OUTDOOR LINEAR
GAS FIREPLACE
MODELS
OLL48FP12S(N,P)-2
OLL48SP12S(N,P)-2
GAS-FIRED
WARNING
Do not store or use gasoline or other ammable vapors and
liquids in the vicinity of this or any other appliance.
An propane-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
DANGER
If you smell gas:
1. Shut off gas to the replace.
2. Extinguish any open ame.
3. If odor continues, keep away from the replace and im-
mediately call your gas supplier or re department.
WARNING
If not installed, operated and maintained in
accordance with the manufacturer's instruc-
tions, this product could expose you to sub-
stances in fuel or from fuel combustion which
can cause death or serious illness.
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Read the installation, operat-
ing and maintenance instructions thoroughly
before installing or servicing this equipment.
WARNING
If the information in these instructions are
not followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
WARNING
For Outdoor Use Only.
— Installation and service must be per-
formed by a qualied installer, service
agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
Page 1

35305-8-0818Page 2
BEFORE YOU START
1. Read the safety information on pages 4, 32 and 33.
2. What to consider before installing. See Page 9.
3. Water drainage is required. See page 10. Optional drain
tray available.
4. Where are you going to install the unit? See pages 9 to 10.
5. Frame the opening. See pages 6-8 and 12.
6. Installthereplace.Seepages12to14.
7. Connect the electricity. See pages 15 and 24.
8. Connect the gas. See page 16 to 18.
9. Install the crushed glass. See page 20.
10. Lightthereplaceandtroubleshoot.Seepages21and26.
11. Showthehomeownerhowtooperatethereplace.See
page 23.
12. Show the homeowner how to do the basic maintenance.
See page 25.
CARTON CONTENTS
INDEX
NO. DESCRIPTION
QUANTITY
SUPPLIED
OLL48FP OLL48SP
1 Glass Panel 1 2
2 Non-Combustible Panel - Top 2 4
3 Non-Combustible Panel - Side 2 4
4 Envelope 1 1
5 Nailing Flange 4 8
6 Top Mounting 3 6
7 Receptacle 1 1
8 Cover Plate 1 1
9 Conduit Connector 1/2-in. 1 1
10 AA Battery 1 1
11 Burner Service Support 2 2
See Parts Lists on pages 28 to 31 for ordering replacement parts.
Do not order batteries, bolts, screws, washers or nuts. They are
standard hardware items and can be purchased at any local
hardware store.
1
7
2
3
5
6
8
4
910
11
HARDWARE PACK CONTENTS
1-1/4” PHILLIPS DRYWALL SCREW (20)
#10-32 X ½” STAINLESS HEX HEAD SCREW (16)
#10-32 X 1/2" STAINLESS HEX HEAD SCREW
14 - OLL48FP12S(N,P)
28 - OLL48SP12S(N,P)
1-1/4" PHILLIPS DRYWALL SCREW
33 - OLL48FP12S(N,P)
66 - OLL48SP12S(N,P)
1-1/4” PHILLIPS DRYWALL SCREW (20)
#10-32 X ½” STAINLESS HEX HEAD SCREW (16)

35305-8-0818 Page 3
TABLE OF CONTENTS
Before You Start ..........................................................................................................................2
Table Of Contents ........................................................................................................................3
Introduction .................................................................................................................................4
Specications ..............................................................................................................................5
Accessories .................................................................................................................................5
Combustible Materials ................................................................................................................6
Clearances ................................................................................................................................6-7
Fireplace Dimensions .................................................................................................................8
Planning Installation ..............................................................................................................9-11
Fireplace Framing And Installation ....................................................................................12-19
- Framing & Installation ......................................................................................................12-13
- Electrical Supply....................................................................................................................14
- Gas Supply............................................................................................................................15
- Propane Gas Cylinder Information...................................................................................16-17
- Finishing...........................................................................................................................18-19
Lighting Instructions .................................................................................................................20
Main Burner Flame Characteristics .........................................................................................21
Operation Instructions/Flame Appearance .............................................................................22
Wiring .........................................................................................................................................23
Maintenance...............................................................................................................................24
Troubleshooting ........................................................................................................................25
Master Parts Distributor List ....................................................................................................26
How To Order Repair Parts .......................................................................................................26
OLL48FP12S Parts List .............................................................................................................28
OLL48FP12S Parts View ...........................................................................................................29
OLL48SP12S Parts List.............................................................................................................30
OLL48SP12S Parts View ...........................................................................................................31
Important Safety Information ...................................................................................................32
Safety Information For Users Of Propane Gas .......................................................................33
Appliance Service History ........................................................................................................34
Warranty Terms .........................................................................................................................35
SECTION PAGE

35305-8-0818Page 4
INTRODUCTION
When installed on exterior walls: Empire Comfort Systems
recommends the replace chase be constructed outside the
structure's weather envelope. Where the platform meets the wall,
useaashingdetail similarto thatrequired forattached decks.
Chase platforms, including hearths should slope away from the
structureat1/4in.perfoot.Thereplacecanbeshimmedlevel.
When installed on surfaces where water may collect or cause
damage: Empire Comfort Systems recommends a slope of 1/8 to
1/4in.perfoottowardsthedrainportsuggested.Thereplacecan
be shimmed level.
Hearthsshouldslopeawayfromthefrontofthereplaceandchase
at 1/8 in. to 1/4 in. per foot. Metal safety strips must be on top of
any combustible hearth materials used for moisture management.
Whenpurchasingareboxorreplacewerecommendyoualso
buy a weather cover to protect the unit from moisture. Never install
a burner where moisture cannot drain off easily. We recommend a
weather barrier to protect the burner from moisture.
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization equipment
or accessories and repair and servicing of equipment shall be
performedonlybyaqualiedagency.Theterm"qualiedagency"
meansanyindividual,rm,corporationorcompanywhicheitherin
person or througha representative isengaged in andis responsiblefor
(a) the installation or replacement of gas piping or (b) the connection,
installation, repair or servicing of equipment, who is experienced in
suchwork,familiarwithallprecautionsrequiredandhascomplied
with all the requirements of the authority having jurisdiction.
Local Codes
• Whenthereplaceisconnectedtoaxedpipingsystem,the
installation must conform with local codes, or in the ab-
sence of local codes with the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, or International Fuel Gas Code.
• Wheninstalled,thereplacemustbeelectricallygrounded
in accordance with local codes, or in the absence of local
codes with the National Electrical Code, ANSI/NFPA 70, if
applicable.
Commonwealth of Massachusetts: The installation must be
madebyalicensedplumberorgastterintheCommonwealth
of Massachusetts.
The installation must conform with local codes or, in the absence
of local codes, with the National Fuel Gas Code, ANSI Z223.1.*
*Available from theAmerican National Standards Institute, Inc. 1430
Broadway, New York, N.Y. 10018.
High Altitudes
For altitudes/elevations above 2,000 feet (610m), ratings should be
reduced at the rate of 4 percent for each 1,000 feet (305m) above
sea level. Contact the manufacturer or your gas company before
changingspud/oricesize.
Instructions to Installer
1. Installer must leave instruction manual with owner after
installation.
2. Installer must have owner fill out and mail registration
card supplied with this fireplace or register online at
www.empirecomfort.com.
3. Installer should show owner how to start and operate outdoor
replace.
Always consult your localBuilding Department regarding regulations,
codes or ordinances which apply to the installation of an outdoor
gasreplace.
*Aftermarket: Completionofsale,notforpurposeofresale,from
the manufacturer.
Well Head Gas Installations
Some natural gas utilities use "well head" gas. This may affect the
Btu output of the unit. Contact the gas company for the heating value.
Contact the manufacturer or your gas company before changing
spud/oricesize.
WARNING
This replace is not for use with solid fuels.
WARNING
ANY CHANGE TO THIS FIREPLACE OR ITS CONTROLS CAN
BE DANGEROUS.
Improper installation or use of the replace can cause seri-
ous injury or death from re, burns, explosion or carbon
monoxide poisoning.
ThisseriesisdesigncertiedinaccordancewithANSI Z21.97/CSA
2.41 for Outdoor Gas Fireplaces and should be installed according
to these instructions.
Any alteration of the original design, installing it other than as
shown in these instructions or using a type of gas not shown
on the rating plate, is the responsibility of the person and
company making the change.
Manual Valve Safety System
When the burner ignites, a thermocouple senses a signal (electrical
current) that energizes a magnet in the gas valve. After 30 to 60
seconds,the controlknobcan bereleased. Ifthethermocouple
doesnotsensetheame,thegaswillshutoff.
Important
All correspondence should refer to complete Model Number, Serial
Number and type of gas.
Moisture Resistance
Thisoutdoorreplacewillshedmoderateamountsofwater,butis
not waterproof. Water and condensing water vapor may enter the
chase under certain conditions.
Thereplacewillnotperformasanexteriorwall.Moisturepenetration
must be considered for construction that places the replace in
structure walls or on moisture sensitive surfaces.

35305-8-0818 Page 5
SPECIFICATIONS
Model OLL48(FP,SP)12SP (Propane) OLL48(FP,SP)12SN (Natural)
Gas Input BTU/Hr Maximum 55,000 55,000
Gas Input BTU/Hr Medium 45,000 45,000
Gas Input BTU/Hr Minimum 35,000 35,000
Orice #44 #24
Air Shutter Setting 3/8 in. Open 1/16 in. Open
Manifold Pressure 11 in. W.C. 4-1/2 in. W.C.
DECORATIVE CRUSHED GLASS
Required Decorative Crushed Glass Media Kits (8 Sq. Ft. Required for Burner and LED Lighting)
Model Description
DG1CLF* Clear Frost
Decorative Crushed Glass (For Accent Only)
Model Description
DG1BKP* BlackPolished
DG1BUC* Blue Clear
*Clear Frost Decorative Crushed Glass is required. Decorative Glass Droplets can not be substituted for crushed glass. One bag of
crushed glass covers 1 sq. ft. Enough crushed glass to cover 8 sq. ft. is required. Glass colors may be mixed. The maximum amount
of Crushed Decorative Glass allowed is 8 bags. Transparent and Translucent crushed glass will allow LEDs to better shine through.
DECORATIVE GLASS DROPS 1-IN. (MAY BE USED IN ADDITION TO CRUSHED GLASS)
Model Description
DG1NXS Onyx Solid
DG1RYC Ruby Clear
DG1TZC Topaz Clear
DECORATIVE GLASS DROPLETS 1/2-IN. (MAY BE USED IN ADDITION TO CRUSHED GLASS)
Model Description
DG1AB Aqua Blue
DG1GC Glacier Ice
DG1SL Sangria Luster
Note: Decorative Glass Droplets may be added on top of the crushed glass as an enhancement. Decorative Glass Droplets must not
beplacedintheburnerame.SeeCrushedGlassInstallation,Page20.DonotaddmorethanonebagofDecorativeglassdroplets.
ACCESSORIES
Model Description
DT48LSS Stainless Steel Drain Tray - 48-in
WD48LSS StainlessSteelWeatherDoor-48-in(ordertwoforsee-throughreplaces)
WG48LT1 DeectorGlassforWindyApplications-48-in(ordertwoforsee-throughreplaces)
33815 Natural to Propane Conversion Kit
33814 Propane to Natural Conversion Kit
ACCESSORIES

35305-8-0818Page 6
CLEARANCES
Index
Letter Description
Dimension from
Fireplace Opening
(in inches)
AFrom ground or other
non-combustible surface 10-1/4*
B From Side Walls 6
C From Ceiling 24
D Alcove Width (minimum) 60
E Alcove Depth (maximum) 24
*NOTE: DimensionAincludes3-1/2in.underreplacefor
support framing and drain tray installation.
Figure 3 - Alcove Clearances
Minimum Wall and Ceiling Clearances
SidewallClearances:Theclearancefromtheinsideofthereplace
to any combustible wall should not be less than 6 in.
Ceiling Clearances: The ceiling height should not be less than
24 in. from the top opening.
Mantel Clearances: If a combustible mantel is installed, it must meet
the clearance requirements detailed in Figure 2.
Figure 2 - Mantel Clearances
Donotattachcombustiblematerialtothemantelofyourreplace.
Thisisarehazard.
Figure 1
COMBUSTIBLE MATERIALS
Nogreetingcards,stockingsorornamentationofanytypeshouldbe
placedonorattachedtothereplace.Thisisaheatingappliance.
Theowofheatcanignitecombustibles.
NOTE: Forsee-thrureplaces,thisappliestobothsidesofthe
unit.
Television Considerations
Installingatelevisionaboveareplacehasbecomeincreasingly
popular;however,theareaaboveanyreplacegetshotandmost
TV manufacturers recommend against placing their products near
a heat source.
Ifyouinstallatelevisionabovethisreplace,EmpireComfortSys-
tems accepts no responsibility for damage or injuries. Follow the
television manufacturer’s installation instructions, including any
recommendations regarding proximity to heat sources.
IfyouhaveaTVaboveyourreplace,turnoffthereplaceand
let it cool completely before servicing or touching any buttons on
the TV.

35305-8-0818 Page 7
Figure 4
Front and Side View of Non-Combustible Panel to Opening on Fireplace's Face
NOTE: Recommendedinstallationifusing6in.orsmallertilesornishingmaterials.
CLEARANCES
Figure 5
Front View and Side Prole of Non-Combustible Panel to Top of Fireplace
NOTE: Recommendedinstallationifusing6-in.orlargertilesornishingmaterials.
Note for Figures 4 and 5:Ifinstallingthewallboardintheushfaceconguration,trimthetwotoppanelsto16-1/2in.x26-3/4in.The
smaller non-combustible panels will not be needed.

35305-8-0818Page 8
FIREPLACE DIMENSIONS
INDEX
LETTER DIMENSION DESCRIPTION OLL48FP OLL48SP
Dimensions in Inches
AThemaximumheightofreboxface(excludingstandoffs) 24-5/16 24-5/16
BThemaximumwidthofthereboxface(excludingnailinganges) 51-3/4 51-3/4
CThemaximumdepthoftherebox 19-1/16 22-5/16
DTheheightofthereboxopening 16-3/16 16-3/16
EThewidthofthereboxopening 48 48
FTheinteriordepthoftherebox(notshown) 19 22-9/32
GTherearexteriorwidthoftherebox(notshown) 51-3/4 51-3/4
HTheheighttothereboxstandoffs 16-1/2 16-1/2
I Width from the left side of the box to the centerline of vent N/A N/A
JDepthfrombackofboxtocenterlineoftopvent N/A N/A
K Height from the bottom of the box to the gas line opening 2-9/16 2-9/16
L Depth from the front of the box to gas line opening 5-3/16 5-3/16
M Depth from rear of box to gas line opening 13-21/32 N/A
N Glass height 3-1/2 3-1/2
O Glass width 47-3/8 47-3/8
P Depth from front of box to centerline of vent N/A N/A
QDistancefromoortoreplaceopening 6-11/16 6-11/16
RHeightfromoortoventcollar N/A N/A
S Overall height to header 40-13/16 40-13/16
N/A - Not applicable for this unit.

35305-8-0818 Page 9
What to Consider Before Installing
1. Verifyreplacegastypeandgassupplytypearethesame.
2. Lookforalocationwherecombustibleswillnotinterfere.
3. 120V GFI power outlet will be needed for LED lights
4. Choose a location for gas shutoff valve.
5. Verify ventilation meets at least minimum requirements
6. Wind and rain direction
7. Drainageunderreplace.
8. Consideration drain pan and weather door accessories.
9. Glass accessories
In planning the installation for the replace, it is necessary to
determine where the unit is to be installed and whether optional
accessories are desired. Gas supply piping should also be planned
at this time.
Thereplacecanbemountedonanyofthesesurfaces:
1. A raised frame of combustible material so contact is made on
allfourperimeteredgesofthebottomofthereplaceatleast
3-1/2in.abovetheoor.
2. Fourcornersof thereplace so contactis made onall four
perimeter edges on the bottom of the unit at least 3-1/2 in.
abovetheoor.Checklocalcodesforallowances.
At this point, you should have decided what components to include
inyourinstallation,andwherethereplaceistobelocated.Ifthis
has not been done, stop and consult your dealer for assistance
with this planning.
WARNING
This replace is intended for installation on an outdoor patio
or yard. This replace shall be used only outdoors in a well
ventilated space and shall NOT be used in a building, garage,
or other enclosed area. This replace cannot be installed
with an opening to the inside of a residence.
NOTICE: This fireplace is NOT equipped with an Oxygen
Depletion Sensor (ODS) pilot.
Itisrecommendedthatthisreplacebeinstalledina“sheltered”
area.Directwind will cause anerraticame and possible main
burner outage.  This erratic ame could also lead to excessive
blacksoot.Theseissuesarenuisanceissuesratherthanasafety
issues. Avoid areas where excessive moisture or running water may
benearoronreplace.
Typical installation may include covered patio, open porch, gazebo
or an outside wall of a house.
• Minimum porch area – 96 square feet
• Minimum ceiling height – 90 inches
LED Lights will require a 120V GFI power outlet on the valve side of
thereplace.TheGFIplugwillbelocatedoutsideofthereplace.
Ajunctionboxisprovidedinsidethereplacetoprovidealocation
to plug in the LEDs.
Outdoor Fireplace Enclosure Requirements
Donotinstallreplaceuntilallnecessaryprovisionsaremadefor
combustion and ventilation air. Consult the written instructions
providedwiththereplaceforinformationconcerningcombustion
and ventilation air. In the absence of instructions, refer to the
National Fuel Gas Code, ANSI Z223.1/NFPA 54, Air for Combustion
and Ventilation, or applicable local codes.
Installation must conform with one of the following conditions:
• With walls on all sides, but with no overhead cover.
See Figure 6.
Figure 6
• Within a partial enclosure which includes an overhead cover
and no more than two side walls. These side walls may be
parallel, as in a breezeway or at right angles to each side.
See Figure 7.
Figure 7
PLANNING INSTALLATION

35305-8-0818Page 10
PLANNING INSTALLATION
• Within a partial enclosure that includes an overhead cover and
three side walls, as long as 30 percent or more of the horizontal
periphery (perimeter of walls and open side) of the enclosure
is permanently open. See Figure 8.
Figure 8
If installing in a screened in porch, the open space must be adjusted
(increased) from 30 percent (adjusted open space = 30% / % open
area of the screen mesh). "Example, if you used a screen with a
66% open area, the minimum open space of your building must
be 46% of the periphery. If you have a covered screened-in porch
that has two side walls that are 16', one wall that was against the
house that's 20' and one open side that's 20', you would have a
perimeter of 72'. You would need to have 33' of the perimeter open
(72' x 46% = 33')."
(Contact your screen manufacturer or screen dealer to
determine your screens open area).
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, personal injury
or loss of life. Installation and service must be performed
by a qualied installer, service agency or the gas supplier.
Gas Line Connection
Thereplaceisdesignedtoaccepta1/2in.gasline.Havethe
lineinstalledbyaqualiedservicepersoninaccordancewithall
building codes. Consult local building codes to properly size the gas
supplylineleadingtothe1/2in.hook-upattheunit.Thestateof
Massachusettsrequiresthataexiblereplaceconnectorcannot
exceed three feet in length.
Aex-lineconnectiontothevalveshashavebeenprovided.The
gas shut-off valve must be located outside of the unit in an
accessible area.
Checkgastypeontheratinglabellocatedonthebackofthecontrol
door. If the gas listed on the rating label located on the control pane,
does not match your gas supply, DO NOT INSTALL. Contact your
dealerforpropermodelorconversionkit.
AlwaysuseanexternalregulatorforallPropanereplacestoreduce
thesupplytankpressuretoamaximumof13in.w.c.
WARNING
Connection directly to an unregulated propane tank can
cause an explosion.
WARNING
Risk of re, explosion or asphyxiation. Ensure no ignition
ame or spark are near during installation. This includes
cigarettes or cell phones.
Leaktestallconnectionswithasoapandwatersolution.Bubble
formationwillindicatealeak.Usecautiontoavoidburns.
Figure 9
Water Drainage Requirement
Provisions must be made to drain water away from the unit. An
optional drain pan can be purchased from your Empire Dealer to
tunderthereplace.Ifinstallingtheoptionaldrainpan,itmust
beinstalledpriortoinstallingthereplace.Formoreinformation,
refer to the installation instructions supplied with the drain pan. If
this drain is not used, other water drainage is required.
