Emerson Network Power Dacobas User manual

A
Assembly Instructions
Dacobas – Lochblech-Rückwand
Dacobas – Perforated rear panel
Dacobas – Panneau arrière en tôle perforée
■Technical Furniture
General information
Refer to the other
documentation
Consignes générales
Respecter les indications
ci-dessous
1Allgemeine Hinweise
Weitere Dokumentation
beachten
Validity
This document applies to the following
Dacobas components from Knürr AG:
Perforated rear panel–
Tools required
5mm Allen key–
Philips screwdriver–
Validité
Le présent manuel concerne les éléments
Dacobas de Knürr AG suivants :
Panneau arrière en tôle perforée–
Outils nécessaires
clé Allen 5mm–
tournevis cruciforme–
Gültigkeit
Diese Anleitung gilt für folgende Dacobas-
Komponenten der Knürr AG:
Lochblech Rückwand–
Notwendiges Werkzeug
Innensechskantschlüssel 5 mm–
Kreuzschlitzschraubendreher–
Installation
Attach the holding sections
Montage
Montage des profilés de maintien
2Montage
Halteprofile montieren
Achtung!
Montageanleitung „Dacobas
– Arbeitsplatz“ oder „Dacobas
– Leitwartentisch“ unbedingt
beachten.
Warning
See assembly instructions “Dacobas –
Workstation” or “Dacobas – Control
room desk”.
Attention !
Respecter impérativement les
instructions de montage “ Dacobas
– Poste de travail ” ou “ Dacobas –
Bureau pour poste de contrôle ”.
A2
A4
A3
A1
A

DEUTSCH ENGLISH FRANÇAIS
Dacobas Rückwand Dacobas rear panel Panneau arrière Dacobas
Ensure that the ready-fitted thread strip•
A3 is in the correct position.
Attach the rear panel
Veiller à ce que la position de montage•
de la barre filetée A3 prémontée soit
correcte !
Montage du panneau arrière
Auf richtige Einbaulage der vormon-•
tierten Gewindeleiste A3 achten!
Rückwand montieren
B
5
B2
B1
B3
B
C
C1
C2
2x
C
Schrauben B1 noch nicht festziehen!• Do not tighten screws B1 yet.• Ne pas bloquer encore les vis B1 !•
Schrauben C1 auf beiden Seiten•
festziehen.
Fasten screws C1 on both sides.• Serrer à bloc les vis C1 des deux côtés.•
2

DEUTSCH ENGLISH FRANÇAIS
Dacobas Rückwand Dacobas rear panel Panneau arrière Dacobas
E2E1 E1
D1
D2
2x
5
2x
5
D
Fasten the higher support foot D2 in the•
same way.
Fit the rear panel
Prepare the angle bracket and screws in•
sections E1 (2B), insert the rear panel and
secure it (2C).
Fixer de la même manière le pied d'appui•
plus haut D2.
Montage du panneau arrière
Préparer l’équerre et les vis dans les•
profilés E1 (2B), accrocher et fixer le
panneau arrière (2C).
Höheren Stützfuß auf gleiche Weise•
befestigen D2.
Rückwand montieren
In den Profilen E1 Winkel und Schrauben•
vorbereiten (2B), Rückwand einhängen
und befestigen (2C).
Trapezoidal wall cover
assembly
Replace the support foot
Montage pour l'élément
d'angle mural trapézoïdal
Remplacement du pied d'appui
3Montage für Trapez-
Wandeckteil
Stützfuß wechseln
5
E
3
