Assembly InstructionsAssembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt. To
report information regarding missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
0191446R1 Page 1 of 3
1. Assemble slide brackets1. Assemble slide brackets
1. Attach the ‘L’ brackets to each outer slide with screws (included
with slides). The brackets need to be attached “inboard” (facing
each other). Figure 1.
• For Freedom XRS / CORE Lecterns, multiple height positions /
mounting holes are available with the brackets-use the same hole
position on all four brackets.
• For Pivot Premiere Lecterns, use the tallest position on all four
brackets.
2. Tighten the bracket screws securely.
3. Separate the inner from the outer slides using the black levers.
4. Raise the lectern up all the way and unplug the power cord.
Note: On Freedom XRS and Pivot Premier installations, the ‘L’ brackets can be
adjusted to provide varied keyboard heights-the keyboard tray may protrude up to
a maximum of 3.9” [10 cm] below the worksurface. If the lectern is used for ADA
use, a higher adjusted worksurface will be necessary to provide ADA leg clearance.
Figure 1
Screw
(included with slides)
‘L’ Bracket
Outer slide
‘L’ Bracket
(14) 0100167
8-32 x 1/2” PH
thread-cutting
screw
(8) 037542
#8 x 5/8” PHSM
(1pr) 050092
12” Slide set
(1) 0140345
Keyboard Tray
Pull-out Keyboard TrayPull-out Keyboard Tray
5549655496
Inner slide
(8) 029019
8-32 Locknut
Note: For CORE Lectern installations only, (12 8-32 x 1/2” PH thread-cutting
screws, (8) #8 x 5/8” PHSM screws and (8) 8-32 locknuts are used.
3/8
”

0191446R1 Page 2 of 3
8-32 x 1/2” PH
thread-cutting screw
(3 required per slide)
Figure 2.1
Keyboard Tray
Inner
slide
2. Attach inner slides to tray2. Attach inner slides to tray
1. Attach each inner left and right slide to the keyboard tray with (3) 8-32
x 1/2” PH thread-cutting screws and tighten securely. Figure 2.1
Freedom XRS / CORE Lecterns: Pivot Premier
Figure 2.2
Keyboard Tray
8-32 x 1/2” PH
thread-cutting screw
(2 required per slide)
Inner
slide
1. Slides mounted in rear position. Attach each inner left and right slide
to the keyboard tray with (2) 8-32 x 1/2” PH thread-cutting screws
and tighten securely. Figure 2.2
3. Install slide assemblies3. Install slide assemblies
1. Determine the preferred position of the keyboard tray (left center right).
Pre-drilled mounting holes are available for multiple mounting locations.
2. Attach each outer slide assembly to the underside of the worksurface
with (4) #8 x 5/8” PHSM screws but do not tighten completely.
(Brackets face inward). Figure 3.1.
3. Tighten screws on one slide assembly only-leave the screws on the
other slide assembly slightly loose.
Note: The lecterns have pre-drilled holes in left, center, and
right positions for keyboard tray mounting.
On Freedom XRS Lecterns, the keyboard tray should be in-
stalled on the side opposite the equipment rack (if equipped).
Figure 3.2
(4) #8 x 5/8”
PHSM
Outer slide
assembly
Outer slide
assembly
Worksurface
Inner
slide
Inner
slide
1. Align and attach the left and right slide assemblies with 8-32 x 1/2”
PH thread-cutting screws, but do not tighten completely. Figure 3.2.
Mid-panel
Slide assembly
(right)
Slide assembly
(left)
8-32 x 1/2” PH
thread-cutting
screw
(2 per bracket)
8-32 Locknut
(2 per bracket)
Freedom XRS / Pivot Premiere: CORE Lectern:
(4) #8 x 5/8”
PHSM
Figure 3.1

0191446R1 Page 3 of 3
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2021 Spectrum Industries Inc., All rights reserved.
4. Install keyboard tray4. Install keyboard tray
Keyboard Tray
Assembly
Figure 4.1
Note: The dual-use tray can be used as a keyboard
tray, or easily ipped and used as a drawer.
1. Align the keyboard tray assembly with the installed slides and slide together. Figure 4.1-2.
2. Open and close (cycle) the tray a few times to ensure parallel and free movement.
3. With the keyboard tray pulled out, securely tighten the (4) loose worksurface slide screws from step 3.
Flipping keyboard tray / drawer - optionalFlipping keyboard tray / drawer - optional
1. To ip, pull the tray out fully and locate the plastic lever on each slide.
Figure 5.
2. Release the levers on the both slides while pulling the tray out.
3. Flip the tray over, re-align the slides, and push tray back in.
Figure 5
Push here to release
inner slide
Inner slide
Outer slide
Keyboard Tray
Figure 4.2
