Endon Kalamos Mirror Manual

• Re-connectthemouldedmale/femaleconnectorsfrom
thedemister–(A).
• Re-fitthemirrorfrontmakingsureanysiliconesealsare
correctlypositioned–toprotectthefittingagainstwater
ingressandthatnocablesaretrapped-thensecurein
positionwiththe4screwassembliesremovedabove.
• Turnonthepowerandtesttheproximityswitch.
Commissioning
Instructionleaflet
Kalamos Mirror
EL-KALAMOS(56420)
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilitiesexist.
CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
EndonLightingLS90SE
• Werecommendcleaningwithasoftdrycloth.Donotuse
solventsorabrasivecleanersasthesecoulddamagethe
finish.
• Mirror–Useadampclothoraproprietyglasscleaner.
Donotuseabrasivematerialsasthesewilldamagethe
finish.
Live Voltages may be present in this unit even when turned of or when completely disconnected.Foryoursafety,
alwaysswitchoffthesupplybeforechanginglightbulbs,orcleaning.
Themirrormustbereplacedimmediatelyshoulditbecomecrackedordamaged.Thisfittingmust
notbeusedwithoutthemirrorinplace.
ReplaceCracked

Shade
• Thisoperatesonaproximitysensor.Passahandoverthe
mirrorsurface,thesensorwillactivate,andthedemister
padwillwarmthemirrorsurface.
• Thedemistingeffectwillspreadapproximately10-20%
furtherthanthepaditself.
Demister Operation
Iss.303082016
Check that...
• Youhavecorrectlyidentifiedthewires
• Theconnectionsaretight
• Noloosestrandshavebeenleftoutoftheconnection
block.
Havingcorrectlyidentifiedthewiringfromyourexistinglight
fitting,pullthewirethroughtheholeandconnecttothe
connectionblockinsidetheproductinthefollowingway:
Wiring
SUPPLY
NEUTRAL
LIGHT FITTING
BLUE(N)
EARTH(GREEN/YELLOW) GREEN/YELLOW
BROWN(L)
SWITCHEDLIVE

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeandsatisfactory
operationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
This is a Class 1 product and must be earthed
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisunitmustbefittedbyacompetentandqualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
beforeinstallingormaintainingthisfitting.Ensureother
personscannotrestoretheelectricalsupplywithoutyour
knowledge.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Ifreplacinganexistingfitting,makeacarefulnoteofthe
connections.
Thissystemcontainsnon-replaceablepartsandcannotbe
serviced.Ifdamageoccursthepartshouldbescrapped.
Thisproductisnotsuitablefordimming.
ThisproductisratedatIP44.
Thisproductcontainsademisterpad.Ifthispadis
damagedinanywaythenitshouldbereplacedbya
qualifiedelectrician.
Thisfittingisheavyandyouwillrequireassistancein
connectingthemtothesupplyandsecuringthemtothe
mountingsurface.
Becarefulduringhandlingandmaintenancetoavoid
breakageoftheglassparts.
Specification
Voltage: 240V50Hza.c.
Lamp: 1x6WWhiteLED's
IPrating: 44
Layout
• Planthedesiredlayoutofthisfittingcarefully,ensuring
thecableswillreachthedistancebetweenthejunction
boxandthelightfitting.
• Avoidlocatinganycablesinpositionsthatwouldcause
ahazard.Positioncablesandjunctionboxes(not
supplied)awayfromareaswheretheymaybeatrisk
frombeingcut,trappedordamaged.
• Cablesinwallsmustbeprotectedusingsuitable
conduitorplastictrunking.
• Themainssupplycablemusthaveaminimumcross
sectionalareaof1.0mm².
• Thisproducthasspecialprotectionagainsttheingress
ofmoistureandisIP44rated.
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Beforeremovingtheexisting
fitting,carefully note the position of each set of wires.
• Ensurethewalliscapableofholdingtheweightofthe
product.Takecaretoavoiddamaginganyconcealed
wiringandpipes.Thecorrectfixingsshouldbeusedfor
brick,cavitywallsorplasterboard.
• Removethemirrorfrontbyremovingthe4sidescrew
assemblies,retaintheseforre-use.Gentlypullapartthe
demisterpadplug/socket(A)andremovethemainsin
terminalblockconnectioncover(B).
• Markoutthe4mountingpositions,anddeterminethe
positionofthecableentry,asshown(C).Drillandplug
themountingsurface.Bringthemainscablethroughthe
rubbergrommetinthebackhousingandsecuretheback
housingtothemountingsurface–makingsurethatthe
sidesareverticalandthetopishorizontal.NOTE: The
rubber grommet must be used at the cable entry
point to ensure that the water ingress protection of
the fitting is maintained.
Installation
ThisproductissuitableforuseinZones1,2
andoutsideZonesofabathroom.Seediagram.
Ifthisunitisbeingfittedinaroomcontaininga
bathorshower,a30mARCDmustbeused,in
accordancewithIEEregulations.
Makesurethatthereisa200mmspacebetween
thesensorandanyothersurfacee.g.asinkor
shelf.
OUTSIDE ZONES
ZONE
2
ZONE
1
0.6m
0.6m
2.25m
Ceiling
Mains-in
Cable (C)
(A)
(B)
Cable entry
grommet
Fig1.
Fig2. Fig3.
