elsner elektronik KNX Touch One Style User manual

KNX Touch One Style
Technical specifications and installation instructions
Item number 70197
EN
T echnical support: +49 (0) 70 33 / 30 945-250
Elsner Elektronik GmbH Control and Automation Engineering
Sohlengrund 16
75395 Ostelsheim Phone [phone] / 30 945-0 [email protected]
Germany Fax [phone] www.elsner-elektronik.de

2 Field of application
Room Controller KNX Touch One Style • Status: 06.03.2017 • Errors excepted. Subject to technical changes
1. Field of application
The Room Controller KNX Touch One Style enables control of the KNX building
technology for one room by means of a touch-sensitive display screen. The unit pro-
vides integrated control functions which can also be directly set on the display (auto-
matic). Basic settings are made by the installer in the ETS.
The KNX Touch OneStyle with integrated indoor sensor (temperature, air humidity)
includes an internal automated operation function for shades (sun/privacy shades) and
room climate control (heating, cooling, ventilation), internal light control as well as bus
functions for time and scene control. 4 binary inputs enable the connection of conven-
tional buttons, switches and window contacts.
Eight universal pages with up to eight functions per page can be created to ensure the
orderly operation and display of the function and object assignments.
For remote control of the drives, one Remo 8 eight-channel wireless remote control
can be used with the KNX Touch OneStyle.
Functions
• Internal automatic shade controls (protection from the sun/privacy)
• Room climate control (heating, cooling, ventilation)
• Internal lighting control
• Integrated interior sensors (temperature, air humidity)
• Bus functions for time and scene control
• Universal menu to display and operate the function and object assignments
• Bus functions: Actuating variable comparators, multi-function modules
(computers), AND/OR logic
Configuration is made using the KNX software ETS. The product file can be down-
loaded from the Elsner Elektronik website on www.elsner-elektronik.de in the “Ser-
vice” menu.
1.1. Scope of delivery
• Central control and operation unit with colour touch-display screen, 5.7 inch
Integrated interior sensors (temperature, air humidity) and
4 binary inputs (e.g. for buttons)
• Data sheet
Accessories (not included in the scope of delivery):
• Radio remote control Remo 8
1.2. Technical Data
Housing Glass, plastic
Colour White/grey
Assembly Flush/cavity wall
Protection Class IP 20

3 Field of application
Room Controller KNX Touch One Style • Status: 06.03.2017 • Errors excepted. Subject to technical changes
* Concerning the accuracy of the measurement, please not chapter
Installation location
Please also take note that the displayed temperature value will be too high temporarily
after a power breakdown.
The product conforms with the provisions of EU directives.
Dimensions Display front approx. 181 × 131 (W × H, mm),
mounting depth approx. 8 mm,
concealed box approx. 172 × 122 × 81 (W × H × D, mm)
Weight approx. 765 g
Ambient temperature Operational 0 to +45°C, Storage -30 to +70°C,
Avoid condensation
Auxiliary supply 12...40 V DC / 14...28 V AC
Residual ripple 10 %
Auxiliary current at
100% display lighting
300 mA at 12 V DC 230 mA at 14 V AC
130 mA at 24 V DC 110 mA at 28 V AC
80 mA at 40 V DC
Auxiliary current at
0% display lighting
120 mA at 12 V DC 85 mA at 14 V AC
55 mA at 24 V DC 45 mA at 28 V AC
35 mA at 40 V DC
Power consumption For 100 % display lighting: max. 3.6 Watt
For 0 % display lighting: max. 1.5 Watt
Bus current max. 10 mA
Data output KNX +/- Bus connector terminal
BCU type TP UART
PEI type 0
Group addresses max. 1024
Assignments max. 1024
Communications objects 447 (Number 1 ... 532)
Temperature measurement
range*
0...+45°C
Resolution (temperature) 0.1°C
Humidity measurement
range
0...100 % RH
Resolution (humidity) 0,1 % RH
Accuracy (humidity) ± 7.5% RH at 0… 10% RH
± 4.5% RH at 10… 90% RH
± 7.5% RH at 90…100% RH

4 Installation
Room Controller KNX Touch One Style • Status: 06.03.2017 • Errors excepted. Subject to technical changes
2. Installation
2.1. Installation notes
Installation, testing, operational start-up and troubleshooting should
only be performed by an electrician.
CAUTION!
Live voltage!
There are unprotected live components inside the device.
• National legal regulations are to be followed.
• Ensure that all lines to be assembled are free of voltage and take
precautions against accidental switching on.
• Do not use the device if it is damaged.
• Take the device or system out of service and secure it against
unintentional use, if it can be assumed, that risk-free operation is no
longer guaranteed.
The device is only to be used for its intended purpose. Any improper modification or
failure to follow the operating instructions voids any and all warranty and guarantee
claims.
After unpacking the device, check it immediately for possible mechanical damage. If it
has been damaged in transport, inform the supplier immediately.
The device may only be used as a fixed-site installation; that means only when assem-
bled and after conclusion of all installation and operational start-up tasks and only in
the surroundings designated for it.
Elsner Elektronik is not liable for any changes in norms and standards which may occur
after publication of these operating instructions.
2.2. Installation location
The device must only be installed and used in dry, interior spac-
es. Avoid condensation.
The device is to be installed flush to the wall surface. When selecting an installation
location, please ensure that the measurement results of the integrated temperature/
humidity sensor are affected as little as possible by external influences. Possible sourc-
es of interference include:
• Direct sunlight
• Drafts from windows and doors
• Draft from ducts which lead from other rooms to the concealed box
• Warming or cooling of the building structure on which the device is mounted,
e.g. due to sunlight, heating or cold water pipes

5 Installation
Room Controller KNX Touch One Style • Status: 06.03.2017 • Errors excepted. Subject to technical changes
• Connection lines which lead from warmer or colder areas to the device
You can correct temperature and humidity variations from such sources of interference
on the ETS (temperature offset).
Cut-out dimensions for concealed box:
W = 166 mm +1 -0 | H = 116 mm +1 -0 | D = 80 mm
2.3. Preparing for installation
2.3.1. Wall-fitting
The display unit is held by magnets.
Remove the front part from the con-
cealed box.
Place the concealed box in the wall so
that the arrows point upwards.
For fitting, screw the cover (board) on
to the concealed box with the en-
closed screws.

6 Installation
Room Controller KNX Touch One Style • Status: 06.03.2017 • Errors excepted. Subject to technical changes
2.3.2. Cavity wall fitting
2.4. Assembling the operating unit
During electrical installation, please introduce all connection cables into the concealed
box through the lower or upper side wall.
By adjusting the mounting screws, the display unit will rest flat on the wall later and be
held by the magnets safely.
Connect the cables to the display and place the display unit on the concealed box. The
magnets must be attracted by the mounting screws considerably and the display unit
must rest tightly on the concealed box.
Clamp the concealed box to the wall
with the four enclosed screws.
Upon delivery, the pouch containing
the assembly screws can be found in
the control unit’s concealed box.
or
Adjust the screws of the magnetic
mounting with the enclosed template.
Each of the four screws must be ad-
justed individially in height.
When the edge of the template rests
on the wall surface (1), the template
must rest on the mounting screws as
well (2).
1
1
2

7 Installation
Room Controller KNX Touch One Style • Status: 06.03.2017 • Errors excepted. Subject to technical changes
2.5. Assigning connector terminals
2.6. Addressing the unit
The physical address is assigned using the display screen menu Settings > Phys. Ad-
dress. Press the buttons:
The Physical Address menu displays the current address and the status of the pro-
gramming LED (the address is 15.15.250 on delivery).
Plug 1:
Terminal 1, 2: Button interface 1
Terminal 3, 4: Button interface 2
Terminal 5, 6: Button interface 3
Terminal 7, 8: Button interface 4
Plug 2:
Terminal 1, 2:
VCC (Auxiliary voltage AC/DC)
Terminal 5: KNX +
Terminal 6: KNX -
1
2
Phys. Adrdess
Press the Programming button, in order to address the device to the bus.

8 Installation
Room Controller KNX Touch One Style • Status: 06.03.2017 • Errors excepted. Subject to technical changes
2.7. Maintenance and care
Finger marks on the touch screen are best removed with a damp cloth or a microfiber
cloth. You can wipe the buttons without activating them.
Do not use abrasives / detergents or aggressive cleaners for cleaning.
If there is a power outage, the data you have entered will be saved for around 10 years.
No battery is required for this.
