DS-Control
1-0-4/0521
Outdoor Directional Yagi Antenna
OY-MN-V11P
746-896MHz, N-Female
•Covering 746-896MHz Public Safety Band
•Narrow beamwidth and High gain with 8 elements
•Suitable for donor antenna and aluminum finished
•Supporting antenna tilt adjustment
Electrical Specification
Product Model
OY-MN-V11P
Frequency (MHz)
746-896
Gain (dBi)
11.2
Polarization
Linear / Preinstalled with Vertical Pol.
Beamwidth Horizontal (°)
48
Beamwidth Vertical (°)
40
VSWR
≤1.5
Front to Back Ratio (dB)
≥15
Average Power, max (W)
100
Impedance (ohm)
50
Mechanical Specification
Environment & Compliance
Dimension Diameter, height (in/mm)
33.5 x 7.5 x 2.0 / 850 x 190 x 50
Application
Outdoor
Weight (lb./kg)
0.9 / 0.4
Operating Temperature
-40°C to +60°C
Shipping Dimension(in/mm)
35.6 x 9.1 x 2.4 / 905 x 230 x 60
Relative Humidity
Up to 95%
Shipping Weight(lb./kg)
1.8 / 0.7
RoHS
Compliant
Radome Material & color
Aluminum finished, White
Environment
Diameter of the pole mounting pole (in/mm)
1.57-2.00 / 40-50
Lightening protection
Direct Grounding
Antenna Tilt adjustment ()
± 30max
Maximum Wind Speed(mph)
186
Connector type
N-Female
Antenna Pattern
Horizontal Vertical
746MHz 821MHz 896MHz

Comba Telecom Inc. 568 Gibraltar Drive, Milpitas, CA 95035. http://www.combausa.com/
Tel: [phone], [e-mail], Fax: [phone]
Information contained in this document is subject to confirmation at time of ordering. Specifications may differ depending on region and customers’ requirements
Page 2 of 2
DS-Control
1-0-4/0521
Mechanical Drawing and Installation Guide
Installation Instruction
A. The antenna bracket and the antenna frame are pre-assembled for vertical polarization(default)
B. Put the antenna bracket and the mounting pole according to the position and direction shown in the drawing
C. Fasten two U-bolts and clamps the antenna bracket to the mounting pole. (not included)
D. Adjust antenna tilt angle (max ± 30) and fasten the nut (HEX M6)
E. Connect the equipment and antenna with their respective connectors
F. Ensure that all connections are waterproof
G. Fasten the cables of the antenna and equipment
U-Bolt
Hex nut M6
Antenna Tilt
Adjustment
Antenna frame
Antenna mount
bracket
Mounting
pole
30°
Clamp
U-Bolt
Clamp
Antenna frame
Antenna
mounting
bracket
U-bolts/nuts for pole
mounting
mounting pole
Ø 40-50mm / 1.5-2inches
Antenna Tilt
Adjustment
U-bolt
Clamp
Plain washer ɸ6
Spring washer ɸ6Hex Nut M6
Antenna installation for vertical Pol. (default)
33.5 [850]
Unit: inch[mm]
Optional installation - Horizontal Pol.
