2 Description
GPS-DCF Converter UTC± • Date of issue: 17.05.2011 • Errors excepted. Subject to technical changes.
1. Description
The GPS-DCF Converter UTC± can be connected to a DCF77 signal input as an alter-
native to a DCF77 antenna. The device receives global UTC via GPS and converts this
information into the DCF77 protocol.
The UTC offset at he installation location is set with DIP switches in the device. The
GPS-DCF Converter UTC± then outputs the local time to the timer. When set to MEZ
(Central European Time), the summer/winter time change will take place automati-
cally.
1.0.1. Scope of delivery
• Converter in housing for surface mounting
1.1. Technical data
2. Installation and commissioning
2.1. Notes on installation
Installation, inspection, commissioning and troubleshooting of
the device must only be carried out by a competent electrician.
Disconnect all lines to be assembled, and take safety precautions against accidental
switch-on.
The device is exclusively intended for appropriate use. With each inappropriate change
or non-observance of the instructions for use, any warranty or guarantee claim will be
void.
After unpacking the device, check immediately for any mechanical damages. In case of
transport damage, this must immediately notified to the supplier.
If damaged, the device must not be put into operation.
Mounting Surface-mounted
Protection rating IP 54
Dimensions approx. 80 x 80 x 55 (W × H × D, mm)
Weight approx. 160 g
Auxiliary voltage 24 V DC
Auxiliary current 49 mA
DCF output +24 V / - / out

3 Installation and commissioning
GPS-DCF Converter UTC± • Date of issue: 17.05.2011 • Errors excepted. Subject to technical changes.
If an operation without risk may supposedly not be guaranteed, the device must be put
out of operation and be secured against accidental operation.
The device must only be operated as stationary system, i.e. only in a fitted state and
after completion of all installation and start-up works, and only in the environment in-
tended for this purpose.
Elsner Elektronik does not assume any liability for changes in standards after publica-
tion of this instruction manual.
2.2. Layout of the circuit board / Connection
Assignment DIP switches:
1 +/- (Setting of time offset, switch OFF: + | switch ON:-)
2 0,5 hours offset
3 1 hours offset
4 2 hours offset
5 4 hours offset
6 8 hours offset
The common time offset values can be reached by adding the values of the switches.
7MEZ/CET
If switch 7 is set to ON, the Central European Time is ouput, including automatic sum-
mer/winter time switch-over.
1
Fig. 1
1 LED indicator
“Transmit DCF”
2 LED indicator
“GPS Reception”
3 LED indicator
“Voltage Supply”
4 DIP switches
45 DCF Output
1: +24 V
2: -
3: out
2
3
5
4

4 Installation and commissioning
GPS-DCF Converter UTC± • Date of issue: 17.05.2011 • Errors excepted. Subject to technical changes.
Timer
Power
24 V DC
Converter
Fig. 2
Connection Example
supply
