Encore ENLWI-SG User manual

Encore Electronics 2005
WWW.ENCORE-USA.COM
ENLWI-SG
1
Wireless 802.11 Super-G PCI Adapter
ENLWI-SG
Product Description
The Super-G PCI Wireless Adapter is capable of transferring file at 108Mbps.
That’s 2x faster than normal 802.11g. Supports WPA and WEP for your
protection and is backwards compatible with 802.11b and 802.11g devices.
Installation is quick and easy using the included software. Perfect for increasing
wireless speed and performance in your home network.
Product Features
•Compatible with IEEE 802.11b and IEEE 802.11g standards
•Dynamic date rate scaling at 11, 5.5, 2 and 1Mbps for 802.11b
•Dynamic date rate scaling at 54, 48, 36, 24, 18, 12, 9 and 6Mbps for 802.11g
•Supports Super G™ technology data rate up to 108Mbps
•Maximum reliability, throughput and connectivity with automatic data rate
switching
•Supports wireless data encryption with 64/128-bit WEP Key for security
•Supports WPA-PSK, WPA
•Drivers support Windows 2000, XP
•Simple user setup & diagnostics utilities
•Thumb size design
•Type approval compliant with FCC Part 15.247 for US, ETS 300 328 for Europe

Encore Electronics 2005
WWW.ENCORE-USA.COM
ENLWI-SG
2
Figure 1 Usage Diagram
Specifications
Radio Technology
IEEE 802.11g Orthogonal Frequency Division
Multiplexing (OFDM)
IEEE 802.11b Direct Sequence Spread
Spectrum (DSSS)
Interface
32-bit PCI interface
Transmission Rate
1, 2, 5.5, 6, 11, 12, 18, 22, 24, 36, 48, 54Mbps
(auto sense)
108Mbps for Super G™ Technology
Receiver Sensitivity
54Mbps: Typical - 71dBm @ 10% PER
11Mbps: Typical - 83dBm @ 8% PER
Modulation Schemes
DBPSK/DQPSK/CCK/OFDM
Media Access Protocol
CSMA/CA with ACK
Transmit Power
Minimum 18dBm typically @ 802.11b
Minimum 14dBm typically @ 802.11g
Channel
USA: 11
Europe: 13
Japan: 14
Driver Support
Windows 98(SE)
Windows 2000
Windows ME
Windows XP
Security
64/128-bits WEP Encryption
WPA-PSK (Wi-Fi Protected Access Pre-Shared
Key)
WPA
Wireless LAN Frequency Range
2412 ~ 2484 MHz ISM band (channels 1 ~ 14)
Roaming
Full mobility and seamless roaming from cell to
cell
Range Coverage
Indoor: 35 ~ 100 meters (depends on
environment)
Outdoor: 100 ~ 300 meters (depends on
environment)
Continuous Current Consumption
300mA typ. for receive mode
480mA typ. for transmit mode
Diagnostic LEDs
Link status
Dimensions (W x H x D)
133 x 121 x 21.6 mm (without antenna)
Operation Temperature
0 ~ 40 oC
Storage Temperature
-10 ~ 70 oC
Humidity
10% ~ 95% RH, no condensation
Certifications
FCC Part 15.247 for US
ETS 300 328 for Europe
