elvita CDM6602V User manual

1
CDM6602V - 2023-02-23
CONTENTS/INNEHÅLL/INNHOLD/INDHOLD/SISÄLLYSLUETTELO/EFNISYFIRLIT
ENGLISH ................................................................................................................................................2
SVENSKA .............................................................................................................................................77
NORSK................................................................................................................................................151
DANSK.............................................................................................................................................. 227
SUOMI ............................................................................................................................................... 301
ÍSLENSKA .......................................................................................................................................... 375
You can find the latest updated manual online. Please go to elvita.se and use the search function and the product's model code
to find the manual.

2 Contents - ENGLISH
Contents
SAFETY 5
Admonitions .............................................................................................................................. 5
Intended use ............................................................................................................................. 5
Safety for children and people with disabilities........................................................................ 5
General safety........................................................................................................................... 6
Safety during installation .......................................................................................................... 6
Safety during operation ............................................................................................................ 7
Safety during maintenance ...................................................................................................... 8
Disposal..................................................................................................................................... 8
QUICK START 9
GETTING STARTED 13
Getting to know your dishwasher............................................................................................. 13
Controls................................................................................................................................................ 13
Symbols on the display....................................................................................................................... 13
Detergent dispenser and rinse aid dispenser ................................................................................... 13
Accessories.......................................................................................................................................... 14
Use the child lock ................................................................................................................................ 14
Find the model code............................................................................................................................ 15
Before first use .......................................................................................................................... 15
Adjust the water softener level ........................................................................................................... 15
Run an empty load.............................................................................................................................. 16
WASHING 17
Before each wash ..................................................................................................................... 17
Start washing ............................................................................................................................ 18
Add dishes during a wash ........................................................................................................ 18
Change programme during a wash ......................................................................................... 18
Purpose of detergent ................................................................................................................ 19
Fill the detergent dispenser....................................................................................................... 19
Purpose of rinse aid .................................................................................................................. 20
Fill the rinse aid dispenser......................................................................................................... 21
Adjust the rinse aid consumption ............................................................................................. 22
Purpose of salt for the water softener ...................................................................................... 22
Add salt to the water softener .................................................................................................. 22
After each wash........................................................................................................................ 25
Items suitable for use in dishwasher ........................................................................................ 27
Adjusting baskets and racks before loading ............................................................................ 28
Adjust the height of the upper basket................................................................................................ 28
Fold up and fold down the cup rack ................................................................................................. 29
Fold back the plate racks.................................................................................................................... 30
Loading the dishwasher efficiently ........................................................................................... 30
Guidelines for loading the upper basket ........................................................................................... 31
Guidelines for loading the lower basket ............................................................................................ 31

Contents - ENGLISH 3
Guidelines for loading the cutlery rack............................................................................................... 32
Guidelines for loading the cutlery basket .......................................................................................... 33
Options, settings and functions................................................................................................. 34
Use the Nozzle selector option........................................................................................................... 34
Use the Auto open function................................................................................................................ 34
Use the Delay function........................................................................................................................ 35
Programmes.............................................................................................................................. 35
90 min ................................................................................................................................................. 35
Auto ..................................................................................................................................................... 35
ECO ...................................................................................................................................................... 36
Glass ................................................................................................................................................... 36
Intensive .............................................................................................................................................. 37
Rapid ................................................................................................................................................... 37
Soak .................................................................................................................................................... 37
Universal ............................................................................................................................................. 38
CLEANING 39
Clean the door and door seals ................................................................................................. 39
Clean the spray arms................................................................................................................ 40
Remove and clean the filtering system..................................................................................... 42
Prepare for longer periods of non-use ..................................................................................... 45
Prepare for frost ........................................................................................................................ 47
TROUBLESHOOTING 50
The machine does not start ...................................................................................................... 50
Water is not pumped out of dishwasher .................................................................................. 50
Residue, deposits and stains..................................................................................................... 50
Suds in the tub..................................................................................................................................... 50
Stained dishwasher interior................................................................................................................ 51
White film on inside surface................................................................................................................ 51
Detergent left in dispenser.................................................................................................................. 51
Noises........................................................................................................................................ 51
Knocking noise in the dishwasher ..................................................................................................... 51
Rattling noise in the dishwasher ........................................................................................................ 51
Knocking noise in the water pipes ..................................................................................................... 51
Dirty dishes................................................................................................................................ 51
The dishes are not clean..................................................................................................................... 51
Cloudiness on glassware.................................................................................................................... 52
There are rust stains on the cutlery .................................................................................................... 52
White spots appear on dishes and glasses ...................................................................................... 52
Black or grey marks on dishes ........................................................................................................... 52
The dishes are not drying ................................................................................................................... 52
Error messages.......................................................................................................................... 53
The E1 error code is displayed ............................................................................................................ 53
The E3 error code is displayed............................................................................................................ 53
The E4 error code is displayed............................................................................................................ 54
The E8 error code is displayed............................................................................................................ 54

4 Contents - ENGLISH
The Ed error code is displayed ........................................................................................................... 55
INSTALLATION 56
Unpack the machine................................................................................................................. 56
Connect the cold-water supply hose to a tap .......................................................................... 59
Connect the safety supply hose to a tap .................................................................................. 60
Connect to an external drain .................................................................................................... 61
Position the drain hose into a floor drain........................................................................................... 62
Connect the drain hose to a sink drain pipe...................................................................................... 62
Position the drain hose into a sink ..................................................................................................... 62
Connecting to the electrical supply........................................................................................... 62
Position the machine................................................................................................................. 63
Fit the condensation strip.......................................................................................................... 65
Change to the longer feet......................................................................................................... 65
Level the machine ..................................................................................................................... 67
Adjust the door spring tension.................................................................................................. 68
Secure the machine in place - for normal work surfaces......................................................... 69
Secure the machine in place - for marble or granite surfaces................................................. 70
Install the kick plate .................................................................................................................. 71
SPECIFICATIONS 73
Technical specifications............................................................................................................. 73
Dimensions................................................................................................................................ 74
Consumption values.................................................................................................................. 74
EU directives and standards...................................................................................................... 75

Safety - ENGLISH 5
SAFETY
Carefully read the instructions before you install and use the product. Save the instructions and keep them near the
product for future reference. All kinds of warranties shall be invalid if these instructions are not followed.
Admonitions
WARNING!
Used when there is a risk for personal injury.
CAUTION!
Used when there is a risk for damage to the product.
NOTE!
General information that you should be aware of.
Helpful tips that you may find useful.
Intended use
This product is only intended for indoor use in a household or a household environment such as:
• staff kitchen areas in shops, offices and other working environments;
• farm houses;
• by clients in hotels, motels and other residential type environments;
• bed and breakfast type environments.
Safety for children and people with disabilities
WARNING!
Only let the following groups use the product if they are supervised or if instructions are provided to them
about how to use the product in a safe way. They must understand the hazards involved.
• Children. (Children younger than 8 years old must be continuously supervised.)
• People with reduced physical, sensory or mental capabilities.
• People with lack of experience and knowledge.
WARNING!
• Do not let children play with the product.
• Do not let children clean the product without supervision.
WARNING!
Remove the packaging material, as it can be dangerous for children.
WARNING!
Keep dishwasher detergent out of the reach of children. Dishwasher detergent is corrosive.

6 Safety - ENGLISH
General safety
WARNING!
• Installation and repair must only be carried out by a qualified technician.
• Some dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid
contact with the skin and eyes and keep children away from the dishwasher when the door is open.
• If an overflow occurs, turn off the main water supply before calling for service.
• If there is water in the base of the dishwasher due to overfilling or a small leak, the water should be
removed before restarting the dishwasher.
• Do not place any heavy objects on, or stand on, the door when it is open. The product could tip forward.
WARNING!
Do not leave the door in the open position since this could present a tripping hazard.
WARNING!
Risk of electric shock!
• Disconnect electrical power before installing the dishwasher. Failure to do so could result in death or
electrical shock.
• Do not immerse the unit, power cord, or plug in water or other liquid.
• This product must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
an electric shock by providing a path of least resistance for electric current. This product is equipped with
a plug with an earthing conductor.
CAUTION!
• Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent. For plastic items
that do not have this marking, check the manufacturer’s recommendations.
• Use only detergent and rinse agents recommended for use in a dishwasher.
• Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
• Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
• Do not tamper with the controls when loading items to be washed.
Safety during installation
WARNING!
• Electrical equipment must be installed by professionals.
• Hoses should be installed by professionals.
WARNING!
Risk for electric shock!
• Disconnect electrical power before installing the product. Failure to do so could result in death or
electrical shock.
• The plug must be plugged into an appropriate power socket that is installed and earthed in accordance
with all local laws and regulations.
• Improper connection of the earthing conductor can result in the risk of an electric shock.
• Check with a qualified electrician or service representative if you are in doubt whether the product is
properly earthed.
• Do not modify the plug provided with the product if it does not fit the power socket.
• Have a proper power socket installed by a qualified electrician.
• Ensure the dishwasher is correctly earthed before use.
• Do not use an extension cord or an adapter plug with this product.
• Do not, under any circumstances, cut or remove the earthing connection from the power cord.
• Take care to avoid kinking or crushing the power cord.

Safety - ENGLISH 7
CAUTION!
• The inlet water pressure must be between 0.04MPa and 1MPa.
• The product must be connected to the water supply using new hoses. Do not reuse old hoses.
• If the water pipes are new or have not been used for an extended period of time, let the water run to
make sure that the water is clear. This precaution is necessary to avoid the risk of the water inlet
becoming blocked and damaging the product.
• If your sink has a spray jet fed by a hose that is connected to the same water line as the dishwasher the
safety supply hose could burst. If your sink has one, it is recommended that the safety supply hose is
disconnected and the hole plugged.
CAUTION!
The product must not be tilted more than 2°.
Safety during operation
WARNING!
Do not operate your dishwasher unless all enclosure panels are properly in place.
WARNING!
• Do not let any item stick through the basket bottom.
• Knives and other utensils with sharp points must be loaded in the basket with their points facing down or
placed in a horizontal position.
WARNING!
Keep dishwasher detergent out of the reach of children. Dishwasher detergent is corrosive.
WARNING!
• It is dangerous to open the door mid-cycle, as hot steam may scald you.
• Open the door very carefully if the dishwasher is operating. There is a risk of water squirting out.
• When removing dishes items will be hot. Wait 15 minutes after the programme has ended before
removing glass or cutlery.
CAUTION!
If the water pipes are new or have not been used for an extended period of time, let the water run to make
sure that the water is clear. This precaution is necessary to avoid the risk of the water inlet becoming blocked
and damaging the product.
CAUTION!
• Only use detergent that is specifically intended for dishwasher use. Keep your detergent fresh and dry.
• Do not put powdered detergent into the dispenser until you are ready to wash dishes.
• Only use branded rinse aid that is formulated for dishwashers. Never fill the rinse aid dispenser with any
other substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage the product.
• Only use salt specifically designed for dishwasher use. Any other type of salt that is not specifically
designed for dishwasher use, especially table salt, will damage the water softener. The manufacturer’s
warranty does not cover any damage that results from the use of unsuitable salt.
• Only fill with salt before running a cycle. This will prevent any grains of salt or salty water that may have
been spilled from remaining on the bottom of the machine for any period of time, which may cause
corrosion.
CAUTION!
• When cleaning the filters, do not over-tighten the filters. Refit the filters securely in the correct order,
otherwise coarse debris could get into the system and cause a blockage.
• Never use the dishwasher without the filters in place. Incorrect replacement of the filters may reduce the
performance of the product and damage dishes and utensils.

8 Safety - ENGLISH
CAUTION!
Place sharp items so that they are not likely to damage the door seal.
Washing dishes using this dishwasher consumes less energy and water than doing it by hand, provided
that you use the machine for household purposes and follow the instructions in this manual.
Safety during maintenance
WARNING!
• Installation and repair must only be carried out by a qualified technician.
• Any repair performed by someone who is not a qualified technician puts the users of the product at risk
of personal injury.
• Any warranty claim resulting from repairs performed by someone who is not a qualified technician shall
not be covered by the warranty.
• If the power cord is damaged, it must be replaced by the manufacturer, the manufacturer’s service agent
or a similarly qualified person in order to avoid a hazard.
WARNING!
Disconnect the product from the mains before cleaning and carrying out maintenance on the product.
CAUTION!
• To avoid penetration of water into the door lock and electrical components, do not use a spray cleaner of
any kind.
• Do not use solvents or abrasive cleaning products to clean the exterior and rubber parts of the
dishwasher.
• Never use abrasive cleaners or scouring pads on the outer surfaces, as they may scratch the finish.
Some paper towels may also scratch or leave marks on the surface.
CAUTION!
• When cleaning the filters, do not over-tighten the filters. Refit the filters securely in the correct order,
otherwise coarse debris could get into the system and cause a blockage.
• Never use the dishwasher without the filters in place. Incorrect replacement of the filters may reduce the
performance of the product and damage dishes and utensils.
Disposal
Before you dispose of the product, cut off the power cord and ensure that the door lock is disabled.
Dispose of packaging in an environmentally-friendly manner. Recycling packaging, while observing national
and local regulations, can reduce the consumption of raw materials and the amount of waste in landfill
sites.
This product is marked in compliance with European Directive 2012/19/EU, Waste Electrical and Electronic
Equipment (WEEE). The symbol on the product or on its packaging indicates that this product should not be
treated as household waste. Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product, please contact the relevant
municipal body in charge of waste management, your household waste disposal service or the store where
you purchased the product.

Quick start - ENGLISH 9
QUICK START
Before washing

10 Quick start - ENGLISH
* Optional
Washing

Quick start - ENGLISH 11
After washing

12 Quick start - ENGLISH

Getting started - ENGLISH 13
GETTING STARTED
Getting to know your dishwasher
Controls
A. On/Off
B. Display
C. Programme selector
D. Options, settings, and functions
E. Start/Pause
Symbols on the display
Auto Intensive Universal ECO
Glass 90 min Rapid Soak
Upper nozzle Lower nozzle Child lock Rinse aid
Salt Auto open
Detergent dispenser and rinse aid dispenser
A. Detergent dispenser
B. Rinse aid dispenser

14 Getting started - ENGLISH
WARNING!
Do not use soap, laundry detergent, or hand washing detergent in your dishwasher. Only use detergent and
rinse aid that is specifically intended for dishwasher use.
Accessories
A. Safety supply hose
B. Drain hose holder
C. Salt funnel
D. Measuring cup
E. Kick plate
F. Mounting brackets
G. Longer feet
Safety supply hose For connecting the dishwasher to the water supply.
Drain hose holder For securing the hose and avoiding kinks, for example when placing the hose over
the edge of a sink.
Salt funnel For adding salt to the water softener.
Measuring cup For measuring the correct amount of powder detergent.
Kick plate For covering the service panel under the dishwasher door.
Mounting brackets For installing the kick plate.
Longer feet For increasing the height of the machine.
Use the child lock
Activate the child lock to avoid accidental operation by children.
1. Press and hold and for 3 seconds until the indicator light is lit.
All buttons except are now locked.
2. Press and hold and for 3 seconds to deactivate the child lock.
NOTE! Turning the power off and on will deactivate the child lock.

Getting started - ENGLISH 15
Find the model code
The model code is printed on a label on the product. You need the code to find the complete and most recent information,
service and support for your product model.
NOTE!
This product and label text are examples. Your product and text may have a different look and content.
Before first use
CAUTION!
Before washing, make sure the dishwasher is correctly installed.
You need to add salt to the water softener to remove minerals and salts from the water that would have an adverse effect
on the operation of the dishwasher. See section "Add salt to the water softener", page 22.
Adjust the water softener level
Set the water softener level according to the hardness of the water in your area. See the following table to select the
appropriate level. Your local water authority can advise you on the local water hardness.
Water hardness Water softener
level
Regeneration
occurrence*
Salt
consumption
(grams/cycle)
German °dH French °fH British °Clarke mmol/l
0-5 0-9 0-6 0-0.94 H1 is displayed No
regeneration
0
6 - 11 10 - 20 7 - 14 1.0 - 2.0 H2 is displayed 10 9
12 - 17 21 - 30 15 - 21 2.1 - 3.0 H3 is displayed 5 12
18 - 22 31 - 40 22 - 28 3.1 - 4.0 H4 is displayed 3 20
23 - 34 41 - 60 29 - 42 4.1 - 6.0 H5 is displayed 2 30
35 - 55 61 - 98 43 - 69 6.1 - 9.8 H6 is displayed 1 60
*Regeneration occurs every X programme sequence.
NOTE!
Every cycle with a regeneration operation increases the water consumption by 2.0litres of water, the energy
consumption by 0.02kWh, and the programme duration by 4minutes.

16 Getting started - ENGLISH
1. Close the door.
2. Press to turn on the machine.
3. Within 60 seconds, press and hold for more than 5 seconds to enter the water softener setup mode.
4. Press to cycle through the available water softener levels (H1,H2,H3 (default), H4,H5,H6).
5. Press to confirm and to exit the water softener setup mode.
You will exit the water softener setup mode if you leave the settings unchanged for 5seconds.
Run an empty load
Make sure that the machine is installed properly.
1. Plug in the power cord.
2. Open the water tap.
3. Start a programme.
NOTE! Do not put any dishes in the machine.
The machine is ready for use when the programme has been completed.

Washing - ENGLISH 17
WASHING
Before each wash
1. Check if the items are dishwasher-safe. See section "Items suitable for use in dishwasher", page 27.
2. Remove scraps of leftover food.
NOTE! It is not recommended to rinse the dishes under running water. This leads to increased water and energy
consumption.
3. Soften remnants of burnt food in pans by soaking them in water.

18 Washing - ENGLISH
Start washing
NOTE!
To save energy, in standby mode, the dishwasher will automatically turn off if it has not been used for 15
minutes.
1. Turn on the water supply.
2. Slide out the lower and upper baskets.
3. Load the dishes.
WARNING! Knives and other utensils with sharp points must be loaded in the basket with their points facing
down or placed in a horizontal position.
4. Push the lower and upper baskets back.
5. Add detergent in the detergent dispenser. See section "Fill the detergent dispenser", page 19.
NOTE! Only use detergents recommended for use in dishwasher. Never use soap, laundry detergent or hand
washing detergent in the dishwasher.
6. Close the door.
7. Press to turn on the power.
8. Press to select a programme.
The selected programme's indicator light is lit.
9. Select settings and options if needed.
10. Press to start the wash cycle.
When the washing is completed an acoustic signal sounds and the dishwasher door opens.
NOTE!
The dishwasher door only opens if the Auto open function is being used.
WARNING!
Do not empty your dishwasher immediately after washing, items will be hot. Wait for 15 minutes before
emptying the dishwasher.
Add dishes during a wash
You can add more dishes to a wash any time before the detergent dispenser opens.
WARNING!
It is dangerous to open the door mid-cycle, as hot steam may scald you.
1. Press to pause the wash cycle.
2. Wait for 5 seconds and then open the door.
3. Add the dishes.
4. Close the door.
5. Press to resume washing.
Change programme during a wash
You can change the programme any time by performing a reset.
1. Press to pause the wash cycle.
2. Press and hold for more than 3 seconds to cancel the programme.
3. Check if the detergent dispenser is open. If it is open, refill the detergent dispenser with detergent.

Washing - ENGLISH 19
4. Press to select a programme.
5. Press to start the wash cycle.
After 10 seconds the dishwasher will start.
Purpose of detergent
The chemical ingredients in the detergent are necessary to remove, dissolve and flush all dirt out of the dishwasher. Most
commercial-quality dishwasher detergents are suitable for this purpose.
Fill the detergent dispenser
CAUTION!
Only use detergent that is specifically intended for dishwasher use. Keep your detergent fresh and dry. Do not
put powdered detergent into the dispenser until you are ready to wash dishes.
1. Open the door.
2. Slide the release catch to open the detergent dispenser.

20 Washing - ENGLISH
3. The cap moves forward.
4. Add detergent for the main wash cycle to the cavity.
For better cleaning result, especially if you have very dirty items, pour a small amount of detergent
onto the door. The additional detergent will be used during the pre-wash phase.
5. Slide and then press down to close the cap.
Purpose of rinse aid
Rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots
and streaks. It also improves drying by allowing water to run off the dishes. Your dishwasher is designed to use liquid
rinse aids.
