easytemp™ TSM 470A–VN
Connector
Short Operating Instructions
KA 168R/24/ae/12.03
51007334
Hauser+Endress
Description
Connector, unshielded, female, angled, M
12 A–coded, 4–position. This connector is
manufactured by Phoenix Contact.
Endress+Hauser, Inc.
2350 Endress Place
Greenwood, IN 46143
Phone: [phone]
888-ENDRESS
FAX: [phone]
Endress+Hauser
Canada Ltd.
1440 Graham’s Lane
Unit 1, Burlington
ON, L7S 1W3
Phone: [phone]
800-668-3199
FAX: [phone]
Endress+Hauser
Paseo del Pedregal No. 610
Col. Jardines del Pedregal
01900, Mexico D.F.
MEXICO
Phone: [phone]
FAX: [phone]
USA Canada Mexico
© 2003 Endress+Hauser, Inc.
KA 168R/24/ae/12.03
For application and selection assistance,
in the U.S. call 888-ENDRESS
For total support of your installed base, 24 hours a day,
in the U.S. call 800-642-8737
Visit us on our web site, www.us.endress.com
Hauser+Endress
• Capacitance (RF)
• Mechanical
• Vibration
• Ultrasonic
• Radar
• Guided Radar (TDR)
• Hydrostatic
LEVEL
FLOW
PRESSURE
• Electromagnetic
• Vortex Shedding
• Coriolis Mass Flow
• Ultrasonic
• Gauge/Absolute
• Differential Pressure
• Hydrostatic
ANALYSIS
• Conductivity
• pH/ORP
• Chlorine
• Dissolved Oxygen
• Turbidity
• Chemical Analyzers
• Nitrate Sensors
• Sludge Level • Paperless Recorders
• Visual Data Managers
• Safety Data Managers
RECORDERS
• Temperature Transmitters
• RTDs / Thermocouples
TEMPERATURE
• Displays
• Active Barriers
• Process Transmitters
• Power Supplies
COMPONENTS
www.us.endress.com/e-direct
• Shop on-line for low-cost
instruments, devices and
components
E-direct
• Total support for you and
your instruments
SERVICE
Important Notice
Warning!
Electrical shock could cause death or serious injury. If the sensor is
installed in a high voltage environment and a fault or installation error
occurs, high voltage may be present on the TSM 470A–VN or the probe
itself.
Safe and secure operation of the compact RTD transmitter can only be guaranteed if the
operating instructions (BA 162R/24/ae) and all safety notes are read, understood and followed.
Visit www.us.endress.com/temp.
Correct use
The manufacturer cannot be held responsible for damage caused by misuse of the unit.
The installation conditions and connection values indicated in the operating instructions must
be followed!
Installation, commissioning and operation
The unit is constructed using the most up to date production equipment and complies to the
safety requirements of the local guidelines. However, if it is installed incorrectly or misused,
certain application dangers can occur. Installation, wiring and maintenance of the unit must
only be done by trained skilled personnel who are authorized to do so by the plant operator.
This skilled staff must have read and understood these instructions and must follow them to
the letter. The plant operator must make sure that the measurement system has been correctly
wired to the connection schematics.
Hazardous areas
Installation of the compact RTD transmitter in hazardous areas is prohibited!
Returns
Please follow the Return Authorization Policy in the operating instructions (BA 162R/24/ae).
All Temperature Operating Instructions are available on CD–ROM, Part Number SONDTT–AG.
Safety pictograms and symbols
Though the information provided herein is believed to be accurate, be advised that the information contained
herein is NOT a guarantee of satisfactory results. Specifically, this information is neither a warranty nor guarantee,
expressed or implied, regarding performance; merchantability, fitness, or other matter with respect to the
products; and recommendation for the use of the product/process information in conflict with any patent. Please
note that Endress+Hauser reserves the right to change and/or improve the product design and specifications
without notice.
Note!
Notes draw attention to activities or procedures that can have a direct influence on
operation or trigger an unforeseen device reaction if they are not carried out properly.
Caution!
Cautions draw attention to activities or procedures that can lead to persons being
injured or to incorrect device operation if they are not carried out properly.
Warning!
Warnings draw attention to activities or procedures that can lead to persons being
seriously injured, to safety risks or to the destruction of the device if they are not
carried out properly.
Installation
For installation, proceed as follows:
1. Seal the ½” NPT process connection with silicone tape (TSM 470G) before
screwing in the device.
2. Make sure that the hygienic process fitting (TSM 470F & TSM 470P) and the
clamp assembly match the maximum specified process pressure.
3. Install and tighten the compact temperature transmitter before applying
process pressure.
4. Plug in the TSM 470A–VN at the compact temperature transmitter and connect
the cable cores from Spike 1 and 3 to a power supply.
Note!
The requirement to ensure NEMA 6P rating is that the female connector to
plug the compact temperature transmitter to a power supply also has NEMA
6P rating or better.
Caution!
In order to avoid damaging the compact transmitter, do not over–tighten the
nut on the TSM 470A–VN.
*
*Used with permission of Phoenix Contact GmbH & Co. KG.

Technical Data
+
TSM 470G
TSM 470F
TSM 470P
General Information
Rated Current IN4A
Rated Voltage UN150V DC (for/to DIN VDE 0110)
Rated Voltage UN125V AC (for/to DIN VDE 0110)
Number of Poles 4
Contact Resistance 8 mOhm
Environmental (Operating)
Temperature –40 to +185 °F (–40 to +85 °C)
General Properties
Combustability Class according
to UL 94 HB
Insulating Material PBT/PA
Contact Surface Material Ni
Contact Material CuSnZn
Protection Class NEMA 6P RATED (IP 67)
Conductor Cross Section
Flexible Mininum 0.0098 in. (0.25 mm)
Conductor Cross Section
Flexible Maximum 0.0295 in. (0.75 mm)
Connection Manner Screw connection
Contact Resistance 8 mOhm
Insulation Resistance 1,000,000,000,000
Testing Voltage 1.25 kV AC
Conductor General Information
Conductor Cross Section* 24
Conductor Cross Section
AWG/KCmil max. 18
*AWG/KCmil min.
0.79”
(20)
1.61”
(41)
1.38” (35)
0.58”
(14.8)
Dimensions in
inches (mm)
Dimensions Schematic Diagram
Housing, angled
Gasket
Clamp type
cage
Pressure screw
Housing, straight
Male or female
insert
Insulating sleeve
0 V
(4 to 20 mA)
10 - 35V DC
(4 to 20 mA)
*
*
*
*
*Used with permission of Phoenix Contact GmbH & Co. KG.
