ENER-J SHA5101 User manual

EXPANDABLE
SMART HOME
SECURITY KIT
[email protected]
www.ener-j.co.uk
1
SKU Code: SHA5108
SMART HOME AUTOMATION WITH
SECURITY ALARM & OUTDOOR SIREN
(2 way RF 868Mhz communication).
ALL MANAGED VIA 1 APP ON YOUR
SMARTPHONE
Download
Our App
YooSee
Indoor IP Camera
Features
AP Mode YES
Mobile view Compatible with LiveCloud
iOS and Android App
PC Compatible with LiveCloud
Multi-window software
Local memory Support 64 G (Max)
Micro SD card,24 hours
continuous recording
Onvif None
Rated Power 2200W
USB Output Rated Power 5V/4A
USB Output Voltage 4.75V~5.25V
Working Temperature -40°~40°
Working Humidity ≤95%
Storage Temperature -35°~60°

[email protected]
www.ener-j.co.uk
2
Video
Compression format H.264
Frame rate 50Hz: 1~25 fps, 60Hz: 1-30
fps
Resolution 1280 x 720, 640 x 480,
320 x 240
Image adjustment The hue, brightness,
contrast, saturation, and
sharpness are adjustable
LUX 0.4 LUX/F1.2
SNR >48dB
Audio
Compression format AMR
Built-in microphone YES
External microphone YES
Built-in speaker YES
External Speaker YES
SNR >48dB
PTZ
Motor Built-in motor control
Rotation angle Horizontal:355°, vertical: 90°
Preset 3
Alarm
Alarm Motion detection
RF Alarm 868MHz RF alarm
accessories
Alarm notification Cloud Push Alarm,
snapshot and short record
be uploaded to cloud
storage
Certification
Certificate ISO 9001:2008, FCC, CE,
RoHS
Night Vision
IR-CUT Auto-switch automatically,
without color cast
Night vision 8Φ5 LED lights, IR
distance:10m
Physical property
Shape material Zinc Alloy
Environment Waterproof outdoor
Power supply DC5V 2A
Operating temperature -5Φ+50°C
Operating humidity 10%~80%RH
Dimension Item size: 230 x 130 x
210mm (L*W*H)
Package size:290 x 190 x
270mm (L*W*H)
Weight Item weight:
Package weight:
Accessories Power adapter, manual,
screws, bracket,Door
Sensor, PIR,smoke,siren,gas
Lens
Lens type 3.6MM Glass Lens
Image sensor 1/3 CMOS
Pixel 1280×720 (1.0 megapixel)
Lens 3.6mm
Angle of View 90°
IR-CUT Yes
Network
Protocol HTTP, UDP, SMTP, FTP,
DHCP, DNS, NTP, UPnP
Network RJ45 10/100MB self-
adaptable Ethernet slot
Wireless WIFI (IEEE 802.11b/g/n)
Wireless Solar Siren
Features
• Waterproof case
• Intelligent Control
• Built-in backup lithium batteries, solar charger
• Tamper alarm
• Intelligent control, eliminate false negative, to prevent
false positives, stable and reliable
• Flood monitoring, on-site high-decibel sound and light
alarm, the longest one minute
• AC/DC, with backup rechargeable lithium battery, power
can be used normally
• scalable output control signal, automatically turn off after
the alarm valve function

[email protected]
www.ener-j.co.uk
3
Technical
Install
1. The flooding fixed probe mounted in a suitable position
detection
2. Place a good alarm, then turned on the power, the buzzer
“beep” sound, warning light flashes four times off, enters
the standby state
3. The alarm behind the switch to open the battery status
4. Lasted about 2 seconds when the probe detects a leak or
overflow, the alarm sound and light alarm instantly spot,
one minute in duration
• Power consumption: static: ≤ 16 m
• Dynamic: ≤ 220 mA
• Back-up battery: 3.7v 4400ma / h
• The solar charging current: 330mA
• Electricity charge: 110 ~ 240VAC, USB 5V,
• Charge time: ≤ 12 hours
• Continuous cloudy standby time: ≤ 10 days
• The longest sound and light alarm time: 3 minutes.
• Receiving distance: ≥ 150 meters (open area)
• Alarm volume: ≥105db
• Power supply: 100 ~ 240VAC
• Quiescent current: ≤ 25 mA
• Alarm current: ≤ 250 mA
• Alarm volume: ≥ 105db
• Trigger delay: ≤ 2 seconds
• The alarm time: ≤ 3 minute
• Back-up battery: Lithium battery 3.7V / 800mAh
• Charging time: ≥ 8 hours
• Standby time: ≤ 6 hours
• Probe connection: 2 m
• Allows the maximum connection distance: ≤ 30 M
• Dimensions: 105 * 65 * 35 mm
Wireless Remote Control
Features
Technical Parameters
• Fashion, exquisite, beautiful
• Control the host alarm/ disalarm operation
• With emergency help button
• Low power consumption, strong anti-interference
• Working power: CR2032 button lithium battery
• Wireless frequency: 868MHZ
• Launch distance: ≥100 meters (open area)
• Battery life: ≤ 2 years

[email protected]
www.ener-j.co.uk
4
Installation
Function Features
Function Features
Installation and Usage
• Easy to Carry
• Generally away from home when you press the “leave
home key” to alarm; at home when you press the “at home
key” to arm
• When the remote control distance is close, please replace
the battery as soon as possible
• Microcomputer intelligent control, anti-electromagnetic
interference, anti white light inference
• Infrared detection, temperature compensation, delay
power, low pressure flash warning
• Wide-angle, low power consumption, strong anti-
interference
• External hidden power switch
• Fast charging, charging status indication
• Power supply: 3.7V rechargeable Li-ion battery
• Power: static: < 50uA; dynamic: < 30mA
• Emission distance: ≥ 150 meters (in open air)
• Full loaded battery work time: ≤2 years
• Charging time: 2h charging voltage: 5VDC
• Detecting range: 110° 10m×10m
• Product size: 105 * 62 * 35
1. The installation bracket fixed installation in the appropriate
wall or corner, distance from the ground 2~2.4 meters
2. Switch the power switch on the back of the detector to the
“ON” state, turn on the power supply, the indicator light
flashes two times, and enter the normal working state after
about 10 seconds
3. Fix the detector on the bracket and adjust to the appropriate
detection angle
4. detect alarm: under the working condition, after the
detector is triggered, the indicator lights flashing
5. when the detector battery is low, the indicator light
interval 5S flashing once, at this time must be as soon as
possible with standard USB line connection for charging
operation; The charging operation can be carried out
regardless of whether the power switch is closed or not
Note: when the power switch is on, the indicator
light is long and the detection function is normal.
When the power switch is closed: about 10 seconds delay,
the indicator light is long, no detection function during the
period.
Rechargeable Wireless PIR Sensor

[email protected]
www.ener-j.co.uk
5
Function Features
Technical Parameters
1. Monitoring and control doors and windows of the switch
states
2. when the doors and windows open, Door sensor will send
signal to alarm
3. Remote control “alarm and disarm”
4. Alert when battery low, Low power consumption, strong
anti-interference
5. External hidden power switch
6. Removable installation
1. Smart design, beautiful artist and easy installing.
2. Intellectual single chip process and steady and credible
self-testing.
3. Photo-sonic alarming and restore automatically
4. Connection pole design, convenience, fastness and
shortcut
5. Suited to use it solely or fit on the wireless electropult
module to use with the wireless control system
1. Working power: 3.7V rechargeable Li-ion battery
2. Power: static: < 50uA; dynamic: < 30mA
3. Wireless transmission distance: ≥ 150 meters (open area)
4. Service life: ≤ 2 years
5. Charging time: 2h charging voltage: 5VDC
6. Alarm distance: ≥ 3cm
Installation and use
• The magnet fixed to the door, 1.6 meters above the ground,
to prevent child collisions.
• Controlling the launch part of the fixed installation in the
door frame, pay attention to maintain the level with the
magnet, while the gap should be less than 10 mm.
• When the detector battery is low, the indicator light
interval 5S flashing once, at this time must be as soon
as possible with standard USB line connection charging
operation; regardless of power supply When the switch is
closed, the charging operation can be carried out.
Note: when the power switch is on, the indicator light is
long and the detection function is normal.
When the power switch is closed: about 10 seconds delay,
the indicator light is long, no detection function during the
period.
• According to the deployment of key, remote host in
defense state (only set “away” mode).
Wireless Door Sensor
Wireless Smoke Detector
Features

[email protected]
www.ener-j.co.uk
6
Specification
Power supply 3.7V/800mAh rechargeable
Li-ion battery
Static Current <20 uA
Alarm Current <25mA
Alarm output photo-sonic alarm
Alarm volume ≥95db
Operated temperature -10 to 45ºC
Operated humidity <97%
Size R=5.25(cm) H=3.2(cm)
LED indicator
Self-testing condition lighting one time every 1.67s
Monitoring condition light one time every 40s
Alarming condition lighting one time every
second
Products Structure
PCB
Installation and Usage Specification
Noted
Confirm the monitor area and fixup the bracket on the cell
or roof of the monitored area with two bolts. Then open
the cover of the detector and turn on the power supply and
close the cover. In the end, fixup the detector on the bracket.
1080P HD video, two million pixels
Security host alarm linkage
Wifi and wired network port
Support SD card video file loop storage
Support remote download video files
Alarm video platform storage
Support NVR
Maintenance
After-sales service
The dust and other factors will letdown the sensitivity of the
detector so it must be test and maintain always.
Test the detector one time every week: press the test button
Clean the detector one time every half year: cutoff the
power and clean the dust with the soft brush.
1. This system is guaranteed for 1 year from purchase date
2. In guarantee period, loss resulted from use beyond
normal use, user’s factor, visitation of providence or other
force majeure is not in guarantee scope
1. Close the cover and the LED indicator and testing/restore
button should be correspond with the hole.
2. Do not fixup the detector to the vent, ventilator and door
and etc.
3. The distance between the detector and corner should be
over 0.75 meter.
4. Should be dustproof and dampproof.
5. You need to program smoke sensor into alarm host panel,
detailed step is: please take out alarm host panel firstly,
press “SET” from alarm host → Enter code( input the 6-digit
code, default: 888888) → ENT→ choose menu ”Program
Sensor” → Zone Number (press “ ” button to delete old
record, and input 03, you can randomly choose from 02
to 10) → Group Number (press “ ” button to delete old
record , and input 00, you can also choose to put 01 or 02
or 03, other digits won’t be recognized) → choose “program”
from “learn\delete” → Trigger smoke sensor twice (you can
release some gas by lighter near the gas sensor) → when
alarm host panel successfully get signal from sensors, will
show ‘success’ in LCD screen, or else, please try from very
beginning again.
Outdoor IP Camera
Product NameSKU Code
SHA5101 Smart IP Camera Indoor (Also is a HUB)
SHA5102 Long Range PIR Sensor with inbuilt
rechargeable lithium battery
SHA5103 Door Sensor with inbuilt rechargeable
lithium battery
SHA5104 Smoke Alarm with inbuilt rechargeable
lithium battery
SHA5105 Remote for On/Off the Alarm
SHA5106 Outdoor Siren with Solar (no need to wire
to mains or charge again)
SHA5107 Smart IP Camera Outdoor IP65
SHA5108
Complete Mini Automation Kit
(1x Smart IP Camera IP20, +1x PIR Sensor,
+1x Door Sensor, +1x Co2 Detector Sensor, 1
ON/OFF Alarm Remote, 1 Outdoor Siren & 1
IP65 outdoor camera)
