emmegi GIOCAMPER M7 T-Sat Troubleshooting guide

1
Use and warrantie booklet for satellite antenna
GIOCAMPER M7 T-Sat
By EMMEGI Electronics
Di Gasperini M.G.
Serial Number: ____________________
Dish Diameter: ____________________
Firmware: ____________________
Customer: ____________________ Date: ____/____/____
STAMP/SIGN RESELLER:
INDEX:
PREAMBLE Pag. 2
INSTALLATION Pag. 3
ELECTRICAL LINKS Pag. 6
KEYS FUNCTIONS Pag. 7
PROBLEMS Pag. 11
WARRANTIE Pag. 12
CONTACT Pag. 14
INCLINATIONS GEO-CHART Pag. 15
READ CAREFULLY THIS BOOKLET BEFORE
INSTALL OR USE THE PRODUCT.

2
PREAMBLE
Preamble:
GIOCAMPER M7 T-SAT is a motorized antenna with automatic alignment.
Automatic alignment is provided using the GPS position and integrated tuner information for
satellite identification.
Some external factors could prolong or fail the automatic alignment of the antenna, such as: trees,
buildings or great obstacles positioned between the antenna and the satellite, vehicle not in good
lateral/frontal inclination, unstable vehicle due to peoples moving during the alignment. To
improve the result of automatic alignment please keep that in consideration.
Specifications:
-Power Supply 12/15 Vcc.
-Rotation motor electrical imput 3 Watt.
-Inclination motor electrical imput 6 Watt.
-Stand-by electrical imput 2 Watt.
-“LCD off” electrical imput 1 Watt.
-Dish dia. of model 60 54 cm.
-Dish dia. of model 70 64 cm.
-Dish dia. of model 80 78 cm.
-Weight of model 60 5.5 Kg c.a
-Weight of model 70 6.5 Kg c.a
-Weight of model 80 7.5 Kg c.a
-Height with dish closed 17 cm.
-Inclination and rotation motorized movement.
-Emergency automatic closure function.
-Work with most of all satellite receiver.
-Dedicated SAT cable from LNB to the receiver to avoid loss of signal.
-LNB DUAL able to receive analog and digital signals, little size and low noise figure:
Exits 2
Imput Frequency 10.70 –12.75 Ghz
Output Frequency 950 –2150 Mhz
L.O. Freq. 9.75 –10 Ghz
F. connect serie 5/24300
Noise 0.2 db
What’s in the box:
-1 x Antenna sat. GIOCAMPER M7 T-Sat.
-1 x User Consolle of antenna sat. GIOCAMPER M7 T-Sat.
-1 x LNB DUAL (Replaced in case of KIT DUAL purchase), complete of bracket.
-1 x Dish bracket.
-1 x Satellite Dish.
-1 x Electricity connection kit.
-3 x SAT Connectors.
-1 x Fixing Plate.

3
INSTALLATION
Dish Installation:
1. Place the sat dish bracket in
vertical position, putting inside
the 2 spacing washer and the
screws as in the figure
(Bolt –Steel washer –Dish
Bracket –Alloy Washer –
motor structure), when
positioned tight the 2 screws
with a 13 mm tighten tool.
2. Place the sat dish on its holder
and fix it with the 4 screws as
in the figure.
3. Insert SAT cables, passing
through the bracket and going
out below the LNB bracket.
4. Insert the LNB bracket into the
metal bracket until hearing the
“clac” sound caused by the 2
plastic pins locked in the holes.
5. Prepare SAT connections as
figure below.
(See Pag. 6)

4
6. Untighten the 2 dish holder
screws and leave the dish to go
down, leaning on the abs white
carter as shown in the picture.
The LNB have to be in contact
with the dish. (do not put any
material between LNB and
dish)
7. Tighten the screws in order to avoid free movement of dish. Pay attention to not force too
much.
Fixing of plate:
WARNING: we suggest to place the antenna in the middle of the vehicle roof, or driver side. A lateral
positioning is more exposed to unintentional damage, like trees at side street.
NEVER PLACE IT ON THE INCLINATED AREA OF VEHICLE (BUNK).
Check the space available around the plate positioning point to avoid hitting obstacles during
rotation (oblo, cappe, ecc.):
-For 60 model at least 30cm of free space around the plate positioning point.
-For 70 model at least 35cm of free space around the plate positioning point.
-For 80 model at least 40cm of free space around the plate positioning point.
Clean with a diluent the area of gluing on the fixing plate. We suggest you do not use
commercial grease/dirty remover because they leave a protective patina.
If necessary use a sandpaper fine-grained to remove smog.
Clean with a diluent the fixing plate and wait that is completely dry before applying the glue.
Distribute glue (POLIURETANIC) on the fixing plate, drawing tight rows to avoid emty space. We
suggest to perform even the contour of the fixing plate to avoid water infiltration.
Press the glued fixing plate on the roof, paying attention to remove bubbles of air and aligning
the fixing plate with vehicle side.
Take care of the fixing plate contour, sealing the four side will prevent water infiltration, very
dangerous during winter time (water icing could separate glue from roof).
Remove glue in excess.
Let dry the glue according times listed below:
At least 24h during hot days (For example during springs or summer).
At least 36/48h during cold days (For example during autumn or winter).
After drying time you can proceed with installation of the product.
Positioning of the antenna:
Remove from the plate the first 4 bolts (8mm).
Place antenna on the plate, paying attention to join each pins and holes.
WARNING: Antenna is sent out in TRAVEL POSITION, that is to say that LNB have to be backside
of camper. (Look the picture in the next page).
Tight the four 8 mm bolts using the correct size tool.

5
BACK SIDE OF CAMPER FRONT SIDE OF CAMPER
Positioning of User Consolle:
User Consolle is designed to be placed in an hole in the wood furniture. If you do not want do any
holes you have to purchase the plastic box (Optional).
Choose the best point to place the user consolle.
If you chose to make the hole please take a note of these measures:
Height 6.5 cm c.a.
Lenght 11.8 cm c.a.
Verify that the User Consolle match the hole size, if not perfect please adjust the hole with a
wood rasp.
If you choose to use the plastic box (Optional), make an hole in the box to insert the
cables(According cables position).
WARNING: During the installation of user
consolle, in the wood or in the plastic box,
pay attention to the FLAT cable and power
cable on the back side of the consolle.
Any damage or breaking of these cables will
NOT BE COVERED FROM WARRANTIE.
Positioning of cables:
Choose a point where you want to
install the antenna on the roof.
Chose the entry point of the cables (for example a fairlead or kitchen hood).
Use a protective tube to avoid the exposure of cables and fix it on the roof.
Pass the cables from outside to the inner side of the camper (power and SAT cables).
Place the SAT cable untill the digital SAT receiver.
Place the Power Supply cable untill the point you will place the user consolle.
We suggest to make electrical connection near the user consoll place.
Place the user consolle cable near the point you will make the electrical connection.
Where electrical connection will be made you must have a positive and negative 12Vcc
cable coming from the living cell electrical plant. We suggest to use cable with a section of
at least 1.5 squared/mm.
We suggest, if possible, to use a dedicated line coming directly from battery.

6
Where electrical connection will be made you must have a positive 12Vcc coming from the
camper plant that have energy only when the alternator run, this is to have an Emergency
Closure function in case you forget antenna opened (Be careful do not use alternator imput
to close antenna instead of normal user consolle imput, this is only an emergency feature).
We suggest to use cable with a section of at least 1.5 squared/mm.
WARNING: Antenna doesn’t have to be connected using the lighter plug.
Temporary connections are not to be considered a proper way to use product.
Malfunctions caused by this type of connections are NOT COVERED FROM WARRANTIE.
ELETTRICAL CONNECTIONS
Power Supply cable connection:
Do not round toghether the cable in excess, please cut cable if not necessary.
Using the connection kit you can connect cable color by
color. We suggest you to connect same color by the same
side of the connection kit for better electrical connection,
adding to the opposite side the 3 cables
(+12Vcc, -12Vcc and Alt +12Vcc).
Connect color by color rounding togheter copper wire
(as shown in the picture).
IT IS MANDATORY ON POSITIVE CABLES INSERT A FUSE OF 5 Ah.
It will prevent short circuit damages. No Warrantie cover in case of no fuse.
Follow the connection scheme to connect cables:
Yellow Yellow
Green Green
Grey Grey
Pink Pink +12 Vcc available with alternator running
Brown Brown +12 Vcc of living cell plant
White White -12 Vcc of living cell plant
SAT cable connection:
Do not round toghether the cable in excess, please
cut SAT cable if not necessary.
Put the female connector on the SAT cable as shown.
Plug the connector to the digital receiver.
(Normally the correct socket is marcked as “SAT IN”).
WARNING be carefully that external socket of sat cable
have not to be in contact with internal copper wire of the
sat cable. On the sat cable there are normally 12 / 18 Vcc
and a this shortcircuit will damage the receiver or the
LNB.
This kind of damage, produced by wrong connection
procedure, is not covered by warrantie.

7
HOW DOES IT WORKS
WARNING: DO NOT USE ANTENNA WITH STRONG WIND OR STRONG GUST.
Key Functions:
ON –OFF –OK
1. Turn ON and OFF the User Consolle.
2. Save modifications on the PROTECTED MENU.
Menu –SET
1. Change the menu.
2. Close the parabola.
3. With user consolle OFF will close the parabola (If open).
Ricerca –AUT
1. Start Satellite allignment.
2. With user consolle OFF will allign the satellite (Short procedure).
3. From any menu come back directly to the main menu (MENU RICERCA SAT).
Arrows
1. Move antenna manually.
2. Stop automatic movement.
3. Change parameters in each MENU.
Suggestions/Menu:
During normal working, on the lower side of the user consolle, key functions for that menu
are shown.
Doing anything for a preset time value, the main menu will be automatically shown (MENU
PRINCIPALE).
A screensaver will appear after a long time with no actions (Voltage of Battery).

8
Satellite Allignment Procedure:
WARNING: Before start automatic alignment of satellite, we suggest you to stabilize the camper to
avoid roll or yaw movement caused by people walking. This action will help you to avoid satellite
aligment failure.
We suggest you to place the camper levelled to avoid alignment problems.
Quick Alignment procedure:
With user consolle OFF, press AUT key. Antenna will turno ON and start immediately
the automatic alignment for the preset Satellite.
WARNING: if during the automatic alignment of the satellite the GPS is not active,
the user consolle will shown the MENU AUTOMATICO page, giving you the way to
specify the degrees at which start the research.
MENU AUTOMATICO
__________________________
Satellite= Hotbird
AUT= Inizia Ricerca
SET= Chiude parabola
GPS non attivo controlla
Gradi inizio ricerca: 38
__________________________
Starting alignment with GPS not active, antenna will scan at 360° changing the
inclination by 8° each rotation movement. We suggest, before start research
procedure with GPS no active, to read the geo-chart at Pag. 15/16 in order to check
the degrees at which start the alignment procedure.
Standard procedure:
Turn ON the user consolle pressing ON key.
When turned ON the user consolle will show you the MENU PRINCIPALE.
MENU PRINCIPALE
__________________________
Satellite: --------------------------
Gradi alzata:
Gradi rotazione:
Segnale SAT:
GPS attivo
__________________________
Press AUT key to enter in the MENU AUTOMATICO.
MENU AUTOMATICO
__________________________
Satellite= Hotbird
AUT= Inizia Ricerca
SET= Chiude Parabola
GPS attivo
Gradi inizio ricerca: 38
__________________________

9
Select desired satellite by pressing orizontal arrow keys. Press AUT key to start
alignment process.
When antenna will find and align the correct satellite, a message “SATELLITE
TROVATO” will be shown.
Anytime you need you can stop research. Just press any arrows to interrupt
automatic movement and enter in “manual movement mode”.
Satellite list:
Below the satellite list available on the antenna firmware:
HOTBIRD 13°E
ASTRA 19°E
ASTRA3 23°E
ASTRA2 28°E
TURKSAT 42°E
HISPASAT 30 W
EUTELSAT 5°W
THOR 1°W
ASTRA4 5°E
EUTELSAT 9°E
If the provider will perform a frequency update of satellite, the update of our antenna is
out of warrantie and a price will be gived to the customer for the work.
Manual motion:
Manual motion give the way to align satellite manually. The user consolle will show you the
MENU PRINCIPALE page where you can see this values:
Inclination Degrees.
Rotation degrees according camper position.
Closing procedure:
WARNING: The 2 correct procedures to close the antenna are explained below. Automatic closure
of antenna by alternator imput is to be considered ONLY an emergency procedure and not a
standard way to close antenna. Continue automatic closure with alternator imput can cause
shortcircuit due to the high stress energy during engine start up. NO WARRANTIE WILL BE APPLIED
IN CASE OF SHORT CIRCUIT PRODUCED BY CONTINUOS CLOSURE BY ALTERNATOR IMPUT.
Quick Procedure:
With user consolle OFF press SET key and antenna will move in travel position.
Standard Procedure:
Turn ON the user consolle by pressing ON key.
When the user consolle is ON a page MENU PRINCIPALE will be shown.
MENU PRINCIPALE
__________________________
Satellite: --------------------------
Gradi alzata:
Gradi rotazione:
Segnale SAT:
GPS attivo
__________________________

10
Press AUT key to enter in the MENU AUTOMATICO page.
MENU AUTOMATICO
__________________________
Satellite= Hotbird
AUT= Inizia Ricerca
SET= Chiude Parabola
GPS attivo
Gradi inizio ricerca: 38
__________________________
Press SET key to start automatic closure of antenna. The antenna will move in travel
position. At the end of closure procedure the user consolle will turn OFF
automatically.
Pages and menu:
Press SET key with user consolle turned ON a serie of menu will be shown. To come back to
the main page MENU PRINCIPALE just press AUT key, or wait few seconds and user consolle
will show you the MENU PRINCIPALE page automatically.
Menu of antenna are listed below:
MENU PRINCIPALE
1. Satellite Show selected satellite.
2. Gradi alzata Show elevation degrees.
3. Gradi rotazione Show rotation degrees according camper position
4. Segnale SAT Show SAT signal level.
5. GPS attivo Show GPS status: if active or not.
MENU AUTOMATICO
1. Satellite Select the desired satellite with arrow keys.
2. AUT Press AUTO to start the research.
3. SET Press SET for automatic closure.
4. Gradi inizio ricerca Modify it in case of GPS malfunctions
MENU PARABOLA
1. Imp. Alzo Technical parameter of antenna.
2. Imp. Rotazione Technical parameter of antenna.
3. Livello segnale SAT Technical parameter of antenna.
4. FC.Rot:0-0 FC.Alzo:0-0 Technical parameter of antenna.
MENU GPS
1. Latit. GPS Parameter.
2. Longit. GPS Parameter.
3. Altitudine GPS Parameter.
4. N. Satelliti GPS Parameter.
5. Qualità segnale GPS Parameter.
MENU LCD
1. Contrasto LCD LCD Contrast.
2. Volt Batteria Show battery voltage.
3. Stato parabola Show antenna status APERTA(Open) or
CHIUSA(Closed).

11
MENU SET FUSO ORARIO
1. Fuso Orario If clock is installed (Optional), set local timetable.
MENU INFO
1. Numero telefonico Show Assistance phone number.
assistenza
MENU SALVASCHERMO
1. Modello antenna Show antenna model.
2. Volt batteria Show voltage of battery.
3. Time: Data e ora Show time and date if clock is installed.
If clock is installed, the voice “SET OROLOGIO” will be shown, here you can change time
and date.
With vertical arrows will change numbers.
With orizontal arrows will change parameter.
In the user consolle there is a “Ghost Menu” (MENU DATI). This menu give the way to
change parameters of the antenna such as satellite’s frequencies, language and
others…
This menu is password protected and according the password insterted give the way to
change a little selection of data.
You cannot access to this menu by yourself but you will be instructed to use it by phone
assistance to guide you step by step with modifications.
Modify data without know what you are doing can cause the failure of good working
system. Please, if you want to continue to watch TV without stress yourself, never
modify anything without contact us.
ANOMALIE
Anomalies and solutions:
Known anomalies and relative solutions are listed below:
1. ERRORE COMUNICAZIONE
With user consolle turned ON remove power for 30 seconds. Then
connect again the system to the power supply and press ON to reset.
With antenna in OPEN position start the camper engine to force an
automatic closure and a reset of the system.
If problem is still present please contact post sales service of EMMEGI
Electronics refering to the Pag. 14.
2. SFORZO ALZO PARABOLA –SFORZO ROTAZIONE PARABOLA
Verify that no obstacles are locking the movement of antenna.
With user consolle turned ON remove power for 30 seconds. Then
connect again the system to the power supply and press ON to reset.
With antenna in OPEN position start the camper engine to force an
automatic closure and a reset of the system.
With antenna in OPEN position proceed to remove sat dish, by untighten
the 2 bolt of 13mm, in order to travel in safe.
If problem is still present please contact post sales service of EMMEGI
Electronics refering to the Pag. 14.

12
ERRORE MICRO ALZO –ERRORE MICRO ROTAZIONE
With user consolle turned ON remove power for 30 seconds. Then
connect again the system to the power supply and press ON to reset.
With antenna in OPEN position start the camper engine to force an
automatic closure and a reset of the system.
If problem is still present please contact post sales service of EMMEGI
Electronics refering to the Pag. 14.
3. MOVIMENTAZIONE ANOMALA (L’antenna si muove molto lentamente)
With user consolle turned ON remove power for 30 seconds. Then
connect again the system to the power supply and press ON to reset.
With antenna in OPEN position start the camper engine to force an
automatic closure and a reset of the system.
If problem is still present please contact post sales service of EMMEGI
Electronics refering to the Pag. 14.
4. GPS NON ATTIVO
It happen when antenna’s power has been removed. GPS have to warm
again and try to lock satellites.
If GPS doesn’t activate please contact post sales service of EMMEGI
Electronics refering to the Pag. 14.
5. SATELLITE NON TROVATO
Verify that no obstacles exist between antenna and the sky like houses,
trees, big buildings, etc…
Start a new research.
Satellite frequency could been changed, please contact post sales service
of EMMEGI Electronics refering to the Pag. 14.
6. MANCA ALIMENTAZIONE LNB
Check digital sat receiver is powered and turned ON.
Check SAT connectors. See Pag. 6.
Check LNB power is flagged to ON in the digital sat receiver configuration.
7. TENSIONE BATTERIA BASSA
Check voltage of Service Battery.
8. ERRORE DI SALVATAGGIO
Repeat the saving procedure in the “Ghost Menu” (MENU DATI).

13
WARRANTY
Product is covered by warrantie for a period of 2 years from purchase date, as stated by
italian regulation.
Warranty covers the replacement or repair of product due to fabrication problems.
Any damage derived from a bad or improper use of the product or its modification will
cause the end of the warranty.
The company undertakes to repair, replace or substitute the product in case of fault. The
product will have to be sent (shipping paid by customer) to our company with all the
material, upon notice to our notice.
The reparation in warranty is free ONLY if carried out in our company. The costs for
dismantle and reassemble of the product will not be recognized if done by other
companies.
The warranty will not be recognized if it is assessed that the product was tampered by
unauthorized personal, Before executing any modifying operation on the product, ask
the authorization from EMMEGI Electronics di Gasperini Maria Grazia or the warranty
will be lost.
Warranty is not applied to shipping costs. The product for which warranty is requested
have to be sent to our company as PAID SHIPPING (shipping price are paid by the
customer). SHIPPING COMING NOT PAID WILL BE REFUSED.
If the fault of the product is recognized as covered from warranty, shipping costs to send
back the product (On ITALIAN field) to the customer will be at EMMEGI Electronics di
Gasperini Maria Grazia charge.
The warranty will be cancelled if it recognized that the product was improperly or
irresponsibily used.

14
CONTACT
Headquarter:
EMMEGI Electronics di Gasperini M. Grazia
Via per Mombello, 30/B
21033 Cittiglio (VA)
Commercial contact:
Phone: [phone] (Just for commercial info)(No English Speacker)
Fax: [phone]
Mail: [email protected]
OPENING TIMETABLE
-From Monday to Friday
From 9.00 till 12.00
From 15.00 till 18.30
-Saturday
From 9.00 till 12.00
Technical Office Contact:
Phone: [phone] (Only for technical assistance) (No English Speacker)
Mail: [email protected]
OPENING TIMETABLE
-From Monday to Friday
From 9.00 till 12.00
From 15.00 till 18.00
Booklet Revision 2.0
01/12/2016

15
GEO-CHARTS
Degrees have to be considered as “more or less”, so an error tolerance of 2/3 degrees is acceptable.
Antenna will perform the research even if the degrees are not perfectly correct.

16
