Endress+Hauser Commubox FXA291 Manual

TI405C/07/en/02.07
71020219
Technical Information
Commubox FXA291
Gateways / Interfaces
Intrinsically safe CDI interface for transmitters
Converts signals at USB interface
Application
• The Commubox FXA291 connects Endress+Hauser field
devices with a CDI interface (= Endress+Hauser Common
Data Interface) with the USB interface of a computer or
laptop. This allows the remote operation and execution of
service functions of field devices with the aid of an
Endress+Hauser operating program, such as the FieldCare
software platform for plant-specific asset management for
example.
• The Commubox is a USB low-power device that is powered
by means of the USB interface of the computer.
Your benefits
• Onsite commissioning of Endress+Hauser field devices
• Easy to connect field devices with a CDI interface to a
computer with a USB interface
• Power is supplied to Commubox by means of the USB
interface
• Possible to supply power to the field devices by means of the
CDI interface
• Connection to intrinsically safe and non-intrinsically safe
field devices
• Suitable for Endress+Hauser operating programs such as
FieldCare

Commubox FXA291
2Endress+Hauser
Function and system design
#Warning!
• The Commubox FXA291 must not be used in potentially explosive atmospheres.
• The warnings and installation and operating instructions of the EEx documentation for field devices with a
CDI interface must be observed.
a0005927
Areas of application of Commubox FXA291
Field device
Field of application, e.g. Liquid analysis (--> picto bar, top of title page)
"Caution!
Due to safety reasons the field devices FMR2xx, FMR53x, FMR540, FMP4x, FMU4x, PMC71, PMP7x,
PMD7x, FMD7x, FMB70, FMG60 may only be connected to Commubox FXA291 via the ToF adapter
FXA291.
!Note!
You can find more information about field devices at www.produkte.endress.com/FXA291.
Commubox FXA291 ToF adapter FXA291
1
2
3
Cable between FXA291 and USB
of the PC
cable between FXA291 and M8
connector
cable standard adapter FXA291
4
5
cable for ToF field devices
cable for more level measurement
devices

Commubox FXA291
Endress+Hauser 3
Wiring
Connection • For computers: USB 1.1 and 2.0 compatible, 4-pole USB connector, type A
• For transmitters: CDI connectors, short-circuit proof, reverse polarity protection
!Note!
When delivered, the USB and adapter cables are fully wired on the box side and are fixed in place with a cable
gland.
Supply voltage • Voltage range: from the USB interface of the PC, typically 5VDC
• Field devices powered via VCC up to 100mW, reverse polarity protection
Intrinsically safe signal circuit For connecting an intrinsically safe circuit with explosion protection [EEx ia] IIC with:
• Connection voltage: < 7 VDC
•U
m: 260V
!Note!
With Commubox FXA291 the intrinsically safe and the non-intrinsically safe connection are protected.
Therefore, you can connect an Ex device to the intrinsically safe side of Commubox FXA291 even if a non-Ex
device was connected before. The Commubox will not lose its Ex approval.
Performance characteristics
Communication Communication between computer and FXA291:
• Baudrate: 2400 to 115.2k
• Data bits: 8
• Stop bits: 1
• Parity: none
• Start bits: 1
• Duplex communication
Environment
Ambient temperature range -20 to +60 °C (-4 to +140 °F)
Storage temperature -40 to +85 °C (-40 to +185 °F)
Ingress protection IP51, NEMA/type 3
Relative humidity 0 % to 95 % (no condensation)

Commubox FXA291
4Endress+Hauser
Mechanical construction
Design, dimensions
a0005926
Design, dimensions: top view
a0005928
Design, dimensions: side view (CDI connection/device side)
a0005931
Commubox FXA291 and components
1 Cable between Commubox FXA291 and USB connection of the PC
2 Cable with CDI connection bushing and M8 connector for ToF adapter
3 Cable of standard adapter with CDI device connector
4 Cable glands
5 Safety cord
Weight approx. 0.2 kg (0.44 lbs)
Material
USB interface Personal computer and Commubox FXA291 = USB signal as per USB specification
CDI interface Measuring device(s) and Commubox FXA291 = Endress+Hauser Service protocol
120 (4.72)
60 (2.36)
mm (inch)
0.4 (1.3)
5.0 (16)
m (ft)
23
45
1
0.2 (0.66)
Housing: ABS
Front membrane: Polyester

Commubox FXA291
Endress+Hauser 5
Human interface
Signals
a0005933
Signal lamps (USB connection/PC side)
Certificates and approvals
CE mark Declaration of conformity
The product meets the requirements of the harmonized European standards. It thus complies with the legal
requirements of the EC directives.
The manufacturer confirms successful testing of the product by affixing the 4symbol.
Ex approvals • ATEX II (2) G [EEx ia] IIC
Ordering information
Order number 51516983
Scope of delivery The scope of delivery comprises:
• Commubox FXA291
• USB cable, fully wired on box side
• Adapter cable, fully wired on box side
• Cable for standard adapter FXA291
• Installation CD:
–USB Commubox FXA291 Serial Port Driver:
Is automatically installed via hardware detection. See the document on the installation setup for this
purpose.
Please follow the appropriate installation instructions.
System requirements • USB interface (USB 1.1 or 2.0)
• DVD/CD-ROM drive
• Windows 2000/Windows XP/Windows 2003
Signal Light Meaning
READY Green Commubox FXA291 is operational
Tx / Rx Red Communication from computer to field device
Tx / Rx Yellow Communication from field device to computer
Tx / Rx Orange Duplex communication

Commubox FXA291
6Endress+Hauser
Accessories
ToF adapter FXA291
• Power limitation for connection between FXA291 and input of intrinsically safe ToF M devices
• Prevents violation of Ex-permitted limit values of ToF devices
• Baudrate of digital communication and software installations for field devices are not affected
• Order No. 71007843

Commubox FXA291
Endress+Hauser 7

Instruments International
Endress+Hauser
Instruments International AG
Kaegenstrasse 2
4153 Reinach
Switzerland
Tel.[phone]
Fax[phone]
www.endress.com
[email protected]
