mikroElektronika 4-20mA R click User manual

1. Introduction
Once you have soldered the headers your
board is ready to be placed into desired
mikroBUS™ socket. Make sure to align the
cut in the lower-right part of the board
with the markings on the silkscreen at the
mikroBUS™ socket. If all of the pins are
aligned correctly, push the board all
the way into the socket.
3. Plugging the board in
2 3
2. Soldering the headers
1
4. Essential features
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
bottom side is facing you upwards. Place
shorter parts of the header pins in both
soldering pad locations.
click
Before using your click board™, make sure
to solder 1x8 male headers to both left
and right side of the board. Two 1x8 male
headers are included with the board in
the package.
click
BOARD
www.mikroe.com
4-20mA R click Manual
ver. 1.01
0 100000 023242
4-20mA R Click™ is an accessory board in
mikroBUS™form factor. It’s a compact and
easy solution for adding 4-to-20mA industry
standard communication protocol to your
design. It features INA196 current shunt
monitor, MCP3201 12-bit ADC as well as
TPS61041 DC/DC boost converter. 4-20mA
R Click™ communicates with target board
microcontroller via mikroBUS™SPI (SDO,
SCK, CS) and EN lines. The board is designed
to use 3.3V and 5V power supply. LED diode
indicates the presence of power supply.
4-20mA R
4-20mA R Click™ board is ideal for using in
eld of industrial process control and test
systems. The board serves as receiver in
4-20mA current loop standard. It receives
output current (4-20mA) from transmitter
and convert into a voltage (0.4-2V). Then
through the AD converter sends signal to
main board microcontroller. This board and
the 4-20mA T Click™ board together form a
complete 4-to-20mA current loop standard.

8. Support
MikroElektronika oers Free Tech Support
(www.mikroe.com/esupport) until the
end of product lifetime, so if something goes
wrong, we are ready and willing to help!
7. Code Examples
.com
Once you have done all the necessary
preparations, it’s time to get your click
board up and running. We have provided
the examples for mikroC, mikroBasic and
mikroPascal compilers on our Libstock
website. Just download them and you are
ready to start.
5. 4-20mA R Click™ Board Schematic
VCC
VCC
R1
2K2
LD1
C1
100nFAN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
VCC-16
R3
4.99R
1
2
3
SW
GND
VIN
5
4FBEN
U2
TPS61041
L3 10uH
C2
10uF
D1
PMEG3010ER
VCC
C3
22uF
FP2
FERRITE
R6
100K
R5
1M2
C4
22pF
J1
PWR SEL
VCC-16
CN1
SCREW TERMINAL
VCC
EN
EN
OUT
OUT
VIN-
VIN-
R2
0
R4
10K
1
2
3
OUT
GND
VIN- 5
4
V+ VIN+
U3
INA196
1
2
3
54
6
7
8
Vref
IN+
IN-
Vss CS
Dout
CLK
Vdd
U1
MCP3201
1
2
3
VIN
VOUT
VSS
REF1
MAX6106EUR
C6
1uF
C8
1uFVCC
R7
10K
CS#
SCK
SDO
SDO
CS#
SCK
REF
REF
VCC
C9
100nF
C5
100nFC7
100nF
VCCVCCVCCVCC
VCC
MIKROBUS DEVICE CONN.
MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.
Specication and information contained in the present schematic are subject to change at any time without notice. Copyright © 2013 MikroElektronika. All rights reserved.
6. SMD Jumper
There is one zero-ohm SMD jumper J1 used
to select whether 3.3V or 5V power supply is
used. Jumper J1 is soldered in 3.3V position by
default.
