Table of Contents
Step 1: Getting Started .......................................................................................................................................... 3
A: Thermostat Buttons and Indicators ......................................................................................................... 3
B. Thermostat Display ................................................................................................................................ 4
Step 2: User Main Menu and Other Settings .......................................................................................................... 5
A. User Main Menu .................................................................................................................................... 5
B. Other Settings ....................................................................................................................................... 7
C. Description of User and Other Settings Menu Options ........................................................................... 8
Step 3: How to Program Your Delmarva Power Energy Wise Rewards Thermostat ................................................ 10
Step 4: Temporary Versus Permanent Hold ........................................................................................................... 12
Troubleshooting ................................................................................................................................................... 13
Your Delmarva Power Energy Wise Rewards thermostat controls your central air conditioning system and your
heating system. The types of compatible cooling and heating appliances include:
Central Air Conditioners:
• Single Stage
• Multi-Stage
Heat Pump:
• Single Stage
• Multi-Stage
Furnaces:
• Single Stage Gas or Oil
• Multi-Stage Gas or Oil
• Single Stage Electric
• Multi-Stage Electric
Aux Heat:
• Single Stage Electric
• Multi-Stage Electric
All compatible components are connected and configured by the Energy Wise Rewards technician during
installation.

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
Delmarva Power Energy Wise Rewards Thermostat User’s Manual 3
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
Step 1: Getting Started
A. Thermostat Buttons and Indicators
1Left Arrow Navigates menu items
2Up Arrow Raises temperature setpoint/changes selected menu item
3Action Button Selects action of selected menu item
4LED Indicates occurrence of curtailment event
5Right Arrow Navigates menu items
6Down Arrow Lowers temperature setpoint/changes selected menu item
7SYSTEM Button Changes system selection (OFF, COOL, HEAT, AUX [displayed on heat pump
units only])
8FAN Button Changes fan setting (Auto/On)
9Soft Keys Performs action listed on display above the button
9 78
5
6
4
123

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
4 Delmarva Power Energy Wise Rewards Thermostat User’s Manual
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
Step 1: Getting Started
B. Thermostat Display
1Messaging Area Displays day/time, thermostat, and Delmarva Power-related messages. In the event
of a power outage, the clock will maintain the correct time for 48 hours.
2Temperature Displays current room temperature
3Setpoint
Temperature
Displays current desired temperature
• Blank when user selects the OFF mode via the menu (turns system off)
• When system is ON, the words SET AT changes to HOLD AT when in temporary
or permanent hold
4FAN Status Blank when in auto mode—displays “FAN ON” when fan is on continuously
5System Status Displays current operation mode according to system configuration as set by installer
• OFF – system is OFF
• COOL – system is in COOL mode but no call for cool
COOL1 – call for first stage of cool
COOL2 – call for second stage of cool (multi-stage units only)
• AUX – system is in AUX heat mode but no call for heat (heat pump only)
AUX1 – call for first stage of Auxiliary heat (heat pump only)
AUX2 – call for second stage of Auxiliary heat (multi-stage heat pump only)
• HEAT – system is in HEAT mode but no call for heat
HEAT1 – call for first stage of heat
HEAT2 – call for second stage of heat (multi-stage units only)
HEAT3 – call for first stage of auxiliary heat (heat pump only)
HEAT4 – call for second stage of auxiliary heat (multi-stage heat pump only)
6Soft Key Display Actions to be performed when corresponding button is pressed
1
2
3
4
5
6

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
Delmarva Power Energy Wise Rewards Thermostat User’s Manual 5
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
Step 2: User Main Menu and Other Settings
A. User Main Menu
The “User Programming Menu” table (next page) summarizes the configuration items that the user can change,
and a convenient space to keep track of your settings. For more details on each user programming menu option,
see “Description of User and Other Settings Menu Options” on page 8. To enter the User Programming Menu:
1. Ensure the thermostat is at the idle screen (display with the room temperature displaying).
2. Press the MENU soft key. The display will show the first level of the User Programming Menu.
3. While in the User Programming Menu:
• The and scrolls the cursor up and down, respectively
• The soft key labeled HOME exits the User Programming Menu back to the IDLE screen
(NOTE: when the HOME soft key is pressed, any changes made on the current menu item are not saved)
• The button selects the highlighted menu item
• The BACK soft key goes back one menu level
• When changes are made to a menu item, the BACK soft key changes to SAVE. Press SAVE once after
making a change (the screen goes back one menu level after a change is saved)
• If a mistake is made during programming, press SAVE once, then return to the programming option and
re-enter the information (press SAVE again, press HOME to exit)
4. To exit the menu and return to the program operation, press HOME (when available).
If no keys are pressed within two minutes, the thermostat will revert to normal operation.

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
6 Delmarva Power Energy Wise Rewards Thermostat User’s Manual
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
Thermostat Programming Menu
Menu Name Submenu
Press or to
Select Other Options
(Defaults in BOLD)
Comments
Heat Programming Mon–Fri
Sat–Sun
7 Days
Default settings:
Morning 6:00 am 70°
Day 8:00 am 62°
Evening 5:00 pm 70°
Night 10:00 pm 62°
Use the to scroll through
items to change
Use to raise/lower values
When complete, press SAVE to
save settings or GO TO COOL
to program cool settings
Cool Programming Mon–Fri
Sat–Sun
7 Days
Default settings:
Morning 6:00 am 78°
Day 8:00 am 85°
Evening 5:00 pm 78°
Night 10:00 pm 82°
Use the to scroll through
items to change
Use to increment/
decrement values
When complete, press SAVE to
save settings or GO TO HEAT to
program heat settings
Keep Track of Your Thermostat Settings Below
Period
Weekdays Weekend
Start Time Temp Start Time Temp
HEAT MOR
DAY
EVE
NGT
COOL MOR
DAY
EVE
NGT

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
Delmarva Power Energy Wise Rewards Thermostat User’s Manual 7
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
Menu Name Submenu
Press or to
Select Other Options
(Defaults in BOLD)
Comments
Backlight:
(Auto/On)
Auto
On
Use to change values
When complete, press SAVE
Temperature Limits Min Cool Setpoint:
45°F
Max Heat Setpoint:
99°F
Use the to select setpoint
to change
Use to raise/lower value
When complete, press SAVE to
save settings or HOME to exit
without saving
Adjust
Temperature
Display
Current Room Temp
(measured temp)
Desired Offset 0°
Use to increment/
decrement value
When complete, press SAVE to
save settings or HOME to exit
without saving
Time Based
Programming
Not Currently Used
Energy
Management
Recovery
(see page 9)
Off
On
Use to change selection
When complete, press SAVE to
save settings or HOME to exit
without saving
°F/°C °F
°C
Use to change selection
When complete, press SAVE to
save settings or HOME to exit
without saving
Step 2: Thermostat Main Menu and Other Settings
B. Other Settings

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
8 Delmarva Power Energy Wise Rewards Thermostat User’s Manual
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
Step 2: Thermostat Main Menu and Other Settings
C. Description of Programming and Other Settings
Menu Options
The following are detailed descriptions of your Energy Wise Rewards thermostat configuration menu options.
1. Programming – Heat/Cool Programming
The Energy Wise Rewards thermostat can be programmed as a 7-day or 5/2 day thermostat. Using a 7-day
programming profile, you can program each day of the week with its own individual setpoint profile. With a
5/2 day programming profile, Monday–Friday each has the same setpoint profile while Saturday–Sunday can be
programmed with its own setpoint profile.
You can increase or decrease the temperature during the programming cycle, if desired.
2. Other Settings – Backlight
This menu item controls the display backlight. You can choose either:
• AUTO – (Default) Backlight comes on when you press any key. Backlight goes off after a short delay when
there is no button pressed
• ON – Backlight is always On.
3. Other Settings – Temperature Limits
Temperature limits can be used to set limits on how high your heating temperature can be set and how low
your cooling temperature can be set. The range for both values is from 45°F to 99°F.
• Cool Setpoint – 45°F (default)
• Heat Setpoint – 99°F (default)
4. Other Settings – Adjust Temperature Display
This allows you to adjust the displayed temperature up to 5° higher or lower than the actual room temperature.
Your thermostat was accurately calibrated at the factory, but you have the option to change the display
temperature to match your previous thermostat. The current or adjusted room temperature will be displayed on
the left side of the display while your desired offset will be displayed on the right side of the display.
Options for this menu item include:
• +1° through +5° – Adjusts the displayed temperature the specified number of degrees higher than the
measured room temperature.
• 0 – (Default) Displays the measured room temperature.
• –1° through –5° – Adjusts the displayed temperature the specified number of degrees lower than the
measured room temperature.

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
Delmarva Power Energy Wise Rewards Thermostat User’s Manual 9
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
5. Other Settings – Energy Management Recovery
Options for this menu item include:
• OFF – (Default) The system starts heating or cooling at the start time for the program period.
• ON – The system starts heating or cooling before the start time for the program period so that the room
temperature reaches the program setpoint at the period start time.
Example: You select EMR ON and have your heat (conventional heating system) programmed to 65° at night
and 70° at 7:00 AM (a difference of 5°). Allowing 7 minutes per degree, the thermostat will start calling for
heat prior to the 7:00 AM period start time in an attempt to reach the 70° setpoint by 7:00 AM. With EMR OFF,
the thermostat will wait until the 7:00 AM period start time to begin heating the facility.
6. Other Settings – °F/°C
You can display temperature in either:
• °F – Fahrenheit (Default)
• °C – Celsius
7. Other Settings – “Control Event Pending”
The phrase Control Event Pending will appear in the message rotation at the top of the display screen before
an Energy Wise Rewards conservation period is set to begin. The LED at the center of the control arrows will
flash until the event begins.
8. Other Settings – “Event in Progress”
When an Energy Wise Rewards conservation period is in progress, the phrase Event in Progress will be
displayed in the message rotation at the top of the display screen. The LED at the center of the control arrows
will maintain a steady light for the duration of the event.

DECS1214
Delmarva Power COMM Energy Wise Rewards Thermostat Manual
Job Opened: August 15, 2012
Requested In-Home Date: August 13, 2012
Latest Revision: August 20, 2012
Approved: ______________
10 Delmarva Power Energy Wise Rewards Thermostat User’s Manual
GRAPHIC
DESIGNER
CREATIVE
DIRECTOR
PROOFREADER COPY
SUPERVISOR
COPYWRITER CREATIVE
SERVICES
MANAGER
ACCOUNT
MANAGER
DECS1214—Delmarva Power COMM Energy Wise Rewards
Thermostat Manual
Piece: Manual
Quantity: 000,000
Size: 8.5" x 11"
Colors: 4/4
Finishing: ffffffffff
Mail: mmmmmmm
Program Specific Checklist Name: Date:
☐ Phone Number _________ _________
☐ URL _________ _________
☐ Program Details _________ _________
☐ Spell Check
Step 3: How to Program Your Delmarva Power Energy Wise Rewards
Thermostat
1. Press MENU to enter the Main Menu.
2. Press or to highlight the Programming menu item. Then press
(Action button) to enter the Programming Menu.
3. Press or to highlight Heating Program or Cooling Program,
then press (Action button).
4. Press or to highlight Mon–Fri, Sat–Sun or 7 Days, then press
(Action button).
a. Mon–Fri sets all weekdays to the same operating schedule.
b. Sat–Sun sets the weekend days to the same operating schedule.
c. 7 Days allows the user to program each day individually.
NOTE: If the HOME button is pressed at any point during the
programming sequence, any changes made will not be saved
and the thermostat will return to the HOME screen.
NOTE: If the EXIT key is pressed at any point while in the Time of
Day (TOD) programming menu, the thermostat will return to the
previous menu. If any changes are made to a TOD time period or
setpoint, the EXIT key label will change to SAVE.
