Introduction
Overview
The Endace DAG 7.5G4 card provides the means to transfer data at the full speed from the
network into the memory of the host computer, with zero packet loss in even worst-case
conditions. Further, unlike a Network Interface Card (NIC), Endace products actively
manage the movement of network data into memory while only consuming a minimal
amount of the host computer's resources. The full attention of the CPU remains focused on
the analysis of incoming data without a constant stream of interrupts as new packets arrive
from the network. For a busy network link, this feature has a turbo-charging effect similar to
that of adding a second CPU to the system.
The DAG 7.5G4 card provides independent four port Ethernet network monitoring at Gigabit
speeds and supports header only or variable length capture. It is capable of transmitting and
receiving on each channel simultaneously allowing a single card to operate inline,
monitoring and transmitting in both directions on a full duplex link.
The DAG 7.5G4 card is a four port, PCIe card that allows capture and transmission of data. It
a multi-speed card, capable of speeds of 10/100/1000 Mbps. The speed of both ends must
match. The card auto negotiates the correct speed.
Half Duplex is not supported by this DAG card.
Card Features
The following features are available on this DAG card. Note: Different firmware images
may be required. Not all features are available on each firmware image. For further
information on which feature is available in what firmware image, see Firmware images
15 (page ).
•10/100/1000 MB Ethernet (copper) and 1000 MB Ethernet (optical).
•Timed Release TERF (TR-TERF)
•DSM
•Inline forwarding

EDM01-33v1 DAG_7.5G4_Card_User_Guide
2 ©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008
Purpose of this User Guide
The purpose of this User Guide is to provide you with an understanding of the DAG 7.5G4
card architecture, functionality and to guide you through the following:
•Installing the card and associated software and firmware
•Configuring the card for your specific network requirements
•Running a data capture session
•Synchronizing clock time
•Data formats
You can also find additional information relating to functions and features of the DAG 7.5G4
card in the following documents which are available from the Support section of the Endace
website at http://www.endace.com
•EDM04-01 DAG Software Installation Guide
:
•EDM04-03 dagflood User Manual
•EDM04-06 Daggen User Guide
•EDM04-07 dsm-loader User Guide
•EDM04-08 Configuration and Status API Programming Guide
•EDM04-10 Data Stream Management API Programming Guide
•EDM04-19 DAG Programming Guide
•EDM05-01 Time Distribution Server User Guide
•EDM11-01 ERF types
•PN01-13 DAG Card Quick Start Guide
This User Guide and the EDM04-01 DAG Software Installation Guide are also available in PDF
format on the installation CD shipped with your DAG 7.5G4 card.
System Requirements
General
The minimum system requirements for the DAG 7.5G4 card are:
•A computer, with at least a Intel Xeon 1.8GHz or faster and a minimum of 1GB RAM.
•At least one free PCIe slot supporting 4-lane operation.
•Software distribution requires 60MB free space.
•For details of the supported operating systems, see one of the following documents:
•EDM04-01 DAG Software Installation Guide
•Current release notes - See the Documentation CD or the Endace support website
at https://www.endace.com/support
.
Operating System
This document assumes you are installing the DAG 7.5G4 card in a computer which already
has an operating system installed. To install refer to EDM04-01 DAG Software Installation
Guide. All related documentation is included on the CD shipped with the DAG 7.5G4 card.
Other Systems
For advice on using an operating system that is substantially different from any of those
specified above, please contact Endace Customer Support at [email protected].

EDM01-33v1 DAG_7.5G4_Card_User_Guide
©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008 3
Card Description
The DAG 7.5G4 card provides four optical or copper Gigabit Ethernet interfaces. It is capable
of full line rate (1,000Mbps) capture and transmission of Ethernet traffic. Full packet capture
at line rate allows recording of all header information and/or payload with a high precision
timestamp.
The key features of the card are:
•Four SFP ports for 1000Base-SX or 1000Base-LX optical Ethernet or 10/100/1000Base-
T copper Ethernet,
•Header only or variable length capture,
•Full line rate transmit,
•100% capture into host memory at full line rate for IP packets from 48 to 9600 bytes
•Conditioned clock with PPS input and local synchronization capability.
•PCIe x4 Gen 1.0a, 8 Gigabits per second (Raw). Actual performance of PCIe will
depend on the motherboard and other factors in the system architecture.
•Bit level masks applied to the first 64 bytes of each packet can be used to classify
packets and make drop/capture decisions.
Battery removal – don’t do it!
Removing the battery from a DAG card voids your warranty.
Removing the battery from a DAG card will cause the loss of encryption key used to decode
the DAG card's firmware. Once the encryption key is lost the DAG card must be returned to
Endace for reprogramming.
The battery in this product is expected to last a minimum of 10 years.
Caution
Risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries carefully.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
4 ©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008
Card Architecture
Serial Ethernet network data received by each 1000Base interface flows directly into the Field
Programmable Gate Array (FPGA).
The FPGA contains the packet processor, PCIe interface logic and the DAG Universal Clock
Kit (DUCK) timestamp engine. The DUCK provides high resolution per-packet timestamps
which can be accurately synchronized.
Note: For further information on the DUCK and time synchronization, see Synchronizing
Clock Time 41(page ) later in this user guide.
Because of component close association, packets are time-stamped accurately. Time stamped
packet records are stored in an external FIFO memory before transmission to the host.
The diagram below shows the DAG 7.5G4G4 card's major components and flow of data.
For more information about the Boot jumpers and LEDs see:
•Boot jumper settings 11(page )
•Boot LEDs

EDM01-33v1 DAG_7.5G4_Card_User_Guide
©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008 5
Line Types
It is important that you understand the physical characteristics of the network to which you
want to connect. If your configuration settings do not match your network, the DAG 7.5G4
card will not function as expected.
There are various Ethernet line speeds and corresponding protocols which are identified
using the IEEE naming convention. Each line speed has a set of requirements associated with
it relating to the type of cable, maximum allowable distance, etc.
Note: If you are unsure about which of the options listed below to apply to your network,
please contact your Network Administrator for further information.
Supported Line Types
The line characteristics supported by the DAG 7.5G4 card are described below.
Type Description
10Base-T 10 Mbps over two pairs of twisted telephone cable.
100Base-TX 100 Mbps over two pairs of shielded or unshielded twisted Cat 5 copper
cable.
1000Base-T 1000Mbps over four pairs of balanced Cat5 or Cat6 copper cable.
1000Base-LX 1000Mbps over single mode or multi mode fiber optic cable with long
wavelength laser driver (1310nm)
1000Base-SX 1000Mbps over single mode or multi mode fiber optic cable with short
wavelength laser driver (850nm)
Note: For more detailed information regarding Ethernet line types and speeds, please refer
to IEEE Standard 802.3 available from the IEEE website at http://www.ieee.org.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
6 ©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008
Extended Functions
Data Stream Management
The DAG 7.5G4 card supports the Data Stream Manager (DSM) feature. DSM allows you to
drop packets or route them to a particular receive stream based on the packet contents,
physical port and the output of two load balancing algorithms.
The DSM logic is implemented in firmware on the DAG 7.5G4 card and does not require
intervention from the host CPU once it is configured.
Note: For detailed information on using the Data Stream Manager please refer to EDM04-
10 Data Stream Management API Programming Guide and EDM04-07 dsm-loader User
Guide available from the support section of the Endace website at
http://www.endace.com
Filter / Load Balancing Block
.
Packets are received from the line and stamped with an ERF header, then passed to the filter
and load balancing block. The filter block applies eight bit-mask filters simultaneously from
the start of the packet, producing a single true/false value for each filter (64 bytes).
The load balancing block applies two algorithms to the packet data, also producing one
true/false Boolean output per algorithm.
Lookup Table Block
The lookup table accepts the filter and load balancing outputs. It also receives the physical
port the packet arrived on and calculates a classification (also known as color) for the packet.
Colorizer and Drop Block
The color is then passed to the Colorizer And Drop (CAD) block to check if the packet should
be dropped. If not the color is inserted into the packet ERF record header and the packet
record is passed to the packet steering module.
Packet Steering Module
The Packet steering module looks at the color information contained in the record and
determines which receive stream the record should be routed to.
Inline Forwarding
The DAG 7.5G4 card supports inline forwarding which enables the card to receive and
transmit packets directly from a single memory. This allows you to forward packets from the
DAG card receive interface(s) to the DAG cards transmit interface(s) without the requirement
to copy them. Using inline forwarding you can receive, inspect, filter and forward packets
between ports.
dagfwddemo which is a tool supplied with your DAG card demonstrates how you can apply a
user-defined BSD Packet Filter (BPF) to the traffic forwarded by the DAG card. Packets
which match the filter are forwarded, while packets that do not match are dropped.
For more detailed information on inline forwarding and using dagfwddemo please refer to the
EDM04-04 dagfwddemo User Guide available from the support section of the Endace website
at http://www.endace.com.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008 7
Timed Release TERF (TR-TERF)
The Timed Release TERF (TR-TERF) module is a option that enables you to transmit an ERF
stream while reproducing the timestamps of the packets within that stream. It is able to
transmit on all channels.
TR-TERF has two modes of operation. They are:
•No Delay Mode, and
•Relative Timed Release Mode.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008 9
Installation
Introduction
The DAG 7.5G4 card operates on an 4 lane PCIe bus and can be installed in any free 4 lane
PCIe slot.
The PCIe bus allows multiple DAG cards to be installed without affecting the bandwidth
used by each DAG 7.5G4 card.
DAG Software package
The latest DAG Software package must be installed before you install the DAG 7.5G4 card
itself. See EDM04-01 DAG Software Installation Guide, which is included on the CD shipped
with the DAG 7.5G4 card.
Inserting the DAG Card
Caution:
It is very important to protect both the computer and the DAG 7.5G4 card from
damage by electro-static discharge (ESD). Failure to do so could cause damage to
components and subsequently cause the card to partially or completely fail.
1. Turn power to the computer OFF.
2. Remove the PCIe bus slot screw and cover.
3. Using an approved ESD protection device attach the end with the strap to your wrist
and pull or clip firmly so there is firm contact with your wrist.
4. Securely attach the clip on the other end of the strap to a solid metal area on the
computer chassis as shown below.
5. Insert the DAG 7.5G4 card into PCIe bus slot ensuring it is firmly seated.
6. If this DAG card requires an external power supply, complete the following steps:
a. Connect the supplied (or equivalent) power cable to the external power connector
on the DAG card.
b. Connect the cable to the appropriate power connector on your server's power
supply unit.
7. Check the free end of the card fits securely into the card-end bracket that supports the
weight of the card.
8. Secure the card with the bus slot cover screw.
9. Turn power to the computer ON.
10. Ensure the blue (FPGA successfully programmed) LED on the DAG card illuminates.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
10 ©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008
Port connector
The DAG 7.5G4 card has 4 x Small Form Factor (SFP) socket connectors. Each connector
consists of an optical fiber or copper transmitter and receiver.
Note: The DAG 7.5G4 supports both optical and copper transceivers.
The DAG 7.5G4G4 has an 8-pin RJ45 socket located below the optical port connectors on the
card bracket. This socket is available for connection to an external time synchronization
source.
Caution:
Never connect anything other than a PPS input to the time synchronization sockets.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008 11
Boot jumper settings
The DAG 7.5G4 has two sets of jumpers mounted on the DAG card:
•IP (Inhibit Program)
•FF (Force Factory)
IP Jumper settings
Jumper set
between
Definition
1 & 2 Used in development. Do not use.
2 & 3 or jumper not
fitted
Normal operation of the DAG card
FF jumper settings
Jumper set
between
Definition
1 & 2 Loads the factory image into the FPGA at power on.
2 & 3 or jumper not
fitted
Loads the user defined image into the FPGA at power on.
Boot LEDs
The following tables describe the Boot LED configurations of the DAG 7.5G4.
Boot LED numbering:
If the blue FPGA programmed LED is off or flashing - contact support.
If the red Boot LED is flashing, a jumper is fitted - contact support for further information.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
12 ©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008
Pluggable Optical Transceivers
Overview
The DAG 7.5G4 card supports industry standard Small Form-factor Pluggable (SFP) optical
transceivers.
The transceivers consist of two parts:
•Mechanical chassis attached to the circuit board
•Transceiver unit which may be inserted into the chassis
Note: You must select the correct transceiver type to match the optical parameters of the
network to which you want to connect. Configuring the card with the wrong
transceiver type may damage the card.
You can connect the transceiver to the network via LC-style optical connectors.
For further information on pluggable optical transceivers please refer to the Endace website
at http://www.endace.com
Optical modules
.
The optical power range depends on the particular SFP module that is fitted to the DAG
4.5Z2/4.5Z8 card. Optics modules are supplied in either Single or Multi mode. See the
following table for details.
Optical power is measured in dBm. This is decibels relative to 1 mW where 10 dB is
equivalent to a factor of 10 in power. A negative optical power value indicates power that is
less than 1 mW. The most sensitive devices can work at power levels down as low as -30dBm
or 1µW.
The DAG 4.5Z2/4.5Z8 card optics power module specification is shown below:
Product
Number Network Support
Receive Characteristics Transmit Characteristics
Wavelength
(nm)
Sensitivity
(dBm)
Wavelength Tx Power
(dBm)
Min Max Min Max (nm) Min Max
TXR-1000SX 1000BASE-SX Multimode 770 860 -20 0 850 -9 -3.5
TXR-1000LX 1000BASE-LX Single mode 1270 1600 -22 0 1310 -9.5 -3
If you are in doubt over the light levels available for the DAG card receive ports, check the
light levels using an optical power meter.
Cover DAG 4.5Z2/4.5Z8 card transmit ports with LC-style plugs to prevent dust and
mechanical hazards damaging optics if not in use.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008 13
Power Input
Note: The optical power input to the DAG card must be within the receiver’s dynamic
range. See the previous table for details. If it is slightly outside of this range it will
cause an increased bit error rate. If it is significantly outside of this range the system
will not be able to lock onto the signal.
When power is above the upper limit the optical receiver saturates and fails to function.
When power is below the lower limit the bit error rate increases until the device is unable to
obtain lock and fails. In extreme cases, excess power can damage the receiver.
When you set up the DAG card you should measure the optical power at the receiver and
ensure that it is within the specified power range. If it is not, adjust the input power as
follows:
•Insert an optical attenuator if power is too high, or
•Change the splitter ratio if power is too high or too low.
Splitter Losses
Splitters have the insertion losses either marked on their packaging or described in their
accompanying documentation. General guidelines are:
•A 50:50 splitter will have an insertion loss of between 3 dB and 4 dB on each output
•90:10 splitter will have losses of about 10 dB in the high loss output, and <2 dB in the
low loss output
Note: Endace recommends that you do not use a combination of single mode and multi
mode fibers and optics modules on the same link, as the quality of the received
signal cannot be guaranteed.
If you have no choice but to mix single mode and multi mode you should be aware
that a single mode input connected to a multi mode fiber will have some attenuation
but may still be acceptable. However a multi mode input connected to a single mode
fiber will likely have large and unpredictable losses.
Pluggable Copper Transceivers
The DAG 7.5G4 card supports industry standard Small Form-factor pluggable (SFP) copper
transceivers.
The transceivers consist of two parts:
•Mechanical chassis attached to the circuit board
•Transceiver unit which may be inserted into the chassis
Endace recommends that you use Cat6 copper cable. The DAG 4.5Z2/4.5Z8 card copper
module specification is shown below:
Part Type Data Rate
TXR-1000TX 10/100/1000 Base-T >1.25Gbps

EDM01-33v1 DAG_7.5G4_Card_User_Guide
©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008 15
Configuring the DAG card
Introduction
Configuring the DAG 7.5G4 card ready for capturing data requires the following steps:
•Setting up the FPGA
•Preparing the DAG card for use 19(page )
•Configuring the DAG Card 20(page )
•Viewing the DAG card statistics 29(page )
Once the DAG 7.5G4 is configured you can start capturing data, see Using your DAG card to
capture data 31(page ) for details on capturing data.
Before configuring the DAG card
Before configuring the FPGA, you should ensure that:
•dagmem has been run and memory allocated to each installed DAG card.
•dagload has been run so that all DAG drivers have been installed.
Refer to the Installing the drivers section for the required Operating system in EDM04-01 DAG
Software Installation Guide for the further details.
Firmware images
The following lists the features available on each firmware image available on this DAG card.
FPGA image
(Software version string)
TR-TERF 10/100/1000
Ethernet
DSM
dag75g4pci_dsm.bit
(dag75g4pci_dsm...)
The software version strings are displayed in the dagconfig output and when using the
dagrom -x command. They include a version number and creation date.

EDM01-33v1 DAG_7.5G4_Card_User_Guide
16 ©2008 Endace Technology Ltd. Confidential - Version 1 - November 2008
Setting up the FPGA
All DAG cards have at least one Field-Programmable Gate Array (FPGA). The FPGA
contains the firmware for the installed DAG card. The firmware defines how the DAG card
operates when capturing data and contains the specific configuration.
For the FPGA on the DAG 7.5G4 there are up to four firmware images stored in the ROM:
•The factory image - contains fixed basic functionality for operating the DAG card. It
cannot be overwritten by the user.
•The user images 1 to 3 - User image #1 is programmed at the factory. Other images
may or may not be pre-programmed. User images can be updated by the user either
to update to a new release, or to load an image with different functionality than that
originally shipped from the factory.
By default, the DAG 7.5G4 card boots user image #1, unless the Force factory jumper is
fitted. For more details on the Force factory jumper, see Boot jumper settings 11(page ).
Booting from the factory image is normally only required if the DAG card cannot boot from
any of the user images because of a ROM programming error when updating the user
images.
Selecting the firmware image to boot
Use the following command to select the firmware image from which to boot. on the DAG
7.5G4 the are up to four images from which to select.
dagconfig -d0 -p x
x Image loaded
0 Factory image
1 User image 1
2 User image 2
3 User image 3
where "0" is the device number of the DAG card you wish to capture data from.
Note: The old options described below are only work for the factory and user image 1.
The options are described below.
To boot the DAG card with the factory image, type the following command:
dagreset –d0
To boot the DAG card with the user image, type the following command:
dagrom –d0 –p
