EN SpinCycle User manual

SpinCycle
Rotating Speaker Emulator
User’s Manual

Copyright © 2014 Experimental Noize, All Rights Reserved
Experimental Noize | www.xnoize.com | [e-mail]
Table of Contents
1. Introducon..........................
2. Top Panel................................
3. Rear Panel...............................
4. Typical Connecon................
5. Footswitch Wiring.................
6. FCC Regulaon.....................
7. Warranty Informaon........
2
3
6
7
9
10
11

SpinCycle
Thank you for choosing the SpinCycle rotang
speaker emulator from Experimental Noize. This
unit has been designed to both accurately
emulate a rotang speaker as well as giving the
user the ability to adjust the sound in order to
meet their requirements.
Experimental Noize | Los Angeles, CA USA | xnoize.com
INTRODUCTION
2

Experimental Noize | Los Angeles, CA USA | xnoize.com
TOP PANEL
3
Slow Speed: Sets the slow speed of the rotaon emulaon;
the Speed push buon selects between the
slow and fast sengs.
Fast Speed: Sets the fast speed of the rotaon emulaon;
the Speed push buon selects between the
slow and fast sengs.
Acceleraon: Sets the rate at which the transion between

Experimental Noize | Los Angeles, CA USA | xnoize.com 4
TOP PANEL
the slow and fast speeds happen.
Also affects the speed at which the
emulator comes to a stop when the brake
buon is pressed.
Drum:Rotor Rao: On many rotang speakers, the drum
and rotor are driven by separate motors.
While their speeds may be close, they are
not idencal; the drum is always a lile
slower than the rotor. The speed difference
between the two motors creates a “beat”
between the drum and rotor that can be
unique to a parcular rotang speaker
cabinet. This control allows the user to
adjust the speed rao between the drum
and rotor to emulate this difference in
motor speeds.
Tube Emulaon: Increasing this control increases the
amount of tube emulaon, from a clean to
an asymmetric tube compression sounds.
Cab Emulaon: This control allows the user to enable and
adjust the cabinet emulaon. Part of what
gives the spinning speaker its unique sound
is the cabinet; this control emulates the
frequency response and reflecons that in
the cabinet and allows the user to adjust
the level of the emulaon.

Experimental Noize | Los Angeles, CA USA | xnoize.com
5
TOP PANEL
Distance: Adjusts the distance of the virtual microphones
from the cabinet. Closer will give a very heavy
“throbbing” sound, while further away will
give a more subtle sound.
Balance: Adjusts the balance between the rotor and
drum sounds.
Enable: This switch will enable/disable the effect. When
enabled the blue LED above the switch will be
lit.
Brake: This switch, when pressed, will slow the spinning
emulaon to a complete stop. Releasing the
switch will allow the emulaon to speed back
up to the set speed.
Speed: This switch selects between the slow and fast
speed sengs. The LED above this switch will
blink at the current rotaon speed.

Experimental Noize | Los Angeles, CA USA | xnoize.com 6
REAR PANEL
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
Made in Taiwan
PA01A00001R01
2014
9V DC: Power adapter input. Use only approved adapters.
Footswitch: Input for remote footswitch to control the
Enable and Speed switches remotely. If plugged
in, the footswitch will override the pedal
switches.
Mono In: Instrument input, typically from an electric
guitar or keyboard.
+Gain: This switch provides 12dB of gain to the input.
Typically used with electric guitars that have a
low output level; generally not required with
instruments such as keyboards.
Right Out: Right channel output.
Le Out: Le channel output.

Experimental Noize | Los Angeles, CA USA | xnoize.com
7
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
Made in Taiwan
PA01A00001R01
2014
Step 1: Connect the instrument to the Mono In jack. If
using a low signal level instrument, such as an
electric guitar, press the +Gain switch so that it is
in the in posion.
Step 2: Connect the Right Out and Le Out to a pair of
amplifiers, or a stereo amplifier.
TYPICAL CONNECTION

Experimental Noize | Los Angeles, CA USA | xnoize.com 8
TYPICAL CONNECTION
Step 3: Plug in the power adapter to the pedal and to a
mains power plug.
Step 4: Play!

Experimental Noize | Los Angeles, CA USA | xnoize.com
9
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
Made in Taiwan
PA01A00001R01
2014
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
Made in Taiwan
PA01A00001R01
2014
FOOTSWITCH WIRING
FAST/SLOW ENABLE
Tip: Fast/Slow Ring: Enable Sleeve: Common
The switches should be single-pole/single-throw on/off
type switches, not momentary switches.

Experimental Noize | Los Angeles, CA USA | xnoize.com 10
FCC REGULATION
Note
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protecon against harmful interfer-
ence in a residenal installaon.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful
interference to radio communicaons. However, there is
no guarantee that interference will not occur in a
parcular installaon.
If this equipment does cause harmful interference to
radio or television recepon, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separaon between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.

Experimental Noize | Los Angeles, CA USA | xnoize.com
11
WARRANTY INFORMATION
ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE REQUIRED.
Experimental Noize ("EN") warrants unit to be free from defects in
materials and workmanship for one (1) year from date of purchase to the
original purchaser and is not transferable.
This warranty does not include damage resulng from accident, misuse,
abuse, alteraon, damage due to incorrect voltage or signal levels or an act
of God (such as a flood).
If unit becomes defecve within warranty period EN will, at its opon,
repair or replace with new or refurbished product or parts any product or
parts determined to be defecve.
Any parts or products replaced under this warranty become the property
of EN.
USE PROVIDED POWER SUPPLY ONLY! Failure to do so may damage the unit
and will void warranty.
Aempng to repair unit will void warranty.
Missing or altered serial numbers automacally void warranty. Please
register your unit at www.xnoize.com
All repairs for residents of U.S.: Email [e-mail] or use the
website form to obtain a Return Authorizaon Number. Experimental Noize
will not accept packages without prior authorizaon, pre-paid freight (use a
tracking shipper) and proper insurance.
EN shall not be liable for any consequenal or incidental damages for
breach of any express or implied warranty on this product. EN disclaims any
other warranes, express or implied. By using the product, the user accepts
all terms herein. Some states do not allow the exclusion or limitaon of
incidental or consequenal damages, so the above limitaon or exclusion
may not apply to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
