Empire Heating Systems DVC55SPPXLP-1 Quick start guide

Page 132188-0-0616
INSTALLATION INSTRUCTIONS
AND
OWNER'S MANUAL
FAN TYPE
DIRECT VENT
WALL FURNACE
MODEL
DVC55SPPXLP-1
DVC55SPPXNAT-1
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by state or local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not

kit is used.
WARNING: If not installed, operated and maintained
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
WARNING: If the information in these instructions are
-
ing property damage, personal injury or loss of life.
 
and liquids in the vicinity of this or any other appli-
ance.
— WHAT TO DO IF YOU SMELL GAS
  
  
phone in your building.
         -
bor’s phone. Follow the gas supplier’s instruc-
tions.
  
department.
— Installation and service must be performed by a quali-


Page 2 32188-0-0616
TABLE OF CONTENTS
Important Safety Information....................................................................................3
Safety Information for Users of LP Gas ...................................................................4
Requirements for Massachusetts.............................................................................5
Introduction ..............................................................................................................6
Specications...........................................................................................................6
Gas Supply............................................................................................................7-8
Clearances ..............................................................................................................8
Installation Instructions........................................................................................9-11
Lighting Instructions ..............................................................................................12
Pilot Flame Characteristics ...................................................................................13
Main Burner Flame Characteristics .......................................................................13
Wiring.....................................................................................................................14
Service and Maintenance Suggestions..................................................................15
Parts List ...............................................................................................................16
Parts View ..............................................................................................................17
Master Parts Distributor List...................................................................................18
How To Order Repair Parts ....................................................................................18
Service Notes.........................................................................................................19
SECTION PAGE

Page 332188-0-0616
THIS IS A HEATING APPLIANCE
DO NOT OPERATE THIS APPLIANCE WITHOUT FRONT PANEL INSTALLED.
•Due to high temperatures the appliance should be

draperies.
 
of high surface temperatures and should stay away
to avoid burns or clothing ignition.
 
they are in the same room as the appliance.
 
placed on or near the appliance.
 
an appliance must be replaced prior to operating
the appliance.
 
 
 Installation and repair should be done by a QUALI-
FIED SERVICE PERSON. The appliance should be
inspected before use and at least annually by a

may be required due to excessive lint from carpet-
ing, bedding materials, etc. It is imperative that
control compartments, burners and circulating air
passageways of the appliance be kept clean.
 put anything around the furnace that will

  keep the appliance area clear and free from

vapors and liquids.
  examine venting system periodically and replace
damaged parts.
 make a periodic visual check of pilot and burn-
ers. Clean and replace damaged parts.
         
closed during operation.
 use this heater if any part has been under
-
cian to inspect the heater and to replace any part of
the control system and any gas control which has
been under water.
IMPORTANT SAFETY INFORMATION

Page 4 32188-0-0616
SAFETY INFORMATION FOR USERS OF LP-GAS

and explosions. In its natural state, propane is odorless and
colorless. You may not know all the following safety precau-
tions which can protect both you and your family from an ac-
cident. Read them carefully now, then review them point by
point with the members of your household. Someday when
there may not be a minute to lose, everyone's safety will depend
on knowing exactly what to do. If, after reading the following
information, you feel you still need more information, please
contact your gas supplier.
LP-GAS WARNING ODOR
If a gas leak happens, you should be able to smell the gas
because of the odorant put in the LP-Gas.
That's your signal to go into immediate action!
• Donotoperateelectricswitches,lightmatches,useyourphone.
Do not do anything that could ignite the gas.
• Geteveryoneoutofthebuilding,vehicle,trailer,orarea.Do
that IMMEDIATELY.
• Closeallgastankorcylindersupplyvalves.
• LP-Gasisheavierthanairandmaysettleinlowareassuch
asbasements.Whenyouhavereasontosuspectagasleak,
keepoutofbasementsandotherlowareas.Stayoutuntil
reghtersdeclarethemtobesafe.
• Useyourneighbor'sphoneandcallatrainedLP-Gasservice
personand the redepartment.Eventhoughyoumaynot
continuetosmellgas,donotturnonthegasagain.Donot
re-enterthebuilding,vehicle,trailer,orarea.
• Finally, lettheservicemanandreghterscheckforescaped
gas. Have them air out the area before you return. Properly
trained LP-Gas service people should repair the leak, then
checkandrelightthegasapplianceforyou.
NO ODOR DETECTED - ODOR FADE
Some people cannot smell well. Some people cannot smell the
odorofthechemicalputintothegas.Youmustndoutifyoucan
smelltheodorantinpropane.Smokingcandecreaseyourabilityto
smell. Being around an odor for a time can affect your sensitivity or
abilitytodetectthatodor.Sometimesotherodorsintheareamask
the gas odor. People may not smell the gas odor or their minds are
onsomethingelse.Thinkingaboutsmellingagasodorcanmake
it easier to smell.
TheodorantinLP-gasiscolorless,anditcanfadeundersome
circumstances.Forexample,ifthereisanundergroundleak,the
movementofthegasthroughsoilcanltertheodorant.Odorantsin
LP-Gas also are subject to oxidation. This fading can occur if there
isrustinsidethestoragetankorinirongaspipes.
The odorant in escaped gas can adsorb or absorb onto or into
walls,masonryandothermaterialsandfabricsinaroom.Thatwill
takesomeoftheodorantoutofthegas,reducingitsodorintensity.
LP-Gasmaystratifyinaclosedarea,andtheodorintensitycould
varyatdifferentlevels.Sinceitisheavierthanair,theremaybe
more odor at lower levels. Always be sensitive to the slightest gas
odor.Ifyoudetectanyodor,treatitasaseriousleak.Immediately
go into action as instructed earlier.
SOME POINTS TO REMEMBER
• Learn to recognize the odor of LP-gas. Your local LP-Gas
Dealer can give you a "Scratch and Sniff" pamphlet. Use it to
ndoutwhatthepropaneodorsmellslike.Ifyoususpectthat
yourLP-Gashasaweakorabnormalodor,callyourLP-Gas
Dealer.
• Ifyouarenotqualied,donotlightpilotlights,performservice,
ormakeadjustmentstoappliancesontheLP-Gassystem.If
youarequalied,consciouslythinkabouttheodorofLP-Gas
prior to and while lighting pilot lights or performing service or
makingadjustments.
• Sometimesa basementor aclosed-uphouse hasa musty
smell that can cover up the LP-Gas odor. Do not try to light
pilotlights,performservice,ormakeadjustmentsinanarea
where the conditions are such that you may not detect the odor
iftherehasbeenaleakofLP-Gas.
• Odorfade,duetooxidationbyrustoradsorptiononwallsof
newcylindersandtanks,ispossible.Therefore,peopleshould
beparticularlyalertandcarefulwhennewtanksorcylinders
areplacedinservice.Odorfadecanoccurinnewtanks,or
reinstalledoldtanks,iftheyarelledandallowedtosettoo
longbeforerelling.Cylindersandtankswhichhavebeenout
of service for a time may develop internal rust which will cause
odorfade.Ifsuchconditionsaresuspectedtoexist,aperiodic
sniff test of the gas is advisable. If you have any question about
thegasodor,callyourLP-gas dealer. Aperiodic sniff test of the
LP-gas is a good safety measure under any condition.
• If,atanytime,youdonotsmelltheLP-Gasodorantandyou
thinkyoushould,assumeyouhavealeak.Thentakethesame
immediate action recommended above for the occasion when
youdodetecttheodorizedLP-Gas.
• Ifyouexperienceacomplete"gasout,"(thecontainerisunder
novaporpressure),turnthetankvalveoffimmediately.Ifthe
containervalveislefton,thecontainermaydrawinsomeair
throughopeningssuchaspilotlightorices.Ifthisoccurs,some
newinternalrustingcouldoccur.Ifthevalveisleftopen,then
treatthecontainerasanewtank.Alwaysbesureyourcon-
tainer is under vapor pressure by turning it off at the container
beforeitgoescompletelyemptyorhavingitrelledbeforeitis
completely empty.

Page 532188-0-0616
REQUIREMENTS FOR MASSACHUSETTS
Forallsidewallhorizontallyventedgasfueledequipmentinstalled
ineverydwelling,buildingorstructureusedinwholeorinpartfor
residential purposes, including those owned or operated by the
Commonwealth and where the side wall exhaust vent termination
islessthanseven(7)feetabovenishedgradeintheareaofthe
venting,includingbutnotlimitedtodecksandporches,thefollowing
requirementsshallbesatised:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At
thetimeofinstallationofthesidewallhorizontalventedgasfu-
eledequipment,theinstallingplumberorgasttershallobserve
that a hard wired carbon monoxide detector with an alarm and
batteryback-upisinstalledontheoorlevelwherethegas
equipmentistobeinstalled.Inaddition,theinstallingplumber
orgasttershallobservethatabatteryoperatedorhardwired
carbon monoxide detector with an alarm is installed on each
additionallevelofthedwelling,buildingorstructureservedby
thesidewallhorizontalventedgasfueledequipment.Itshallbe
the responsibility of the property owner to secure the services
ofqualiedlicensedprofessionalsfortheinstallationofhard
wired carbon monoxide detectors
 a. Intheeventthatthesidewallhorizontallyventedgasfu-
eledequipmentisinstalledinacrawlspaceoranattic,
the hard wired carbon monoxide detector with alarm and
batteryback-upmaybeinstalledonthenextadjacentoor
level.
b. In the event that the requirements of thissubdivision can not
bemetatthetimeofcompletionofinstallation,theowner
shallhaveaperiodofthirty(30)daystocomplywiththe
aboverequirements;provided,however,thatduringsaid
thirty(30)dayperiod,abatteryoperatedcarbonmonoxide
detector with an alarm shall be installed.
2. APPROVEDCARBONMONOXIDEDETECTORS.Eachcarbon
monoxide detector as required in accordance with the above
provisionsshallcomplywithNFPA720andbeANSI/UL2034
listedandIAScertied.
3. SIGNAGE.Ametalorplasticidenticationplateshallbeper-
manently mounted to the exterior of the building at a minimum
heightof eight(8) feetabove gradedirectlyin linewith the
exhaustventterminalforthehorizontallyvented gas fueled
heatingapplianceorequipment.Thesignshallread,inprintsize
nolessthanone-half(1/2)inchinsize,“GAS VENT DIRECTLY

4. INSPECTION. The state or local gas inspector of the side wall
horizontally vented gas fueled equipment shall not approve
theinstallationunless,uponinspection,theinspectorobserves
carbon monoxide detectors and signage installed in accordance
withtheprovisionsof248CMR5.08(2)(a)1through4.
 (b) EXEMPTIONS:Thefollowingequipmentisexemptfrom
248CMR5.08(2)(a)1through4:
  1. TheequipmentlistedinChapter10entitled“Equip-
ment Not Required To Be Vented” in the most current
edition of NFPA 54 as adopted by the Board; and
  2. ProductApprovedsidewallhorizontallyventedgas
fueled equipment installed in a room or structure
separatefromthedwelling,buildingorstructureused
in whole or in part for residential purposes.
 (c) MANUFACTURERREQUIREMENTS-GASEQUIPMENT
VENTING SYSTEM PROVIDED.When the manufacturer of
ProductApprovedsidewallhorizontallyventedgasequip-
ment provides a venting system design or venting system
componentswiththeequipment,theinstructionsprovided
by the manufacturer for installation of the equipment and
theventingsystemshallinclude:
1. Detailed instructions for the installation of the venting
systemdesign orthe venting systemcomponents; and
2. A complete parts list for the venting system design or
venting system.
 (e) AcopyofallinstallationinstructionsforallProductApproved
side wall horizontally vented gas fueled equipment, all
ventinginstructions,allpartslistsforventinginstructions,
and/orallventingdesigninstructionsshallremainwiththe
appliance or equipment at the completion of the installation.

Page 6 32188-0-0616
Introduction
Always consult your local Building Department regarding regula-
tions,codesorordinanceswhichapplytotheinstallationofadirect
vent wall furnace.
Instructions to Installer
1. Installer must leave instruction manual with owner after instal-
lation.
2. Installermusthaveownerlloutandmailwarrantycardsup-
plied with furnace.
3. Installer should show owner how to start and operate furnace.
Warning:
Any change to this furnace or its control can be dangerous.
This is a heating appliance and any panel, door or guard
removed for servicing an appliance must be replaced prior
to operating the appliance.
General Information
ThisfurnaceisdesigncertiedinaccordancewithAmericanNational
Standard/CSAStandardZ21.86andCSA2.32bytheCanadian
StandardsAssociation,asafantypedirectventwallfurnacetobe
installed according to these instructions.
Any alteration of the original design, installed other than as
shown in these instructions or use with a type of gas not
shown on the rating plate is the responsibility of the person
and company making the change.
Important
AllcorrespondenceshouldrefertocompleteModelNo.,SerialNo.
and type of gas.
Notice:Duringinitialringofthisunit,itspaintwillbakeoutand
smokewilloccur.Topreventtriggeringofsmokealarms,ventilate
the room in which the unit is installed.
Installation on Rugs and Tile
If this appliance is installed directly on carpeting, tile or other
combustiblematerialotherthanwoodooringtheapplianceshall
be installed on a metal or wood panel extending the full width and
depth of the appliance.
Thebasereferredtoabovedoesnotmeanthere-proofbaseas
used on wood stoves. The protection is for rugs that are extremely
thickandlightcoloredtile.
Installation in Residential Garages
Gasutilizationequipmentinresidentialgaragesshallbeinstalled
so that all burners and burner ignition devices are located not less
than18"abovetheoor.
Suchequipmentshallbelocated,orprotected,soitisnotsubject
to physical damage by a moving vehicle.

Installationandreplacementofgaspiping,gasutilizationequip-
ment or accessories and repair and servicing of equipment shall
be performed only by a  qualied agency.  The term "qualied
agency"meansanyindividual,rm,corporationorcompanywhich
either in person or through a representative is engaged in and is
responsiblefor(a)theinstallationorreplacementofgaspipingor
(b)theconnection,installation,repairorservicingofequipment,who
isexperiencedinsuchwork,familiarwithallprecautionsrequired
and has complied with all the requirements of the authority having
jurisdiction.
State of Massachusetts: The installation must be made
by a licensed plumber or gas tter in the Commonwealth of
Massachusetts.
Theinstallationmustconformwithlocalcodesor,intheabsenceof
localcodes,withtheNational Fuel Gas Code ANSI Z223.1/NFPA
54* Natural Gas and Propane Installation Code, CSA B149.1.
*Available from the American National Standards Institute, Inc., 11
West 42nd St., New York, N.Y. 10036.
High Altitudes
Foraltitudes/elevationsabove2,000feet,inputratingsshouldbe
reducedattherateof4percentforeach1,000feetabovesealevel.
Canadian High Altitudes for locations having an elevation above
meansealevelbetween2,000feet(610m)and4,500feet(1370m),
themanifoldpressureistobedecreasedfrom4.0"w.c.to3.2"w.c.
forNaturalGasandfrom10.0"w.c.to8.0"w.c.forPropaneGas.

Depressingtheredbuttoncompletelycausesasparktooccurat
the pilot. This is a substitute for a match which requires opening
the pilot hole cover.
Tolightthepilot,itisimportantthattheelectrodebe1/8"fromthe
thermocouple.Thesparkmustoccuratthepointtheburnerame
hits the thermocouple. The end of the electrode will be red hot with
the pilot on.
Onanewinstallationwithairinthegasline,itissuggestedthata
matchbeused.Thematchwilllightthepilotfasterthanthepiezo
under this condition.
Model DV-55SPP
InputBTU/HR 55,000
Height 823/8"
Width 16"
Depth 111/2"
Gas Inlet 1/2"Pipe
CFM 400
Accessories
SOR-1 Register Side Outlet
SOK-1 SideOutletKit,10"BootAssemblywithRegister
DV-822 Vinyl Siding Vent Kit
INTRODUCTION
SPECIFICATIONS
To Conserve Gas: Turn off pilot when heater is not in use.

Page 732188-0-0616
GAS SUPPLY
Locating Gas Supply
Thegaslinecanentertheuniteitherthroughtheoororoutside
wall. The gas line opening should be made at this time. Location
oftheopeningwillbedeterminedbythepositionofoorjoistsand
the valve and union used for servicing.
Recommended Gas Pipe Diameter
Pipe Length
Schedule40Pipe
Inside Diameter
Tubing,TypeL
Outside Diameter
Nat. L.P. Nat. L.P.
0-10feet
0-3meters
1/2”
12.7 mm
3/8”
9.5mm
1/2”
12.7 mm
3/8”
9.5 mm
10-40feet
4-12 meters
1/2”
12.7 mm
1/2”
12.7mm
5/8”
15.9 mm
1/2”
12.7 mm
40-100feet
13-30meters
1/2”
12.7 mm
1/2”
12.7mm
3/4”
19 mm
1/2”
12.7 mm
100-150feet
31-46 meters
3/4”
19 mm
1/2”
12.7 mm
7/8”
22.2 mm
3/4”
19 mm
Note:Neveruseplasticpipe.Checktoconrmwhetheryourlocal
codesallowcoppertubingorgalvanized.
Note: Sincesomemunicipalitieshaveadditionallocalcodes,itis
always best to consult your local authority and installation code.
Theuseofthefollowinggasconnectorsisrecommended:
— ANSZ21.24ApplianceConnectorsofCorrugatedMetalTubing
and Fittings
— ANSZ21.45AssembledFlexibleApplianceConnectorsofOther
Than All-Metal Construction
The above connectors may be used if acceptable by the authority
having jurisdiction. The state of Massachusetts requires that a
exibleapplianceconnectorcannotexceedthreefeetinlength.
NPT NIPPLE
Figure 1
ConsultthecurrentNationalFuelGasCode,ANSIZ223.1CAN/
CGA-B149(.1or.2)installationcode.
Installing a New Main Gas Cock
Eachapplianceshouldhaveitsownmanualgascock.
Amanualmaingascockshouldbelocatedinthevicinityoftheunit.
Wherenoneexists,orwhereitssizeorlocationisnotadequate,
contactyourlocalauthorizedinstallerforinstallationorrelocation.
Compounds used on threaded joints of gas piping shall be resistant
totheactionofliqueedpetroleumgases.
Thegaslinesmustbecheckedforleaksbytheinstaller.Thisshould
be done with a soap solution watching for bubbles on all exposed
connections,andifunexposed,apressuretestshouldbemade.

be disconnected from piping at inlet of control valve and pipe
capped or plugged for pressure test. Never pressure test with

A gas valve and ground joint union should be installed in the gas
line upstream of the gas control to aid in servicing. It is required by
the National Fuel Gas Code that a drip line be installed near the gas
inlet. This should consist of a vertical length of pipe tee connected
into the gas line that is capped on the bottom in which condensation
and foreign particles may collect.
Figure 2
Method of Installing a Tee Fitting Sediment Trap
Pressure Testing of the Gas Supply System
1. Tochecktheinletpressuretothegasvalve,a1/8"(3mm)N.P.T.
pluggedtapping,accessiblefortestgaugeconnection,mustbe
placed immediately upstream of the gas supply connection to
the appliance.
2. The appliance and its individual shutoff valve must be
disconnected from the gas supply piping system during any
pressure testing of that system at test pressures in excess of
1/2psig(3.5kPa).
3. The appliance must be isolatedfrom the gas supply piping system
by closing its individual manual shutoff valve during any pressure
testing of the gas supply piping system at test pressures equal
toorlessthan1/2psig(3.5kPa).
Attention! If one of the above procedures results in pressures in
excessof1/2psig(14"w.c.)(3.5kPa)ontheappliancegasvalve,
itwillresultinahazardouscondition.
Figure 3

Page 8 32188-0-0616
1. Inselectingalocationforinstallation,itisnecessarytoprovide
adequate accessibility clearances for servicing and proper
installation.
2. TheDV-55minimumwalldepthis41/2inchesandmaximum
wall depth is 13 inches. The maximum wall depth may be
extendedto19"(483mm)usingthemodelDV-1190extended
uekit.Theuseoftubesnotsuppliedbythemanufacturer
results in unsatisfactory performance.
3. The DV-55 can be attached to the wall or recessed into the
wallupto4inchesindepthbuttheminimum41/2inchesvent/
airintakesystemwalldepthmustbemaintained.Example:
Iffurnaceisrecessedintothewallatadepthof4inches,the
minimumwalldepthmustbe81/2inches.
4. Thewallinwhichthefurnaceisrecessedhas(0)zeroclear-
ance to the furnace sides and top.
5. Whenusingsidedischargeregisters,SOR-1orSOK-1,the
furnace cannot be recessed into the wall.
6. Clearance to sidewall or combustible material is 4 inches.
7. Ceiling clearance is 4 inches.
8. Floorandrearwallclearanceis(0)zeroinches.
9. Clearance of 18 inches is required to sidewall or combustible
material when ush mounted SOR-1, side outlet register is
used. See Figure 4.
10. Theminimumdistancefromthecenteroftheventcaptothe
nearest outside corner or obstruction is 24 inches.
CLEARANCES
Checking Manifold Pressure
Both Propane and Natural gas valves have a built-in pressure
regulator in the gas valve. Natural gas models will have a manifold
pressureofapproximately4.0"w.c.atthevalveoutletwiththeinlet
pressuretothevalvefromaminimumof6.0"w.c.forthepurposeof
inputadjustmenttoamaximumof7.0"w.c.Propanegasmodels
willhaveamanifoldpressureapproximately10.0"w.c.atthevalve
outletwiththeinletpressuretothevalvefromaminimumof11.0"
w.c.forthepurposeofinputadjustmenttoamaximumof13.0"w.c.
A1/8"N.P.T.pluggedtapping,accessiblefortestgaugeconnection,
is located on the outlet side of the gas control.
Thebuilt-inregulatorcomesonatapproximately1/4thpressure
andfullonin10seconds.
GAS SUPPLY
The vent terminal of a direct vent appliance with an input over
50,000BTUperhourshallbelocatedatleast12inchesfromany
openingthroughwhichuegasescouldenterabuilding.Thebot-
tomoftheventterminalandtheairintakeshallbelocatedatleast
12 inches above grade.
WARNING: The nearest point of the vent cap should be a


distance will reduce the chance of gas entering the vent cap.
Figure 4

Page 932188-0-0616
Locating Wall Opening
The furnace is to be located on an outside wall. Locate wall studs
so that wall opening will be located between wall studs. The furnace
is 16 inches in width and normal 16 inches on center studs will
not allow the furnace to be recessed into the wall unless a stud is
repositioned. The wall opening required as shown in Figure 5 is a
diameterof71/2inches.
A template is provided in furnace carton for positioning furnace on
thewall.Also,refertoFigure5forpositioningthefurnaceonwall
and for locating gas line connection.
Installing Optional Side Outlets
Sideoutletregister,SOR-1maybeinstalledononeorbothsides
of the furnace at the required clearances of 18 inches to adjacent
wall or combustible material as shown in Figure 4.
 1. Locate and cut the 5 1/2" square opening in the cabinet
sideusingthetemplatefromthekit,exposingtheinnerliner
knock-out.
 2. Removetheknock-out.
 3. Placetheregisteronthe51/2"openingwiththelouversset
forthedesireddirectionandmarkthemountingholesusing
the register as a template.
 4. Drill(2)1/8"diameterholesincabinetsideandfastenthe
registerinplacewith(2)#10x1"screwsprovided.
Sideoutletkit,10"bootassemblywithregister,SOK-1forwarmair
discharge into an adjoining room may be installed on either side of
the furnace at the required clearance of 4 inches to adjacent wall
as shown in Figure 7.
 1. Locate and cut the 5 1/2" square opening in the cabinet
sideusingthetemplatefromthekit,exposingtheinnerliner
knock-out.
 2. Removetheknock-out.
 3. Usingtheinnerandouterbootsasholetemplates,markand
drill(8)1/8"diameterholesintheinnerlinerandcabinetside.
 4. UsingFigure7locateandcuta63/4"squareopeningthrough
walls.
 5. Prepare wall opening for the vent-air intake system (see
Locating Wall Opening).
 6. Withfurnaceinplace,aftercheckingalignmentofsideoutlet
openinginwallandfurnace,placethe93/8"x93/8"side
outletwallplateoverouterboot,passtheouterbootthrough
the wall and attach side outlet wall plate to furnace side of
wallwith(2)#10x1"screwsprovided.
 7. Fastenouterboottothecabinetsidewith(4)#8x1/4"screws
provided.
 8. Positionandattachinnerboottoinnerlinerwith(4)#8x1/4"
screws provided.
9. Locate the register with its louvers positioned for the desired
airdischargedirectionandmarkthemountingholesusing
the register as a template.
 10. Drill(2)1/8"diameterholesinthewallandfastentheregister
inplacewith(2)#10x1"screwsprovided.
Figure 5
   
INSTALLATION INSTRUCTIONS

Page10 32188-0-0616
Cutting Vent Tubes
This is the most important part of the installation. With the furnace
installedonwallthe6"diameterairinlettubeandthe4"diameterue
outlettubearetobemarkedandcutusingthefollowingprocedure.
1. Attach 6" diameter air inlet tube onto the collar of air drop as-
sembly. Be sure 6" diameter air inlet tube is placed as far as
possibleontothecollaroftheairdropassembly.Markthe6"
diameterairinlettube1/2"beyondtheoutsidewall.Remove
6" diameter air inlet tube from collar of air drop assembly.
2. Attach4"diameterueoutlettubeontoueoutletcollaron
combustionchamber.Besure4"diameterueoutlettubeis
placedasfaraspossibleontothecollarofueoutlet.Mark
the4"diameterueoutlettube21/4"beyondtheoutsidewall.
Remove4"diameterueoutlettubefromcollarofueoutlet
on combustion chamber.
3. Markorwraptapecompletelyaroundthetubesatthemarked
pointstohelpinmakingatruecut.Donotcrimporenlarge
tubes.
Installing Vent Assembly
1. Placecaulking(notprovided)beneaththeedgeoftheoutside
mountingplate.Useadditionalcaulkingtocorrectunevenwall
surface,suchasclapboard.
2. Attach 6" diameter air inlet tube onto the collar of air drop
assembly.Attachcaulked,outsidemountingplateintothe6"
diameter air inlet tube. Position the outside mounting plate so
that 6" diameter air inlet tube has a slight downward slope to the
outside. The downward slope is necessary to prevent the
entry of rainwater. Attach outside mounting plate to exterior
wallwith(4)#10x11/2"screwsprovided.
3. Applyfurnacecementto4"diameterueoutletcollaroncom-
bustion chamber and to 4" diameter collar on vent cap. Attach
4"diameterueoutlettubeontoueoutletcollaroncombustion
chamber.Attachventcapintothe4"diameterueoutlettube.
Attachventcaptooutsidemountingplatewith(3)#10x1/2"
screws provided.
4. Installation is completed.
Reassembly And Resealing Vent-Air Intake System
Whenvent-airintakesystemisremovedforservicingthefurnace,
the following steps will assure proper reassembly and resealing of
thevent-airintakeassembly.
1. Removeoldcaulkingbeneaththeedgeoftheoutsidemount-
ingplate.Applynewcaulkingbeneaththeedgeoftheoutside
mountingplate.Useadditionalcaulkingtocorrectunevenwall
surface,suchasclapboard.
2. Removeoldfurnacecementfromueoutletcollaroncombustion
chamber and collar of vent cap. Remove old furnace cement
frombothendsof4"diameterueoutlettube.
3. Attach 6" diameter air inlet tube onto the collar of air drop
assembly.Attachcaulked,outsidemountingplateintothe6"
diameter air inlet tube. Position the outside mounting plate so
that 6" diameter air inlet tube has a slight downward slope to the
outside. The downward slope is necessary to prevent the
entry of rainwater. Attach outside mounting plate to exterior
wallwith(4)#10x1"screwsprovided.
4. Applyfurnacecementto4"diameterueoutletcollaroncom-
bustion chamber and to 4" diameter collar on vent cap. Attach
4"diameterueoutlettubeontoueoutletcollaroncombustion
chamber.Attachventcapintothe4"diameterueoutlettube.
Attachventcaptooutsidemountingplatewith(3)#10x1/2"
screws provided.
5. Reassemblyandresealingvent-airintakesystemiscompleted.
Figure 8
Locating Electric Supply
A7/8"diameterknockoutisprovidedatthebottomoftheleftand
rightsidepanels.Athree-prong(grounding)plugassemblyislocated
within the control compartment (bottom) of the furnace. Please
remove7/8" knockoutfromappropriatesidepanelwhenrouting
plug assembly to an electrical outlet.
Installation of Three-prong (Grounding) Plug Assembly
1.Disconnectnyloncapon3'plugassemblyfromnylonplugon
wiringharness.Remove3'plugassemblyfromcontrolcompart-
ment(bottom)ofthefurnace.
2.Remove7/8"knockoutfromappropriatesidepanel.
3.Insertnyloncapon3'plugassemblyintothe7/8"holeintheside
panel.
4.Connect nylon capon 3' plugassemblyto nylon plug onthe
wiring harness.
5.Place7/8"strainreliefbushingaroundthecordofthe3'plug
assembly.Insert7/8"strainreliefbushingintothe7/8"holein
the side panel.
Attention! The7/8"strainreliefbushingislocatedwithinthesame
envelopeastheInstallationInstructionsandOwner'sManual.
Attaching Furnace to Wall
RefertoFigure5forthelocationofthe71/2"diameterwallopen-
ing for the furnace. After the wall opening has been located and
cut,positionueoutletonfurnaceincenterofwallopening.When
attaching furnace to the wall remove that portion of baseboard and
molding on the wall which is behind the furnace. Attach furnace to
wall,attheoutercasingtop,with(2)toggleboltsprovidedandtooor,
attheoutercasingbottom,with(2)#10x11/2"screwsprovided.
Attention! The screw holes on the outer casing bottom are off-set
abovetheoorapproximately3/8".Donotover-tightenscrewsand
distort the off-set on the outer casing bottom. Distortion of the outer
casing bottom will not allow the lower front panel to be attached
to the furnace.
INSTALLATION INSTRUCTIONS (continued)

Page 1132188-0-0616
Installing a Vent Near a Window Ledge,
Other Type of Projection or on Siding (vinyl, aluminum, etc.)
Direct vent furnaces are designed to be installed on a uniform out-
sidewall.Whenthewindcomesfromanyangle(up,downorfrom
eitherside),itmusthittheventcapequallyoverboththeairinlet
andtheueoutletportionsofthevent.Anywallprojection,such
asadoororwindowcasing,whichdisturbsthewindononesideof
theairinletsectionwillresultinbackpressureontheuesection
smotheringtheameandeventualpilotoutage.
When the vent cap is to be installed on siding or it appears that a
projection within 6" of any side of the air inlet section could shield
theairinletsection,theentireventshouldbesupportedawayfrom
the wall at least the distance of the projection. 2" x 4" framing whose
outside dimensions match the overall dimensions of the mounting
plate is recommended. The 2" x 4" framing protects siding from
possible warpage or discoloration. All joints can then be sealed and
painted. The wall depth plus the additional depth of the 2" x 4" fram-
ingshouldnotexceedatotaldepthof13"forDV-55.(SeeFigure9)
Vinyl siding vent kit, DV-822, is available from Empire Comfort
Systems,Inc.Thedepthis3",whichenablestheventcaptobe
extended away from siding or projections. The wall depth plus the
additional 3" depth of the vinyl siding vent cap extension should not
exceedatotaldepthof13"forDV-55.(SeeFigure10)
Warning: When vinyl siding vent kit, DV-822 or 2" x 4" fram-
ing is added to an existing installation (furnace is installed)

or air inlet tube. An air tight seal is required for both tubes.

Figure 9 Figure 10
INSTALLATION INSTRUCTIONS (continued)

Page 12 32188-0-0616
1. STOP! Read the safety information above.
2. Turn off all electric power to the appliance.
3. Remove control access panel (lower front panel).
4. Turn gas control knob clockwise to "OFF."
5. Wait ten (10) minutes to clear out any gas. Then

gas, STOP! Follow "B" in the safety information
above. If you don't smell gas, go to the next step.
 
cover located on the
combustion chamber.
 
tube from gas control.
The pilot is located
between the two burner
tubes behind the pilot access cover.
8. Turn gas control knob counterclockwise to
"PILOT."
9. Push and hold red reset button down completely
and repeatedly push the ignitor button until the
pilot burner is lit. Pilot may also be lit with a match.
Continue to hold the red reset button down for about
one (1) minute after the pilot is lit. Release button
and it will pop back up. Pilot should remain lit. If
it goes out, repeat steps 5 through 10.
        

technician or gas supplier.
 
turn the gas control knob to "OFF" and call
your service technician or gas supplier.
10. Replace pilot access cover.
11. Turn gas control knob counterclockwise
to "ON."
12. Replace control access panel (lower front panel).
13. Turn on all electric power to the appliance.
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING:
may result causing property damage, personal injury or loss of life.
A. This appliance has a pilot which must be lighted by hand.
When lighting the pilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around the appliance area


WHAT TO DO IF YOU SMELL GAS
 
 
do not use any phone in your building.
 
phone. Follow the gas supplier's instructions.
     

C. Use only your hand to push in or turn the gas control
knob. Never use tools. If the knob will not push in or
-
vice technician. Force or attempted repair may result

D. Do not use this appliance if any part has been under

to inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
TO TURN OFF GAS TO APPLIANCE
1. Turn off all electric power to appliance if service is
to be performed .
2. Remove control access panel (lower front panel).
3. Push in gas control knob slightly and turn clock-
wise to "OFF." Do not force.
4. Replace control access panel (lower front panel).
LIGHTING INSTRUCTIONS
LIGHTING INSTRUCTIONS

Page 1332188-0-0616
Thecorrectamewillbeashortblueinneramewithamuchlarger
lightblueouterame.Themainburner(Figure12)showstheap-
proximateheightofeachpartoftheameforeachgas.Theburner
doesnothaveaprimaryairadjustment.Theamewillbecorrect
ifthefactory-setpressureandoriceopeningareused.Afterthe
furnacehasbeenoperating,theburnerportsmaybeblockedby
foreignmattercarriedinbycombustionair.Therefore,cleaningof
theburnermaybeneededforproperame.
Tocleanburnerportdisconnectthegassupplytothevalve,and
remove the eight screwsfastening the burner door.After removing the
burnerdoorfromthecombustionchamber,removerearburner,pilot
burner and front burner. With front and rear burners removed from
furnace,forcewaterintotheribbonportsanddrywithairpressure.
The correct pilot ame (Figure 11) will be blue, extending past
thethermocouple.Theamewillsurroundthethermocouplejust
below the tip.
Natural gas pilots require adjusting when the inlet gas pressure is
above 5" w.c. Remove the pilot cover screw on the control valve
(Figure 3, page 8), and turn the adjustment screw clockwise to
reduceame.Replacepilotcoverscrewtoeliminategasleaking
at that control valve opening.
LPgas(propane)willnotrequireadjustment.
Afteruse,cleaningmayberequiredfortheproperame.
PROPER FLAME ADJUSTMENT
Figure 11
Figure 12
PILOT FLAME CHARACTERISTICS
MAIN BURNER FLAME CHARACTERISTICS

Page 14 32188-0-0616
Figure 13
Wiring
Theappliance,wheninstalled,mustbeelectricallygrounded
inaccordancewithlocalcodesor,intheabsenceoflocal
codes,withtheNational Electrical Code, ANSI/NFPA 70 or
Canadian Electrical Code, CSAC22.1, if an external electrical
sourceisutilized.This appliance is equipped with a three-
prong [grounding] plug for your protection against shock

grounded three-prong receptacle. Do not cut or remove
the grounding prong from this plug. For an ungrounded
receptacle,anadapter,whichhastwoprongsandawirefor
grounding,canbepurchased,pluggedintotheungrounded
receptacle and its wire connected to the receptacle mounting
screw.Withthiswirecompletingtheground,theappliance
cord plug can be plugged into the adapter and be electrically
grounded. A7/8" hole is provided in the junction box for use
with a conduit connector if local codes require this type of
protection.
CAUTION: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause improper
and dangerous operation. Verify proper operation after
servicing.
To Conserve Gas: Turn off pilot when heater is not in use.
Installing the ON/OFF Device
ToinstallanON/OFFdevice(suchasawallswitch,remote,
toggleswitch,orthermostat),removethewirenutfromthe
two wires from the valve. Run additional wire from the valve
wirestotheON/OFFdevice.InstalltheON/OFFdeviceinthe
same room as the furnace following the installation instruc-
tionssuppliedwithit.Intheabsenceofinstructions,installthe
ON/OFFdevice4to5feetabovetheooronaninteriorwall
notaffectedbyanotherheatingsource(i.e.stoveorwater
heater) or the temperature of an adjoining room.
WIRING
IF ANY OF THE ORIGINAL WIRE AS SUPPLIED
WITH THIS UNIT MUST BE REPLACED, IT MUST
BE REPLACED WITH 150°C THERMOPLASTIC
4/64 THICK OR ITS EQUIVALENT.
120V. 60Hz. LESS THAN 3 AMPS
S´IL YAUN FIL ORIGINAL FOURNI AVEC
L´APPAREIL QUI DIOT ÊTRE REMPLACÉ. IL DOIT
ÊTRE REMPLACÉ AVEC UN FIL
THERMOPLASTIQUE 150°C.
120V. 60Hz. MOINS DE 3 AMPS.
—————— ———————————————————————————————————————————————
VALVE DE GAZ
PÉRIPHÉRIQUES
120 VOLTS
LADDER WIRING DIAGRAM
——————————————————————————
DIAGRAMME À L´ÉCHELLE
D´INSTALLATION ÉLECTRIQUE
YELLOW
——— —————————
JAUNE
WHITE
————————————
BLANC
BLACK
——— —————————
NOIR
RED
—
ROUGE
RED
—
ROUGE
TRANSFORMER
——— —— —————————————————— —
TRANSFORMATEUR
24 VOLTS
MOTOR
————— —————
MOTEUR
AUTO FAN
——— —— ——————————— —
VENTILATEUR
AUTO
GAS VALVE
——— —— ————————————— —
LIMIT CONTROL
——— ———————————————— —
CONTROL DE
TOLERANCE
ON/OFF DEVICE
——— ———————————————— —
ON/OFF
WIRE NUT
—————————————---------------- —
FILS TORSADÉS
LOW VOLTAGE (BAS VOLTAGE)
120 VOLTS
SCHEMATIC WIRING DIAGRAM
——————————————————————————————
SCHÉMA ÉINSTALLATION LECTRIQUE
JUNCTION BOX
—— —— ——— —————————————— ——
BOÎTE DE JONCTION
LIMIT CONTROL
——— — ————————————————
CONTROL DE
TOLERANCE
AUTO FAN
——— —— ————————————
VENTILATE
AUTO
TRANSFORMER
——— —— ———————————————————
TRANSFORMATEUR
SPT-3 CORDSET
———————————————————— —
CORDON SPT-3
GAS VALVE
——— —— ————————————— —
VALVE DE GAZ
WHITE (BLANC)
BLACK (NOIR)
MOTOR
————— —————
MOTEUR
ON/OFF DEVICE
——— ———————————————— —
ON/OFF
PÉRIPHÉRIQUES
WIRE NUT
—————————————---------------- —
FILS TORSADÉS

Page 1532188-0-0616
Replacing Fan and Oiling the Motor
The fan motorshould be cleaned and oiled onceeach heating season.
Toreachthemotor,withdrawthemetalshroudsurroundingthefan
blade by removing the screws on each side. Oil holes are located
onthetopateachendofthemotor.Useafewdropsof#10motor
oil.Tocleanthemotor,blowairthroughitsventilationopeningswith
a vacuum cleaner or low pressure air source.
Iffanmotorisreplaced,thesiliconerubbergaskets,seePage16,
IndexNo.4,PartNo.712059,shouldalsobereplaced.Thegaskets
mustbestretchedtotthemotorboltsintothegasketholesand
thenthemotorandgasketsinstalledonthemotormountingbars.
GENERAL : Allfurnaceshavebeenre-testedtocheckforproper
operation.Thisincludes,mainburnerame,pilotame,fanop-
eration,fancontrol,limitcontrolandautomaticvalveoperation.If
thefurnacefailstofunctiononinitialinstallation,itisadvisableto
re-checkthefollowing:
1. 115 volts to the junction box.
2. Inlet gas pressure.
3. The 24 volt system.
4. Type of gas being used and that shown on the rating label.
TheServiceDepartmentatEmpireComfortSystems,Inc.maybe
contactedtoassistinservicingfurnaceorcallaqualiedserviceman..
    -
Disconnect the gas supply at
the inlet to the control valve. Then remove the burner door to which
the above components are attached.
Servicing The Fan Motor: The upper front panel, the shroud
surrounding the fan blade and fan blade must be removed. See
"Replacing Fan and Oiling the Motor" paragraph above.
Spark Igniter Does Not Light Pilot: Withairinthegasline,such
aswhenthe furnace isrstinstalled or wasoffallsummer,the
pilotamemaybetooleantoigniteontherstfewtrials.Turnthe
controlvalveknobtopilotpositionanddepresstheredresetbutton.
Holdingthebuttondowncontinuallytobleedtheline:
1. Use lighter rod to light pilot with a match.
2. Usethepiezoignitorat30secondintervalsuntilitlights.
If Electrode Does Not Produce Spark:
1. Checkwireconnections.
2. Checkgapforpilotburnertotheelectrodetip.Shouldbe
between1/8"and3/16".Electrodewireandtipmustbemore
than1/4"awayfromallothermetalcomponents.
If Pilot Does Not Light By Any Means:
1. Checkvalveknobforbeinginthe"Pilot"position.
2. Checkpilotadjustmentforbeingfullopen(counterclockwise
to open).
3. Ifgasisavailableinthesupplytubing,thepilotoriceand/
or pilot burner is probably restricted by a spider web. Clean
pilot assembly and relight.

1. Follow instructions and hold button down longer and harder.
2. Determineifpilotameextendspastthermocouple;ifnot,
adjust input or clean pilot burner.
3. Replace thermocouple if millivolts read less than 15 millivolts.
Pilot Outage During Normal Operation:
1. Checkairinlettubeforagoodtighttatbothends
(6"diametertube).
2. Checkburnerdoorandpilotholecoverfortightseal.
3. Checkinputbymanifoldpressuregaugeorgasmeter.
Main Gas Valve Does Not Open When The ON/OFF Device Is
Turned To On:
1. Checkfor24voltstovalvebyremovingonewireandtouching
to the SAME TERMINAL it was on. Terminal should have a
lightspark.
2. Tocheckforlinevoltagetofurnace,removelowerfrontpanel
and switch compartment cover and short across two-terminal
fancontroltoallowfantooperate.(Figure13)
SERVICE & MAINTENANCE SUGGESTIONS

Page 16 32188-0-0616
PLEASE NOTE: Whenorderingparts,itisveryimportantthatpart number and description of part coincide.
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
PARTS LIST
Index
No. Part No. Description
1 11762 Outer Casing Top
2 R618 MotorMount(FourRequired)
3 11764 MotorMountingBar(TwoRequired)
4 M147 Gasket(TwoRequired)
5 R619 Motor
6 11787 Fan Blade
7 11766 Fan Housing
8 DV559 Upper Front Panel
9 11759 Side Panel
10 DV613 Right Inner Shield
11 DV725 Vent Cap
12 DV131 Outside Mounting Plate
13 DV548 Air Inlet Tube
14 DV524 Flue Outlet Tube
15 DV600 Vent Kit Complete
(Nos.11,12,13,14)
16 DV1386 Air Drop
17 M96 GasketforFlueOutletFlange
18 DV579C Combustion Chamber
19 R1536 Bushing
20 11765 Switch Compartment Assembly
21 R630 Limit Control
22 R1941 Fan Control
23 DV832 Switch Compartment Cover
24 DV562 Lower Front Panel
25 DV826 Rear Burner
26 R685 Thermocouple
27 R622L PilotwithOriceLPGas
27 R622N PilotwithOriceNaturalGas
28 DV808 Pilot Tubing
29 DV824 Front Burner
30 P8842 MainBurnerOriceNaturalGas(Two
Required)
30 P8853 MainBurnerOriceLPGas(Two
Required)
31 DV687 Manifold and Plate Assembly
32 M148 ManifoldGasket
33 M155 GasketforObservationHoleCover
34 DV781 LightingHoleCoverw/Mica
35 DV064 Cover Plate for Observation Hole
36 DV775 SealBracket
37 M147 GasketTubingSeal
38 DV847 Burner Door Natural Gas
38 DV972 Burner Door LP Gas
39 DV779 GasketforBurnerDoor
40 P112 Manifold Union
41 R5655 GasValveVR8200CLPGas
41 R2148 GasValveVR8200CNaturalGas
42 UH810 TransformerMountingBracket
43 R1995 Transformer
44 UH451 Junction Box Cover
45 DV967 Outer Casing Bottom
46 R1515 Bushing
47 R2708 PiezoIgnitor
48 DV571 Control Compartment Divider
49 DV671 Manifold Support
50 DV765 GasketforChamberAirInlet(Top&
Bottom)(TwoRequired)
51 DV764 GasketforChamberAirInlet(Sides)
(TwoRequired)
52 R690 Cord Set
53 R1404 Bushing
54 DV614 Left Inner Shield
55 11759 Side Panel
Not
Shown R9832 Wiring Assembly Upper
Not
Shown R9833 Wiring Assembly Lower
Not
Shown R734 Lighter Rod
Not
Shown 742265 PilotOriceLPGas
Not
Shown R3469 PilotOriceNaturalGas
Index
No.
Part No. Description

Page 1732188-0-0616
PARTS VIEW

Page 18 32188-0-0616
ToOrderPartsUnderWarranty,pleasecontactyourlocalEmpiredealer.Seethedealerlocatoratwww.empirecomfort.com.Toprovidewar-
rantyservice,yourdealerwillneedyournameandaddress,purchasedateandserialnumber,andthenatureoftheproblemwiththeunit.
ToOrderPartsAftertheWarrantyPeriod,pleasecontactyourdealeroroneoftheMasterPartsDistributorslistedbelow.Thislistchanges
fromtimetotime.Forthecurrentlist,pleaseclickontheMasterPartsbuttonatwww.empirecomfort.com.
Pleasenote:MasterPartsDistributorsareindependentbusinessesthatstockthemostcommonlyorderedOriginalEquipmentrepairparts
forHeaters,Grills,andFireplacesmanufacturedbyEmpireComfortSystemsInc.
MASTER PARTS DISTRIBUTOR LIST
Parts Not Under Warranty
PartscanbeorderedthroughyourServicePerson,Dealer,oraMasterPartsDistributor.SeethispagefortheMasterPartsDistribu-
torslist.Forbestresults,theservice person or dealer should order parts through the distributor. Parts can be shipped directly to the
service person/dealer.
Warranty Parts
Warranty parts will need a proof of purchase and can be ordered by your Service Person or Dealer. Proof of purchase is required for
warranty parts.
AllpartslistedinthePartsListhaveaPartNumber.Whenorderingparts,rstobtaintheModelNumberandSerialNumberfromthe
nameplateonyourequipment.ThendeterminethePartNumber(not the Index Number) and the Description of each part from the fol-
lowing illustration and part list. Be sure to give all this information . . .
Appliance Model Number Part Description
Appliance Serial Number Part Number
TypeofGas(PropaneorNatural)
Donotorderbolts,screws,washersornuts.Theyarestandardhardwareitemsandcanbepurchasedatanylocalhardwarestore.
Shipmentscontingentuponstrikes,resandallcausesbeyondourcontrol.
HOW TO ORDER REPAIR PARTS
Dey Distributing
1401WillowLakeBoulevard
VadnaisHeights,MN55101
Phone: [phone]
Toll Free:800-397-1339
Website: www.deydistributing.com
Parts: Heater, Hearth and Grills
Victor Division of F. W. Webb Company
200LocustStreet
Hartford,CT06114
Phone:860-722-2433
Toll Free: 800-243-9360
Fax: [phone]
Toll Free Fax:800-274-2004
Websites: www.fwwebb.com&www.victormfg.com
Parts: Heater, Hearth and Grills
East Coast Energy Products
10EastRoute36
WestLongBranch,NJ07764
Phone: [phone]
Toll Free:800-755-8809
Fax: [phone]
Website: www.eastcoastenergy.com
Parts: Heater, Hearth and Grills
Able Distributors
2501NorthCentralAvenue
Chicago,IL60639
Phone: [phone]
Toll Free:800-880-2253
Fax: [phone]
Website: www. abledistributors.com
Parts: Heater

Page 1932188-0-0616
WARRANTY
Empire Comfort Systems Inc. warranties this space heating product to be free from defects at the time of purchase and for the
periodsspeciedbelow.Spaceheatingproductsmustbeinstalledbyaqualiedtechnicianandmustbemaintainedandoperated
safely,inaccordancewiththeinstructionsintheowner’smanual.Thiswarrantyappliestotheoriginalpurchaseronlyandisnot
transferable.Allwarrantyrepairsmustbeaccomplishedbyaqualiedgasappliancetechnician.
Limited Ten-Year Parts Warranty – Combustion Chamber
 Empirepromisestotheownerthatifthecombustionchamber(seepartslist)failsbecauseofdefectiveworkmanship
 ormaterialwithtenyearsfromthedateofpurchase,EmpirewillrepairorreplaceatEmpire’soption.
Limited One-Year Parts Warranty – Remote Controls, Accessories, and Parts
 Shouldanyremotecontrol,accessory,orotherpartfailbecauseofdefectiveworkmanshipwithinoneyearfromthe
 dateofpurchase,EmpirewillrepairorreplaceatEmpire’soption.
Duties Of The Owner
 Theappliancemustbeinstalledbyaqualiedinstallerandoperatedinaccordancewiththeinstructionsfurnishedwith
 theappliance.Abillofsale,cancelledcheck,orpaymentrecordshouldbekepttoverifypurchasedateandestablish
warranty period. Ready access to the appliance for service.
What Is Not Covered
 Damagesthatmightresultfromtheuse,misuse,orimproperinstallationofthisappliance.
 Travel,diagnosticcostsandfreightchargesonwarrantedpartstoandfromthefactory.
 Claimsthatdonotinvolvedefectiveworkmanshipormaterials.
 Unauthorizedserviceorpartsreplacements.
Removal and reinstallation cost.
 Inoperableduetoimproperorlackofmaintenance.
How To Get Service
 Tomakeaclaimunderthiswarranty,pleasehaveyourreceiptavailableandcontactyourinstallingdealer.Providethe
 dealerwiththemodelnumber,serialnumber,typeofgas,andpurchaseverication.Theinstallingdealerisresponsible
 forprovidingserviceandwillcontactthefactorytoinitiateanywarrantedpartsreplacements.Empirewillmake
replacement parts available at the factory. Shipping expenses are not covered.
 If,aftercontactingyourEmpiredealer,servicereceivedhasnotbeensatisfactory,contact:ConsumerRelations
 Department,EmpireComfortSystemsInc.,POBox529,Belleville,Illinois62222,orsendane-mailto
 [email protected]with“ConsumerRelations”inthesubjectline.
Your Rights Under State Law
 Thiswarrantygivesyourspeciclegalrights,andyoumayalsohaveotherrights,whichvaryfromstatetostate.

Page20 32188-0-0616
EMPIRE
EMPIRE
Comfort Systems
Empire Comfort Systems Inc.
Belleville, IL
If you have a general question
aboutourproducts,pleasee-mail
us at [email protected].
If you have a service or repair
question,pleasecontactyourdealer.
www.empirecomfort.com
