Siemens WW8000 MP4.70 User manual

A6V10062401_a_en Building Technologies
30.09.2014 Fire Safety & Security Products
WW8000 MP4.70
Composer
Technical Manual

3
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
Table of Contents
About this document.........................................................................................................7
1Safety regulations............................................................................................11
1.1Country-specific standards.................................................................................11
1.2Commissioning and testing................................................................................11
1.3Modifications to system design and products ....................................................11
2Introduction - system description..................................................................12
2.1System architecture............................................................................................13
2.2What's new.........................................................................................................13
3Structure and function.....................................................................................14
3.1Modes of operation.............................................................................................14
3.1.1Stand-alone configuration...................................................................14
3.1.2Remote Composer configuration........................................................14
3.2Data flow ............................................................................................................15
3.3User Interface.....................................................................................................15
3.4Nodes, properties, projects, and templates........................................................17
3.4.1Nodes..................................................................................................17
3.4.1.1Node interface controls.......................................................................17
3.4.1.2Node appearance and what it tells you...............................................17
3.4.2Properties............................................................................................18
3.4.3Projects...............................................................................................19
3.4.4Node Templates..................................................................................19
3.4.5Folder templates.................................................................................21
4Installation ........................................................................................................22
4.1Installing Composer............................................................................................22
4.1.1Installing Windows IIS.........................................................................23
4.2Managing Composer security ............................................................................23
4.2.1Composer User Manager....................................................................25
4.2.1.1Configuring user privileges .................................................................26
4.3Managing Composer License ............................................................................29
4.3.1Activating the license..........................................................................29
4.3.1.1Attaching the hardware key ................................................................30
4.3.1.2Activating the hardware key by importing the .REG file .....................30
4.3.1.3Converting a .TXT file to activate PAK ...............................................31
4.3.1.4Activating the hardware key by manually entering the PAK code......32
4.3.2Limited Composer – Composer GW Tool (no license required).........33
4.3.3Accessing Composer as guest user (without a license).....................33
4.3.4Reviewing license limits......................................................................34
4.3.5Editing license data.............................................................................35
4.3.6License options...................................................................................36
4.4Installing the Plug-ins.........................................................................................37
4.4.1Checking the plug-in version in Composer.........................................38
4.5Composer projects – changing default folder location.......................................39

4
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
5Getting started..................................................................................................40
5.1Launching Composer .........................................................................................40
5.1.1Projects Management commands ......................................................42
5.1.1.1Creating a new project........................................................................43
5.1.1.2Opening an existing project ................................................................44
5.2Setting up the node structure.............................................................................46
5.3Reviewing project data.......................................................................................47
5.4Saving projects...................................................................................................48
6User interface components.............................................................................49
6.1The Main menu...................................................................................................49
6.1.1File menu ............................................................................................51
6.1.2Edit menu............................................................................................52
6.1.3View menu ..........................................................................................54
6.1.4Insert menu.........................................................................................55
6.1.5Format menu.......................................................................................57
6.1.6Tools menu .........................................................................................58
6.1.7Help menu...........................................................................................61
6.2The Tree View....................................................................................................62
6.2.1Structure and organisation..................................................................62
6.2.1.1Node representation............................................................................62
6.2.1.2Tabs in the Tree View.........................................................................62
6.2.1.3Split Tree View....................................................................................63
6.2.1.4Tree properties....................................................................................63
6.2.1.5Drag-and-drop.....................................................................................64
6.2.2Right-click context menus in the Tree View........................................65
6.2.2.1Right-click on a selected node............................................................65
6.2.2.2Right-click on a tab..............................................................................66
6.2.2.3Right-click Node tab context menu.....................................................66
6.3The Data View....................................................................................................68
6.3.1Structure and organisation..................................................................68
6.3.1.1Node representation............................................................................68
6.3.1.2Tabs in the Data View.........................................................................68
6.3.1.3The Edit Grid.......................................................................................69
6.3.1.4Split Edit Grid......................................................................................71
6.3.1.5Split Data View....................................................................................71
6.3.2Right-click context menu in the Edit Grid............................................71
6.4Node View..........................................................................................................73
7Working in Composer......................................................................................74
7.1Creating and using node templates....................................................................74
7.1.1Saving a node or a sub-tree as a template.........................................74
7.1.2Organising templates..........................................................................75
7.1.3Using templates ..................................................................................75
7.1.4Sharing templates...............................................................................76
7.2Creating links......................................................................................................77
7.3Modifying the Geographical tree ........................................................................78
7.4Executing node commands................................................................................78

5
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
7.5Filtering & zooming.............................................................................................79
7.5.1Creating filtered views.........................................................................79
7.6Using shortcut keys............................................................................................81
7.7Printing customised reports................................................................................82
7.8Importing ............................................................................................................84
7.9Downloading.......................................................................................................85
7.10Backing up..........................................................................................................85
7.11Restoring............................................................................................................87
7.12Creating configuration reports............................................................................88
Keyword index .................................................................................................................91

About this document
7
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
About this document
Purpose
This Technical Manual provides a reference to commands and instructions to be
used during a system configuration.
Scope
This paper explains the basic concepts of Composer and the user interface for
MP4.70.
The goal is to explain how to use Composer in general. Also included in this
document are ways to use Composer that make configuration faster and easier.
Separate documents describe the use and purpose of specific software
components that can be integrated in Composer, such as Plug-ins.
 To learn more about use and purpose of additional software components, see
DMS8000 Connectivity Configuration Guides:
–
Network Connectivity (Doc. # A6V10359485)
–
Fire Connectivity (Doc. # A6V10359481)
–
Intrusion Connectivity (Doc. # A6V10359489)
–
Access Control Connectivity (Doc. # A6V10062451)
–
Video Connectivity (Doc. # A6V10062457)
–
OPC Connectivity (Doc. # A6V10065253)
 To learn how to access these guides, see Reference documents in this section.
Target audience
This documentation is intended for the following users:
 Project Engineers
 Commissioning Personnel
It is assumed that individuals performing the operations described in this manual
have prior expertise and training in the field of safety and security, at least a
moderate level of familiarity with the Siemens Building Technologies product line,
and experience with the installation, configuration, and commissioning of security
management systems.
Documentation resource information
The DMS8000 Documentation Resource Information and Glossary Guide
assembles important information regarding documentation resources. This
document contains the following:
 Comprehensive definitions of the target audiences for Siemens FS DMS
documents
 Training program information including the Siemens intranet link
 A complete list of all available DMS8000 documents
 Instructions for how to obtain a document via the Siemens intranet using the
Siemens Asset Portal
 A map of relevant documents for each target audience group
 Customer Support links & resources
 A glossary containing definitions of all terms and acronyms used in DMS8000
documentation
To access the
DMS8000 Documentation Resource Information and Glossary
Guide
(document no. A6V10089056), go to the link and follow the document
search instructions below:
http://assetportal.bt.siemens.com/portal/index.html

About this document
8
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
1. In the Search column on the left, set:
- Segment: 04 Fire -3F
- Document Type: All
- Image Type: All
- Advanced search criterias: Select Brochure No. and enter the document
number to search for (
A6V10089056 ). Alternatively, select Title and enter
the product name (
DMS8000 ).
2. Click Search to start.
3. In the resulting area on the right, click on Contents link to show the list of
search results.
For more information such as Siemens news and announcements, visit the STEP
Web portal at:
https://workspace.sbt.siemens.com/content/00001123/default.aspx
Operational and safety regulations
Before groups of persons begin work on the system, they must have read and
understood the Safety Regulations [➙ 11] section in this manual.
Liability disclaimer for damage or injuries
Before products are delivered, they are tested to ensure they function correctly
when used properly. Siemens disclaims all liability for damage or injuries caused
by the incorrect application of the instructions, or the disregard of danger
advisories. This disclaimer applies in particular to personal injuries or damage
caused by:
 Improper and/or incorrect use.
 Disregard of safety instructions in the documentation or on the product.
 Poor maintenance or a lack of maintenance.
We have checked the contents of this manual for agreement with the hardware and
software described. Since deviations cannot be precluded entirely, we cannot
guarantee full agreement. However, the data in this manual are reviewed regularly
and any necessary corrections are included in subsequent editions. Suggestions
for improvement are welcome.
Copyrights and registered trademarks
Brand or product names mentioned in this document may be names protected by
copyright law or registered trademarks of other companies. These are mentioned
only for identification purposes and have no recommendatory character in regard to
the product or manufacturer, unless otherwise stated.
Documentation Conventions
The following table lists conventions to help you use this document in a quick and
efficient manner.
Convention Examples
Numbered Lists (1, 2, 3…) indicate a
procedure with sequential steps.
1. Turn OFF power to the field panel.
2. Disconnect the power cord.
3. Open the cabinet.
One-step procedures are indicated by a
bullet point.
 Expand the Event List.

About this document
9
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
Conditions that you must complete or must
be met before beginning a procedure are
designated with a ⊳.
Results, after completing a step or at the
end of the entire procedure, are designated
with a ⇨.
⊳ The report you want to print is open.
1. Click the Print icon .
⇨ The Print dialog box appears.
2. Select the printer and click Print.
⇨ The print confirmation appears.
Bold font in a procedure indicates something
you should select or type.
Type F for Field panels.
Click OK to save changes and close the
dialog box.
Menu paths are indicated in bold. Select File > Text, Copy > Group, which
means from the File menu, then select Text,
Copy and finally Group.
Error and system messages are displayed in
Courier New font.
The message Definition
successfully renamed displays in the
status bar.
Italics are used to emphasize a term. The Open Processor continuously executes
a user-defined set of instructions called the
control program .
This symbol signifies a Note. Notes provide
additional information or helpful hints.
Caution
This is a Caution message and indicates
that minor or moderate injury or property
damage may occur if a procedure is not
followed.
Warning
This is a Warning message and indicates
that a serious injury or a severe equipment
and property damage may occur if a
procedure is not followed.
Cross references to other information in
printed material are indicated with an arrow
and the page number, enclosed in brackets:
[→92]
For more information on creating flowcharts,
see Flowcharts [→92].

About this document
10
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
Modification index
Note: For versions more than four years old, please visit the Siemens Asset Portal.
Version Date Notes
A6V10062401_a_en 09.2014 For details regarding updates/modifications for the
MP4.70 edition of the manual, see What's new
[➙ 13].
A6V10062401_a_en 06.2013 DMS8000 MP4.60.
 Enhanced the installation procedure to include
the new Web Site setup type option.
 Moved Installing Windows IIS from MM8000 ICC
and enhanced to include the new Web Site setup
type option.
 Updated backward compatibility.
 Moved
Creating configuration reports from
MM8000 ICC.
 Updated images throughout document.
A6V10062401_a_en 06.2012 DMS8000 MP4.50.
 Enhanced installation procedure
 New Composer GW Tool installation option
 Enhanced Composer guest user functionality
 Project version detection section updated
according to MP4.50
 New missing add-ons message during project
restore
 Screenshot updates
A6V10062401_a_en 06.2011 DMS8000 MP4.40.
 Restore, Backup, Open, and Download possible
without Composer license
 Possibility to cut/copy and paste parts of
geographical tree
 Project version detection section updated
according to MP4.40
 Windows 7 support
 Screenshot updates
A6V10062401_a_en 06.2010 DMS8000 MP4.30.
 Project version detection section updated
according to MP4.30
 New tree sorting functionality
 Node appearance enhancements for information
about nodes
 Content reorganized for clarity
 Index updated
 Screenshot and illustration updates
A6V10062401_a_en 06.2009 DMS8000 MP4.20.
 Shortcut key section added
 Project version detection section updated
according to MP4.20
 New Edit menu command:
Repeat last inserted
node action
 Screenshot and drawing updates

Safety regulations
Country-specific standards 1
11
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
1Safety regulations
This section describes the danger levels and the relevant safety regulations
applicable to the use of the products described in this manual. Please read the
following work instructions as well as the preceding section
About this document
thoroughly before beginning any work.
1.1 Country-specific standards
Siemens products are developed and produced in compliance with the relevant
international and European safety standards. Should additional country-specific,
and/or local safety standards or regulations concerning project planning,
installation, and/or operation of the product(s) apply, then these standards and/or
regulations must also be taken into account, in addition to the safety regulations
mentioned in the product documentation.
1.2 Commissioning and testing
 Activate security-, fire- and third party systems or devices only in the presence
of the person responsible.
 Abide by the safety regulations of the connected sub-systems when working on
management stations. This especially applies when switching-off system
components.
 Inform people before the testing of alarm devices; take the possibility of panic
reactions into account.
 Inform the alarm and fault receiving stations connected to the system before
carrying out any tests.
1.3 Modifications to system design and products
Modifications to a system or to individual products may cause faults or
malfunctioning.
Please request written approval from Siemens Building Technologies, FS-DMS,
and the relevant authorities concerning intended system modifications and system
extensions.

Introduction - system description
2 Modifications to system design and products
12
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
2Introduction - system description
The Composer (Common Project Services) is a common configuration tool
environment that provides:
 General user interface and common functionality to configure a security system
 General configuration environment that hosts Plug-ins
The Plug-ins can be plugged into Composer to form an environment devoted to the
configuration of the control units of a security system. Depending on the number
and kind of Plug-ins, this environment allows configuration of a single control unit
up to a large security system that includes several control units of different
disciplines (including the management stations). Data from configuration tools that
are not included can be imported with dedicated Importer Plug-ins.
The end user perceives a single application for the configuration activities, however
the system is made up of different pieces of software (Composer and the Plug-ins).
Composer with Plug-ins
Composer runs under Windows 7/Vista/XP Professional/2008/2003 operating
system. You work with a project, which contains all the configuration data of a
certain site.

Introduction - system description
System architecture 2
13
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
2.1 System architecture
Composer uses a client/server application. Both the client and the server part are
made up of many components, as shown in the following figure.
System Architecture
Composer provides services to the Plug-in component(s) that, in turn deal with the
data configuration for the control units.
Note: The client and the server do not necessarily need to reside on the same
PC. For details, see section Modes of operation [➙ 14].
2.2 What's new
The following is the list of modifications for new functions and software
improvements for MP4.70.
Section Modifications
Introduction - system description [➙ 12]  New Operating Systems support.
Accessing Composer as guest user (without a
license) [➙ 33]
 Improved functions in guest-mode.

Structure and function
3 Modes of operation
14
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
3Structure and function
3.1 Modes of operation
The following describes the different operational modes available in Composer.
For details on installation options, see section Installing Composer [➙ 22].
3.1.1 Stand-alone configuration
Composer can be installed on a single machine (Stand-alone configuration) as
shown in the following figure.
Stand-alone configuration
In this case only one user at a time works with Composer, as the client and server
reside together. An engineer who works in the field typically uses this configuration.
He configures the system on his laptop using Composer, and afterwards he
downloads the configuration into the management stations or network devices.
3.1.2 Remote Composer configuration
In the case where the server is not directly available to a client, the client can
connect remotely to the server. This allows for configuration when the server is not
physically present.
Remote configuration
A multi-user configuration is possible with Composer (where more than one
configuration person is simultaneously working on the same project).
We do
not , however, recommend this type of configuration.

Structure and function
Data flow 3
15
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
For details on the type of setup to install, see section Installing Composer [➙ 22].
3.2 Data flow
The following illustrates the data flow from Composer to the management station.
Composer data flow
3.3 User Interface
Composer allows you to work with one project at a time. The project contains all
the configuration data of a certain site. The user interface looks like the following:
Composer user interface
Note: The
Data View display in the right pane varies according to tab selection.
See the following table for details.
The user interface or screen display is divided in the following areas, described in
the following figure:
 Menu Area
 Standard Toolbar
 Node Template Toolbar
 Work Area

Structure and function
3 User Interface
16
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
A
C
D
B
Data View
Tree View
Composer workspace
Workspace components
Item Area Description For more information,
see section….
A Menu Area This area contains the principal menus,
which allow the management of the
project as a whole
The Main menu
[➙ 49]
B Standard
Toolbar,
This toolbar provides the typical menu
commands (
New , Open , Cut , Copy , and
so on), as well as commands unique to
Composer.
C Node Template
Toolbar
This toolbar is a context sensitive bar
that allows the insertion of nodes in the
project structure, depending on the node
currently selected.
 File menu [➙ 51]
 Edit menu [➙ 52]
 Insert menu
[➙ 55]
D Work Area This area shows the project, and is
divided in two panes:
 The
Tree View shows the structure
of the project. It is possible to build
zoomed and/or filtered views of the
project structure that are shown as
new tabs of the
Tree View.
 The
Data View shows the properties
of the node currently selected in the
Tree View. If the node has children
or links associated with it, selecting
these tabs displays the
Edit Grid
(shown in the
Data View in the
previous figure)
 The Tree View
[➙ 62]
 The Data View
[➙ 68]
For more details, see section User interface components [➙ 49].

Structure and function
Nodes, properties, projects, and templates 3
17
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
3.4 Nodes, properties, projects, and templates
3.4.1 Nodes
Any object of a security system that you need to configure is modelled by
Composer in a standardised way. Since these objects are organised in a tree
structure, they are called
nodes .
Nodes organised in a tree structure
3.4.1.1 Node interface controls
The nodes are presented to you by using three different user interface controls:
 The Tree View , which shows the hierarchical structure of a project.
 The Data View , which shows the properties of a selected node.
 The Node View , which shows the property page of a selected node.
We will examine them in detail in sections The Tree View [➙ 62], The Data View
[➙ 68], and the Node View [➙ 73].
3.4.1.2 Node appearance and what it tells you
The appearance of a node and/or its corresponding text in the tree may provide
you with additional information regarding the object.
See the following figure and table to learn how to interpret what you see:

Structure and function
3 Nodes, properties, projects, and templates
18
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
A
B
C
D
Node appearance examples
Item Description
A Map indicators:
 A node deposited on a map (automatic or manual page) has a
small green square next to its symbol.
 A node deposited on a map that is currently open for editing is
also labelled by text in red.
For more information about configuring graphical maps, see the
DMS8000 Graphical Map Configuration Guide (Doc. #
A6V10062441).
B A node whose configuration has changed since the last download
has blue text next to it as opposed to black.
For more information on downloading, see section Downloading
[➙ 85].
C A node linked to the Geographical tree is indicated by a small blue
box next to its symbol.
D A node which is Off-Scan is indicated by italics and a grey
background.
Note: The node icons appear in the same way in the Data View.
3.4.2 Properties
Nodes are grouped into node classes that are characterised by a set of properties.
Nodes that belong to the same node class have the same set of properties.
The Plug-ins define and publish the node classes according to the structure of the
objects they have to configure.
Properties are attributes of a node, which can assume different values according to
the need of the specific configuration.
A node inherits the set of properties of the node class it belongs to.

Structure and function
Nodes, properties, projects, and templates 3
19
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
Node view of properties for selected node
3.4.3 Projects
All the nodes that belong to the same installation of a security system (such as the
site) are stored in a
project .
You always work on a
document that is the project, which contains all the
configuration data of a certain site.
Projects are made up of nodes that are presented to you by using the three
different user interface controls (
Tree View , Data View , and Node View ).
Project node
3.4.4 Node Templates
A Node Template (or, simply Template) is a profile of nodes whose property values
are set to predefined values. Thanks to the Templates, it is possible to provide
nodes that are ready to be inserted in the project with proper values for all the
properties.
When you create a project, some predefined node templates will be present. You
add to these templates to configure a project with the organisation of the actual
site.
When you insert a node, you select the Template available for that node. The
system inserts an instance of the node, taking the actual values of the properties
from the Template. Predefined templates are contained in the Node Template
Toolbar, most organised in folders such as
Fire , Intrusion , Network , etc. The
following figure shows the node templates contained in the
Network folder.

Structure and function
3 Nodes, properties, projects, and templates
20
Building Technologies A6V10062401_a_en
Fire Safety & Security Products 30.09.2014
Node Template example
Since a Template is not limited to one single node, but can contain many nodes
organised in a tree structure, this dramatically increases the power in building up
the configuration of the site.
In addition to the Templates defined by the Plug-in development teams, you can
also create new Templates at configuration time.
For details, see section Working in Composer [➙ 74].
