The standard recording time is set to 1 minute. The motion sensitivity level of the
motion detector can be adjusted accordingly. Caution: A micro SD card is required to use this
function.
Activate motion detection recording
In order to enable the motion detection recording function, take the following instructions into
account:
-A micro SD card of at least 2 GB or more should be inserted in the monitor. For optimal
performance of the DVR function we recommend using a SD card of 8 GB or more.
-For high quality video select the 1280x720 resolution in the settings menu.
Follow the steps below to enable motion detection recording:
1. In the main menu select .
2. Subsequently select .
3. Then make sure to set DVR to ENABLE and activate Motion detect sensitivity.
4. Now the fuction is ready to use.
Change settings
Tap the left/right arrow to change the settings. Swipe up or down to scroll through the menu.
General settings
In this menu you will find the general settings of the device.

- 18 -
Language
Select a system language.
Do not disturb
No sound is played by the monitor during incoming
calls if do not disturb is enabled.
Listening on other monitors
Enable/disable the option to listen on other monitors
(relevant only if more than one monitor is connected).
Monitor unlock
Once this function is enabled, you can release the gate
or door in Watch mode. In this case, no incoming call is
required to release the door/gate.
Connection ports
This function is unavailable for this system.
Monitor location
Assign a room to the monitor (available selection:
rooms 1, 2, 3, or 4). Caution: room 1 must be assigned
to the main monitor.
Reset to factory settings
Reset to default settings.
Format flash memory
Remove all files stored in internal memory.
Format SD card
Remove all files stored on the micro SD card.
Copy to SD card
Copy all files from the internal memory to the SD card.
Automatic picture incoming
calls
Set how many pictures are taken during an incoming
call:
00: no automatic pictures
01: 1 automatic picture.
Leave automatic message
(Absence Assistant)
Enable if you want visitors to be able to leave a
message via the outdoor unit. This function works only
if an SD card is inserted. In order to use this function, a
welcome message and concluding message should be
recorded. If you decide not to, a standard message is
played.
Screensaver time
Set the time for the monitor to switch to standby
mode if inactive (between 30 seconds and 1 hour)
Software version
System software version

- 19 -
DVR
Enable/disable DVR function
FRAME RATE
Set the number of frames per second (5 - 10 -
15 - 20 – 25). More frames per second means
a higher streaming quality of recorded
videos.
SCREEN RESOLUTION
Set the screen resolution of video recordings
(640x480, 1280x720, 1920x1080). A higher
screen resolution means sharper video
quality.
MOTION DETECTION
Set the motion detector's sensitivity (off -
low - medium - high). This setting determines
at which degree of motion the camera starts
recording.
START TIME
Set at what time the DVR function switches
on.
END TIME
Set at what time the DVR function switches
off.
RECORDING LOCATION
Set to door 1.
SCREENSAVER TIME
On = The screen displays the time when the
DVR function is active and when the screen is
in standby mode.
Off = The screen is in standby mode only
when the DVR function is active. Nothing is
displayed on the monitor.
SCREENSAVER - MOTION
On = When the DVR function is enabled, the
monitor switches on if motion is detected. In
this case you can tell what caused motion
detection to be activated.
Off = The screen remains black when the
DVR function is enabled and if motion is
detected.

- 20 -
Time settings
In this menu you will find all the device's time settings. It also provides the option to set an alarm.
Current time
Set the current time (hour-minute-second).
Current date
Set the current date (day - month - year)
Alarm tone selection
Set an alarm tone. There are 13 available
melodies.
Alarm clock 1
Set an alarm. Choose the preferred time and
day (off-always-per day-time).
Alarm clock 2
Set an alarm. Choose the preferred time and
day (off-always-per day-time).
Alarm clock 3
Set an alarm. Choose the preferred time and
day (off-always-per day-time).
Alarm clock 4
Set an alarm. Choose the preferred time and
day (off-always-per day-time).
Sound settings
In this menu you will find all the device's sound settings.
Melody duration
Set the cancellation time for unanswered
calls. Once this time runs out, the incoming
call will be cancelled. An automatic message
is played if the absence assitance is enabled
(only if a micro SD card is inserted in the
monitor and the function is enabled).
Ringtone volume
Set the ringtone volume:
00 = Off
09 = Maximum volume
Door 1: Ringtone selection
Set the ringtone that is played when
someone rings at door 1.
