EmberGlo ES5 Series Quick guide

Installation and Service Instructions
Quality Designed for Proven Performance Printed in USA
8449 96
AVOID ERROR IN PARTS SELECTION. When ordering use
complete EMBERGLO Part Number and Description. Furnish
Model Number, Bill of Material Number and Serial Number (if
available) from the specifi cation plate found on the product.
IMPORTANT: Availability of parts as well as specifi cations are
subject to change without notice. Please consult factory for
item availability.
SAFETY INFORMATION TERMS: The following terms are used to identify hazards, safety precaution of
special notations and have standard meanings throughout this manual. They are printed in all capital letters
using a bold type face as shown below, and preceded by the exclamation mark symbol. When you see the
safety alert symbol and one of the safety information terms as shown below, be aware of the hazard potential.
DANGER: Identifi es the most serious hazards which will result in severe personal injury or
death.
WARNING: Signifi es a hazard that could result in personal injury or death.
CAUTION: Identifi es unsafe practices which would result in minor personal injury or product and
property damage.
ES5 Series - Designed to operate without distilled water,
Self Contained or Direct Water Hookup, Stainless steel
construction
Specifi cations:
• 120 volts 60HZ AC 1500 watts, max 12.5 amp
• ES5 1800 series - 1800 watts, max 15 amps
• Manual pump (push button) or timer operation
• Closed generator
• Half Pan size
• Removable water drawer (self contained models)
• Spring loaded adjustable hinge with 60° or 90° opening
• Food Grid
• ES5 1800 series - 1800 watts, max 15 amps
• ES5 1800 series - 20% faster temperature recovery time
• Quick connect fi ttings (direct hookup models)
This manual contains suffi cient information for installation of the
EmberGlo Steamer in normal locations.
In the United States, installation must conform with local codes.
PURCHASER: Retain these instructions for future use.
Post in a prominent location near the steamer.
ES5 Series
Top Open / Half Pan
Counter Top Steamer
C
O
M
P
A
N
Y
R
E
G
I
S
T
E
R
E
D
EmberGlo
A Div of Midco® International Inc.
4140 West Victoria Street
Chicago, Illinois 60646
toll free 866.705.0514
tel 773.604.8700
fax 866.580.8700
web www.emberglo.com
e-mail [email protected]
CAUTION: Cooking equipment should be used in
an environment protected by an automatic fi re suppression
system. Consult the National Fire Protection Association NFPA
Code 96 or the latest edition of Standards for Installation of
Equipment for Removal of Smoke and Grease-Laden Vapors
From Commercial Cooking Equipment.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operating
and maintenance instructions thoroughly before
installing or servicing this equipment.
Warranty
See the back of this manual for warranty.
This warranty does not apply to damages resulting from
accident, misuse, abuse or alteration.
No equipment may be returned without written authorization
from EmberGlo (or Midco). Returned goods must be shipped
prepaid to the factory.
Warranty card must be fi lled in and returned to EmberGlo (or
Midco) to validate warranty.
U
L
®
Model ES5M
MADE in the USA
ES5 Series - 1500W
ES5CTS: Timer Operation with Water Pan
ES5M: Manual Operation with Water Pan
ES5MT Manual Operation with Water Pan
and Specially Perforated Tortilla Food Pan
ES5PBS: Push Button Operation with Water Pan
ES5PCS: Fixed Timer Operation with Water Pan
ES5PB: Push Button Operation with Direct Water Connect
ES5CT: Timer Operation with Direct Water Connect
ES5PC: Fixed Timer Operation with Direct Water Connect
ES5 1800 Series - 1800W
ES5M18: Manual Operation with Water Pan
ES5CTS18: Timer Operation with Water Pan
ES5PBS18: Push Button Operation with Water Pan
ES5CT18: Timer Operation with Direct Water Connect
ES5PB18: Push Button Operation with Direct Water Connect
As of June 2013 the following steamers are no longer being
manufactured - they are replaced with CT series steamers
ES5TS - now ES5CTS
ES5T - now ES5CT
ES5PTS - now Obsolete
As an ISO 9001:2008 certified company, we proudly design, manufacture and assemble our products in Chicago, Illinois, USA. 517

2EmberGlo A Division of Midco International Inc 8449 96
Installation In the United States, wiring must conform to local codes, or in the absence of local codes, to the
National Electrical code ANSI/NFPA No. 70-latest edition. In Canada, wiring must conform to
local codes, or in the absence of local codes, to Canadian Electrical Code Part 1, CSA Standard
C22.1.
1. All ES5 Models: Locate on level surface and plug power cord into 120 volt, single phase 60Hz.
grounded outlet.
2. ES5M, ES5M18, ES5MT, ES5CTS, ES5CTS18, ES5PBS & ES5PCS: Fill water pan by pulling
water pan out to stop position and fi ll with cold water to top of baffl es, then close drawer.
3. ES5PB, ES5PB18, ES5CT, ES5CT18, & ES5PC: Connect water hose assembly to water
supply system. The supply end has 1/8″ female pipe fi tting and should be attached down
stream to a shut-off valve. Steamer end of hose has a quick connect fi tting which snaps onto
mating fi tting on steamer. This fi tting has an automatic shut-off valve that allows steamer to be
disconnected without shutting off water supply. After connecting, turn on water and check for
leaks.
4. EmberGlo Steamers do not require a separate hood for vapor produced during operation
according to the Uniform Mechanical Codes per the International Conference of Building
Offi cials Code. And there are no requirements in NSF Standard 4 (2006e) for steamers to
have ventilation.
5. Lid Angle Adjustment: To adjust the angle of the lid to 60° or 90°
1. With the lid closed, loosen and remove slotted screw. Set aside.
2. Remove lid stop by sliding it up and away from the steamer.
3. Adjust lid stop for desired position (60° or 90° open) and place on steamer.
4. Insert and tighten slotted screw.
See Figure 1a, 1b and Figure 1c for orientation of lid stop.
Factory default setting is 60°.
__________________________________________
General Instructions for Operation. For operation tips and recommendations see below.
Before Using: (See Figure 2 for locations of buttons and switches)
1. Remove the protective plastic covering before using.
2. Steamers with self contained water drawers: If there is a water drawer open and fi ll reservoir
with water.
3. Steamers with direct hookup water supply: If the steamer is a direct hookup connect to a
water supply
4. Plug into 120V AC outlet.
5. Push power switch to the ON position (light on) and allow approximately 15-20 minutes to reach
operating temperature.
6. Test to make sure unit will generate steam (except the ES5PCS and ES5PC).
7. For ES5CT, ES5CT18, ES5CTS & ES5CTS18 steamers: Switch the Cycle/Manual switch to
the manual mode.
Operation
ES5 Series - Installation
MADE in the USA
Figure 1a
Back of ES Series Steamer
60° Opening Position
Figure 1b
Back of ES Series Steamer
Lid Stop Reversed
90° Opening Position
1
2
1
2
Item # Part # Description
1 HW1-099 #8-32 X 5/16″ Slotted
Pan Head Screw 18ss
2 1421-21 Lid Stop
90°
60°
Figure 1c

EmberGlo A Division of Midco International Inc
8449 96 3
ES5 Series - Operation
Operation
Continued
8. Press the round Steam button several times to remove the air from the system, you will notice it
will start to steam. The Steamer is now ready to use.
General Operating Instructions: (See Figure 2 for locations of buttons and switches on timer
models)
1. Open lid, place food on grid and close lid.
2. ES5M, ES5M18 & ES5MT: Press handle until it stops - then release. See Heating and
Cooking Guide - 8474-75S for suggested number of operations or “shots” (a shot is one press
of pump handle).
ES5PB, ES5PB18, ES5PBS & ES5PBS18: Push round button momentarily for each operation.
Do not hold button more than one second.
Note: After installation, operate several times until the water hose fi lls with water.
ES5CT, ES5CT18, ES5CTS & ES5CTS18: (see Timer/Manual Operating Instructions below)
Operate the same as ES5PB & ES5PB18 above, or follow directions on label on front of unit
which will automatically deliver three shots per minute for time set. At end of cooking time,
READY light will come ON and signal will sound. Turn toggle switch to OFF to silence signal.
ES5PC & ES5PCS (Preset Timer Models): Operates by pressing the round button to start
thecook cycle. At the end of the cook cycle the READY light will come ON and the signal will
sound.
3. Open lid and remove food.
4. For effi ciency and safety purposes, keep lid closed when not in use. This keeps the food pan
hot and reduces condensation in the steam chamber.
5. To shut off , push power switch to OFF position.
Timer Operating Instructions with ES5CT, ES5CT18, ES5CTS & ES5CTS18 timer steamers: (See
Figure 2 for locations of buttons and switches)
1. ES5CTS & ES5CTS18: Fill the water reservoir at the beginning of each day. During use check
the water reservoir periodically.
2. Turn unit on, the Ready indicator will light.
3. Allow the steamer warm up for about 10 minutes.
4. Move the Cycle/Manual switch to the cycle mode.
5. Lift the lid and place product on the rack, close lid.
6. Rotate the timer dial to the desired cooking time.
7. Press the round Steam button to start the cooking cycle (the ready light will go out). Move the
buzzer toggle switch to on position. Note: The steamer will automatically generate steam about
every 15/20 seconds.
8. After the cycle has been completed, the Ready indicator light will turn on and the buzzer will
sound indicating the cycle is done. Use the buzzer switch to turn off the buzzer.
9. Open the lid, carefully remove the very hot product.
10. The steamer is now ready for another cycle.
Manual Operating Instructions with a ES5CT, ES5CT18, ES5CTS & ES5CTS18:
1. Move the “Cycle/Manual” switch to the “Manual” mode.
2. Depress Round Steam push button approximately 1 second. Note: Excessive pressing of the
steam button will fl ood the steam chamber.
1 65432
Item # Description
1. Steam Button - starts cycle timer or for manual steaming
2. Cycle/Manual Switch -
Cycle is for position for timer usage
Manual is for push button steaming
3. Cycle Timer - used to adjust cycle time
4. Signal Switch - turns on/off ‘Cycle Done’ buzzer
5. Ready Light - lights at the end of cycle time
6. Power Switch - turn on before usage for approximately 10 minutes to warm steamer
Figure 2
ES5CT, ES5CT18, ES5CTS & ES5CTS18 Steamers - Front Panel

4EmberGlo A Division of Midco International Inc 8449 96
ES5 Series - Schematic & Wiring Diagrams
L1 NLGND
BLK
BLK
WHT
THERMOSTAT
OPEN @ 350°F
THERMAL
FUSE
HEATING
ELEMENT
1500 Watts
(OPT - 1800 Watts)
120V / 60Hz
WHT
GRN
BLK BLK WHT
BLK
PILOT
ON / OFF
R
WIRING DIAGRAM
HEATING
ELEMENT
BLK
HEATING
ELEMENT
THERMAL
FUSE
BLK
BLK
GRN
THERMOSTAT
WHT
WHT
LINE CORD
ON / OFF
PILOT
BLK
BLK
SCHEMATIC
ES5M, ES5M18 & ES5MT
FRONT PANEL CHASSIS
L1 NLGND
BLK
BLK
WHT
THERMOSTAT
OPEN @ 350°F
THERMAL
FUSE
HEATING
ELEMENT
1500 Watts
(OPT - 1800 Watts)
120V / 60Hz
WHT
GRN
BLK BLK WHT
BLK
PILOT
ON / OFF
R
PUSH
BUTTON
NC
NO
COM
SOLENOID
VALVE
S
BLK WHT
BLK
FRONT PANEL CHASSIS
SOLENOID
VALVE
THERMOSTAT
THERMAL
FUSE
HEATING
ELEMENT
PUSH
BUTTON
PILOT
ON / OFF
HEATING
ELEMENT
LINE CORD
ES5PB & ES5PB18
WIRING DIAGRAMSCHEMATIC
FRONT PANEL CHASSIS
PUMP
THERMOSTAT
THERMAL
FUSE
HEATING
ELEMENT
PUSH
BUTTON
PILOT
ON / OFF
HEATING
ELEMENT
LINE CORD
ES5PBS & ES5PBS18
WIRING DIAGRAM
L1 NLGND
BLK
BLK
WHT
THERMOSTAT
OPEN @ 350°F
THERMAL
FUSE
HEATING
ELEMENT
1500 Watts
(OPT - 1800 Watts)
120V / 60Hz
WHT
GRN
BLK BLK WHT
BLK
PILOT
ON / OFF
R
PUSH
BUTTON
NC
NO
COM
PUMP
P
BLK WHT
BLK
SCHEMATIC
Figure 3A
Wiring Diagrams for ES5 Series Steamers - ES5M, ES5M18, ES5MT, ES5PB, ES5PB18, ES5PBS & ES5PBS18
Note: ES5 1800 Series Steamers have an 1800 watt heating element

EmberGlo A Division of Midco International Inc
8449 96 5
ES5 Series - Schematic & Wiring Diagrams
ES5CT, ES5CT18, ES5CTS & ES5CTS18
OPEN @ 350°F
PUMP /
SOLENOID
P/S
READY LIGHT
THERMOSTAT THERMAL
FUSE
HEATING
ELEMENT
L1 GND NL
120 VAC
COM
BLU
PUSH
BUTTON
PILOT
ON / OFF
NO
NC
SCHEMATIC
1500 Watts
(OPT - 1800 Watts)
BLK
RED
BLK
WHT
8406-92
YEL
YEL
SIGNAL SW
BUZZER
RED
ON
0.2 SEC
22K OHMS
OFF
20 SEC
2M OHMS
COM
NO
INITIATE
AC
NEUT
NC
SHOT
TIMER
8406-64
1
8
7
6
5
9
23
EXT RES
20 MIN / 1 MEG
AC
HOT
CYCLE
TIMER
8406-92
AC
NEUT
23
AC
HOT
LOAD
1
CYCLE / MANUAL
SWITCH
MANUAL
CYCLE
MANUAL
CYCLE
BLU
BLU
BLK
BLK
RED
ORN
RED
BLK
BLK
LOAD
INPUT
1
- 2
+ 3
67
CYCLE
TIMER
INITIATE
NEUT 3
7
6
NC
SHOT
TIMER
-
NO
COM
AIROTRONICS TIMERS
OFF
54
ON
1
8
9
5
HOT 2
AC
LOAD
1
INPUT
- 2
+ 3
76
5
4
CYCLE
TIMER
INITIATE
3
INPUT
-
54
NO
SHOT
TIMER
NC
COM
ACP TIMERS
ON
OFF
OFF
10 SEC
TIME
150 SEC
ON
0.2 SEC
690K OHMS
580K OHMS
22K OHMS
470K OHMS
220K OHMS
220K OHMS
220K OHMS
470K OHMS
22K OHMS
READY
LIGHT
THERMOSTAT
THERMAL
FUSE
HEATING
ELEMENT
PUSH
BUTTON
ON / OFF
PILOT
HEATING
ELEMENT
LINE CORD
WIRING
DIAGRAM
FRONT PANEL CHASSIS
FRONT PANEL CHASSIS
1411-90
PUMP /
SOLENOID
CYCLE
TIMER
SIGNAL
SW
BUZZER
MANUAL CYCLE
EXT
RES
SHOT
TIMER
Figure 3B
Wiring Diagrams for ES5 Series Steamers - ES5CT, ES5CT18, ES5CTS & ES5CTS18 with Mechanical Timer
Note: ES5 1800 Series Steamers have an 1800 watt heating element
NOTE: for
Old Style
Timer
Steamers,
ES5T &
ES5TS
wiring
diagrams
refer to
8449-96B

6EmberGlo A Division of Midco International Inc 8449 96
ES5 Series - Operation and Maintenence
IMPORTANT: KEEP LID CLOSED WHEN NOT IN USE. This keeps the food pan hot and reduces
condensation in the steam chamber. When steamer is fi rst installed, or when reconnecting water
hose, operate STEAM button several times to purge air from lines.
General Tips and Recommendations for Operation.
To sustain optimum cooking performance: It is important to maintain the correct amount of steam
generated. Either holding the manual pump (ES5M, ES5M18, & ES5MT) or pressing the button
(ES5PB, ES5PB18 or ES5PBS, ES5PBS18) too long will fl ood the generator with too much water.
On the other hand not holding the pump (ES5M & ES5M18) or pressing the button (ES5PB,
ES5PB18, ES5PBS & ES5PBS18) long enough and not spraying enough water will not produce
enough steam on the generator to properly cook the food in the desired time.
Recommended pumping and button pressing times for proper water levels in the generator:
ES5M, ES5M18 & ES5MT - It is recommended that the user pump the handle two to three
times every 20 to 30 seconds. If it is pumped more times or if the user does not wait long enough
between pumps, the generator will fl ood. Also, if it is pumped only once every minute there will not
be enough water in the generator to produce the correct amount of steam to sustain optimal cooking
performance.
ES5PB, ES5PB18, ES5PBS & ES5PBS18 - It is important to hold the button in for 3 seconds.
If the button is held too long, the generator will fl ood. If the button is held too short of a time, not
enough water will be sprayed onto the generator to create enough cooking steam. See below (next
paragraph) for recommendations on how to know this.
Recommended Procedure for Understanding the Amount of Steam Generated in both the Manual
and Push Button Types of Steamers:
1. On a cool steamer take the food rack and food pan out of the steamer so that the
generator and water nozzle can be seen.
2. Warm up the unit for 10 to 15 minutes.
3. ES5M ES5M18 & ES5MT - Push the manual lever two to three times
ES5PB, ES5PB18, ES5PBS & ES5PBS18 - Push the button long enough to spray water
on the generator surface.
4. Watch the water turn into steam. All of the water should evaporate in approximately 20 to
30 seconds.
By pumping the manual lever (ES5M, ES5M18 & ES5MT) or pushing the button (ES5PB, ES5PB18,
ES5PBS &ES5PBS18) and watching the time it takes to evaporate the water, the user will learn how
to reach the optimal cooking results, whether by pushing the button in or pumping the manual lever.
Timer Type of Steamers - (ES5CTS, ES5CTS18, ES5CT & ES5CT18) - this timing is internally set
by the manufacturer to obtain the optimum cooking steam cycle.
__________________________________________
Maintenance
Food Pan and Grid on all models should be removed and washed with a detergent or run through a
dishwasher.
WARNING: Under no circumstances should the entire steamer be run through a
dishwasher. If any of the switches or components get wet they can malfunction. Never try to
use a device that has been wet— replace it.
WARNING: Perform all maintenance when the unit is cool.
Exterior of unit should be wiped with a damp cloth or cleaned with a stainless steel cleaner.
Water Pan on ES5M, ES5M18, ES5MT, ES5CT, ES5CT18, ES5CTS, ES5CTS18, ES5PB,
ES5PB18, ES5PBS & ES5PBS18 may be removed for cleaning by pulling out to stop position; lift
front of steamer about 3″ to clear pump and pull pan all the way out. To replace, lift front of steamer
about 3″, slide pan in pan track until it is about 2″ from closed position, then lower steamer front and
push pan completely in.
__________________________________________
Generator: The cavity in the generator may accumulate lime and is cleaned by scraping or wire
brushing. Do not remove all of this deposit since a thin coating improves steaming.
Water Nozzle: The water nozzle, the round cap in front center of generator, may be pulled out for
cleaning. Clean small holes and inside of tube with spring clip provided in the tube.
Water Inlet: If the tube through generator is limed, remove plug at bottom and push lime out with a
wire or small rod.
Maintenance -
As Required
Maintenance -
Daily
Operation
Continued

EmberGlo A Division of Midco International Inc
8449 96 7
ES5 Series - Manintenance and Service
Strainers:
ES5M, ES5M18 & ES5MT: Strainer is in bottom of pump. Remove wire ring, then strainer
wash and replace.
ES5CTS, ES5CTS18, ES5PBS & ES5PBS18: Strainer is located in front center of bottom.
Slip strainer off Tube, wash and replace.
ES5PB, ES5PB18 ES5CT & ES5CT18: To wash strainer located in hose:
1. Remove hose.
2. Remove quick connect fi tting.
3. Reverse hose (connect steamer end to supply valve). Drain into sink or bucket.
4. Run water through hose to clean.
5. Return to original connections.
There is a strainer in inlet of solenoid valve that normally does not require cleaning but under
extreme conditions may have to be removed and cleaned.
__________________________________________
Service
DANGER: Before attempting service, unplug power cord.
We recommend any service be done by qualifi ed service personnel. Refer to separate Parts List for
parts identifi cation and assembly guide.
1. All electrical components are contained in enclosure behind switch panel. For access, remove
sloping front and switch panel.
2. ES5M, ES5M18 & ES5MT pump is easily removed for service or replacement. Disconnect
water line (under steamer) from pump, open electric enclosure, disconnect linkage and remove
two screws holding pump.
3. To remove ES5CTS, ES5CTS18, ES5PBS & ES5PBS18 pump:
A. Disconnect electric wires from terminals.
B. Disconnect discharge hose from pump.
C. Remove two screws through bottom of steamer holding pump bracket.
D. Lift pump out.
4. To adjust lid, loosen screws in lower hinge. With lid closed, tighten screws.
5. Thermostat is set to control temperature from 350° to 375°, and we suggest replacement if off
calibration. Thermostat may be removed by:
A. Removing electric enclosure covers and switch panel.
B. Removing wires from thermostat terminals.
C. Removing two screws holding thermostat.
D. Pull capillary straight out to remove bulb.
CAUTION: Capillary tube is critical and care should be taken not to “kink”.
6. f water nozzle should clog with lime, remove by lifting up then clean small holes with paper clip
or similar tool. Lime inside tube is removed by fl exing tube, then shaking or washing out lime.
7. The water inlet is cleaned by removing plug at bottom and pushing lime out with wire or rod.
8. The main timer controls the cooking time and the shot timer delivers a measured amount of
water to produce steam every 20 seconds. If defective, replace (attempted service may aff ect
timing).
DANGER: Read and understand this bulletin thoroughly before starting any
troubleshooting. An inadvertent service error could result in severe personal injury or death.
Only a trained experienced service technician should attempt any repair procedure.
Qualifi ed service agencies are available at most locations—Refer to EmberGlo listing of Authorized
Service Agencies included in Standard Equipment Catalog.
Important: Defective wiring or loose connections can simulate the defects outlined below. Check
associated wiring before replacing a component.
__________________________________________
Service
Maintenance -
Daily Continued

8EmberGlo A Division of Midco International Inc 8449 96
ES5 Series -Trouble Shooting
Trouble Shooting
1.
A. Confi rm electric cord is securely plugged in.
B. Confi rm receptacle is energized—reset breaker or repair house wiring.
WARNING: The following checks thru 7.A.1. should be done with electric cord
removed from receptacle.
C. Confi rm continuity in 3-conductor cord—replace if defective.
D. Confi rm continuity in single pole, single throw Power Switch (the two adjacent terminals are
switch terminals and the remote terminal is a tie-terminal). Replace if defective.
______________
2.
A. Confi rm continuity of Thermostat—replace if defective.
B. Confi rm continuity of Heating Element—replace Steam Generator Casting if defective.
C. Confi rm Thermal cutoff .
______________
3.
A. Defective light in switch— replace entire switch.
______________
4.
A. All Models: Clogged water nozzle, water inlet or strainers—check and clean as required,
see Maintenance and Service sections.
B. Models ES5M, ES5M18, ES5MT, ES5CTS, ES5CTS18, ES5PBS & ES5PBS18: Water pan
empty—fi ll pan.
C. Model ES5M & ES5M18: Confi rm pump is operative—check valves—inlet hose must not
leak.See Service section. Rebuild or replace as required.
D. Models ES5PB, ES5PB18, ES5CT & ES5CT18:
1. Confi rm Water Shut-Off Valve is on and Water Hose Assembly is properly hooked
up. Refer to #3 from the Installation section page 2. A quick way to confi rm water line
is operational is to disconnect Water Hose at quick disconnect fi tting and push a small
probe into quick disconnect fi tting—water should fl ow freely.
2. Confi rm continuity of Water Solenoid Valve—replace if defective.
E. Models ES5CT, ES5CT18, ES5PB, ES5PB18, ES5PBS, ES5PBS18, ES5CTS &
ES5CT18: Confi rm continuity of Steam Push Button Switch when depressed—replace if
defective.
F. Models ES5CTS, ES5CTS18, ES5PBS & ES5PBS18:
1. Confi rm continuity of Oscillating Pump—replace if defective.
2. Confi rm integrity of hoses and fi ttings. Any and all leakage must be eliminated.
______________
5.
A. Models ES5CT, ES5CT18, ES5PB & ES5PB18: Water Solenoid Valve seat dirty—clean or
replace as required.
______________
6.
A. Models ES5CT, ES5CT18, ES5CTS & ES5CTS18: Confi rm continuity of light replace if
defective.
______________
__________________________________________
1. Unit Does Not Heat
Switch On, Light Out
2. Unit Does Not Heat
Switch On, Light On
3. Unit Heats
Switch on, Light Out.
4. Unit Heats Up,
But Does Not Steam—
No Water Evident on,
Light Out.
5. Unit Floods—
Switch On
6. Unit Works—
Ready Light Inoperative

EmberGlo A Division of Midco International Inc
8449 96 9
Heating and Cooking Guide
These suggestions are made only to help the operator get started. Since each location will
have diff erent portions and diff erent requirements, each operator must determine his own
operation habits. Please remember that the steamer conserves its steam in the drawer and
therefore does not often need repeated shots. The main exception is when frozen product
must be defrosted.
If a product is at room temperature or refrigerated, start with 2 shots. This ensures that the
food pan is full of steam.
If a product is frozen, start with 3 shots because condensation on the cold product eliminates
the steam quickly.
Cooking
Instructions
Breads Refrigerated Frozen
Bread 1 to 2 shots of steam 2 min
Bagels 1 to 2 min 3 to 4 min
Croissant 15 seconds
Muffi n 1-2 shots of steam
Pastries 1 to 2 min 3 to 4 min
Tamales 5 min 10 min
Tortillas 1 shot of steam 10 seconds
Eggs
Soft Boiled 6 min
Poached 3 min
Scrambled (dz) 5 min
Meat
Bratwurst 8 min 16 min
Breakfast sausage 8 min 14 min
Chicken breast (lg) 15 min 25 to 30 min
Chicken breast (precooked) 5 min 15 min
Deli meats 2 to 3 min
Hamburger (precooked) 4 min 4 min
Hot dogs 4 min 8 min
Italian sausage 4 min 8 min
Ribs (precooked) 10 min 18 min
Noodles and Rice
Macaroni (2 qt. cooked, 1 pt. water, 2 oz. oil) 5 min
Egg Noodles (2 qt. cooked, 1 pt. water, 2 oz. oil) 6 to 7 min
Rice (precooked) 5 min 8 to 10 min
Spaghetti (2 qt. cooked, 1 pt. water) 5 min
Vegetables Refrigerated Frozen
Artichokes 25 to 30 min 50 min
Asparagus 10 min 14 min
Brussels 15 min 18 min
Broccoli 10 min 12 min
Carrots sliced 4 min 8 min
Carrots whole baby (2 lb) 15 to 20 min
Caulifl ower 12 min 16 min
Corn on the cob 3 min 5 min
Fennel 10 min
Green beans 4 min 8 min
Pea pods 6 min 9 min
Peas 5 min 8 min
Potatoes 8 whole (3 oz each) 20 min
Potatoes mashed (2 qt) 8 min
Squash, Acorn 4 (8 oz each) 12 to 20 min
Squash, Zucchini -sliced frozen (1 lb) 10 Min
Seafood
Large clams 4 min 8 min
King crab 8 min 12 min
Snow crab 6 min 10 min
Fish fi lets 6 min 8 to 10 min
Lobster 8 oz Tails 8 min 14 to 16 min
Scallops 5 min 8 to 10 min
Shrimp 4 min 6 min

10 EmberGlo A Division of Midco International Inc
EmberGlo A Division of Midco International - 4140 West Victoria Street - Chicago, Illinois 60646
toll free: 866 705 0515 - tel: 773.604.8700 - fax: 866.580.8700 - web: www.emberglo.com - e-mail: [email protected]
Printed in USA
8449 96
ISO
9001
C
O
M
P
A
N
Y
R
E
G
I
S
T
E
R
E
D
517
Warranty
Midco® International Inc Limited Warranty Policy Exclusions Terms, Customer Requirements and Instructions
All claims should be fi led through Warranty Central. Call factory for information (773 604 8700)
Only Authorized Service Providers are authorized to provide Limited Warranty service on all EmberGlo®, a Division of Midco® International
Inc., food equipment as described under and Midco® International Limited Warranty Policy. A list of providers can be found on our web site:
www.emberglo.com
Provisions: In lieu of an implied warranty, all repairs and replacement parts furnished under our Limited Warranty shall be f.o.b. point of
distribution, but the owner must pay the necessary freight, delivery and labor costs involved when required. Any Federal, State or Local taxes
are also extra. This Limited Warranty is eff ective for a period of one year from date of installation. EmberGlo® Char Broilers and EmberGlo®
Electric Food Preparation Equipment manufactured by Midco International, sold under the EmberGlo® trademark, are guaranteed to be free
from defect in material and workmanship under normal use and service for a period of 1 (one) year after the date of original installation.
Midco’s obligation under this Limited Warranty Policy shall be limited to repairing or replacing, at our option, any part of said equipment which
Midco examination shall disclose to its satisfaction to be thus defective.
Exclusions: This Limited Warranty Policy does not apply to damages resulting from accident, misuse, abuse or alteration, nor does it
apply to limed steam generators, nor does it apply to any consequential damages. Most geographical areas require the use of distilled or
demineralized water. Tap water is permissible only with ES Series Steamers. Nor does it apply to Barbriq’s®, briquettes, or rods used in gas
broilers. Midco’s obligation will be the replacement of the product or parts removed.
Terms: Under the terms of this Limited Warranty Policy, models considered portable (devices with cords and plug caps such as EmberGlo
Steamers) must be taken or returned to the nearest service provider, transportation prepaid, returned transportation collect. Non-portable
units with permanent wiring will be serviced on the customer’s premises. Under these terms, Midco agrees, within the terms of this Limited
Warranty period, to make all repairs at no charge by the authorized service provider. Labor and mileage charges submitted by any other
provider not authorized will be the responsibility of the customer.
Customer Requirements: All charges related to repairs made one (1) year after the date of original installation, during the Limited Warranty
period will be the responsibility of the customer. The product registration information is located on the product I.D. plate.
If a part is defective due to workmanship or materials and is removed from the product within the applicable warranty period and returned to
Midco in accordance with the following procedure described, Midco will, at its option, either repair or replace the part.
Call the factory for Instructions on returned goods.
No equipment may be returned without written authorization from MIDCO. Returned goods must be shipped prepaid to the factory.
WARNING: Improper installation and use of this product could result in personal or property injury.
MADE in the USA
Keep for your records
Gas Broiler Electric Broiler Steamer
Model Number
Serial Number
Installation Date
Purchased from - Name:
Address
City, State, Zip
TO VALIDATE WARRANTY:
FILL OUT THE FORM ON THE LAST PAGES AND RETURN TO EMBERGLO
Warranty

8449 96 11
EmberGlo A Division of Midco International Inc
Warranty
Warranty
Midco® International Inc Limited Warranty Policy
Exclusions Terms, Customer Requirements and Instructions
All claims should be fi led through Warranty Central. Call factory for information (866 705 0514)
Fill out form and fax to 866 580 8700 or copy and mail to: EmberGlo Div of Midco International Inc
4140 West Victoria Street
Chicago, Illinois 60646
Date of Purchase
End User Name
Company Name
Street & Apt. No.
City, State, Zip
E-mail Address
Web Address
Telephone
Fax
Steamer Gas Broiler Electric Broiler
Model Number
Serial Number
Installation Date
Purchased from - Name:
Address
City, State, Zip

EmberGlo Div of Midco International Inc.
Attn: Warranty Department
4140 West Victoria Street
Chicago, Illinois 60646
PLACE
STAMP
HERE
FOLD LINE
FOLD LINE
EmberGlo A Division of Midco International - 4140 West Victoria Street - Chicago, Illinois 60646
toll free: 866 705 0515 - tel: 773.604.8700 - fax: 866.580.8700 - web: www.emberglo.com - e-mail: [email protected]
Printed in USA
517
8449 96
ISO
9001
C
O
M
P
A
N
Y
R
E
G
I
S
T
E
R
E
D
Other manuals for ES5 Series
1
This manual suits for next models
13
Table of contents
Other EmberGlo Commercial Food Equipment manuals
Popular Commercial Food Equipment manuals by other brands

Amitek
Amitek AX215RG Installation, operating and service instructions

Bonnet Neve
Bonnet Neve MULTIFRESCO PLUS User instructions

Antunes
Antunes Egg Station Dual Zone ESDZ-1200 Series owner's manual

Gastrodomus
Gastrodomus DOMI MUP Series instruction manual

GILES
GILES GGF Series Operation & service manual

American Eagle
American Eagle AE-MC12N Operation manual
