EMT HTP1010 KNX-IO User manual
USERMANUAL
HTP1010KNXIO
KNXMultiFunctionTouchPanelswithIntercom
Copyright©2015EMTKontrolElektronik.Allrightsreserved
EMTControlsandtheEMTlogoareregisteredtrademarksofEMTKontrolElektronikLtd.
Allothertrademarksarethepropertyoftheirrespectiveowners.
TableofContents
1.AboutHTP1010Functions
1.1DeviceOverview
1.2TechnicalSpecifications
1.3WiringDiagrams
1.3.1PowerSupplyandEthernetConnection
1.3.2KNXTwistedPairConnection
1.4MainScreenandSystemBar
1.5IntercomFunction(HTP1010KNXIO)
1.6KNXControllerandMobileDeviceConnection
1.7MailboxFunction(HTP1010KNXIO)
1.8ConciergeServices(HTP1010KNXIO)
2.ConfiguringDevice
2.1PowerSupplyAndIPConnection(Allthreedevices)
2.2IntercomConfiguration(HTP1010KNXIO)
2.3KNXControllerandEMTBuilderPCSoftware(Allthreedevices)
2.4MailboxConfiguration(HTP1010KNXIO)
2.5ConciergeFunction(HTP1010KNXIO)
3.KNXFunctionsandDeviceInputs/Outputs(HTP1010KNXIO)
3.1InputsofHTP1010KNXIO
3.1.1ON/OFFButtonandPushButtonFunctions
3.1.2ToggleButtonFunction
3.1.3SceneFunction
3.1.4AnalogValueFunction
3.1OutputsofHTP1010KNXIO
4.WarrantyInformation
4.1DetailsofWarranty
4.1.1WarrantyPeriod
4.1.2WarrantyScope
4.2LimitationsofLiability
4.3SuitabilityforUse
4.4SpecificationsChange
1. About HTP1010-KNX-IO Functions
HTP1010KNXIO series devices are compact, extremely flexible and multifunctional
touch panel solutions providing complete array of highvalue solutions for building automation.
While HTP1010KNXIO allows users to connect to KNX Twisted Pair medium, there are two
other available devices (HTP1010KNXIO) which also provide ethernet connection and many
features using IP connection including IP calls and messaging, interactive services etc.
HTP1010KNXIO also provides more additional input output functions and takes a place in the
smartbuildingautomationsystemslikeswitchingelectricalappliances.
1.1 Device Overview
HTP1010KNXIO devices offer touch panel solutions for the entire control and intercom
functionality for building automation systems. Device has many solutions which can increase the
comfort like Intercom (VoIP telephony), Home Automation Control, Messaging and Concierge
services. HTP1010KNXIO devices also allow you to monitor your home while you are away
and control your building automation devices using your mobile devices. Three different options
are available for HTP1010KNXIO devices. These are HTP1010KNXIO (KNX Controller With
EthernetConnection,IntercomandadditionalIOfeaturesforbuildingautomation)
BelowisalistoffunctionsHTP1010KNXIOdevicessupport:
● TouchPanelUserInterface
● FullKNXSupport
● VoIPCommunicationandIntercomSystem(HTP1010KNXIO)
● Ethernet10/100(ModbusTCP,BACnetIP,Socket)(HTP1010KNXIO)
● Remotecontrolandmonitoringofthebuildingusingmobiledevices(HTP1010KNXIO)
1.2 Technical Specifications
Powersupply
802.3af(PoE)48V/380mADC
Outputs(HTP1010KNXIO)
2RelayOutputs:10A125VAC/5A250VAC/
5A30VDC
Inputs(HTP1010KNXIO)
4InputsDigital/AnalogConfigurable
DigitalInputsRange:05VDCMax.
AnalogInputsRange:010V(HardwareDependent)
Temperaturerange
0...+50ºC
Casematerial
AluminiumandGlass
Dimensions(WxHxD)
TouchPanel(Floating):283x185x30mm
BackBox(Inwall):278x163x40mm
Height
TouchPanel(Floating):1500gr.
BackBox(Inwall):550gr
1.3 Wiring Diagrams
HTP1010KNXIO devices can be assembled in different configurations with different
equipments.BelowisatypicaldiagramforaHTP1010KNXIObasedsystem.
1.3.1 Power Supply and Ethernet Connection
HTP1010KNXIOdevicescanbesuppliedbyPoEtechnology(802.3af(PoE)48V/380
mADC).ThusonlyethernetcableisenoughforbothpowersupplyandInternetcommunication
ofdevice.HTP1010KNXIOneedsinternetconnectiontobeabletoperformitscommunication
tasks.Belowisafigurerepresentingthepowerandethernetconnection.
1.3.2 KNX Twisted Pair Connection
InordertouseKNXfunctionsHTP1010KNXIO,devicemustbeconnectedtoKNX
TwistedPairmedium.StandardKNXTwistedPairconnectorisusedforthispurpose.
WARNING:
Assembly, installation, and commissioning of system must only be carried out by a
qualifiedelectrician!
WARNING:
Do not cut wires when HTP1010KNXIO is powered. It can destroy communication
circuitsofdevice!
1.4 Main Screen and System Bar
Main Screen of HTP1010KNXIO devices is a user friendly graphical user interface
which displays widgets like weather, date and time. With its technological and easy to use
interface it requires no extra effort for making VoIP calls or controlling your home automation
appliances.
The system bar behind the screen is the quick menu for navigating among different
functionsoftheHTP1010KNXIOdevices.
1.5 Intercom Function (HTP1010-KNX-IO)
HTP1010KNXIOE can be integrated to the intercom system of a building. Intercom
service is provided via VoIP telephony and device can be configured and registered to a SIP
server over IP network. Intercom function of device allows users to answer calls from the
building entrance or make calls to other devices (apartments,buildings..) connected to the SIP
server.
Intercom function does not only provide audio but also provides video communication
between two devices. Using the integrated camera of HTP1010KNXIO, you can see the
person who is at the gate even when you are not home by any device with internet connection.
Belowisthemainscreenofintercomfunction.
BytappingtheCallbutton,akeypadpopsupandusercandialthenumberofdestination.
1.6 KNX Controller and Mobile Device Connection
HTP1010KNXIO devices are mainly used for controlling every device a home
automation system may contain without any restriction like manufacturer or device type. With
the practical methods which EMT Builder software provides, any building automation system
can be modelled and imported as a project to HTP1010KNXIO devices. When prepared as a
project, your building automation system can be controlled via touch panel over the KNX
twisted pair bus. HTP1010KNXIO devices does not require any external devices or gateways
to connect with KNX Twisted Pair medium. Standard KNX TP connectors are included on the
device.
With the graphical user interface of KNX Controller function, user can easily switch
lights,adjustsshutterpositionetc..
BelowisascreenshotofKNXControllerfunction:
Byusingoneoftheethernetenableddevice(HTP1010KNXIO)KNXControllerfunction
canalsobeaccessedusinganymobiledeviceconnectedtointernet.Bythisfeatureyoucan
easilymonitoryourhomeandcontrolyourelectricalappliancesevenwhenyouarenothome.
1.7 Mailbox Function (HTP1010-KNX-IO)
Using the Mailbox function of HTP1010KNXIO, different devices connected to server
can send messages to each other. This function can be used by residents to communicate
easily and also allows notifications and announcements to be delivered to a device or group of
devices.
Each device can both send and receive messages, device has a user friendly typing interface
forcomposingmessages.
Byclickingcomposebuttonuserwillseethescreenbelow:
1.8 Concierge Services (HTP1010-KNX-IO)
HTP1010KNXIOprovidesconciergeservicestouserviaHTTPconnection.Byconnectingtoa
webserverdevicereceivestheconciergeservicesfromserveranddisplayadditionaloptionson
conciergemenulikefindingafloristorcallingataxietc.
Conciergefunctionscreenlookslikethis:
2. Configuring Device
2.1 Power Supply And IP Connection (All three devices)
HTP1010KNXIOneedstobeconnectedtoanIPnetworkforperformingitscommunication
functions.Ethernetcableconnection(RJ45standardjack)canbepluggedintotheconnector
behindthedevicebeforemountingitontoawall.AllHTP1010KNXIOdevicesaresupplied
fromthisconnectorwithPOEpowersupplytechnology(complieswith802.3afstandard)
includingHTP1010KNXIOforcompliancethoughithasnoethernetfunctionality.
2.2 Intercom Configuration (HTP1010-KNX-IO)
Toenableintercomfunctions,someparametersshouldbeadjusted.Theseparametersare
availableonthesettingsmenuofHTP1010KNXIO.Byassigningausername,passwordand
registeringthedevicetoserver,devicescanbeusedasauserpanelforanyintercom
application.
2.3 KNX Controller and EMT Builder PC Software (All three devices)
HTP1010KNXIO,HTP1010KNXIOcanbeusedforcontrollinganyKNXdeviceonabuilding
automationinstallation.Byusingthegeneraltouchinput,easytouseusercontrolslikebuttons,
slidersandinputboxesanyKNXinputtaskcanbeachieved.KNXcontrolleruserinterfaceand
functionalitycanbeeasilychangedusingtheEMTBuilderPCsoftware.Usingthisdeviceany
KNXprojectcanbemodelledandimportedtoHTP1010KNXIOtouchpaneldevices.
EMTBuilderisaPCapplicationforcreatingKNXprojectsandinterfacesforHTP1010KNXIO
seriesdevices.UsingthissoftwareyoucanAddroomsanddevicestoyourprojects,editroom
anddeviceconfigurationslikenamesandgroupaddresses…
BelowisaScreenshotofEMTBuilder:
The left handed column is for adding/removing rooms and the right handed column is for
adding/removingdevicesintotheselectedroom.
Wecanaddroomsanddeviceswithoutanylimit.
Above the columns there are buttons for addingremovingmoving up and moving down rooms
ordevices.Alsotherearetextboxesforeditingnamesoftheseitemsabovethebuttons.
Once we select a device in the project, we can change device parameters from the Device
optionsmenu.
2.4 Mailbox Configuration (HTP1010-KNX-IO)
Mailbox function of HTP1010KNXIO is used for sending/receiving SIP messages between
devices connected to the server. Mailbox function also requires some parameters for
configuration like mailbox information and username password parameters. These parameters
areavailableonsettingsmenuofHTP1010KNXIO.
2.5 Concierge Function (HTP1010-KNX-IO)
Concierge function of HTP1010KNXIO is a screen which displays and allows user to interact
with a web page. This web page can be on any server from the IP network which device is
connected.Conciergeoptionsareavailableonsettingpageofthedevice.
3.KNX Functions and Device Inputs/Outputs (HTP1010-KNX-IO)
HTP1010KNXIO has auxiliary inputs and outputs which can be configured to operate in
buildingcontrolscenarios.
3.1 Inputs of HTP1010-KNX-IO
HTP1010KNXIO has 4 inputs which can be used as both analog and digital inputs.
These inputs can be linked to work with any KNX devices by linking corresponding
communicationobjectsviatheETSsoftware.
Below is the table of functions and related communication objects for each function of
inputs.
3.1.1 ON/OFF Button and Push Button Functions
ON/OFF buttons can perform only one operation. According to its ETS configuration, an
ON/OFF button can transmit either ON or OFF value to the KNX bus. If any input is configured
as a push button, it will have the Push Button object and it will transmit ON when the contact is
closedandOFFwhenthecontactisreleased.
OnlyON/OFFobjectofthecorrespondinginputisrelatedtoON/OFFButtonFunction.
Figure.BlockDiagramRepresentationofON/OFFFunction
3.1.2 Toggle Button Function
If an input is configured as a toggle button then there will be two objects accessible via
ETS. These objects are, ON/OFF object and Output Status object. Each time the button is
pressed the invert of the previous state of the output is sent to the bus via the ON/OFF object of
the touch button. Feedback about current state of the output device is obtained via the Output
Statusobjectoftheinput.
Figure.BlockDiagramRepresentationofToggleFunction
